2ADINNUUX3LTE mobile phone

- 1 - S4517-X3 Dual SIM Cards Smart Phone User Guide Dear Customer, Thank you for choosing S4517- X3 smart phone. This is a smart phone. In addition to common call functions, it also provides you with a variety of practical functions including Bluetooth, English input, Contacts, ringing or image alert for incoming calls, camera, MP3 player, Video player, memory card (T-Flash card), recorder, calculator, Schedule power on/off, MMS (Multimedia Message Service). With this manual, you can acquire a full understanding of the usage of this phone. . Contents 1. Appearance 2. Insertion and Removal of SIM card 3. Insertion and Remove of the Memory Card 4. Installation and Removal of the Battery 5. Battery Charging 6. Dialing 7-9 Guide to Menu Operations 10 Safety Precautions. 11. Cleaning and Maintenance. 12. Trouble shooting Appearance 1 Insertion and Removal of SIM card  Turn off the phone; remove the battery and unplug other external power sources.  Insert the SIM card into the SIM slot.  When you need to remove the SIM card, please first turn off the phone, remove the battery, then remove the SIM card. 2 Insertion and Remove of the Memory Card  Place the Memory Card into the Memory Card Slot.  When you need to insert or remove the memory card, it is suggest that first turn off the phone. When you turn on the phone, insert the memory card can lead to memory card don’t recognize. Warning: when the mobile phone is sending or access messages, please do not remove the memory card. Otherwise it may result in data loss or damage the mobile phone and memory card. 3 Installation,and Removal of the battery If the mobile phone is switched on, please turn off your mobile phone.  When removing the battery follow the following steps: ①Push the battery cover and remove. ②Remove the battery from the mobile phone.  When installing the battery follow the following steps: ① Push the battery to inset mobile-phone. ② Cover with the battery cover. Warning: You must turn off your mobile phone before removing the battery.  Do not place the battery in fire; follow local laws and ordinances in disposing used battery.  Check the model number of the charger before using it to charge the mobile.  Only use approved battery, charger and accessories applicable to the specific mobile model. Using other types of battery, charger and accessories may violate the certification or warranty terms of the equipment and may result in danger.”  Return waste and used batteries to the supplier or specified recovery site.  Hearing protection, long time in the environment of high volume may damage people's hearing. - 2 - Setting the minimum volume required of the call and music is suggested to use. 4 Battery Charging  Plug the charger into the electrical outlet.  Plug the charger connector into the charge interface of the phone.  The mobile phone and charger will become warm during charging and this is normal.  When charging is complete, unplug the charge connector from the electrical outlet and the mobile phone. Warning: do not to take off the charger before removing the battery. Otherwise it will damage the mobile phone.  Charging must be performed in a well-ventilated area with a temperature between -10C and +55C.  If the mobile phone automatically shuts down, or indicates that the Battery is low you should immediately charge the battery.  Do not use damaged charger or battery.  Prevent battery from contacting metal objects, otherwise the pole "+" and "-" of the battery may be connected and cause temporary or permanent damage to the battery. 5 Dialing 5.1 Making Domestic Calls Use the number keys to input number, then press the dial key to dial the call via SIM card 1/2. You can input domestic calls in this order: Area code phone number dial key 5.2 Making International calls For making international calls you should long press the 0 key, until the international phone prefix “+” appears on the screen. This will allow you to make an international call in any country regardless of what the international call prefix is. You can input international calls in this order: + Country code area code telephone number dial key After entering the prefix, enter the country code and full number you wish to call. 5.3 Emergency Calls If you are located within a network area (you can find this out by referring to the network strength indicator located on the upper left-hand corner of your mobile phone screen), even if you do not have a SIM card, you will be able to transmit emergency calls. 5.4 Key board values Power key: hold down for power off or power on, press for close or switch on background light. Volume keys (up/down key): adjust sound volume in stand by interface. Home key: in function interface, shoft press the key to return to standby interface; long press the key to display Recent. Menu key: in standby interface, press the key can display the menu of Add, Wallpapers, Search, Notifications, Settings, Animation: And in different function interface, press the key can display different menus. Back key: in function interface, press the key to return to the menu. - 3 - 7-8 Guide to Menu Operations All function options about the mobile phone are listed as below with brief descriptions. 7.1 Application software The mobile phone provides you with a lot of application software, While at the same time, customer can installed unlimited application software. Note: need to insert the memory card, and keep the memory card has enough space. 7.2 Phone Be used to dial the number. 7.3 Contacts It displays the contacts. Long press one contact, it displays the options in follows: View contact, Edit contact, Delete contact, Add to speed dial, Share contact 7.4 Messages You can compose new message. Press the Menu key, you can choose Compose, Search, Settings to set. In the menu of Settings, you can set it as follows: Delete old messages, Text message limit, Multimedia message limit, Delivery reports, Manage SIM card messages, Edit quick text,…

Text truncated - open the document above for the full version.

Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 63 of 71 8 EUT Constructional Details Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 64 of 71 Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 65 of 71 Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 66 of 71

Label and label location: Label Label size：30mm*34mm label location: Label location

Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 67 of 71 Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 68 of 71 Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 69 of 71 Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 70 of 71 Report No: CCIS15030014701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 71 of 71 ------End of report------

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS15030014801 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: SUN CUPID TECHNOLOGY（HK）LIMITED Address of Applicant: 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan Hong Kong Equipment Under Test (EUT) Product Name: LTE mobile phone Model No.: X3 Trade mark NUU FCC ID: 2ADINNUUX3 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 20 Mar., 2015 ~ 07 Apr., 2015 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 1.194 Body: 0.463 Hotspot: 0.538 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 261 2 Version Version No. Date Description 00 09 Apr., 2015 Original Prepared by: Date: 09 Apr., 2015 Report Clerk Reviewed by: Date: 09 Apr., 2015 Project Engineer Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 261 3 Contents 1 COVER PAGE ................................................................................................................................................... 1 2 VERSION ........................................................................................................................................................... 2 3 CONTENTS ....................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ............................................................................................................................. 5 5 GENERAL INFORMATION .............................................................................................................................. 6 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 6 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 6 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 7 5.4 ENVIRONMENT OF TEST SITE ......................................................................................................................................................... 8 5.5 TEST LOCATION ............................................................................................................................................................................. 8 6 INTRODUCTION ............................................................................................................................................... 9 6.1 INTRODUCTION ............................................................................................................................................................................... 9 6.2 SAR DEFINITION ............................................................................................................................................................................ 9 7 RF EXPOSURE LIMITS .................................................................................................................................. 10 7.1 UNCONTROLLED ENVIRONMENT ................................................................................................................................................... 10 7.2 CONTROLLED ENVIRONMENT ....................................................................................................................................................... 10 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................. 10 8 SAR MEASUREMENT SYSTEM ................................................................................................................... 11 8.1 E-FIELD PROBE ........................................................................................................................................................................... 12 8.2 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................................................... 12 8.3 ROBOT .......................................................................................................................................................…

Text truncated - open the document above for the full version.

Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 90 of 261 Appendix D: Plots of SAR Test Data Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 91 of 261 Test Laboratory: CCIS Date/Time: 03.20.2015 12:07:07 DUT: LTE mobile phone; Type: X3; Serial: 1# Communication System: UID 0, GSM (0); Frequency: 848.8 MHz Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.906 S/m; ε r = 42.604; ρ = 1000 kg/m 3 Phantom section: Right Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration:  Probe: EX3DV4 - SN3924; ConvF(9.46, 9.46, 9.46); Calibrated: 06.20.2014;  Sensor-Surface: 2mm (Mechanical Surface Detection), z = 31.0  Electronics: DAE4 Sn1373; Calibrated: 06.11.2014  Phantom: SAM with CRP; Type: QD000P40CD; Serial: 1765  DASY52 52.8.7(1137); SEMCAD X 14.6.10(7164) GSM 850 Right Cheek/High Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.734 V/m; Power Drift = -0.30 dB Peak SAR (extrapolated) = 0.378 W/kg SAR(1 g) = 0.318 W/kg; SAR(10 g) = 0.242 W/kg Maximum value of SAR (measured) = 0.356 W/kg GSM 850 Right Cheek/High Channel/Area Scan (41x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.351 W/kg 0 dB = 0.351 W/kg = -4.55 dBW/kg . Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 92 of 261 Test Laboratory: CCIS Date/Time: 03.20.2015 13:07:02 DUT: LTE mobile phone; Type: X3; Serial: 1# Communication System: UID 0, GSM (0); Frequency: 848.8 MHz Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.906 S/m; ε r = 42.604; ρ = 1000 kg/m 3 Phantom section: Right Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration:  Probe: EX3DV4 - SN3924; ConvF(9.46, 9.46, 9.46); Calibrated: 06.20.2014;  Sensor-Surface: 2mm (Mechanical Surface Detection), z = 31.0  Electronics: DAE4 Sn1373; Calibrated: 06.11.2014  Phantom: SAM with CRP; Type: QD000P40CD; Serial: 1765  DASY52 52.8.7(1137); SEMCAD X 14.6.10(7164) GSM 850 Right Tilted/High Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.460 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 0.234 W/kg SAR(1 g) = 0.193 W/kg; SAR(10 g) = 0.149 W/kg Maximum value of SAR (measured) = 0.217 W/kg GSM 850 Right Tilted/High Channel/Area Scan (41x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.208 W/kg 0 dB = 0.208 W/kg = -6.82 dBW/kg Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 93 of 261 Test Laboratory: CCIS Date/Time: 03.20.2015 13:56:28 DUT: LTE mobile phone; Type: X3; Serial: 1# Communication System: UID 0, GSM (0); Frequency: 848.8 MHz Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.906 S/m; ε r = 42.604; ρ = 1000 kg/m 3 Phantom section: Left Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration:  Probe: EX3DV4 - SN3924; ConvF(9.46, 9.46, 9.46); Calibrated: 06.20.2014;  Sensor-Surface: 2mm (Mechanical Surface Detection), z = 31.0  Electronics: DAE4 Sn1373; Calibrated: 06.11.2014  Phantom: SAM with CRP; Type: QD000P40CD; Serial: 1765  DASY52 52.8.7(1137); SEMCAD X 14.6.10(7164) GSM 850 Left Cheek/High Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 7.977 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 0.346 W/kg SAR(1 g) = 0.293 W/kg; SAR(10 g) = 0.230 W/kg Maximum value of SAR (measured) = 0.325 W/kg GSM 850 Left Cheek/High Channel/Area Scan (41x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.316 W/kg 0 dB = 0.316 W/kg = -5.00 dBW/kg Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 94 of 261 Test Laboratory: CCIS Date/Time: 03.20.2015 13:36:32 DUT: LTE mobile phone; Type: X3; Serial: 1# Communication System: UID 0, GSM (0); Frequency: 848.8 MHz Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.906 S/m; ε r = 42.604; ρ = 1000 kg/m 3 Phantom section: Left Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration:  Probe: EX3DV4 - SN3924; ConvF(9.46, 9.46, 9.46); Calibrated: 06.20.2014;  Sensor-Surface: 2mm (Mechanical Surface Detection), z = 31.0  Electronics: DAE4 Sn1373; Calibrated: 06.11.2014  Phantom: SAM with CRP; Type: QD000P40CD; Serial: 1765  DASY52 52.8.7(1137); SEMCAD X 14.6.10(7164) GSM 850 Left Tilted/High Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.427 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 0.214 W/kg SAR(1 g) = 0.177 W/kg; SAR(10 g) = 0.136 W/kg Maximum value of SAR (measured) = 0.199 W/kg GSM 850 Left Tilted/High Channel/Area Scan (41x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.186 W/kg 0 dB = 0.186 W/kg = -7.30 dBW/kg Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Pr…

Text truncated - open the document above for the full version.

Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 203 of 261 Appendix E: System Calibration Certificate Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 204 of 261 Calibration information for E-field probes Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 205 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 206 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 207 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 208 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 209 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 210 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 211 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 212 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 213 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 214 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 215 of 261 Calibration information for Dipole Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 216 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 217 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 218 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 219 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 220 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 221 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 222 of 261 Report No: CCIS15030014801 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300148R…

Text truncated - open the document above for the full version.

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS15030014702 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC REPORT (BLE) Applicant: Sun Cupid Technology (HK) Ltd. Address of Applicant: 16/F,CEO Tower,77 Wing Hong Street, Cheung Sha Wan, Hong Kong Equipment Under Test (EUT) Product Name: LTE mobile phone Model No.: X3 Trade mark: NUU FCC ID: 2ADINNUUX3 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: 18 Mar., 2015 Date of Test: 19 Mar., 2015 to 08 Apr., 2015 Date of report issued: 08 Apr., 2015 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: CCIS15030014702 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 36 2 Version Version No. Date Description 00 08 Apr., 2015 Original Prepared by: Date: 08 Apr., 2015 Report Clerk Reviewed by: Date: 08 Apr., 2015 Project Engineer Report No: CCIS15030014702 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150300147RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 36 3 Contents Page 1 COVER PAGE ................................................................................................................................................... 1 2 VERSION ........................................................................................................................................................... 2 3 CONTENTS ....................................................................................................................................................... 3 4 TEST SUMMARY .............................................................................................................................................. 4 5 GENERAL INFORMATION ...........................................................................................................................…

Text truncated - open the document above for the full version.
