2ADK3XO-9980Wireless speaker and UV box

FCCID：2ADK3XO-9980 Functions: 1.Vol-/PreviousTrack 2.Play/Pause/PowerButton 3.Vol+/NextTrack 4.Microphone 5.Type-Cchargingport 6.USB-Aoutput 7.UVPhoneSanitizer TechSpecifications: Inputvoltage:DC5V/2A, USB-Aoutput:5V/2A(max) PairingName:“UVLightSpeaker” **ConnectingtoPower •Placetheproductonaflat,solid,stablesurface. •Plugthesmallconnectoroftheincludedpowercableintothepowerportonthebackofthe product. •PlugthelargeconnectorintoaUSBpowersource,suchastheUSBportonacomputerorintoa compatible5V/2AUSBadapter(notincluded)andplugintoawallsocket. 1.BluetoothSetup: PressandholdpowerbuttontoturnONthespeaker,LEDIndicatorwillflashBLUE wheninpairingmode.TurnontheBluetoothfunctiononmobiledevice,Select“UV LightSpeaker”pairingname. LEDwillturnsolidBLUEifsuccessfullypaired,Speakerwillautomaticallypairifthe mobiledevicehasbeenpairedbefore. IfdisconnectBluetoothafter5mins,thespeakerBluetoothwillautoshutoff. LongpressPowerbuttontoturnoffthespeaker. PlayingMusic: Longpressthespeakerpowerbuttontopoweronthespeaker,atonepromptand BlueLEDquickflash,atonepromptandBlueLEDwillkeeponafterconnect Bluetooth. ShortpressPlay/PausebuttontoPlay/Pausemusic. Shortpress+/-buttontocontrolvolumeincrease/decrease,longpresstocontrol next/previoustrack. DoublepressthevoicebuttontoactivateHISIRI/Googleassistantfunctions. CallFunction: Whenthere'sanincomingcall,shortpressthephonebuttontoansweracall,pressit againtoendthecall.Longpresstorejectacall,doublepressthebuttonredial. **HowtoUsetheUVSanitizer 1.PlugintheTYPE-Ccable. 2.OpentheCaseandplaceyourdeviceinsideofthecase. 3.Makesurethecaseisclosed. 4.TherearetwoUVsanitizemodes: *3minssanitizingmode:ShortpresstheUVbutton,theredlightontopcoverwilllightup,theUVC LEDinsidetheboxwilllightupfor3mins.Theredlightwillflash3timeswhensanitizingfinishedand lightwillturnoff; *5minssanitizingmode:DoublepresstheUVbutton,thegreenlightontopcoverwilllightup,the UVCLEDinsidetheboxwilllightupfor5mins.Thegreenlightwillflash3timeswhensanitizing finishedandlightwillturnoff. 5.OncetheUVsanitizercompletelyfinishessanitizing,openthelid,flipyourdeviceover,andrepeat thesanitizationprocessagainfortheothersideofyourdevice. Thisdeviceisdesignedtolimithuman&animalexposuretoUV-Clight,asitisharmfultoskinand eyes.ThisdeviceisequippedwithasafetyfeaturethatautomaticallyshutstheUV-Clightoffwhen thelidisopened. SafetyPrecautions •ThisproductisNOTatoy,keepawayfromchildrenandpets. •Onlyusethedeviceaccordingtotheinstructionsinthismanual.Neverusethedeviceforanything otherthanitsintendedpurpose. •ThisdeviceisNOTasubstituteforpropermedicalequipmentorattention. •ONLYusethesuppliedpowercable. •Donotopenthisproductorattempttorepairtheunityourselfifitisnotworkingproperly.Doingso risksfire,shockorinjury. •Thedevicecontainsasafetyfeaturethatpowersitoffautomatically when the cover is opened. Do NOT disable this safety feature. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.• Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 <2020-12-02> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID : 2ADK3XO-9980 Model name XO-9980 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (Signed) Name / Title: Sam Shen / Sales Company: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Phone: 0769-83454636 Fax: 0769-83345348 E-Mail: [email protected]

XING DA INTERNATIONAL ELECTRONICS LIMITED Add: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020/12/02 To whom it may concern: We, XING DA INTERNATIONAL ELECTRONICS LIMITED the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ADK3XO-9980 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, (Signed) Name / Title: Sam Shen / Sales Company: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Phone: 0769-83454636 Fax: 0769-83345348 E-Mail: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 4 External Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 4 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 4 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 4 Fig.7

