2ADGKRTAB-10Tablet PC

Royal Sovereign International Inc 1 USER MANUAL Tablet PC RTAB-10 Royal Sovereign International Inc 2 Content Content .............................................................................................................................................. 1 1 Introduction .................................................................................................................................... 4 1.1 Acknowledgement ............................................................................................................... 4 1.2 Announcements ................................................................................................................... 4 1.3 Safety Instruction ................................................................................................................ 5 1.4 Abbreviation/Terminology .................................................................................................. 6 2 MID Introduction ........................................................................................................................... 7 2.1 MID Operation and Preparation .......................................................................................... 7 2.2 MID Status and Reminder ................................................................................................... 7 3 Quick Start Guide ........................................................................................................................... 9 3.1 Keys Function ..................................................................................................................... 9 3.2 Startup and Shutdown ......................................................................................................... 9 3.3 Open and Close of the Screen ............................................................................................. 9 3.4 Usage of Touch Screen ...................................................................................................... 10 3.5 Home Page ........................................................................................................................ 11 3.6 Visit Application Procedures ............................................................................................. 13 3.7 USB Connection ............................................................................................................... 14 3.8 Typing words ..................................................................................................................... 15 3.9 Operation Technique ......................................................................................................... 16 4 Basic Setting ................................................................................................................................ 17 4.1 Wireless and Internet ......................................................................................................... 17 4.2 Bluetooth ........................................................................................................................... 18 4.3 Data Usage ........................................................................................................................ 21 4.4 More .................................................................................................................................. 22 4.13 Language and Input Method ........................................................................................... 35 4.15 Date and Time ................................................................................................................. 37 5 Multi-Media ................................................................................................................................. 41 5.1 Music ................................................................................................................................. 41 5.2 Video ................................................................................................................................. 42 5.3 Photo Gallery .................................................................................................................... 42 5.4 Camera .............................................................................................................................. 43 5.5 FM Radio .......................................................................................................................... 44 6 Internet ......................................................................................................................................... 47 6.1 Browser ............................................................................................................................. 47 6.2 Email ................................................................................................................................. 48 7 Other Application Procedures ...................................................................................................... 50 7.1 Clock ................................................................................................................................. 50 7.2 Calculator .......................................................................................................................... 50 7.3 File Manager ..................................................................................................................... 51 7.4 Recorder .................................................................................................................. .......... 53 8 Installation of Procedures ............................................................................................................. 55 8.1 Installation ......................................................................................................................... 55 8.2 Uninstall ..........................................…

Text truncated - open the document above for the full version.

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Royal Sovereign International Inc Addresss 2 Volvo Drive Rockleigh, NJ 07647 USA City Rockleigh Country USA request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: 2ADGK RTAB-10 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) USA 2014/12/18 Andrew QA Manager

Authorization Letter We, (the approval holder) Company name Royal Sovereign International Inc Addresss 2 Volvo Drive Rockleigh, NJ 07647 USA City Rockleigh Country USA declare that the following representative (agent): Name (person) Brown Lu Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Description Tablet PC Type or Model(s) RTAB-10 Tradename or Brand(s) N/A We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) USA 2014/12/18 Andrew QA Manager

