2ADAP-GRJWB05J6WIFI module

Host Integration Guide FCC ID: 2ADAP-GRJWB05J6 IC: 12478A-GRJWB05J6 The module is not intended for general public and integrators. It is generally for industry/commercial use and must be professionally installed. The module is limited to installation in mobile applications. Installation must be controlled and requires special training. According to KDB996369 D03 2.0 INTEGRATION INSTRUCTIONS(2.2-2.7) 2.2 This module has been assessed against the following FCC rule parts: CFR 47 FCC Part 15 C (15.247, DTS and DSS) and CFR 47 FCC Part 15 E (NII). It is applicable to the modular transmitter. 2.3 This radio transmitter FCC ID: 2AC232AC23-WL3H has been approved by Federal Communications Commission to operate with the integrated PCB antenna. Use of any other antenna is strictly prohibited without filing an application for a new system-specific FCC ID. 2.4 The module complies with FCC Part 15.247 / Part 15.407 and applies for limited module approval. 2.5 Trace antenna designs: Not applicable – the antenna is integrated into the module and cannot be modified. See section 2.3. 2.6 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2.7 Antenna type and antenna gain for BLE/2.4G WIFI/5G WIFI: Antenna Type MAX Antenna Gain (dBi) PCB 1.5 Note: PCB Antenna is permanently attached and can’t be replaced. 2.8 Please note that if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC ID: 2ADAP-GRJWB05J6” Any similar wording that expresses the same meaning may be used. 2.9 Testing of the host product with all the transmitters installed – referred to as the composite investigation test- is recommended, to verify that the host product meets all the applicable FCC rules. The radio spectrum is to be investigated with all the transmitters in the final host product functioning to determine that no emissions exceed the highest limit permitted for any one individual transmitter as required by Section 2.947(f). The host manufacturer is responsible for ensuring that when their product operates as intended it does not have any emissions present that are out of compliance that were not present when the transmitters were tested individually. The host product manufacturer is responsible for compliance with any other FCC rules and a C2PC is required for each host when installed in any host. 2.10 Any company of the host device which installs this modular should perform the test of radiated & conducted emission and spurious emission etc. according to FCC Part 15C: 15.247 and 15.209 & 15.207, 15B class B requirement, only if the test result comply with FCC part 15C: 15.247 and 15.209 & 15.207, 15B class B requirement. Then the host can be sold legally. The host product manufacturer is responsible for compliance with any other FCC rules and a C2PC is required for each host when installed in any host. 2.11 The host manufacture is recommended to use D04 Module Integration Guide recommending as "best practice" RF design engineering testing and evaluation in case non-linear interactions generate additional non-compliant limits due to module placement to host components or properties. 2.12 This module is stand-alone modular. If the end product will involve the Multiple simultaneously transmitting condition or different operational conditions for a stand-alone modular transmitter in a host, host manufacturer have to consult with module manufacturer for the installation method in end system. Detail instructions from the module manufacturer Separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations. The module is limited to OEM installation only. The OEM integrator is responsible for ensuring that the end-user has manual instructions to remove or install the module. Must use the device only in host devices that meet the FCC/ISED RF exposure category of mobile, which means the device is installed and used at distances of at least 20 cm from persons. The end user manual shall include FCC Part 15 /ISED RSS GEN compliance statements related to the transmitter as shown in this manual. The host product manufacturer is responsible for compliance with any other FCC rules and a C2PC is required for each host when installed in any host. The host product manufacturer is responsible for compliance with any other ISED rules and a C4PC is required for each host when installed in any host. Any company of the host device that installs this modular should perform the test of radiated and conducted emission and spurious emission etc. according to FCC Part 15C: 15.247 and 15.209 & 15.207, 15B class B requirement, only if the test result complies with FCC part 15C: 15.247 and 15.209 & 15.207, 15B class B requirement. Then the host can be sold legally. This modular transmitter is only FCC-authorized for the specific rule parts (47CFR Part 15.247) listed on the grant, and the host product manufacturer is responsible for compliance with any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. Host manufacturer is strongly recommended to confirm compliance with FCC/ISED requirements for the transmitter when the module is installed in the host. The use condition limitations extend to professional users, so instructions must state that this information also extends to the host manufacturer’s instruction manual. This module is stand-alone modular. If the end product will involve Multiple simultaneous …

Text truncated - open the document above for the full version.

