2ADOV-IRULUV1Mobile phone with GSM/WCDMA/Bluetooth/Wifi/GPS

Smart series iRULU Mobile Phone V1 User’s Guide FCC Regulations This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐Reorient or relocate the receiving antenna. ‐Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. The antenna(s) used for this transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. RF Exposure Information (SAR) This mobile phone meets the government’s requirements for exposure to radio waves. This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is 0.506 W/kg and when worn on the body, as described in this user guide, is 0.645W/kg (Body‐worn measurements differ among phone models, depending upon available accessories and FCC requirements.) While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: 2ADOV-IRULUV1. For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the positions the handset a minimum of 1.0 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. If you do no t use a body‐worn accessory and are not holding the phone at the ear, position the handset a minimum of 1.0 cm from your body when the phone is switched on. Please make sure the temperature for production unit will be between ‐10~50 ̊C. 1 1 The Basics 1.1 Overview Thank you for choosing the GSM/WCDMA digital mobile phone. After reading this guide you will be able to fully master the use of your phone and appreciate all its functions and ease of use. Not only does the smartphone provide you with basic call functions such as call Register, but also with many practical functions and services, to improve the time you spend working and playing. The color screen mobile phone complies with the GSM/WCDMA technology and has been approved by certification authorities both domestically and abroad. The availability of some services and features described in this manual depends on the network and your subscription. Therefore, some menu items may not be available in your phone. The shortcuts to menus and features may also vary from phone to phone. Our company reserves the right to revise this manual content without prior notice. 2 1.2 Safety guide „ If your mobile phone is lost or stolen, please contact the telecommunications authorities or a sales agent immediately to have a hold on the phone and the SIM card. This will prevent economic loss caused by unauthorized calls made from your mobile phone. „ When you contact the telecommunications authorities or a sales agent, they will need to know the IMEI number of our mobile phone (remove battery to expose number located on the label on back of phone). Please copy this number and keep in a safe place for future use. „ In order to avoid the misuse of your mobile phone please take the following preventative measures: - Set the PIN number of your mobile phone’s SIM card and change this number immediately if it becomes known to a third party. - Please keep the phone out of sight when leaving it in a vehicle. It is best to carry the ph…

Text truncated - open the document above for the full version.

USA111 INC. 5885 Green Pointe Dr. Suite B Groveport OH, 43125 Tel: 614-8360241 Confidentiality Letter Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ADOV-IRULUV1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operation Description Operation Description.pdf Tune up procedure Tune up procedure.pdf BOM BOM.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Carolyn Schafer / Director

USA111 INC. 5885 Green Pointe Dr. Suite B Groveport OH, 43125 Tel: 614-8360241 Letter for Label Proposal FCC ID: 2ADOV-IRULUV1 Date: Dec. 16, 2014 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Dear Sirs: USA111 INC. requests acceptance of the labeling proposal described below for transceivers bearing FCC identifier 2ADOV-IRULUV1. The subject transceivers are compact handheld models as shown in figure 1, authorized under FCC Part 22/24 for mobile services. Figure 1. Because the majority of the transceiver housing is composed of display, speaker, operating controls, and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, we propose placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. USA111 INC. 5885 Green Pointe Dr. Suite B Groveport OH, 43125 Tel: 614-8360241 Proposed Label Location on EUT Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), We will add the FCC identifier "2ADOV-IRULUV1" to the outside of the consumer "gift box" packaging. Sincerely yours, Carolyn Schafer / Director

USA111 INC. 5885 Green Pointe Dr. Suite B Groveport OH, 43125 Tel: 614-8360241 DOC ATTESTATION LETTER FCC ID: 2ADOV-IRULUV1 Date: Dec. 16, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: I, the undersigned, hereby attest to the fact that I will apply the Declaration of Conformity procedure to the computer peripheral. I understand the following FCC requirements: 1. Devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.) 2. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. 3. Pt 2.1077 contains the list of information that must be included in the Declaration of Conformity, which must be supplied with each product sold. The DoC compliance info shall be included in the User’s Manual or as a separate sheet. The info must contain the name, address, and phone number of the responsible party, which must be located within the United States. According to 2.909(c)(2), the responsible party is either the Manufacturer or if the product is imported the Importer. Sincerely, Carolyn Schafer / Director

External Photos of EUT

FCC ID Label Information 1. Label location: 2. FCC ID Label: iRULU Mobile phone V1 GSM/GPRS 850/900/1800/1900 WCDMA/HSPA 850/1900/2100 FCC ID: 2ADOV-IRULUV1

