2ADOV-W181Tablet PC

Moodel: W181 Model: W181 FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

USA111 INC. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/2/2015 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ADOV-W181 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature [Carolyn Schafer] [Director] USA111 INC. 5885 Green Pointe Dr. Suite B, Groveport, Ohio, United States 43125

USA111 INC. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 10/26/2015 Request for Confidentiality Company name: USA111 INC. FCC ID: 2ADOV-W181 FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.457 and CFR 47 § 0.459 USA111 INC. hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, These documents contain detailed system and equipment description and related information about the product which USA111 INC. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, USA111 INC. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature [Carolyn Schafer] [Director] USA111 INC. 5885 Green Pointe Dr. Suite B, Groveport, Ohio, United States 43125

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS FCC ID: 2ADOV-W181 EUT View 1 EUT View 2 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 EUT View 3 EUT View 4 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 EUT View 5 EUT View 6 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 EUT View 7

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2ADOV-W181 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location (Back cover can’t be removed)

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS FCC ID: 2ADOV-W181 EUT Housing and Board View 1 Solder Board-Component View 1 WIFI/BT Antenna Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 Solder Board-Component View 2 Solder Board-Component View 3 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-1/-2/-3 FCC PART 15.247 Solder Board-Component View 4

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 PAGE 1 OF 16 FCC PART 15B FCC Part 15B Measurement and Test Report For USA111 INC. 5885 Green Pointe Dr. Suite B, Groveport, Ohio, United States 43125 FCC ID: 2ADOV-W181 Test Rule(s): FCC Part 15 Subpart B Product Description: Tablet PC Tested Model: W181 Report No.: STR15108046I-4 Tested Date: 2015-10-12 to 2015-10-23 Issued Date: 2015-10-23 Tested By: Jason Su / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen SEM.Test Technology Co., Ltd. Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 PAGE 2 OF 16 FCC PART 15B TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 3 1.2 TEST STANDARDS ................................................................................................................................................... 4 1.3 TEST METHODOLOGY ............................................................................................................................................. 4 1.4 TEST FACILITY ....................................................................................................................................................... 4 1.5 EUT SETUP AND OPERATION MODE ...................................................................................................................... 5 1.6 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 6 3. CONDUCTED EMISSIONS .................................................................................................................................... 7 3.1 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 3.2 TEST PROCEDURE ................................................................................................................................................... 7 3.3 BASIC TEST SETUP BLOCK DIAGRAM ..................................................................................................................... 7 3.4 ENVIRONMENTAL CONDITIONS .............................................................................................................................. 8 3.5 SUMMARY OF TEST RESULTS/PLOTS ...................................................................................................................... 8 3.6 CONDUCTED EMISSIONS TEST DATA ...................................................................................................................... 8 4. RADIATED EMISSIONS ....................................................................................................................................... 11 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................................ 11 4.2 TEST PROCEDURE ................................................................................................................................................. 11 4.3 TEST RECEIVER SETUP ......................................................................................................................................... 12 4.4 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................................ 12 4.5 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 12 4.6 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 12 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 PAGE 3 OF 16 FCC PART 15B 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: USA111 INC. Address of applicant: 5885 Green Pointe Dr. Suite B, Groveport, Ohio, United States 43125 Manufacturer: Allland Networking Co., Ltd. Address of manufacturer: Fourth Floor, #B Building, Weiyulong Industrial Park, Xuegang North Road #16, Bantian Street, Longgang District, Shenzhen General Description of EUT Product Name: Tablet PC Trade Name: / Model No.: W181 Adding Model(s): W27, W38, W20, W21, W19, W22, X18, X181, X11, X19, X27, X30, W171 Note: The test data is gathered from a production sample, provided by the manufacturer. The appearance of others models listed in the report is different from main-test model W181, but the circuit and the electronic construction do not change, declared by the manufacturer. Technical Characteristics of EUT Rated Voltage: Battery DC 3.7V Battery Capacity: 3500mAh Rated Power: / Power Adapter Model: JHD-AP012U-050200AA Input: AC 100-240V Output: DC 5V/2A Lowest Internal Frequency: 32.768KHz Highest Internal Frequency: 1.83GHz Classification of ITE: Class B Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 PAGE 4 OF 16 FCC PART 15B 1.2 Test Standards The following report is prepared on behalf of the USA111 INC. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communica…

Text truncated - open the document above for the full version.

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 FCC PART 15B EXHIBIT 4 - TEST SETUP PHOTOGRAPHS FCC ID: 2ADOV-W181 Conducted Emission Test Setup Radiation Emission Test Setup (30MHz to 1GHz) Charging And HDMI Playing Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 FCC PART 15B OTG Playing Radiation Emission Test Setup (Above 1GHz) Charging And HDMI Playing Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15108046I-4 FCC PART 15B OTG Playing