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 Label and Location Size: L2.5cm*W1.5cm Material: Tagboard Glue: adhesive sticker Font color: White Label color: Black Label Location Wireless speaker and UV box FCC ID: 2ADK3XO-9980 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 3 Internal Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 3 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 Fig.5 Fig.6 BT ANT

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2ADK3XO-9980 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 2 FCC RF Exposure Evaluation 1. Product Information FCC ID: 2ADK3XO-9980 Product name Wireless speaker and UV box Model number XO-9980 Additional Model No. / Model declaration / Power supply Input: DC 5V/2A USB-A output: 5V/2A(max) Operation frequency Bluetooth: 2402MHz-2480MHz Modulation Type GFSK, π/4-DQPSK for Bluetooth V5.1 (DSS) Channel Number 79 Channels for Bluetooth V5.1(DSS) Antenna Type PCB Antenna Antenna Gain -0.58dBi(Max.) Hardware version V1.0 Software version V1.0 Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Portable Devices 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2ADK3XO-9980 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 3. Refer evaluation method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices 4. Conducted Power Results Mode Channel Frequency(MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 -1.750 39 2441 -1.388 78 2480 -1.501 π/4DQPSK 0 2402 -0.963 39 2441 -0.609 78 2480 -0.598 5. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.0 -1.0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 0 0 0 Tolerance ±(dB) 1.0 1.0 1.0 6. Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power SAR Test Exclusion Threshold SAR Test Exclusion dBm mW GFSK 2.45 5 0 1.0000 0.3130< 3.0 Yes π/4DQPSK 2.45 5 1.0 1.2589 0.3941< 3.0 Yes Remark: 1. Output power including tune up tolerance; 2. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. .......................THE END OF REPORT.........................

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 1 of 34 Appendix A RF Test Data for BT V5.1(BDR/EDR) (Conducted Measurement) Product Name: Wireless speaker and UV box Trade Mark: N/A Test Model: XO-9980 Environmental Conditions Temperature: 25.2  C Relative Humidity: 53.6% ATM Pressure: 100.0 kPa Test Engineer: Dancy Chen Supervised by: Li Huan A.1 Maxmum Conducted Peak Output Power Mode Channel. Maximum Peak Output Power [dBm] Limit [dBm] Verdict GFSK LCH -1.750 21 PASS MCH -1.388 21 PASS HCH -1.501 21 PASS π/4DQPSK LCH -0.963 21 PASS MCH -0.609 21 PASS HCH -0.598 21 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 2 of 34 Test Graphs GFSK/LCH GFSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 3 of 34 GFSK/HCH π/4DQPSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 4 of 34 π/4DQPSK/MCH π/4DQPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 5 of 34 A.2 20dB Bandwidth Mode Channel. 20dB Bandwidth [MHz] Limit [MHz] Verdict GFSK LCH 0.9542 Not Specified PASS MCH 0.9534 Not Specified PASS HCH 0.9554 Not Specified PASS π/4DQPSK LCH 1.282 Not Specified PASS MCH 1.283 Not Specified PASS HCH 1.282 Not Specified PASS Test Graphs GFSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 6 of 34 GFSK/MCH GFSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 7 of 34 π/4DQPSK/LCH π/4DQPSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 8 of 34 π/4DQPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 9 of 34 A.3 Carrier Frequency Separation Mode Channel. Carrier Frequency Separation [MHz] Limit [MHz] Verdict GFSK LCH 1.041 0.637 PASS MCH 1.166 0.637 PASS HCH 0.760 0.637 PASS π/4DQPSK LCH 0.904 0.855 PASS MCH 0.938 0.855 PASS HCH 1.120 0.855 PASS Test Graphs GFSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 10 of 34 GFSK/MCH GFSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 11 of 34 π/4DQPSK/LCH π/4DQPSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 12 of 34 π/4DQPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 13 of 34 A.4 Hopping Channel Number Mode Channel. Number of Hopping Channel [N] Limit [N] Verdict GFSK Hop 79 >=15 PASS π/4DQPSK Hop 79 >=15 PASS Test Graphs GFSK/Hop π/4DQPSK/Hop SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 14 of 34 A.5 Dwell Time Mode Packet Channel Burst Width [ms/hop/ch] Total Hops[hop*ch] Dwell Time[s] Limit [s] Verdict GFSK DH5 LCH 2.88 106.7 0.307 0.4 PASS DH5 MCH 2.88 106.7 0.307 0.4 PASS DH5 HCH 2.88 106.7 0.307 0.4 PASS π/4DQPSK 2DH5 LCH 2.88 106.7 0.307 0.4 PASS 2DH5 MCH 2.88 106.7 0.308 0.4 PASS 2DH5 HCH 2.88 106.7 0.308 0.4 PASS Test Graphs GFSK_DH5/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 15 of 34 GFSK_DH5/MCH GFSK_DH5/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 16 of 34 π/4DQPSK _2DH5/LCH π/4DQPSK _2DH5/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 17 of 34 π/4DQPSK _2DH5/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 18 of 34 A.6 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict GFSK LCH -2.131 -38.359 -22.131 PASS MCH -1.862 -37.345 -21.862 PASS HCH -1.936 -37.472 -21.936 PASS π/4DQPSK LCH -2.213 -37.490 -22.213 PASS MCH -1.8 -37.281 -21.800 PASS HCH -1.819 -37.994 -21.819 PASS GFSK_LCH_Graphs Pref SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 19 of 34 Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 20 of 34 GFSK_MCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 21 of 34 GFSK_HCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 22 of 34 π/4DQPSK_LCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 23 of 34 π/4DQPSK_MCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 24 of 34 π/4DQPSK_HCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 25 of 34 A.7 Band-edge for RF Conducted Emissions Mode Channel Carrier Frequency [MHz] Carrier Power [dBm] Frequency Hopping Max Spurious Level [dBm] Limit [dBm] Verdict GFSK LCH 2402 -2.203 Off -42.734 -22.2 PASS -1.917 On -42.441 -21.92 PASS HCH 2480 -1.998 Off -41.672 -22 PASS -1.835 On -42.290 -21.84 PASS π/4DQPSK LCH 2402 -2.427 Off -42.814 -22.43 PASS -1.729 On -42.086 -21.73 PASS HCH 2480 -1.760 Off -40.958 -21.76 PASS -1.646 On -42.132 -21.65 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 26 of 34 Test Graphs GFSK/LCH/No Hop GFSK/LCH/Hop SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 27 of 34 GFSK/HCH/No Hop GFSK/HCH/Hop SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA Page 28 of 34 π/4DQPSK/LCH/No Hop π/4DQPSK/LCH/Hop SHENZHEN LCS COMPLIANCE TESTING …

