2ADINN5004LR1LTE PDA

Getting Started With Your LTE PDA Model: N5004L 3 Type-C connector Index N5004L overview N5004L overview 3 Setting upyour device 4 Safety information 6 Certificate 10 Warranty information& registration 12 Customer support 13 Front/Back Rear camera Speaker Bottom Rear camera flash Volume control Wake/Sleep button 4 Settingupyourdevice Followthesestep-by-stepinstructionstosetup yourN5004L. Power off the device before inserting any cards! 1 Remove Back Cover • Remove the back cover by prying the lower left corner 2 of your device. 2 Insert SIM • Orient SIM card to match diagram on slot. • SIM (Nano) support 4G LTE connections. 3 Replace Back Cover • After installing the SIM card, memory card, and battery, align the cover and snap it closed. Be sure to press all around the edges to ensure a secure fit. 4 Charge/Sync • Plug in the type C connector to charge the device or transfer data. 3 1 4 Warning: SIM cards are small enough to become a choking hazard, so pleasekeep them away from children & pets. SIMcards are also quite delicate. Please becareful when handling your card. 6 7 Safety information • This section contains important information about the operation of your device, it also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment • Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device where prohibited. • Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information. • Pace maker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Areas with flammables and explosives • Do not use the device where flammables or explosives are stored (in a gas station, oil depot,orchemicalplant,forexample).Using your device in the seen viron ments in creases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols. • Do not store or transport the device in containers with flammable liquids, gases, or explosives. Traffic security • Observe local laws and regulations while using the device. Toreduce the risk of accidents, do not use your wireless device while driving. • Concentrate on driving. Your first responsibility is to drive safely. • Do not hold the device while driving. Use hands-free accessories. • RF signals may affect the electronic systems of motor vehicles. For more information, consult the vehicle manufacturer. • Donot place the devic eover the air bagor inthe airbag deploymentarea in amotor vehicle. Doing so may hurt you because of the strong force when the air bag inflates. • Wireless devices may in terfere with the airplane’s flight system. Do not use your device where wireless devices arenot allowed according to the airplane company’s regulations. Operating environment • Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions. Do not use your device during thunderstorms 6 7 to protect your device against any danger caused by lightning. • Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are - 20 °C to 45 °C. Extrem e heat or cold may damage your device or accessories. • Do not expose your device todirect sunlight (such as on a car dashboard) for prolonged periods. • Toprotect your device or accessories from fire or electrical shock hazards, avoid rain and moisture. • Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, orcandle. • Do not place sharp metal objects, such as pins, near the earpiece or speaker.The earpiece may attract these objects and result in injury. • Stop using your device or applications for a while if the device is overheated. If skin is exposed to an overheated device for an extended period, low temperature burn symptoms, such as red spots and darker pigmentation, may occur. • Do not use your device’s camera flash directly in the eyes of people or pets. Otherwise temporary loss of vision or damage to the eyes may occur. • Donot touch the device’santenna.Otherwise, communication quality may be reduced. • Do not allow children or pets to bite or suck the device or accessories. Doing so may result in damage orexplosion. • Observelo callaws and regulations, and respect the privacy and legal rightsof others. Child safety • Comply with all precautions with regardto child’ssafety.Letting children play with the device or its accessories may be dangerous. The device includes detachable parts that may present a choking hazard. Keep away from children. • The device and its accessories are not intended for use by children. Children should only use the device with adult supervision. Accessories • Using an unapproved or incompatible power adapter, charger or battery may cause fire, explosion or otherhazards. • Choose only accessories approved for use with this model by the device manufacturer.The use of any other types of accessories may void the warranty, may violate local regulations and laws, and may be dangerous. • If the power cable is damaged (for example, the cord is exposed or broken), or the plug loosens, stop using it at once. Continued use may lead to electric shocks, short circuits, or fire. • Do not touch the power cord with wet hands or pull the power cord to disconnect the charger. • Do not touch the device or the charger with wet hands. Doing so may lead to short circuits, malfunctions, or electricshocks. • If your charger has been exposed to water, other…

Text truncated - open the document above for the full version.

