2ADQM-KMC10Media Center

23 SOURCE FAVORITES MENU FRONT OUTPUTS REAR OUTPUTS POWER AND AUDIO OUTPUTS INPUTS 1 2 3 4 5 OVERVIEW: 1 - Auxiliary Input 2 - KRC15 Remote Port (5-PIN) 3 - USB Input (Audio Only) 4 - PXIRCX Remote Port 5 - Antenna Input WIRING COLOR CODES INSTALLATION OVERVIEW Black = Ground Red = Accessory 12V (Switched) Orange = Illumination (100mA Max) Blue/White = Amplifier Turn-On White = Left Front (+) White/Black = Left Front (-) Gray = Right Front (+) Gray/Black = Right Front (-) Green = Left Rear (+) Green/Black = Left Rear (-) Purple = Right Rear (+) Purple/Black = Right Rear (-) HOW TO NAVIGATE THE KMC10 The button layout below will give you a quick overview of the button functionality and how to use them. The Warning display will last approximately 25 seconds. SOURCE FAVORITES MENU DISPLAY 4 5 6 7 1 2 3 8 BUTTONS: 1 - Source 2 - Favorites 3 - Menu 4 - Back 5 - Seek/Tune Down 6 - Play/Pause 7 - Seek/Tune Up 8 - Volume Knob Function: How To: Power On Press the Source (1) button once. Power Off Hold the Source (1) button for 2 seconds. Volume Up Turn the knob (8) clockwise. Volume Down Turn the knob (8) counter-clockwise. Seek Up Press Seek Up (7) once. Seek Down Press Seek Down (5) once. Tune Up Hold down Seek Up (7). Tune Down Hold down Seek Down (5) Enter/Select Press the Knob (8) inward once. Pause/Play Press Play/Pause (6) once. Mute Press Play/Pause (6) once. Back Press Back (4) once. Note: The MUTE option is only available on the following sources: AM - FM - WX - AUX 12-PIN CONNECTOR The White 12-Pin connector on the KMC10 harness is a universal connector. If the connector is not suited for your installation type, we recommend using the supplied wiring harness pigtail. Part Number: 1-4807008-0 The KMC10 Main Menu Settings are for the overall display and performance of the media center. The KMC10 offers many features that are adjustable. To enter the Main Menu Structure: Hold the MENU (3) button for 2 seconds. To change any of the settings, simply rotate the knob to highlight the item, then press the knob to select the item. Day/Night: The Day/Night feature allows you to change the theme from Day Mode to Night Mode. The unit is defaulted to Auto. In order for the unit to automatically switch between day and night modes, the orange illumination wire must be connected. Illumination: The Illumination feature allows you turn ON or OFF the blue LED border around the screen. Dimmer: The Dimmer allows you to adjust the brightness of the screen, buttons, and LED border. The unit is defaulted to +10. Background: The Background feature allows you to choose form 4 different wallpapers for your screen, day and night mode included. Low Battery: The Low Battery feature allows you the option to turn ON and OFF the Low Battery Alert. If the unit drops below 10.5V, the unit will display a visual alert and audible alert warning that your batteries need charge. Aux 1: Allows you to rename the AUX1 source. With a selection from 5 different names with icons. Tuner: Allows you to change the region for Tuner Mode. Your available options: N. America - Latin America - Europe - Russia - Australia - Middle East - Asia - Japan AM Source: The AM source allows you to SEEK and TUNE through the stations. WX Source: The Weather Band source allows you to SEEK and TUNE through the weather band stations. USB1: The USB1 source will automatically detect the connected device. The USB1 source will read iPod, MP3/WMA files. Does not support video files. NOTE: The USB Source will display the Album Art if present. On screen while in USB mode you are able to view the: ARTIST - SONG TITTLE - ALBUM - TRACK - TIME - ALBUM ART On screen while in iPod mode you are able to view the: ARTIST - SONG TITTLE - ALBUM - TRACK - TIME - ALBUM ART AUX 1: The AUX1 