Internal Photos of EUT

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Part 15.247 Report Reference No......................: CTL1411182761-WW Compiled by ( position+printed name+signature) .: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature) .: Test Engineer Tracy Qi Approved by ( position+printed name+signature) .: Manager Tracy Qi Date of issue.....................................: Dec. 16, 2014 Test Laboratory Name...................: Shenzhen CTL Testing Technology Co., Ltd. Address ............................................: Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Applicant’s name............................: USA 111 INC. Address ............................................: 5885 Green Pointe Dr. Suite B Groveport OH, 43125 United States Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 902–928 MHz, 2400– 2483.5 MHz, and 5725–5850 MHz. TRF Originator..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mobile phone FCC ID.......................................: 2ADOV-IRULUV1 Trade Mark....................................... : iRULU Model/Type reference ......................: V1 GSM/WCDMA Transmit ........................................... : 2G:GSM 850: 824~849MHz, PCS 1900: 1850~1910MHz 3G:WCDMA Band II: 1850-1910MHz, WCDMA Band V: 824~849MHz Receive ............................................ : 2G:GSM 850: 869~894MHz, PCS 1900: 1930~1990MHz 3G:WCDMA Band II: 1930~1990MHz, WCDMA Band V: 869~894MHz Release Version ............................. : 2G:R99 3G:Rel-6 V1.0 Page 2 of 103 Report No.: CTL1411182761-WW Type of modulation ...........................: 2G: GMSK for GSM/GPRS 3G: QPSK GPRS Type ..................................... : Class B GPRS Class ................................... : Class 12 GPS work frequency ................................: 1575.42MHz Type of modulation ...........................: BPSK Bluetooth Work frequency................................: 2402~2480MHz Version ............................................. : V3.0, V4.0 Type of modulation ........................... : FHSS Data Rate ......................................... : 1Mbps(GFSK), 2Mbps(Pi/4 DQPSK), 3Mbps(8DPSK) Wi-Fi Work frequency ................................: 802.11b/g/n(20MHz): 2412~2462MHz, 802.11n(40MHz): 2422~2452MHz Type of modulation ...........................: 802.11b DSSS, 802.11g/n: OFDM Data Rate ......................................... : 802.11b: 1/2/5.5/11 Mbps 802.11g: 6/9/12/18/24/36/48/54 Mbps 802.11n: up to 150 Mbps Antenna Gain ...................................: -2.0 dBi for GSM850 and WCDMA Band V -2.0 dBi for PCS1900 and WCDMA Band II -3.0 dBi for Bluetooth and Wi-Fi Antenna type ....................................: Internal IMEI .................................................. : 356878021568635/356878021568643 Harware version ...............................: E2109_V1.1 Software version...............................: Android 4.4.2 Result ............................................... : Positive V1.0 Page 3 of 103 Report No.: CTL1411182761-WW T E S T R E P O R T Test Report No. : CTL1411182761-WW Dec. 16, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile phone Model /Type : V1 Applicant : USA111 INC. Address : 5885 Green Pointe Dr. Suite B Groveport OH, 43125 United States Manufacturer SHENZHEN GOTRON ELECTRONIC CO., LTD Address Room 15C, Block C of Electronic& Technology Building,2070 Shennan Middle Road, Shenzhen 518000 P.R.China Test Result according to the standards on page 5: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 4 of 103 Report No.: CTL1411182761-WW Contents 1. TEST STANDARDS................................................................. 5 2. SUMMARY............................................................................ 6 2.1. General Remarks 6 2.2. Equipment Under Test 6 2.3. Short description of the Equipment under Test (EUT) 6 2.4. EUT operation mode 7 2.5. EUT configuration 7 2.6. NOTE 7 2.7. Related Submittal(s) / Grant (s) 7 2.8. Modifications 7 3. TEST ENVIRONMENT ............................................................. 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Duty Cycle 8 3.6. Statement of the measurement uncertainty 9 3.7. Equipments Used during the Test 9 3.8. Summary of Test Result 10 4. TEST CONDITIONS AND RESULTS.......................................... 11 4.1. Conducted Emissions Test 11 4.2. Radiated Emission Test 14 4.3. 6dB Bandwidth Measurement 22 4.4. Maximum Peak Output Power 31 4.5. Band Edge Measurement 33 4.6. Power Spectral Density Measurement 66 4.7. Spurious RF Conducted Emission 75 4.8. Operation Frequency Range of 20dB Bandwidth 88 4.9. Antenna Requirement 93 4.10. RF Exposure 94 5. TEST SETUP PHOTOS OF THE EUT ........................................ 95 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ..................... 97 V1.0 Page 5 of 103 Re…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