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16

No. SpecificationsItem DescriptionBit No. The amount 1 ELINK_Q102CZMotherboard1 2 MT8127A/BBaseband chipU2011 3 MT6627N/AGPS,WIFI,BT,FMFour chipU7021 4 MT6323LGA Power management chip TFBGA158 P0.5 U3011 5 KMSJS000XM-B308L LPDDR2+eMMC (162 MCP) 512M+4GBCombo 1.2V U11 10 CP2121ST-B2BoostIC SOT23-6(OTG)U2;U372 11 CP2123ST-B1BacklitIC SOT23-6 U9021 12 WD1012EA-5/TRDC-DC SOT23-5U9031 13 AR8159Low-noise amplifierU151 15 SSM3K35MFVN MOSFETU3021 18 GSL3676Touch IC GSL3676 QFN56U111 19 DP1608-V1524CAT/LFGPS SplittersF2011 22 MC3433-I53GT ICU12041 23 WPM2026PMOS,WPM2026,SOT23_3Q2;Q9022 24 1N5819W Schottky diodes VF0.2V SOD123 D3;D17;D9013 27 BZT52C6V2Zener diode6.2V SOD123D131 28 WZD58L18-2/TRZener diode18V SOK123D151 29 BAT54WSDual diode，BAT54S，SOT23_3D14;D162 31 PZ3D4V2HZener diode 5.1V SOD323D3011 33 WNT2F04-3/TRNPN_BEC,MMBT3904,SOT23_3Q3;Q9032 35 WPT2E33-3/TRPNP Transistor, SOT-23-6LU201 36 PESDWC9D5VBTVS TVS 5V 2.1PF 923 D501;VR3;VR43 38 ESD9B5V-2/TRTVS 5V 10PF VR5;VR6;VR503;VR504;VR505; VR508 6 39 GRM1555C1H180JA01 Chip Capacitors C0G 18pF ±5% 50V 0402 C10441 40 GRM1555C1H330JA01 Chip Capacitors C0G 33pF ±5% 50V 0402 C10371 41 GRM1555C1H680JA01 Chip Capacitors C0G 68pF ±5% 50V 0402 C7071 42 GRM1555C1H101JA01 Chip Capacitors C0G 100pF ±5% 50V 0402 C704;C503;C506;C516;C7125 43 GRM1555C1H391JA01 Chip Capacitors C0G 390pF ±5% 50V 0402 C519;C5202 44 GRM155R71H102KA01 Chip Capacitors X7R 1nF ±10% 50V 0402 C2311 46 GRM155R71H103KA88 Chip Capacitors X7R 10nF ±10% 50V 0402 C9061 47 GRM155R71A473KA01D Chip Capacitors X7R 47nF ±10% 10V 0402 C201;C320;C3213 48 GRM155R71C104KA88 Chip Capacitors X7R 100nF ±10% 16V 0402 C19;C33;C34;C36;C38;C41;C5 4;C62;C527;C528;C529;C530; C531;C541;C42;C716;C113;C4 ;C12;C14;C55;C56;C139;C140 ;C205;C206;C303;C317;C318; C324;C328;C507;C508;C511;C 703;C910;C1001;C1106;C1109 ;C1110;C1205;C1207;C45;C47 ;C48;C908;C706;C1108;C132 49 52 GRM155R60J105KE19 Chip Capacitors X5R 1uF ±10% 6.3V 0402 C1051;C82;C6;C7;C8;C105;C1 06;C310;C311;C312;C315;C31 6;C323;C329;C512;C513;C711 ;C715;C13;C21;C121;C122;C2 07 23 53 GRM155R61C105KA12 Chip Capacitors X5R 1uF ±10% 16V 0402 C351 54 GRM188R61E105KE Chip Capacitors X5R 1uF ±10% 25V 0603 C301 55 GRM155R60J225ME15D Chip Capacitors X5R 2.2uF ±20% 6.3V 0402 C1;C39;C540;C542;C40;C10;C 325;C1107;C60;C538;C539 11 56 GRM188R6OJ225KE19D Chip Capacitors X5R 2.2uF ±10% 6.3V 0603 C26;C302;C1206;C903;C904;C 905;C909 7 57 GRM188R61C225KE34D Chip Capacitors X5R 2.2uF ±10% 16V 0603 C181 58 GRM188R61E225KA12D Chip Capacitors X5R 2.2uF ±10% 25V 0603 C32;C229;C2363 59 GRM155R60J475M Chip Capacitors X5R 4.7uF ±20% 6.3V 0402 C11051 60 GRM188R60J475KE19D Chip Capacitors X5R 4.7uF ±10% 6.3V 0603 C58;C59;C76;C77;C28;C123;C 306;C307;C308;C309;C326;C3 27;C330;C331;C705;C808;C43 ;C304;C5;C9 20 65 GRM188R60J106ME47D Chip Capacitors X5R 10uF ±20% 6.3V 0603 C22;C23;C107;C108;C115;C11 6;C117;C118;C313;C314 10 66 GRM21BR60J226ME39L Chip Capacitors X5R 22uF ±20% 6.3V 0805 C301;C404;C9073 67 RC0402JR-070R