QA-FR-170-B SunCupidTechnology(HK)Ltd. Address:16/F,CEOTower,77WingHongStreet,CheungShaWan,Kowloon,HongKong Email:[email protected] Tel:+852-27250161 Fax:+852-27250090 FCCAuthorization 2022-07-24 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:AgentAuthorization Towhomitmayconcern: WeSunCupidTechnology(HK)Ltd.,theundersigned,herebyauthorizeChina CertificationICTCo.,Ltd(Dongguan)toactonitsbehalfinallmattersrelatingto applicationforEquipmentauthorization,includingthesigningofalldocumentsrelating tothesematters.AllactscarriedoutbyChinaCertificationICTCo.,Ltd(Dongguan)on ourbehalfshallhavethesameeffectasourownaction. We,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits, thatincludesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988, 21U.S.C.862. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signature: PrintName:DannySit Title:Generalmanager

SunCupidTechnology(HK)Ltd. Address:16/F,CEOTower,77WingHongStreet,CheungShaWan,Kowloon,HongKong Email:[email protected] Tel:+852-27250161 Fax:+852-27250090 FCCConfidentialAuthorization 2022-07-24 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:ConfidentialityRequestregardingapplicationforcertificationof FCCID:2ADINN5004LR1 InaccordancewithSections0.457and0.459oftheCommission’sRules, SunCupidTechnology(HK)Ltd.herebyrequestslong-termconfidentialtreatmentof informationaccompanyingthisapplicationasoutlinedbelow: BlockDiagram Schematics OperationDescription PartsList/Tuneupprocedure(forlicenseddevices) SoftwareSecurityDescription Theabovematerialscontainproprietaryandconfidentialinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesematerialsprovidesunjustified benefitstoitscompetitorsinthemarket. SincerelyYours, Signature: PrintName:DannySit Title:Generalmanager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Port

label location

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bluetooth/WiFi Antenna WWAN Aux Antenna(RX Only) WWAN Main Antenna NFC Antenna Battery

APPENDIX C PROBE CALIBRATION CERTIFICATES DIPOLE CALIBRATION CERTIFICATES

Report No.: CR22070025-20A Page 1 of 4 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm Phantom: Twin SAM; Type: Twin SAM V5.0; Serial: TP:1412 Report No.: CR22070025-20A Page 2 of 4 Body Front Setup Photo (10mm) Body Back Setup Photo (10mm) 10 mm 10 mm Report No.: CR22070025-20A Page 3 of 4 Body Left Setup Photo (10mm) Body Right Setup Photo (10mm) 10 mm 10 mm Report No.: CR22070025-20A Page 4 of 4 Body Top Setup Photo (10mm) Body Bottom Setup Photo (10mm) 10 mm 10 mm