Model: GRJWB05-J6 FCC ID：2ADAP-GRJWB05J6 IC：12478A-GRJWB05J6 Gree Electric Appliances, Inc. of Zhuhai ● Please read this manual carefully before operation and keep it well for future reference. ● Due to product improvement, Gree reserves the right to change contents of this manual without prior notice. ● Gree Electric Appliances, Inc. of Zhuhai reserves the final right to interpret this manual. WiFi Module Manual WiFi Module User Manual 1 1、General Functions The wireless module complies with IEEE 802.11 a/b/g/n standard and it can achieve up to a speed of 65Mbps with single stream in 802.11n, 54Mbps as specified in IEEE 802.11a/g, or 11Mbps for IEEE 802.11b to connect to the wireless LAN. This compact module is a total solution for a combination of Wi-Fi 802.11 a/b/g/n technologies with a Microcontroller Processor. The main control chip of this module is highly integrated with Bluetooth low-power controller, with UART interface. It combines Bluetooth protocol, BLE baseband, MODEM and BLE RF-IN chips. It also supports GATT-based applications and MESH device applications based on BLE users and supports Bluetooth 5.0 low power consumption. This compact module is a total solution for a combination of Wi-Fi 802.11a/b/g/n technologies with Microcontroller Processor. The module is specifically developed for embedded system devices. Detailed Instruction of WiFi Module. WiFi Module User Manual 2 2、Technique Parameters Table1. Module Parameters Categories Feature parameters Operating 2.4G: Bands FCC:2412 MHz to 2462 MHz for 802.11 b/g/n(HT40) RED:2412MHz to 2472 MHz for 802.11b/g/n(HT40) 2402MHz to 2480 MHz for BLE 5G: 5150MHz to 5825 MHz for 802.11 a/n(HT40) Protocol IEEE 802.11 a/b/g/n frequency modulation CCK、OFDM、GFSK Wireless mode specification Receive 802.11b<-90.5dBm@11Mbps 802.11a/g<-77.5dBm@54Mbps Sensitivity 802.11n<-72dBm@MCS7 WIFI: 802.11b：1/2/5.5/11 Mbps Data Rate 802.11a/g：6/9/12/18/24/36/48/54 Mbps 802.11n(HT20):6.5/13/19.5/26/39/52/58.5/65 Mbps 802.11n(HT40):13.5/27/40.5/54/81/108/121.5/135Mbps BLE rate: 1 Mbps Antenna 1.5 dBi gain max WiFi Module User Manual 3 Impedance 50-Ohm electrical specification Supply Voltage +3.3V Connect Internal Antenna physical Dimensions 35.5mm×17.7mm±0.2mm Operating Temperature -- -20-85 deg C. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. WiFi Module User Manual 4 2.2 This module has been assessed against the following FCC rule parts: CFR 47 FCC Part 15 C (15.247, DTS and DSS) and CFR 47 FCC Part 15 E (NII). It is applicable to the modular transmitter. 2.3 This radio transmitter FCC ID: 2AC232AC23-WL3H has been approved by Federal Communications Commission to operate with the integrated PCB antenna. Use of any other antenna is strictly prohibited without filing an application for a new system-specific FCC ID. 2.4 The module complies with FCC Part 15.247 / Part 15.407 and applies for limited module approval. 2.5 Trace antenna designs: Not applicable – the antenna is integrated into the module and cannot be modified. See section 2.3. 2.6 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This WiFi Module User Manual 5 equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2.7 Antenna type and antenna gain for BLE/2.4G WIFI/5G WIFI: Antenna Type MAX Antenna Gain (dBi) PCB 1.5 Note: PCB Antenna is permanently attached and can’t be replaced. 2.8 Please note that if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC ID: 2ADAP- GRJWB05J6” Any similar wording that expresses the same meaning may be used. 2.9 Testing of the host product with all the transmitters installed – referred to as the composite investigation test- is recommended, to verify that the host product meets all the applicable FCC rules. The radio spectrum is to be investigated with all the transmitters in the final host product functioning to determine that no emissions exceed the highest limit permitted for any one individual transmitter as required by Section 2.947(f). The host manufacturer is responsible for ensuring that when their product operates as intended it does not have any emissions present that …

Text truncated - open the document above for the full version.