Chip Resistor0 OHM ±5% 1/16W 0402 FB701;FB702;FB703;R1043;R8 ;R9;R11;R54;R56;R61;R65;R6 6;R69;R89;R418;R1008;R15;R 25;R44;R46;R50;R68;R88;R4; R7;R18;R19;R27;R48;R77;R78 ;R80;R81;R82;R83;R84;R85;R 86;R87;R106;R140;R201;R202 ;R310;R325;R326;R327;R509; R510;R703;R712;R713;R1107; R1108;R1109;R1110;R1204;R1 205;R1206;R1207;R324;R701 62 68 RC0603JR-070RL Chip Resistor0 OHM ±5% 1/10W 0603 R102;R103;R105;R501;R5025 69 RL1206FR-7W0R2L Chip Resistor0.2 OHM ±1% 1/4W 1206 R3121 70 RC0603FR-071R5L Chip Resistor1.5 OHM ±1% 1/10W 0603 R9221 72 RC0402JR-0710R Chip Resistor10 OHM ±5% 1/16W 0402 R1041 74 RC0402JR-07100R Chip Resistor100 OHM ±5% 1/16W 0402 R513;R5152 75 RC0402FR-07240R Chip Resistor240 OHM ±1% 1/16W 0402 R3;R102 76 RC0402FR-071K Chip Resistor1K OHM ±1% 1/16W 0402 R70;R506;R514;R4014 77 RC0402JR-071K Chip Resistor1K OHM ±5% 1/16W 0402 R79;R328;R503;R504;R13025 78 RC0402JR-071K5 Chip Resistor1.5K OHM ±5% 1/16W 0402 R5051 79 RC0402FR-071K5 Chip Resistor1.5K OHM ±1% 1/16W 0402 R507;R508;R9013 82 RC0402FR-072K7 Chip Resistor2.7k OHM ±1% 1/16W 0402 R16;R2232 83 RC0402JR-073K3 Chip Resistor3.3K OHM ±5% 1/16W 0402 R3071 86 RC0402FR-074K7 Chip Resistor4.7K OHM ±1% 1/16W 0402 R531 87 RC0402FR-075K1 Chip Resistor5.1K OHM ±1% 1/16W 0402 R2371 89 RC0402FR-078K2L Chip Resistor8.2K OHM 1% 1/16W 0402 R229;R2302 90 RC0402JR-0710K Chip Resistor10K OHM ±5% 1/16W 0402 R511;R5122 91 RC0402FR-0712K Chip Resistor12K OHM ±1% 1/16W 0402 R7101 92 RC0402FR-0714K3L Chip Resistor14K3 OHM ±1% 1/16W 0402 R511 93 RC0402FR-0716K9 Chip Resistor16K9 OHM ±1% 1/16W 0402 R4021 94 RC0402JR-0720K Chip Resistor20K OHM ±5% 1/16W 0402 R301;R3042 95 RC0402JR-0739K Chip Resistor39K OHM ±5% 1/16W 0402 R471 96 RC0402JR-0747K Chip Resistor47K OHM ±5% 1/16W 0402 R45;R59;R913;R5174 97 RC0402FR-0747K Chip Resistor47K OHM ±1% 1/16W 0402 R9191 98 RC0402JR-07100K Chip Resistor100K OHM ±5% 1/16W 0402 R31;R122;R805;R921;R9155 99 RC0402FR-07100K Chip Resistor100K OHM ±1% 1/16W 0402 R171 101 RC0402JR-07330K Chip Resistor330K OHM ±5% 1/16W 0402 R3301 102 RC0402JR-07470K Chip Resistor470K OHM ±5% 1/16W 0402 R5161 103 RC0402JR-07510K Chip Resistor510K OHM ±5% 1/16W 0402 R135;R9142 104 RC0402FR-071M Chip Resistor1M OHM ±1% 1/16W 0402 R2361 106 SDV1005H180C100NPTFVaristor MLV-18V-10PF-0402 VR16;VR19;VR20;VR401;VR402 ;VR1;VR2;VR11;VR12;VR17;VR 18;VR501;VR502;VR801;VR802 ;VR803;VR804;VR805;VR806;V R807 20 108 SDCL1005C12NJTDF Chip inductors 12nH ±5% 300mA 0402 L10081 112 SPH252012HR68MT Power Inductors 680NH 2.5X2.0X1.5MM L301;L3022 113 MPL2520S4R7MHTPower Inductors 4.7uH 2520L902;L102 114 SWPA4018L100MTPower Inductors 10uH L4X4L9011 118 BLM15AG601SN1 Beads 600ohm@100M,300mA, 1.4ohm, 0402 L7041 119 SZ1005K102CTF Beads 1000ohm@100M,200mA, 1.4ohm, 0402 B501;B502;B5033 121 SZ1005K182CTF Beads 1800ohm@100M,100mA, 1.4ohm, 0402 R10191 123 SZ1608K252CTF Beads 2.5K +-25% @100MHz 250mA 0603 B5041 125 DSB221SDA TCXO SMD IT2205BE 2.5 X 2.0 MM(Four modules) X3021 130 9H0320000932.768KCrystalsX3011 134 ADJ-3592-WX2Headphone jackJ21 135 MCD-HXQK5F-LJ04BU…