SAR TEST REPORT Applicant: Sun Cupid Technology (HK) Ltd. Address: 16/F,CEO Tower,77 Wing Hong Street,Cheung Sha Wan,Kowloon,Hong Kong. FCC ID: 2ADINN5004LR1 Product Name: LTE PDA Model Number: N5004L Standard(s): 47 CFR Part 2(2.1093) The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR22070025-20A Date Of Issue: 2022-08-21 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070025-20A Page 2 of 95 SAR TEST RESULTS SUMMARY Operation Frequency Bands Highest Reported 1g SAR (W/kg) Limits (W/kg) Head SAR Body SAR (Gap 10mm) GSM 850 / 0.58 1.6 PCS 1900 / 0.44 WCDMA Band 2 / 0.68 WCDMA Band 4 / 1.06 WCDMA Band 5 / 0.44 LTE Band 2 / 0.71 LTE Band 5 0.49 LTE Band 7 / 0.55 LTE Band 12 / 0.53 LTE Band 66&4 / 1.03 LTE Band 71 0.59 WLAN 2.4G / 0.26 WLAN 5.2G / 0.19 WLAN 5.8G / 0.12 Bluetooth / 0.2 Maximum Simultaneous Transmission SAR Items Head Body-Worn (Gap 10mm) Hotspot (Gap 10mm) Limits Sum SAR(W/kg) / 1.25 1.25 1.6 SPLSR N/A N/A N/A 0.04 EUT Received Date: 2022/07/14 Tested Date: 2022/08/10 ~ 2022/08/14 Tested Result: Pass China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070025-20A Page 3 of 95 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070025-20A Page 4 of 95 CONTENTS SAR TEST RESULTS SUMMARY .............................................................................................. 2 TEST FACILITY .......................................................................................................................................... 3 DECLARATIONS .......................................................................................................................................... 3 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 TEST SPECIFICATION, METHODS AND PROCEDURES ........................................................................ 7 1.3 SAR LIMTS ........................................................................................................................................... 8 2. SAR MEASUREMENT SYSTEM ............................................................................................ 9 3. EQUIPMENT LIST AND CALIBRATION .......................................................................... 16 3.1 EQUIPMENTS LIST & CALIBRATION INFORMATION ....................................................................... 16 4. SAR MEASUREMENT SYSTEM VERIFICATION ........................................................... 17 4.1 LIQUID VERIFICATION ...................................................................................................................... 17 4.2 SYSTEM ACCURACY VERIFICATION ................................................................................................. 20 4.3 SAR SYSTEM VALIDATION DATA ............................................................................................. 21 5. EUT TEST STRATEGY AND METHODOLOGY .............................................................. 29 5.1 TEST POSITIONS FOR DEVICE OPERATING NEXT TO A PERSON’S EAR ......................................... 29 5.2 CHEEK/TOUCH POSITION .................................................................................................................. 30 5.3 EAR/TILT POSITION ........................................................................................................................... 30 5.4 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS ................................................ 31 5.5 TEST DISTANCE FOR SAR EVALUATION .......................................................................................... 32 5.6 SAR EVALUATION PROCEDURE ....................................................................................................... 33 6. CONDUCTED OUTPUT POWER MEASUREMENT ........................................................ 34 6.1 TEST PROCEDURE .............................................................................................................................. 34 6.2 DESCRIPTION OF TEST CONFIGURATION ......................................................................................... 35 6.3 MAXIMUM TARGET OUTPUT POWER ................................................…

Text truncated - open the document above for the full version.

