2ADINS5502LLTE Smart Phone

Getting Started With Your 4G LTE mobile phone Model: A11L, S5502L 3 Front/Back A11L OverviewIndex A11L Overview 3 Setting Up Your Phone 4 Safety Information 6 Certificate 10 Warranty Information & Registration 14 Customer Support 15 To p Bottom Wake/ Sleep button Microphone Noise Cancelling Microphone Volume control Rear camera Front camera Earpiece Speaker flash AUX-In/ Headset jack USB Type-C connector 45 Setting Up Your Phone Follow these step-by-step instructions to set up your A11L. Power off the phone before inserting any cards! Remove Back Cover • Remove the back cover by prying the lower left corner of your device. Insert microSD™ Memory Card (Optional) • Remember to power off the phone and remove battery before inserting memory card. Insert SIM • Orient SIM card to match diagram on slot. • SIM (Nano) support 4G LTE connections. Insert the Battery • Align the battery contacts, then insert the battery contact-first. Replace Back Cover • After installing the SIM card, memory card, and battery, align the cover and snap it closed. Be sure to press all around the edges to ensure a secure fit. Charge/Sync • Plug in the USB Type-C connector to charge the phone or transfer data. 1 1 3 3 2 2 4 4 5 5 6 6 Warning: SIM cards are small enough to become a choking hazard, so please keep them away from children & pets. SIM cards are also quite delicate. Please be careful when handling your card. 67 Safety information • This section contains important information about the operation of your device, it also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment • Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device where prohibited. • Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information. • Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Protecting your hearing when using a headset • To prevent possible hearing damage, do not listen at high volume levels for long periods. • Using a headset at high volumes may damage your hearing. To reduce this risk, lower the headset volume to a safe and comfortable level. • Exposure to high volumes while driving may cause distraction and increase your risk of an accident. Areas with flammables and explosives • Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols. • Do not store or transport the device in containers with flammable liquids, gases, or explosives. Traffic security • Observe local laws and regulations while using the device. To reduce the risk of accidents, do not use your wireless device while driving. • Concentrate on driving. Your first responsibility is to drive safely. • Do not hold the device while driving. Use hands-free accessories. • When you must make or answer a call, pull off the road safely and park the vehicle first. • RF signals may affect the electronic systems of motor vehicles. For more information, consult the vehicle manufacturer. • Do not place the device over the air bag or in the air bag deployment area in a motor vehicle. Doing so may hurt you because of the strong force when the air bag inflates. • Wireless devices may interfere with the airplane’s flight system. Do not use your device where wireless devices are not allowed according to the airplane company’s regulations. Operating environment • Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions. Do not use your device during thunderstorms to protect your device against any danger caused by lightning. • Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are -20 °C to 45 °C. Extreme heat or cold may damage your device or accessories. • Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged periods. • To protect your device or accessories from fire or electrical shock hazards, avoid rain and moisture. • Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, or candle. • Do not place sharp metal objects, such as pins, near the earpiece or speaker. The earpiece may attract these objects and result in injury. • Stop using your device or applications for a while if the device is overheated. If skin is exposed to an overheated device for an extended period, low temperature burn symptoms, such as red spots and darker pigmentation, may occur. • Do not use your device’s camera flash directly in the eyes of people or pets. Otherwise temporary loss of vision or damage to the eyes may occur. • Do not touch the device’s antenna. Otherwise, communication quality may be reduced. • Do not allow children or pets to bite or suck the device or accessories. Doing so may result in damage or explosion. • Observe local laws and regulations, and respect the privacy and legal rights of others. Child safety • Comply with all precautions with regard to child’s safety. Letting children play with the device or its accessories may be dangerous. The device includes detachable parts that may present a choking hazard. Keep away from children. • The device and its accessories are not intended for use by children. Children should only use the device with adult superv…

Text truncated - open the document above for the full version.

Sun Cupid Technology (HK) Ltd. ADD: 16/F,CEO Tower,77 Wing Hong St,Cheung Sha Wan,Kowloon,Hong Kong Tel: +852-2725 0161 Fax: +852- 27250090 E-mail: [email protected] Date: 2021-03-04 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We,Sun Cupid Technology (HK) Ltd. hereby authorizes Bay Area Compliance Laboratories Corporation to act as a laboratory for testing and test report generation for the following project(s): (product named as LTE Smart Phone ,model: S5502L, Multiple Models: A11L, NUU A11L FCC ID:2ADINS5502L) The chipset MT6739 supports Bluetooth,FM,WLAN,GPS,2G/3G/4G Mode,But for this device,only Bluetooth: 2402-2480MHz, 2.4G WIFI: 2412-2462 MHz(802.11b/g/n ht20), 2422-2452 MHz(802.11n ht40), 5G WIFI:5180-5240MHz(802.11a/n ht20), 5190-5230 MHz(802.11n ht40), 5745-5825MHz(802.11a/n ht20), 5755-5795 MHz(802.11n ht40), GSM850,PCS1900,WCDMA BAND2/4/5, LTE BAND2/4/5/12/13/25/26/41/66/71 were active,the other was disable by software. Sincerely Yours, Signature: Contact person:Danny Sit Title: Manager

