RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Ant gain 1dBi ;so Ant numeric gain=1.26 Field strength = 90.07 dBuV/m @3m So Pt={ [10 ( 90.07 /20) /10 6 x3] 2 /30x1.26 }x1000 mW =0.24 mW So (0.24 mW/5mm)x √2.441 GHz = 0.07 <3 Then SAR evaluation is not required

TMC Rheinland Testing Services Corp Limited Address: 1-A,Baisha Industrial Area, No.3011, Shahe West Road, Nanshan District, Shenzhen, Guangdong, P.R. China FCC Report Product Description: A2-bluetooth Speaker Trade Mark: Handxom Model No.: Handxom-A2 FCC ID: 2ADBT-HANDXOM-A2 Applicant: Handxom, S.A. Address: 11 Rue Oge, Petion-Ville, Haiti HT6140 Applicable standards:FCC CFR Title 47 Part 15 Subpart C Section 15.249:2013 Test Date: 25 ~ 30 September, 2014 Issued Date: 30 September, 2014 Test Result: Complied James Wu Laboratory Manager The test result in this test report relate only to the tested samples in this report . This report shall not be reproduced except in full without the written approval of TMC Rheinland Testing Services Corp Limited Report No.: TMC1409057801 Page: 2 of 21 2 Version Version No. Date Description 00 30 September, 2014 Original Prepared By:Date: 30 September, 2014 Young Li Project Engineer Check By: Date: 30 September, 2014 Dixon Hao Reviewer Report No.: TMC1409057801 Page: 3 of 21 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3CONTENTS .............................................................................................................................................. 3 4TEST SUMMARY ..................................................................................................................................... 4 5GENERAL INFORMATION ...................................................................................................................... 5 5.1CLIENTINFORMATION ......................................................................................................................... 5 5.2GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3TESTMODE ........................................................................................................................................ 6 5.4TESTFACILITY.................................................................................................................................... 6 5.5TESTLOCATION ................................................................................................................................. 6 6TEST INSTRUMENTS LIST ..................................................................................................................... 7 7MEASUREMENT DATA AND TEST RESULTS ...................................................................................... 8 7.1ANTENNA REQUIREMENT ..................................................................................................................... 8 7.2CONDUCTEDEMISSIONS ..................................................................................................................... 9 7.320DBOCCUPYBANDWIDTH .............................................................................................................. 12 7.4RADIATED EMISSION METHOD ........................................................................................................... 14 Report No.: TMC1409057801 Page: 4 of 21 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission15.207 Pass Field strength of the fundamental signal15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) Pass Pass: The EUT has complied with the essential requirements in the standard. Report No.: TMC1409057801 Page: 5 of 21 5 General Information 5.1 Client Information Applicant: Handxom, S.A. Address: 11 Rue Oge, Petion-Ville, Haiti HT6140 Manufacturer: Handxom, S.A. Address: 11 Rue Oge, Petion-Ville, Haiti HT6140 5.2 General Description of EUT Product Name: A2-bluetooth Speaker Brand Mark: Handxom Model No.: Handxom-A2 Bluetooth Version: V2.1+EDR Operation Frequency: 2402MHz~2480MHz Channel numbers: 79 Channel separation: 1MHz Modulation type: Frequency Hopping Spread Spectrum (FHSS) Modulation technology: GFSK, Pi/4QPSK, 8DPSK Antenna Type: Integral Antenna Antenna Gain: 1.00dBi (declare by Applicant) Power supply: lithium-ion charge battery 3.7V Operation Frequency each of channel ChannelFrequency ChannelFrequency ChannelFrequency ChannelFrequency 1 2402MHz 21 2422MHz 41 2442MHz 61 2462MHz 2 2403MHz 22 2423MHz 42 2443MHz 62 2463MHz ................................ 18 2419MHz 38 2439MHz 58 2459MHz 78 2479MHz 19 2420MHz 39 2440MHz 59 2460MHz 79 2480MHz 20 2421MHz 40 2441MHz 60 2461MHz Note: In section 15.31(m), regards to the operating frequency range over 10 MHz, the Lowest frequency, the middle frequency, and the highest frequency of channel were selected to perform the test, and the selected channel see below: Test channel Frequency (MHz) Lowest channel 2402 Middle channel 2441 Highest channel 2480 Report No.: TMC1409057801 Page: 6 of 21 5.3 Test Mode Bluetooth mode Keep the EUT in communicating mode with Bluetooth device. Non-hopping mode Keep the EUT in continuously transmitting mode of modulation with the fix frequency. Hopping mode Keep the EUT in continuously transmitting mode of modulation with hopping. Per-test mode. We have verified the construction and function in typical operation, The EUT was placed on three different polar directions; i.e. X axis, Y axis, Z axis. which was shown in this test report and defined as follows: Axis X Y Z Field Strength(dBuV/m) 86.49 90.07 84.83 Final Test Mode: The EUT was tested in GFSK, Pi/4QPSK, 8DPSK modulation, and found the GFSK modulation is the worst case. According to ANSI C63.4 standards, the test results are both the “worst case” and “worst setup”: Y axis (see the test setup phot…
