2ADK8SW1401BT Smart Watch

Galapad Technology Limited Dec 09, 2014 Federal Communications Commission Authorization and Evaluation Division FCC ID：2ADK8SW1401 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram CONF APPENDIX 2ADK8SW1401_Block Diagram.pdf 2. Circuit Diagram CONF APPENDIX 2ADK8SW1401 _Schematics.pdf 3. Operational Description CONF APPENDIX 2ADK8SW1401_Operational description.pdf 4. BOM List CONF APPENDIX 2ADK8SW1401_BOM List.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Paul Lau / Assistant R&D Manager Applicant: Galapad Technology Limited Address: Unit 1601, 16/F, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Kowloon, HongKong Tel: 852-24238187 EXT.302 Fax: 852-24238981 Email: [email protected]

Internal Photos BT Antenna

Report No.: SET2014-12256 CCIC-SET/T（00） Page 1 of 40 RF TEST REPORT Report No.: SET2014-12256 Product Name: BT Smart Watch FCC ID: 2ADK8SW1401 Model No. : FMXX / SMXX / RMXX / KMXXXX (“X” stand for the product’s model number (From 0 to 9)) Applicant: Address: Galapad Technology Limited Unit 1601, 16/F, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Kowloon, Hongkong Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 40 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2014-12256 CCIC-SET/T（00） Page 2 of 40 Test Report Product Name ....................... : BT Smart Watch Trade Name ........................... : N/A Applicant ............................... : Galapad Technology Limited Applicant Address ................ : Unit 1601, 16/F, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Kowloon, Hongkong Manufacturer ........................ : Shen Zhen Galapad Technology Co.,Ltd. Manufacturer Address ......... : Unit 603,Tower B Tian'an Hi-Tech Venture Park,Futian District,Shenzhen City Test Standards...................... : 47 CFR Part 15 Subpart C：Radio Frequency Devices ANSI C63.10:2009：American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 DTS Meas Guidance v03r02 Test Result ............................ : PASS Tested by ............................. : 2014.11.13 Haigang He, Test Engineer Reviewed by ......................... : 2014.11.13 Lu Lei, Senior Egineer Approved by ......................... : 2014.11.13 Wu Li’an, Manager Report No.: SET2014-12256 CCIC-SET/T（00） Page 3 of 40 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 4 1.1. EUT Description ....................................................................................................................... 4 1.2. Test Standards and Results ........................................................................................................ 5 1.3. Facilities and Accreditations ..................................................................................................... 6 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 7 2.1. Antenna requirement ................................................................................................................. 7 2.2. Peak Output Power.................................................................................................................... 8 2.3. Average power ........................................................................................................................ 11 2.4. 6dB Bandwidth ....................................................................................................................... 12 2.5. Conducted Spurious Emissions ............................................................................................... 15 2.6. Power spectral density (PSD) ................................................................................................. 19 2.7. Band edge ................................................................................................................................ 22 2.8. Conducted Emission ............................................................................................................... 26 2.9. Radiated Emission................................................................................................................... 29 Change History Issue Date Reason for change 1.0 Nov 13, 2014 First edition Report No.: SET2014-12256 Page 4 of 40 1. General Information 1.1. EUT Description EUT Type ............................. : BT Smart Watch Serial No. .............................. : FM45200046 Hardware Version ................. : BM0 Software Version .................. : MAUI.11C.W14.18.SP4 Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (40 channels, at intervals of 2MHz); Modulation Type .................. : GFSK Antenna Type ........................ : PIFA Antenna Antenna Gain ........................ : 1dBi Note 1: The EUT is BT Smart Watch, it contain Bluetooth 4.0 LTE Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth 4.0 LTE is F(MHz)=2402+2*n (0<=n<=39). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 20(2442MHz) and 39 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: The EUT was programmed to be in continuously transmitting mode and the transmit duty cycle is not less than 98%. Note 4: BT Smart Watch has four serials models, called FMXX, SMXX, RMXX and KMXXXX. “X” stand for the product’s model number (From 0 to 9). They have the same designs except appearance. KMXXXX and FMXX share with the same appearance and design, just with different models. In this report, test EUT is the FM05. Report No.: SET2014-12256 Page 5 of 40 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC Certification: No. Identity Document Title 1 47 CFR Part 15 (1…

Text truncated - open the document above for the full version.

Conducted Emission Test setup photos Radiated Emission Test setup photos Below 1G 1GHz~18GHz Conducted Test setup photo