Sun Cupid Technology (HK) Ltd. ADD: 16/F,CEO Tower,77 Wing Hong St,Cheung Sha Wan,Kowloon,Hong Kong Tel: +852-2725 0161 Fax: +852- 27250090 E-mail: [email protected] Product Similarity Declaration Date: 2021-02-18 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We,Sun Cupid Technology (HK) Ltd. hereby declare that we have a product named as LTE Smart Phone , (model: S5502L, FCC ID:2ADINS5502L) were tested by BACL, Meanwhile, for our marketing purpose, we would like to list a series model A11L ,NUU A11L on reports and certificate. The difference among them is just the model name. No other changes were made to them. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely Yours, Signature: Contact person:Danny Sit Title: Manager

Sun Cupid Technology (HK) Ltd. ADD: 16/F,CEO Tower,77 Wing Hong St,Cheung Sha Wan,Kowloon,Hong Kong Tel: +852-2725 0161 Fax: +852- 27250090 E-mail: [email protected] FCC Confidential Authorization Date: 2021-02-18 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:2ADINS5502L In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Sun Cupid Technology (HK) Ltd., hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description  Part List/Tune up procedure(for licensed devices) The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Contact person:Danny Sit Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

Units: mm Label location

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS LTE AUX ANT BT&WiFi ANT WWAN Main ANT

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*”. SAR EVALUATION REPORT For Sun Cupid Technology (HK) Ltd. 16/F,CEO Tower,77 Wing Hong Street,Cheung Sha Wan,Kowloon,Hong Kong. FCC ID: 2ADINS5502L Report Type: Original Report Product Type: LTE Smart Phone Report Number: RSZ210119007-20 Report Date: 2021-03-02 Reviewed By: Brave Lu SAR Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ210119007-20 SAR Evaluation Report 2 of 106 Attestation of Test Results EUT Information EUT Description LTE Smart Phone Tested Model S5502L Multiple Models A11L, NUU A11L FCC ID 2ADINS5502L Serial Number RSZ210119007-SA-S1 Test Date 2021-01-20 ~ 2021-01-26 MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) GSM 850 1g Head SAR 0.37 1.6 1g Body SAR 0.61 PCS 1900 1g Head SAR 0.29 1g Body SAR 1.46 WCDMA Band 2 1g Head SAR 0.29 1g Body SAR 1.39 WCDMA Band 4 1g Head SAR 0.23 1g Body SAR 1.46 WCDMA Band 5 1g Head SAR 0.39 1g Body SAR 0.53 LTE Band 12 1g Head SAR 0.24 1g Body SAR 0.66 LTE Band 13 1g Head SAR 0.36 1g Body SAR 0.62 LTE Band 25/2 1g Head SAR 0.39 1g Body SAR 1.22 LTE Band 26/5 1g Head SAR 0.35 1g Body SAR 0.64 LTE Band 41 1g Head SAR 0.11 1g Body SAR 0.66 LTE Band 66&4 1g Head SAR 0.25 1g Body SAR 1.39 LTE Band 71 1g Head SAR 0.13 1g Body SAR 0.29 Wi-Fi 2.4G 1g Head SAR 0.47 1g Body SAR 0.39 Wi-Fi 5.2G 1g Head SAR 0.47 1g Body SAR 0.39 Wi-Fi 5.8G 1g Head SAR 0.38 1g Body SAR 0.16 Simultaneous 1g Head SAR 0.82 1g Body SAR 1.50 1g Body SAR 1.50 (Hotspot) Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices RF Exposure Procedures: TCB Workshop April 2019 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ210119007-20 SAR Evaluation Report 3 of 106 Applicable Standards IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques IEC 62209-1:2016 Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Part 1: Devices used next to the ear (Frequency range of 300 MHz to 6 GHz) KDB procedures KDB 447498 D01 General RF Exposure Guidance v06 KDB 648474 D04 Handset SAR v01r03 KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 KDB 941225 D01 3G SAR Procedures v03r01 KDB 941225 D05 SAR for LTE Devices v02r05 KDB 248227 D01 802 11 Wi-Fi SAR v02r02 KDB 941225 D06 Hotspot Mode v02r01 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ210119007-20 SAR Evaluation Report 4 of 106 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 5 EUT DESCRIPTION .................................................................................................................................................... 6 TECHNICAL SPECIFICATION ......................................................................................................................................... 6 REFERENCE, STANDARDS, AND GUIDELINES .................................................................................................. 7 SAR LIMITS ................................................................................................................................................................. 8 FACILITIES .................................................................................................................................................................. 9 DESCRIPTION OF TEST SYSTEM ........................................................................................................................ 10 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 16 EQUIPMENTS LIST & CALIBRATION INFORMATION .................................................................................................... 16 SAR MEASUREMENT SYSTEM VERIFICATION .............................................................................................. 17 LIQUID VERIFICATION ............................................................................................................................................... 17 SYSTEM ACCURACY VERIFICATION ........................................................................................................................... 20 SAR SYSTEM VALIDATION DATA ..................................................................................................................... 22 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 32 TEST POSITIONS FOR DEVICE OPERATING NEXT TO A PERSON’S EAR................…