Report No.: CR22070025-20 Page 1 of 137 Test Plot 1#: GSM 850 _Mid_ Body Front DUT: LTE PDA; Type: N5004L; Serial: CR22070025-SA-S1 Communication System: Generic GPRS-3 slots; Frequency: 836.6 MHz; Duty Cycle: 1:2.66 Medium parameters used: f = 836.6 MHz; σ = 0.911 S/m; ε r = 41.613; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.06, 10.06, 10.06) @ 836.6 MHz; Calibrated: 2021/12/31  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1354; Calibrated: 2021/9/1  Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1412  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (91x141x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.450 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.59 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 0.499 W/kg SAR(1 g) = 0.361 W/kg; SAR(10 g) = 0.269 W/kg Maximum value of SAR (measured) = 0.449 W/kg 0 dB = 0.449 W/kg = -3.48 dBW/kg Report No.: CR22070025-20 Page 2 of 137 Test Plot 2#: GSM 850 _Low_ Body Back DUT: LTE PDA; Type: N5004L; Serial: CR22070025-SA-S1 Communication System: Generic GPRS-3 slots; Frequency: 824.2 MHz;Duty Cycle: 1:2.66 Medium parameters used: f = 824.2 MHz; σ = 0.904 S/m; ε r = 41.629; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.06, 10.06, 10.06) @ 824.2 MHz; Calibrated: 2021/12/31  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1354; Calibrated: 2021/9/1  Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1412  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x121x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.592 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 22.46 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.790 W/kg SAR(1 g) = 0.408 W/kg; SAR(10 g) = 0.226 W/kg Maximum value of SAR (measured) = 0.619 W/kg 0 dB = 0.619 W/kg = -2.08 dBW/kg Report No.: CR22070025-20 Page 3 of 137 Test Plot 3#: GSM 850 _Mid_ Body Back DUT: LTE PDA; Type: N5004L; Serial: CR22070025-SA-S1 Communication System: Generic GPRS-3 slots; Frequency: 836.6 MHz;Duty Cycle: 1:2.66 Medium parameters used: f = 836.6 MHz; σ = 0.911 S/m; ε r = 41.613; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.06, 10.06, 10.06) @ 836.6 MHz; Calibrated: 2021/12/31  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1354; Calibrated: 2021/9/1  Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1412  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x121x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.804 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.92 V/m; Power Drift = -0.18 dB Peak SAR (extrapolated) = 0.977 W/kg SAR(1 g) = 0.511 W/kg; SAR(10 g) = 0.284 W/kg Maximum value of SAR (measured) = 0.787 W/kg 0 dB = 0.787 W/kg = -1.04 dBW/kg Report No.: CR22070025-20 Page 4 of 137 Test Plot 4#: GSM 850 _High _Body Back DUT: LTE PDA; Type: N5004L; Serial: CR22070025-SA-S1 Communication System: Generic GPRS-3 slots; Frequency: 848.8 MHz;Duty Cycle: 1:2.66 Medium parameters used: f = 848.8 MHz; σ = 0.926 S/m; ε r = 41.356; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.06, 10.06, 10.06) @ 848.8 MHz; Calibrated: 2021/12/31  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1354; Calibrated: 2021/9/1  Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1412  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x121x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.812 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 18.66 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.947 W/kg SAR(1 g) = 0.501 W/kg; SAR(10 g) = 0.280 W/kg Maximum value of SAR (measured) = 0.768 W/kg 0 dB = 0.768 W/kg = -1.15 dBW/kg Report No.: CR22070025-20 Page 5 of 137 Test Plot 5#: GSM 850 _Mid_ Body Left DUT: LTE PDA; Type: N5004L; Serial: CR22070025-SA-S1 Communication System: Generic GPRS-3 slots; Frequency: 836.6 MHz;Duty Cycle: 1:2.66 Medium parameters used: f = 836.6 MHz; σ = 0.911 S/m; ε r = 41.613; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.06, 10.06, 10.06) @ 836.6 MHz; Calibrated: 2021/12/31  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1354; Calibrated: 2021/9/1  Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1412  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (51x141x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.382 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 14.67 V/m; Power Drift = -0.17 dB Peak SAR (extrapolated) = 0.481 W/kg SAR(1 g) = 0.314 W/kg; SAR(10 g) = 0.212 W/kg Maximum value of SAR (measured) = 0.417 W/kg 0 dB = 0.417 W/kg = -3.80 dBW/kg Report No.: CR22070025-20 Page 6 of 137 Test Plot 6#: GSM 850_ Mid_ Body Right DUT: LTE PDA; Type: N5004L; Serial: CR22070025-SA-S1 Communication System: Generic GPRS-3 slots; Frequency: 836.6 MHz;Duty Cycle: 1:2.66 Medium parameters used: f = 836.6 MHz; σ = 0.911 S/m; ε r = 41.613; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.06, 10.06, 10.06) @ 836.6 MHz; Calibrated: 2021/12/31  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1354; Calibrated: 2021/9/1  Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1412  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.…

Text truncated - open the document above for the full version.

