2ADBMLS6-7620AWireless Audio Module

User Manual LS6-N22S-M SPECIFICATIONS 1.power up for MT7620A with 5V&1A 2.connect with the PC to get IP address automaticlly. 3.run the CMD on PC ,type the word "wifi" and return,then input the IP address:10.10.10.254 and return again. 4.run the MT7620A's QA tools which given by the supplier. 5.choose the " network card" option on the UI,knock OK,then enter operation steps for work environment. 6. The MT7620 router module with two antenna portsˈwhich pattern is MOMI,the two antenna are the same one The antenna manufacturer˖Dongguan City Senling Industry Co.,Ltd Model Name˖SLA-100020108-C10 Antenna gain˖2dBi FCC Statement˖ ˖ This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in any portable device, for example, USB dongle like transmitters is forbidden. This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the radiator and user body. If the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: Contains Transmitter Module FCC ID: 2ADBMLS6-7620A or Contains FCC ID: 2ADBMLS6-7620A when the module is installed inside another device, the user manual of this device must contain below warning statements; 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The devices must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product. http://www.rf-link.net/ 3.Applications: 1.Routers 2.iNICs 3.NAS devices 4.Dual band concurrent routers 4.General Specification Model WL-AM01B-7620A-V2.0 Product Name WLAN 11b/g/n Major Chipset MT7620A Standard IEEE802.11n ǃIEEE 802.11gǃIEEE 802.11b Data Transfer Rate 1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,9 0,120 and maximum of 300Mbps Frequency Band 2.4GHz Power Consumption 3.3 V ±10% I/O supply voltage Dimension 40.0 x 26.0 x 3.25mm (LxWxH) +-0.2MM Hardware Supp ort Flash:8M (25Q64) DDR:64M (W9751G6KB) Ambient Temperature Range -20 ~ 55 °C Storage Conditions The calculated shelf life in a sealed bag is 12 months if stored between 0 °C and 40 °C at less than 90% relative humidity (RH). After the bag is opened, devices that are subjected to solder reflow or other high temperature processes must be handled in the following manner: Mounted within 168 hours of factory conditions, i.e. < 30 °C at 60% RH. ǂ Storage humidity needs to maintained at < 10% RH. ǂ Baking is necessary if the customer exposes the component to air for over 168 ǂ hrs, baking conditions: 125 for 8 hrs.ć http://www.rf-link.net/ 5.Block Diagram 6. Electrical Specifications 1.DC Characteristics Module Voltage Current Consumption (linking) WL-AM01B-7620A-V2.0 3.3V 220MA(Ϟ㔥៪㗙ⳟ⬉ᕅᯊⱘࡳ㗫) 2) RF Characteristics for IEEE802.11b ( 11Mbps mode unless otherwise specified) Items Contents Specification IEEE802.11b Mode DSSS/CCK 11 Mbps Channel frequency 2412 ~ 2484 MHz RX (per) -85 dBm FREQ ERR LIMIT f13PPM TX Characteristics Min. Typ. Max. Unit Power Level (17±2 dBm) 17 dBm EVM ˄<-18˅ -18 dB 3) RF Characteristics for IEEE802.11g ( 54Mbps mode unless otherwise specified) Items Contents Specification IEEE802.11g Mode OFDM 54 Mbps Channel frequency 2412 ~ 2484 MHz RX (per) -70 dBm FREQ ERR LIMIT ±13PPM TX Characteristics Min. Typ. Max. Unit Power Level (14±2 dBm) 14 dBm EVM (<-27) -27 dB http://www.rf-link.net/ 4) RF Characteristics for IEEE802.11n (HT20_MCS7) Items Contents Specification IEEE802.11n (HT20_MCS7) Mode HT20_MCS7 65 Mbps Channel frequency 2412 ~ 2484 MHz RX (per) -65 dBm FREQ ERR LIMIT ±13PPM TX Characteristics Min. Typ. Max. Unit Power Level (13±2dBm) 13 dBm EVM -28 dB 5) RF Characteristics for IEEE802.11n (HT40_MCS7) Items Contents Sp…

Text truncated - open the document above for the full version.

Libre Wireless Technologies Inc. DATE2014-10-14 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Zhongjian Nanfang Testing Co.,Ltd.; 1st Floor, Block No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Libre Wireless Technologies Inc. 5405 Alton Parkway, Suite A-563, Irvine, CA 92604, USA Dated this：2014-10-14 Signature ： Name/Title: Hooman Kashef Tel. No.: +1(513)300-9190 Fax No.: +1(513)300-9190 E-Mail: [email protected] Company Name: Libre Wireless Technologies Inc.

Libre Wireless Technologies Inc. DATE :2014-10-14 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:_ 2ADBMLS6-7620A ___ Product Name: :_ Wireless Audio Module ____ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature ： Name/Title: Hooman Kashef Tel. No.: +1(513)300-9190 Fax No.: +1(513)300-9190 E-Mail: [email protected] Company Name: Libre Wireless Technologies Inc.

Report No: CCIS14090082601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.:CCIS140900826RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 100 of 101 8 EUT Constructional Details Report No: CCIS14090082601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.:CCIS140900826RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 101 of 101 ------End of report------

Label Label location FCC ID: 2ADBMLS6-7620A Label location FCC ID: 2ADBMLS6-7620A

Report No: CCIS14090082601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900826RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 100 of 101 8 EUT Constructional Details Report No: CCIS14090082601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900826RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 101 of 101 ------End of report------

Prediction of MPE at a given distance 1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 2. Test Procedure Equation from page 18 of OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to the antenna G = numeric gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna 3. Result Frequency (MHz) Maximum Output power (dBm) Maximum Output power (mW) Antenna Gain (dBi) Antenna Gain (numeric) Distance (cm) Result (mW/cm 2 ) Limits for General Population/ Uncontrolled Exposure (mW/cm 2 ) 802.11n(H20) 2437 19.25 84.14 2.0 1.58 20.00 0.0265 1