Text truncated - open the document above for the full version.

APPENDIX C PROBE CALIBRATION CERTIFICATES DIPOLE CALIBRATION CERTIFICATES

Report No.: RSZ210119007-20 Page 1 of 228 Plot 1#: GSM 850_ Head Left Cheek_ Mid DUT: LTE Smart Phone; Type: S5502L; Serial: RSZ210119007-SA-S1 Communication System: Generic GSM; Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used: f = 836.6 MHz; σ = 0.917 S/m; ε r = 41.558; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.13, 10.13, 10.13) @ 836.6 MHz; Calibrated: 2020/11/30  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn772; Calibrated: 2020/11/23  Phantom: SAM (30deg probe tilt) with CRP v5.0_20150321; Type: QD000P40CD; Serial: TP:1874  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x131x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.397 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 7.215 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 0.418 W/kg SAR(1 g) = 0.338 W/kg; SAR(10 g) = 0.269 W/kg Maximum value of SAR (measured) = 0.392 W/kg 0 dB = 0.392 W/kg = -4.07 dBW/kg Report No.: RSZ210119007-20 Page 2 of 228 Plot 2#: GSM 850 _Head Left Tilt _Mid DUT: LTE Smart Phone; Type: S5502L; Serial: RSZ210119007-SA-S1 Communication System: Generic GSM; Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used: f = 836.6 MHz; σ = 0.917 S/m; ε r = 41.558; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.13, 10.13, 10.13) @ 836.6 MHz; Calibrated: 2020/11/30  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn772; Calibrated: 2020/11/23  Phantom: SAM (30deg probe tilt) with CRP v5.0_20150321; Type: QD000P40CD; Serial: TP:1874  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x131x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.245 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 12.48 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.267 W/kg SAR(1 g) = 0.226 W/kg; SAR(10 g) = 0.189 W/kg Maximum value of SAR (measured) = 0.253 W/kg 0 dB = 0.253 W/kg = -5.97 dBW/kg Report No.: RSZ210119007-20 Page 3 of 228 Plot 3#: GSM 850_ Head Right Cheek_Mid DUT: LTE Smart Phone; Type: S5502L; Serial: RSZ210119007-SA-S1 Communication System: Generic GSM; Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used: f = 836.6 MHz; σ = 0.917 S/m; ε r = 41.558; ρ = 1000 kg/m 3 Phantom section: Right Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.13, 10.13, 10.13) @ 836.6 MHz; Calibrated: 2020/11/30  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn772; Calibrated: 2020/11/23  Phantom: SAM (30deg probe tilt) with CRP v5.0_20150321; Type: QD000P40CD; Serial: TP:1874  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x131x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.321 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.227 V/m; Power Drift = -0.14 dB Peak SAR (extrapolated) = 0.336 W/kg SAR(1 g) = 0.289 W/kg; SAR(10 g) = 0.242 W/kg Maximum value of SAR (measured) = 0.316 W/kg 0 dB = 0.316 W/kg = -5.00 dBW/kg Report No.: RSZ210119007-20 Page 4 of 228 Plot 4#: GSM 850_Head Right Tilt_Mid DUT: LTE Smart Phone; Type: S5502L; Serial: RSZ210119007-SA-S1 Communication System: Generic GSM; Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used: f = 836.6 MHz; σ = 0.917 S/m; ε r = 41.558; ρ = 1000 kg/m 3 Phantom section: Right Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.13, 10.13, 10.13) @ 836.6 MHz; Calibrated: 2020/11/30  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn772; Calibrated: 2020/11/23  Phantom: SAM (30deg probe tilt) with CRP v5.0_20150321; Type: QD000P40CD; Serial: TP:1874  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x131x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.244 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 12.35 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 0.323 W/kg SAR(1 g) = 0.146 W/kg; SAR(10 g) = 0.098 W/kg Maximum value of SAR (measured) = 0.253 W/kg 0 dB = 0.253 W/kg = -5.97 dBW/kg Report No.: RSZ210119007-20 Page 5 of 228 Plot 5#: GSM 850_Body Worn Back_Mid DUT: LTE Smart Phone; Type: S5502L; Serial: RSZ210119007-SA-S1 Communication System: Generic GSM; Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used: f = 836.6 MHz; σ = 0.917 S/m; ε r = 41.558; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.13, 10.13, 10.13) @ 836.6 MHz; Calibrated: 2020/11/30  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn772; Calibrated: 2020/11/23  Phantom: SAM (30deg probe tilt) with CRP v5.0_20150321; Type: QD000P40CD; Serial: TP:1874  Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7470) Area Scan (71x131x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.812 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 21.53 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 0.943 W/kg SAR(1 g) = 0.553 W/kg; SAR(10 g) = 0.357 W/kg Maximum value of SAR (measured) = 0.766 W/kg 0 dB = 0.766 W/kg = -1.16 dBW/kg Report No.: RSZ210119007-20 Page 6 of 228 Plot 6#: GSM 850_ Body Worn Front_Mid DUT: LTE Smart Phone; Type: S5502L; Serial: RSZ210119007-SA-S1 Communication System: Generic GSM; Frequency: 836.6 MHz;Duty Cycle: 1:8 Medium parameters used: f = 836.6 MHz; σ = 0.917 S/m; ε r = 41.558; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN7329; ConvF(10.13, 10.13, 10.13) @ 836.6 MHz; Calibrated: 2020/11/30  Sensor-Surface: 1.4m…