Gree ElectricAppliances,Inc.ofZhuhai Date:2023/04/27 FederalCommunicationsCommissions Authorizationand EvaluationDivision 7435 OaklandMills Road Columbia,MD 2104 RE:CFR47§2.911(d)(5)Attestation FCCID:2ADAP-GRJWB05J6 1.Gree Electric Appliances,Inc.of Zhuhai (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2.Gree Electric Appliances,Inc.of Zhuhai (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerelyyours, Name:Linda Li Job Title:CertificationEngineer CompanyName:Gree ElectricAppliances,Inc.ofZhuhai

Gree ElectricAppliances,Inc.ofZhuhai Date: 2023/04/27 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: 2ADAP-GRJWB05J6 Gree Electric Appliances,Inc.of Zhuhai (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Contact Person: Louie Liu Company Name: Lucky Cowboy Global Services, LLC FRN: 0033510934 Company Address: 2213 S. Braeswood Blvd. #12E Houston, TX 77030 USA Email: [email protected] Sincerelyyours, Name:Linda Li Job Title:CertificationEngineer CompanyName:Gree ElectricAppliances,Inc.ofZhuhai Grantee FRN: 0023963978

Grantee FRN: 0023963978

GreeElectricAppliances,Inc.ofZhuhai Date:2023/04/27 FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Towhomitmayconcern: I,theundersigned,herebyauthorizeULVerificationServicesInc.toactonourbehalfinall mannersrelatingtoapplicationforequipmentauthorization,includingsigningofalldocuments relatingtothesematters.AnyandallactscarriedoutbyULVerificationServicesInc.onour behalfshallhavethesameeffectasactsofourown. I,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,that includesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C. 853(a). InauthorizingULVerificationServicesInc . asourrepresentative,westillrecognizethatweare responsibleto: a)complywiththerelevantprovisionsofthecertificationprogram; b)makeallnecessaryarrangementsfortheconductoftheevaluation,including provisionforexaminingdocumentationandaccesstoallareas,records(including internalauditreports)andpersonnelforthepurposesofevaluation(e.g.testing, inspection,assessment,surveillance,reassessment)andresolutionofcomplaints; c)makeclaimsregardingcertificationonlyinrespectofthescopeforwhich certificationhasbeengranted; d)donotuseourproductcertificationinsuchamannerastobringtheCertification Divisionintodisreputeandnotmakeanystatementregardingourproduct certificationwhichtheCertificationDivisionmayconsidermisleadingor unauthorized; e)uponsuspensionorcancellationofcertification,discontinueuseofalladvertising matterthatcontainsanyreferencetheretoandreturnanycertificationdocuments asrequiredbytheCertificationDivision; f)usecertificationonlytoindicatetheproductsarecertifiedasbeinginconformity withspecifiedstandards; g)endeavorto ensure that no certificateor report nor any part thereofis used in a misleadingmanner; h) ensure that any referenceto our productcertificationin communicationmedia such as documents,brochuresor advertising,complieswith the requirementsof the CertificationDivision; i) keep a record of all complaintsmade knownto us relatingto the product’s compliancewith requirementsof the relevantstandardand to make these records availableto the when requested; j) take appropriateaction with respectto such complaintsand any deficienciesfound in productsor servicesthat affect compliancewith the requirementsfor certification; k) documentthe actionstaken. This authorizationis valid until furtherwrittennotice from the applicant. SincerelyYours, Signedby: Company Name: Gree Electric Appliances,Inc.of Zhuhai Contact Name: Linda Li Title of Person： Certification Engineer Address: Jinji West Rd,Qianshan,Zhuhai,Guangdong 519070 P.R.China