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 37 FCC TEST REPORT For XING DA INTERNATIONAL ELECTRONICS LIMITED Wireless speaker and UV box Test Model:XO-9980 Prepared for : XING DA INTERNATIONAL ELECTRONICS LIMITED Address : #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Shajing Street, Baoan District, Shenzhen, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : November 18, 2020 Number of tested samples : 2 Sample number : 201111367A-1, 201111367A-2 Serial number : Prototype Date of Test : November 18, 2020~November 27, 2020 Date of Report : November 30, 2020 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 37 FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCS201111367AEA Date of Issue .................................. : November 30, 2020 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Shajing Street, Baoan District, Shenzhen, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : XING DA INTERNATIONAL ELECTRONICS LIMITED Address .......................................... : #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No.................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Wireless speaker and UV box Trade Mark ..................................... : N/A Test Model ...................................... : XO-9980 Ratings ........................................... : Input: DC 5V/2A USB-A output: 5V/2A(max) Result ............................................ : Positive Compiled by: Supervised by: Approved by: Scent Hu/ File administrators Jin Wang/ Technique principal Gavin Liang/ Manager SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 37 FCC -- TEST REPORT Test Model............................... : XO-9980 EUT......................................... : Wireless speaker and UV box Applicant............................... : XING DA INTERNATIONAL ELECTRONICS LIMITED Address.................................. : #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Telephone............................... : Fax.......................................... : Manufacturer........................ : XING DA INTERNATIONAL ELECTRONICS LIMITED Address................................... : #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Telephone............................... : Fax.......................................... : Factory................................... : / Address................................... : / Telephone............................... : Fax.......................................... : Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS201111367AEA November 30, 2020 Date of issue SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 37 Revision History Revision Issue Date Revisions Revised By 000 November 30, 2020 Initial Issue Gavin Liang SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 Report No.: LCS201111367AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 37 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................................. 6 1.1. DESCRIPTION OF DEVICE (EUT) ....................................................................................................................................... 6 1.2. HOST SYSTEM CONFIGURATION LIST AND DETAILS ......................................................................................................... 6 1.3. EXTERNAL I/O CABLE ................................................................................................................................…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 _______________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 2 Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ADK3XO-9980 _______________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 Test Setup Photo(s) of Conducted Emissions Measurement Fig. 3