TEST REPORT Applicant: Sun Cupid Technology (HK) Ltd. Address: 16/F,CEO Tower,77 Wing Hong Street,Cheung Sha Wan,Kowloon, Hong Kong. FCC ID: 2ADINN5004LR1 Product Name: LTE PDA Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR22070025-00B Date Of Issue: 2022-08-13 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070025-00B Page 2 of 52 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070025-00B Page 3 of 52 CONTENTS TEST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 6 1.2.2 Support Equipment List and Details .............................................................................................................. 6 1.2.3 Support Cable List and Details ...................................................................................................................... 6 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 6 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 8 2. SUMMARY OF TEST RESULTS ............................................................................................ 9 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 10 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 10 3.1.1 Applicable Standard ..................................................................................................................................... 10 3.1.2 EUT Setup.................................................................................................................................................... 11 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 11 3.1.4 Test Procedure ............................................................................................................................................. 11 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 12 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 13 3.2.1 Applicable Standard ..................................................................................................................................... 13 3.2.2 EUT Setup.................................................................................................................................................... 13 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 14 3.2.4 Test Procedure ............................................................................................................................................. 14 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 14 3.3 20 DB BANDWIDTH ............................................................................................................................. 15 3.3.1 Applicable Standard ..................................................................................................................................... 15 3.3.2 EUT Setup...................................................................................................................…

Text truncated - open the document above for the full version.

Record T-S07-009-006-002-V1.0 Antenna Specification Last Revision:2017-3-14 Page 1 of 14 ATTENTION： The latest revision is stored on server 172.16.78.127/document database. Sagereal documents. Reproduction and disclosure forbidden. XQ491_GH4911 Specification of Antenna CATALOGUE 1. DESCRIBE .............................................................................................................................................. 2 2. ELECTRICAL SPECIFICATION ............................................................................................................. 3 2.1. Frequency band .................................................................................................................................. 3 2.2. impedance ............................................................................................................................................ 3 2.3. VSWR&RL ............................................................................................................................................ 3 2.4. Maximum of antenna gain .................................................................................................................. 6 2.5. TRP&TIS ............................................................................................................................................... 7 3. Antenna Dimensions ........................................................................................................................... 10 3.1. Aerial images ................................................................................................................................... 10 3.2. Structure size ................................................................................................................................... 12 Record T-S07-009-006-002-V1.0 Antenna Specification Last Revision:2017-3-14 Page 2 of 14 ATTENTION： The latest revision is stored on server 172.16.78.127/document database. Sagereal documents. Reproduction and disclosure forbidden. 1. DESCRIBE This specification applies to XQ491-GH4911 main antenna, diversity antenna, BT/WIFI/GPS antenna The antenna is in the form of built-in antenna PIFA The antenna is made of FPC Record T-S07-009-006-002-V1.0 Antenna Specification Last Revision:2017-3-14 Page 3 of 14 ATTENTION： The latest revision is stored on server 172.16.78.127/document database. Sagereal documents. Reproduction and disclosure forbidden. 2. ELECTRICAL SPECIFICATION 2.1. Frequency band Band Operation Frequency Range(MHz) GSM850/900/1800/1900 WCDMA Band2/4/5/8 LTE2/3/4/5/7/12/20/28/66/71 617-698；699~ 746 ;791~ 862；824~894;880- 960；1710~1990；1850-1990;1710- 2155;2500~2690 BT/WIFI 2.4~2.5GHz, 5.15~5.85GHz GPS 1575.42MHz 2.2. impedance 50Ω 2.3. VSWR&RL Test equipment：Agilent E5071C test method： 1、 Install the main antenna on the test prototype； 2、 Weld the RF test point on the PCB with 50 ω coaxial line, and then connect it to the network analyzer； 3、 ensure that the mobile phone away from the surrounding metal at least 20cm above。 Record T-S07-009-006-002-V1.0 Antenna Specification Last Revision:2017-3-14 Page 4 of 14 ATTENTION： The latest revision is stored on server 172.16.78.127/document database. Sagereal documents. Reproduction and disclosure forbidden. Test result： Main antenn…