Text truncated - open the document above for the full version.

Report No.: RSZ210119007-20 Page 1 of 6 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm Phantom: SAM (30deg probe tilt) with CRP v5.0_20150321; Type: QD000P40CD; Serial: TP:1874 Report No.: RSZ210119007-20 Page 2 of 6 Head Left Cheek Setup Photo Head Left Tilt Setup Photo Report No.: RSZ210119007-20 Page 3 of 6 Head Right Cheek Setup Photo Head Right Tilt Setup Photo Report No.: RSZ210119007-20 Page 4 of 6 Body (Worn) Back Setup Photo (10mm) Body (Worn) Front Setup Photo (10mm) 10 mm 10 mm Report No.: RSZ210119007-20 Page 5 of 6 Body Top Setup Photo (10mm) Body Bottom Setup Photo (10mm) 10 mm 10 mm Report No.: RSZ210119007-20 Page 6 of 6 Body Left Setup Photo (10mm) Body Right Setup Photo (10mm) 10 mm 10 mm

FCC PART 15.407 TEST REPORT For Sun Cupid Technology (HK) Ltd. 16/F,CEO Tower,77 Wing Hong Street,Cheung Sha Wan,Kowloon,Hong Kong. Report Type: Original Report Product Name: LTE Smart Phone Re port Number: RSZ210119007-00D Re port Date: 2021-03--30 Reviewed By: Ivan Cao Assistant Manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn FCC ID:2ADINS5502L Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ210119007-00D Page 2 of 64 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 DECLARATIONS ............................................................................................................................................................ 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 8 SUPPORT CABLE LIST AND DETAILS ............................................................................................................................ 9 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 9 SUMMARY OF TEST RESULTS ............................................................................................................................. 10 FCC §15.407 (f) & §1.1310 & §2.1093- RF EXPOSURE ............................................................................................. 11 APPLICABLE STANDARD ............................................................................................................................................ 11 TEST RESULT ............................................................................................................................................................. 11 FCC §15.203- ANTENNA REQUIREMENT .............................................................................................................. 12 APPLICABLE STANDARD ............................................................................................................................................ 12 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 12 FCC §15.207(a)– CONDUCTED EMISSIONS ......................................................................................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 EUT SETUP ................................................................................................................................................................ 13 EMI TEST RECEIVER SETUP ....................................................................................................................................... 13 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 14 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 14 TEST PROCEDURE ...................................................................................................................................................... 14 TEST DATA ................................................................................................................................................................ 14 FCC §15.209, §15.205 , §15.407(b) –UNWANTED EMISSION .............................................................................. 17 APPLICABLE STANDARD ............................................................................................................................................ 17 EUT SETUP ................................................................................................................................................................ 18 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 18 TEST PROCEDURE ...................................................................................................................................................... 19 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View Radiated Emission Below 1GHz View Radiated Emission Above 1GHz View