Gree ElectricAppliances,Inc. of Zhuhai FederalCommunicationsCommission 7435 OaklandMills Road ColumbiaMD 21046 Subject:Requestfor Confidentiality FCC ID:2ADAP-GRJWB05J6 To WhomIt May Concern: Pursuantto the provisionsof Sections0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459),we are requestingthe Commissionto withholdthe followingattachmentsas confidentialdocumentfrom public disclosureindefinitely. SchematicDiagram Block Diagram Theoryof Operation Abovementioneddocumentcontainsdetailedsystemand equipmentdescriptionare considered as proprietaryinformationin operationof the equipment.The public disclosureof above documentsmight be harmfulto our companyand would give competitoran unfair advantagein the market. It is our understandingthat all measurementtest reports,FCC ID label formatand correspondent during certificationreviewprocesscannotbe grantedas confidentialdocumentsand those informationwill be availablefor public reviewonce the grant of equipmentauthorizationis issued. Best Regards Company Name: Gree Electric Appliances,Inc.of Zhuhai Contact Name: Linda Li Title of Person： Certification Engineer Address: Jinji West Rd,Qianshan,Zhuhai,Guangdong 519070 P.R.China Date: 4/27/2023

Modular Approval Request FCC (Per 15.212) FCC ID: 2ADAP-GRJWB05J6 Items to be covered Answer From Applicant 1.The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. No 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. Yes 3.The modular transmitter must have its own power supply regulation. Yes 4.The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Yes 5.The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). Yes 6.The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A)If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment Yes authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B)If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. 7.The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Yes 8.Radio frequency devices operating under the provisions of this part are subject to the radio frequency radiation exposure requirements specified in §§ 1.1307(b), 1.1310, 2.1091, and 2.1093 of this chapter, as appropriate. Applications for equipment authorization of modular transmitters under this section must contain a statement confirming compliance with these requirements. The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Technical information showing the basis for this statement must be submitted to the Commission upon request. Yes Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). The module transmitter will be a limited module. Contact Name: Linda Li Title of Person: Certification Engineer Company Name: Gree Electric Appliances,Inc.of Zhuhai

External Photographs Page 2 of 3 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-1 View of EUT-2 Page 3 of 3 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-3 View of EUT-4

Size of the label： 21mm X 13mm Label location:paste in the shield FCC ID：2ADAP-GRJWB05J6 IC：12478A-GRJWB05J6 Model:GRJWB05-J6 Label and location Note: 1. This would be a plastic label with a permanent adhesive. 2. The FCC label statement will include in the user manual which will print on a paper insert and sell with the device.

Internal Photographs Page 2 of 2 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-1 Internal View of EUT-2 WIFI ANT 1

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT For WIFI module MODEL NUMBER: GRJWB05-J6 REPORT NUMBER: 4790798017.1-1-RF-4 ISSUE DATE: June 9, 2023 FCC ID:2ADAP-GRJWB05J6 IC:12478A-GRJWB05J6 Prepared for Gree Electric Appliances, Inc. of Zhuhai Jinji West Rd,Qianshan,Zhuhai,Guangdong 519070 P.R.China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4790798017.1-1-RF-4 Page 2 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 June 9, 2023 Initial Issue REPORT NO.: 4790798017.1-1-RF-4 Page 3 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. REQUIREMENT ................................................................................................................. 6 REPORT NO.: 4790798017.1-1-RF-4 Page 4 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Gree Electric Appliances, Inc. of Zhuhai Address: Jinji West Rd,Qianshan,Zhuhai,Guangdong 519070 P.R.China Manufacturer Information Company Name: Gree Electric Appliances, Inc. of Zhuhai Address: Jinji West Rd,Qianshan,Zhuhai,Guangdong 519070 P.R.China EUT Information EUT Name: WIFI module Model: GRJWB05-J6 Brand: gree Sample Received Date: April 10, 2023 Sample Status: Normal Sample ID: 5968759 Date of Tested: April 17, 2023 to June 9, 2023 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared By: Checked By: Fanny Huang Denny Huang Engineer Project Associate Senior Project Engineer Approved By: Stephen Guo Operations Manager REPORT NO.: 4790798017.1-1-RF-4 Page 5 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Delcaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: G-20019, R-20004, C-20012 and T-20011) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20019 and R-20004 Shielding Room B , the VCCI registration No. is C-20012 and T-20011 Note: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, China. REPORT NO.: 4790798017.1-1-RF-4 Page 6 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 4. REQUIREMENT LIMIT AND CALCULATION METHOD Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. Limits for General Population/Uncontrolled Exposure RF EXPOSURE LIMIT Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minu…

Text truncated - open the document above for the full version.