Text truncated - open the document above for the full version.

Tune‐up procedure Rated RF power output: Mode The Tune-up Maximum Avg power(Customer Declared)(dBm) Range Measured Conduct Avg Maximum Power(dBm) IEEE 802,11b 8.5+/-1 7.5~9.5 9.41 IEEE 802,11g 8.3+/-1 7.3~9.3 9.21 IEEE 802,11n20M 8+/-1 7.0~9.0 8.72 IEEE 802,11n40M 7+/-1 6.0~8.0 7.60 Bluetooth 2.5 +2/-1 1.5~4.5 4.38(PK) Then these appropriate rated RF output power settings are stored in each device individually. The user has no possibility to change these settings later on, and during manufacturing each device will be individual calibrated. The measurement is done in fully calibrated setup, which is based on the base station simulator. Furthermore, the highest power level is verified afterwards in a measurement on three channels(low, middle and high).

FCC Test Report FCC ID:2ADGKRTAB-10 Product： Tablet PC Trade Name： RS Model Number： RTAB-10 Serial Model： N/A Report No.： NTEK-2014NT12092189F3 Prepared for Royal Sovereign International Inc. 2 Volvo Drive Rockleigh, NJ 07647 USA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website: www.ntek.org.cn Page 2 of 23 Report No.: NTEK-2014NT12092189F3 TEST RESULT CERTIFICATION Applicant’s name ................. : Royal Sovereign International Inc. Address ................................. : 2 Volvo Drive Rockleigh, NJ 07647 USA Manufacturer's Name .......... : CYX Electronics Co. Address ................................. : 3F, Block 2, Minrui Industry Park, Xixiang, Baoan, Shenzhen, Guandong, China Product description Product name ........................... : Tablet PC Model and/or type reference : RTAB-10 Standards ............................. : FCC Part15B:01 Oct.2014 ANSI C63.4:2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 09 Dec. 2014 ~15 Dec. 2014 Date of Issue ........................................... : 15 Dec. 2014 Test Result ............................................... : Pass Testing Engineer : (Jason Chen) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 23 Report No.: NTEK-2014NT12092189F3 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 EUT OPERATING CONDITIONS 17 3.2.5 TEST RESULTS 18 3.2.6 TEST RESULTS(1000~12400MHz) 21 4 . EUT TEST PHOTO 22 Page 4 of 23 Report No.: NTEK-2014NT12092189F3 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B:2014 ANSI C63.4: 2003 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Page 5 of 23 Report No.: NTEK-2014NT12092189F3 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration Number:238937; IC Registration Number:9270A-1 CNAS Registration Number:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKC01 ANSI150 KHz ~ 30MHz 3.2 B. Radiated Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKA01 ANSI30MHz ~ 1000MHz 4.7 1GHz ~12.4GHz 5.0 Page 6 of 23 Report No.: NTEK-2014NT12092189F3 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet PC Model Name RTAB-10 Additional Model Number(s) N/A Model Difference N/A Product Description The EUT is a Tablet PC. Connecting I/O port:USB, DC in , Operation Frequency: BT:2402~2480 MHz WIFI: 802.11b/g/n(20MHz): 2412~2462MHz 802.11n(40MHz):2422~2452MHz Modulation Type: BT(1Mbps)/BT 4.0: GFSK BT EDR(2Mbps): π/4-DQPSK BT EDR(3Mbps): 8-DPSK WIFI: CCK/OFDM/DBPSK/DAPSK Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Power Source DC Voltage Adapter Model:TEKA012-0502000UK Input: 100-240V~,50/60 Hz,0.35A Max Output: 5V, 2A Battery DC 3.7V ,5500mAh Page 7 of 23 Report No.: NTEK-2014NT12092189F3 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Playing+chagring Mode 2 Data Exchange For Conducted Test Final Test Mode Description Mode 1 Playing+chagring Mode 2 Data Exchange For Radiated Test Final Test Mode Description Mode 1 Playing+chagring Mode 2 Data Exchange Note: Final Test Mode: Through Pre-scan, find the mode 2 is the worse case. Only the worst case mode is recorded in the report. Page 8 of 23 Report No.: NTEK-2014NT12092189F3 2.2 DESCRIPTION OF TEST SETUP RE CE 0.8m Table C-4 C-3 C-5 1.5m C-2 AC Line E-4 Monito r E-3 PC LISN E-1 EUT E-2 Printe r E-5 KB E-6 Mouse C-1 Table C-4 C-3 C-2 C-1 0.8m 1.5m E-1 EUT E-2 Printer E-3 PC E-4 Monito r E-5 KB E-6 Mouse C-5 Page 9 of 23 Report No.: NTEK-2014NT12092189F3 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following suppo…
