2ADINS6003LLTE Smart Phone

Sun Cupid Technology (HK) Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 10, 2020
Application Purpose: Original Equipment
Date of Application: Jul 10, 2020
Equipment Note: LTE Smart Phone
Frequency Range: 2402.00000000 - 2480.00000000
Company: Sun Cupid Technology (HK) Ltd.
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Sun Cupid Technology (HK) Ltd DATE: 2020-07-07 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint Shenzhen Zhongjian Nanfang Testing Co.,Ltd.; 1st Floor, Block No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Sun Cupid Technology (HK) Ltd , 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan, Kowloon, Hong Kong. Dated this 2020-07-07 By: Danny Sit Signature Printed Title: Manager On behalf of : Sun Cupid Technology (HK) Ltd. Telephone: +852-2725 0161

Cover Letter(s)

Sun Cupid Technology (HK) Ltd DATE :2020-07-07 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADINS6003L Product Name: LTE Smart phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description  BOM  Turn up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2020-07-07 By: Danny Sit Signature Printed Title: Manager On behalf of : Sun Cupid Technology (HK) Ltd. Telephone: +852-2725 0161

Cover Letter(s)

Declaration Letter We, Sun Cupid Technology (HK) Ltd declared that our product LTE Smart phone item No.: S6003L, X6 Plus were identical inside, the electrical circuit design, layout, components used and internal wiring, with only difference being model name. Sincerely yours Signature: Name/Title: Danny Sit / Manager Tel. No.: +852-27250161 E-Mail: [email protected] Company: Sun Cupid Technology (HK) Ltd Brand：NUU Date：2020-6-28

External Photos

Internal Photos

Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 53 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 54 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 55 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 56 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 57 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 58 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 59 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 60 of 61 Report No: CCISE200503501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 61 of 61 ------End of report------

