2ADINN6001LLTE Smart Phone

Sun Cupid Technology (HK) Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: May 08, 2023
Application Purpose: Original Equipment
Date of Application: May 06, 2023
Equipment Note: LTE Smart Phone
Frequency Range: 673.00000000 - 688.00000000
Company: Sun Cupid Technology (HK) Ltd.
Country: Hong Kong

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Sun Cupid Technology (HK) Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter DATE TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2ADINN6001L FRN of applicant: 0024055386 Per section 2.911(d)(7) of the FCC rules, Sun Cupid Technology (HK) Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: NUU, Inc. FCC Registration Number (FRN): 0033478264 Physical U.S. Company Address: 8101 Ridgepoint Dr.,Suite 107,Irving,TX75063 Contact Person: Danny Sit Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Danny Sit Title: Manager Company Name: Sun Cupid Technology (HK) Ltd. Date: 5/4/2023 Agent Signed (if different from Applicant): Signed: Printed name: Danny Sit Title: Manager Company Name: NUU, Inc. Date:5/4/2023

Attestation Statements

Sun Cupid Technology (HK) Ltd. Covered Equipment Certification Attestation Letter 5/4/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2ADINN6001L Sun Cupid Technology (HK) Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Sun Cupid Technology (HK) Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Danny Sit Title: Manager Company Name: Sun Cupid Technology (HK) Ltd. Date: 5/4/2023

Cover Letter(s)

Sun Cupid Technology (HK) Ltd. DATE: 2023-5-4 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint JianYan Testing Group Shenzhen Co., Ltd.; No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China.；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Sun Cupid Technology (HK) Ltd , 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan, Kowloon, Hong Kong. Dated this 2023-5-4 By: Danny Sit Signature Printed Title: Manager On behalf of : Sun Cupid Technology (HK) Ltd. Telephone: +852-2725 0161

Cover Letter(s)

Sun Cupid Technology (HK) Ltd. DATE :2023-5-4 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADINN6001L Product Name: LTE Smart Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description  BOM  Turn up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2023-5-4 By: Danny Sit Signature Printed Title: Manager On behalf of : Sun Cupid Technology (HK) Ltd. Telephone: +852-2725 0161

Cover Letter(s)

Sun Cupid Technology (HK) Ltd. Date: 2023-5-4 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Dated this 2023-5-4 By: Danny Sit Signature Printed Title: Manager On behalf of : Sun Cupid Technology (HK) Ltd. Telephone: +852-2725 0161

Cover Letter(s)

Sun Cupid Technology (HK) Ltd. DATE :2023-5-4 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADINN6001L Product Name: LTE Smart Phone Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.:  Test Setup Photos  External Photos  Internal Photos  User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. <Signature> Name: Danny Sit Company: Sun Cupid Technology (HK) Ltd.

Cover Letter(s)

Declaration Letter We, Sun Cupid Technology (HK) Ltd. declared that our LTE Smart Phone item No.: N6001L, A23, NUU A23 were identical inside, the electrical circuit design, layout, components used and internal wiring, with only difference being model name. Sincerely yours Signature: Name/Title:Danny Sit /Manager Tel. No. +852-2725 0161 E-Mail: [email protected] Company: Sun Cupid Technology (HK) Ltd. Date：2023-5-4

External Photos

Internal Photos

JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 12 EUT Internal Photos JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 6 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 7 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 8 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 9 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 10 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 11 of 12 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302008 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 12 of 12 ------End------

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R14-2300007 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configura tion other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) t ested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Sun Cupid Technology (HK) Ltd. Address of Applicant: 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan, Kowloon, Hong Kong. Equipment Under Test (EUT) Product Name: LTE Smart phone Model No.: N6001L, A23,NUU A23 Trade mark NUU FCC ID: 2ADINN6001L Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 12 Feb., 2023 ~ 23 Feb., 2023 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 1.174 Body: 1.326 Hotspot: 1.326 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 2 of 145 2 Version Version No. Date Description 00 04 May., 2023 Original Tested by: Date: 04 May., 2023 Test Engineer Reviewed by: Date: 04 May., 2023 Project Engineer Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 3 of 145 3 Contents 1 COVER PAGE ....................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 7 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 7 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 7 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 9 5.4 ENVIRONMENT OF TEST SITE ....................................................................................................................................................... 10 5.5 TEST SAMPLE PLAN ..................................................................................................................................................................... 10 5.6 TEST LOCATION ........................................................................................................................................................................... 10 6 INTRODUCTION ................................................................................................................................................. 11 6.1 INTRODUCTION ............................................................................................................................................................................. 11 6.2 SAR DEFINITION .......................................................................................................................................................................... 11 7 RF EXPOSURE LIMITS ..................................................................................................................................... 12 7.1 UNCONTROLLED ENVIRONMENT ................................................................................................................................................... 12 7.2 CONTROLLED ENVIRONMENT ....................................................................................................................................................... 12 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................. 12 8 SAR MEASUREMENT SYSTEM ....................................................................................................................... 13 8.1 E-FIELD PROBE....................................................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 1 of 112 Appendix C: System Calibration Certificate Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 2 of 112 Calibration information for E-field probes Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 3 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 4 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 5 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 6 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 7 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 8 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 9 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 10 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 11 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 12 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 13 of 112 Calibration information for Dipole Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 14 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 15 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 16 of 112 Report …

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 69 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 70 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 71 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 72 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 73 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 74 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 75 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 76 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 77 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 78 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 79 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 80 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 81 of 112 Report No.: JYTSZ-R14-2300007 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2302009 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 82 of 112 Dipole Impedance and Return Loss calibration Report Object: SID2450 - SN 50/20 DIP 2G450-514 Calibration Date: January 12, 2023 Calibration reference: IEEE Std 1528:2013, IEC 62209-1:2016, FCC KDB 865664 D01 Calibrated By: (Janet Wei, SAR project engineer) Reviewed By: (Winner Zhang, Technical manager) Environment of Test Site Temperature: 18 ~ 25C Humidity: 50~60% RH Atmospheric Pressure: 1011 mbar Test Data Measurement Plot for Head TSL In 2023 Comparison with Original report Items Calibrated By JYT In 2022 Calibrated …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Danny Sit

[email protected]+852-2725 0161Fax: +852- 27250090

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
42	27	673 MHz - 688 MHz	39.60 mW	24M4W7D	0.06 ppm

Confidentiality

Long Term

Grant Notes

Output Power is EIRP and ERP for above and below 1 GHz, respectively, and conducted for Part 90 operations. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), simultaneous transmission exposure conditions, and product specific 10-g SAR are 0.75 W/kg, 1.33 W/kg, 1.33 W/kg, 1.59 W/kg, and 1.48 W/kg respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations. HAC Rating: M3 T3 - 2011.