RF Exposure Info

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCISE200503601 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Sun Cupid Technology (HK) Ltd. Address of Applicant: 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan, Kowloon, Hong Kong. Equipment Under Test (EUT) Product Name: LTE Smart phone Model No.: S6003L, X6 Plus Trade mark NUU FCC ID: 2ADINS6003L Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 07 Jun., 2020 ~ 18 Jun., 2020 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 0.314 Body: 1.347 Hotspot: 1.347 Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 2 of 207 2 Version Version No. Date Description 00 24 Jun., 2020 Original Tested by: Date: 24 Jun., 2020 Report Clerk Reviewed by: Date: 24 Jun., 2020 Project Engineer Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 3 of 207 3 Contents 1 COVER PAGE ....................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 7 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 7 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 7 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 8 5.4 ENVIRONMENT OF TEST SITE ......................................................................................................................................................... 9 5.5 TEST LOCATION ............................................................................................................................................................................. 9 6 INTRODUCTION ................................................................................................................................................. 10 6.1 INTRODUCTION ............................................................................................................................................................................. 10 6.2 SAR DEFINITION .......................................................................................................................................................................... 10 7 RF EXPOSURE LIMITS ..................................................................................................................................... 11 7.1 UNCONTROLLED ENVIRONMENT ................................................................................................................................................... 11 7.2 CONTROLLED ENVIRONMENT ....................................................................................................................................................... 11 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................. 11 8 SAR MEASUREMENT SYSTEM ....................................................................................................................... 12 8.1 E-FIELD PROBE............................................................................................................................................................................ 13 8.2 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................................................... 13 8.3 ROBOT .....................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 101 of 207 Test Laboratory: CCIS Date/Time: 06.09.2020 10:21:15 DUT: LTE Smart phone; Type: S6003L; Serial: 1# Communication System: UID 0, GSM (0); Frequency: 848.8 MHz; Duty Cycle: 1:8.30042 Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.928 S/m; ε r = 41.945; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(9.67, 9.67, 9.67); Calibrated: 08.30.2019;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 08.09.2019  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) GSM 850 Left Cheek/High Channel/Area Scan (51x71x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.302 W/kg GSM 850 Left Cheek/High Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.804 V/m; Power Drift = -0.27 dB Peak SAR (extrapolated) = 0.336 W/kg SAR(1 g) = 0.247 W/kg; SAR(10 g) = 0.185 W/kg Maximum value of SAR (measured) = 0.302 W/kg 0 dB = 0.302 W/kg = -5.20 dBW/kg Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 102 of 207 Test Laboratory: CCIS Date/Time: 06.13.2020 16:37:51 DUT: LTE Smart phone; Type: S6003L; Serial: 1# Communication System: UID 0, GSM (0); Frequency: 1850.2 MHz; Duty Cycle: 1:8.30042 Medium parameters used: f = 1850.2 MHz; σ = 1.406S/m; ε r = 39.841; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(8.17, 8.17, 8.17); Calibrated: 08.30.2019;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 08.09.2019  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) GSM 1900 Left Cheek/Low Channel/Area Scan (51x71x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.204 W/kg GSM 1900 Left Cheek/Low Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 2.885 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 0.250 W/kg SAR(1 g) = 0.156 W/kg; SAR(10 g) = 0.097 W/kg Maximum value of SAR (measured) = 0.216 W/kg 0 dB = 0.216 W/kg = -6.66 dBW/kg Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 103 of 207 Test Laboratory: CCIS Date/Time: 06.09.2020 11:11:08 DUT: LTE Smart phone; Type: S6003L; Serial: 1# Communication System: UID 0, UMTS-FDD(WCDMA) (0); Frequency: 836.6 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.893 S/m; ε r = 42.024; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(9.67, 9.67, 9.67); Calibrated: 08.30.2019;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 08.09.2019  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) WCDMA 850 Left Cheek/Middle Channel/Area Scan (51x71x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.345 W/kg WCDMA 850 Left Cheek/Middle Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 5.590 V/m; Power Drift = -0.30 dB Peak SAR (extrapolated) = 0.388 W/kg SAR(1 g) = 0.285 W/kg; SAR(10 g) = 0.213 W/kg Maximum value of SAR (measured) = 0.350 W/kg 0 dB = 0.350 W/kg = -4.56 dBW/kg Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 104 of 207 Test Laboratory: CCIS Date/Time: 06.13.2020 17:44:10 DUT: LTE Smart phone; Type: S6003L; Serial: 1# Communication System: UID 0, UMTS-FDD(WCDMA) (0); Frequency: 1752.6 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 1752.6 MHz; σ = 1.365 S/m; ε r = 40.506; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(8.4, 8.4, 8.4); Calibrated: 08.30.2019;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 08.09.2019  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) WCDMA 1700 Left Cheek/High Channel/Area Scan (51x71x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.175 W/kg WCDMA 1700 Left Cheek/High Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 2.497 V/m; Power Drift = 0.23 dB Peak SAR (extrapolated) = 0.204 W/kg SAR(1 g) = 0.133 W/kg; SAR(10 g) = 0.085 W/kg Maximum value of SAR (measured) = 0.174 W/kg 0 dB = 0.174 W/kg = -7.59 dBW/kg Report No: CCISE200503601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005036 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 105 of 207 Test Laboratory: CCIS Date/Time: 06.13.2020 18:38:43 DUT…

Text truncated - open the document above for the full version.

RF Exposure Info

EUT Photos (Model: S6003L) EUT Antenna Locations SAR Test Setup Photos Head Right Cheek Right Tilted Left Cheek Left Tilted Body Front side (10mm) Back side(10mm) Top side(10mm) Bottom side(10mm) Left side(10mm) Right side(10mm) Back side with headset(10mm) EUT holder Perturbation Evaluation Test Setup Photos DUT with device holder (DUT direct contact with the phantom) DUT without device holder (DUT direct contact with the phantom)

Test Report

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCISE200503503 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC REPORT (BLE) Applicant: Sun Cupid Technology (HK) Ltd. Address of Applicant: 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan, Kowloon, Hong Kong. Equipment Under Test (EUT) Product Name: LTE Smart phone Model No.: S6003L, X6 Plus Trade mark: NUU FCC ID: 2ADINS6003L Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: 12 May, 2020 Date of Test: 13 May, to 22 Jun., 2020 Date of report issued: 24 Jun., 2020 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: CCISE200503503 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 39 2 Version Version No. Date Description 00 24 Jun., 2020 Original Tested by: Date: 24 Jun., 2020 Test Engineer Reviewed by: Date: 24 Jun., 2020 Project Engineer Report No: CCISE200503503 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 39 3 Contents Page 1 COVER PAGE ................................................................................................................................................... 1 2 VERSION ........................................................................................................................................................... 2 3 CONTENTS ....................................................................................................................................................... 3 4 TEST SUMMARY .............................................................................................................................................. 4 5 GENERAL INFORMATION .............................................................................................................................. 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST ENVIRONMENT AND TEST MODE ................................................................................................................... 6 5.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................................................ 6 5.5 MEASUREMENT UNCERTAINTY .............................................................................................................................. 6 5.6 ADDITIONS TO, DEVIATIONS, OR EXCLUSIONS FROM THE METHOD ...................................................................... 6 5.7 LABORATORY FACILITY.......................................................................................................................................... 6 5.8 LABORATORY LOCATION ....................................................................................................................................... 6 5.9 TEST INSTRUMENTS LIST ....................................................................................................................................... 7 6 TEST RESULTS AND MEASUREMENT DATA ............................................................................................. 8 6.1 ANTENNA REQUIREMENT: ...................................................................................................................................... 8 6.2 CONDUCTED EMISSION ......................................................................................................................................... 9 6.3 CONDUCTED OUTPUT POWER ............................................................................................................................ 12 6.4 OCCUPY BANDWIDTH .......................................................................................................................................... 14 6.5 POWER SPECTRAL DENSITY ............................................................................................................................... 17 6.6 BAND EDGE ......................................................................................................................................................... 19 6.6.1 Conducted Emission Method ..................................................................................................................... 19 6.6.2 Radiated Emission Method ...........................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCISE200503504 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC REPORT (WIFI) Applicant: Sun Cupid Technology (HK) Ltd. Address of Applicant: 16/F, CEO Tower, 77 Wing Hong Street, Cheung Sha Wan, Kowloon, Hong Kong. Equipment Under Test (EUT) Product Name: LTE Smart phone Model No.: S6003L, X6 Plus Trade mark: NUU FCC ID: 2ADINS6003L Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: 12 May, 2020 Date of Test: 13 May, to 22 Jun., 2020 Date of report issued: 24 Jun., 2020 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. Report No: CCISE200503504 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 49 2 Version Version No. Date Description 00 24 Jun., 2020 Original Tested by: Date: 24 Jun., 2020 Test Engineer Reviewed by: Date: 24 Jun., 2020 Project Engineer Report No: CCISE200503504 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2005035 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 49 3 Contents Page 1 COVER PAGE ................................................................................................................................................... 1 2 VERSION ........................................................................................................................................................... 2 3 CONTENTS ....................................................................................................................................................... 3 4 TEST SUMMARY .............................................................................................................................................. 4 5 GENERAL INFORMATION .............................................................................................................................. 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST ENVIRONMENT AND TEST MODE ................................................................................................................... 6 5.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................................................ 6 5.5 MEASUREMENT UNCERTAINTY .............................................................................................................................. 6 5.6 ADDITIONS TO, DEVIATIONS, OR EXCLUSIONS FROM THE METHOD ...................................................................... 6 5.7 LABORATORY FACILITY.......................................................................................................................................... 6 5.8 LABORATORY LOCATION ....................................................................................................................................... 6 5.9 TEST INSTRUMENTS LIST ....................................................................................................................................... 7 6 TEST RESULTS AND MEASUREMENT DATA ............................................................................................. 8 6.1 ANTENNA REQUIREMENT ....................................................................................................................................... 8 6.2 CONDUCTED EMISSION ......................................................................................................................................... 9 6.3 CONDUCTED OUTPUT POWER ............................................................................................................................ 12 6.4 OCCUPY BANDWIDTH .......................................................................................................................................... 15 6.5 POWER SPECTRAL …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Danny Sit

[email protected]+852-2725 0161Fax: +852- 27250090

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.40 GHz - 2.48 GHz	400.00 µW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. This device is approved for use in the handset described in this filing. SAR compliance for body-worn operations is restricted to belt-clips, holsters, or similar accessories that have no metallic component in the assembly and which provide at least 1 cm separation between the device including its antenna and the body of user. End-users must be informed of the body-worn accessory operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission exposure conditions are 0.14 W/kg, 0.11 W/kg, 0.11 W/kg, and 1.53 W/kg, respectively.