Source allows for any connection via the Audio Left & Right RCA Input. (See Installation Overview items number 1). Bluetooth Source: The Bluetooth Source is only for Music (A2DP) Streaming. Bluetooth Device Name: “Media Center” There is no password required. This unit does not offer the Hands-Free profile. SOURCES CONTINUED Function: How To: Seek Up Press the Seek Up (7) button once. Seek Down Press the Seek Down (5) button once. Tune Up Hold the Tune Up (7) button for 2 seconds. Then press (7) once. Tune Down Hold the Tune Down (5) button for 2 seconds. Then press (5) once. Function: How To: Seek Up Press the Seek Up (7) button once. Seek Down Press the Seek Down (5) button once. Tune Up Hold the Tune Up (7) button for 2 seconds. Then press (7) once. Tune Down Hold the Tune Down (5) button for 2 seconds. Then press (5) once. 5 KMC10 MAIN MENU Auto Day Night Dimmer +10 To change any of the sources: Press the button on the KMC10. Available Sources: FM Source: The FM source allows you to SEEK and TUNE through the stations. SOURCES Function: How To: Seek Up Press the Seek Up (7) button once. Seek Down Press the Seek Down (5) button once. Tune Up Hold the Tune Up (7) button for 2 seconds. Then press (7) once. Tune Down Hold the Tune Down (5) button for 2 seconds. Then press (5) once. SOURCE FAVORITES MENU DISPLAY 4 5 6 7 1 2 3 8 Function: How To: Seek Up Press the Seek Up (7) button once. Seek Down Press the Seek Down (5) button once. Tune Up Hold the Tune Up (7) button for 2 seconds. Then press (7) once. Tune Down Hold the Tune Down (5) button for 2 seconds. Then press (5) once. Function: How To: Seek Up Press the Seek Up (7) button once. Seek Down Press the Seek Down (5) button once. Tune Up Hold the Tune Up (7) button for 2 seconds. Then press (7) once. Tune Down Hold the Tune Down (5) button for 2 seconds. Then press (5) once. Function: How To: Seek Up Press the Seek Up (7) button once. Seek Down Press the Seek Down (5) button once. Tune Up Hold the Tune Up (7) button for 2 seconds. Then press (7) once. Tune Down Hold the Tune Down (5) button for 2 seconds. Then press (5) once. 4 Pressing the Menu button while in the following sources will bring up Source Specific Menu items: WX - USB1 - …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 CPS Distributors, Inc 6024 Parretta Drive Kansas City, MO 64120, USA 2015-1-23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, CPS Distributors, Inc hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2ADQM-KMC10 Model: KMC10 Product name: Media Center Sincerely, signature : name / title: Brandon Lang / NSM address: 6024 Parretta Drive Kansas City, MO 64120, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 CPS Distributors, Inc 6024 Parretta Drive Kansas City, MO 64120, USA 2015-1-23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADQM-KMC10 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Brandon Lang / NSM address: 6024 Parretta Drive Kansas City, MO 64120, USA

Label location

Antenna location

FCC ID: 2ADQM-KMC10 Keyway Testing Technology Co., Ltd. Report No. 15KWE012358R Page 1 of 23 FCC TEST REPORT for CPS Distributors, Inc Media Center Model Number: KMC10 FCC ID: 2ADQM-KMC10 Prepared for : CPS Distributors, Inc Address : 6024 Parretta Drive Kansas City, MO 64120, USA Prepared by : Keyway Testing Technology Co., Ltd. Address : Building 1, Baishun Industrial Zone, Zhangmotou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE012358R Date of Test : Jan. 16~21, 2015 Date of Report : Jan. 22, 2015 FCC ID: 2ADQM-KMC10 Keyway Testing Technology Co., Ltd. Report No. 15KWE012358R Page 2 of 23 TABLE OF CONTENTS Declaration Page 1. TEST SUMMARY........................................................................................................................4 2. GENERAL PRODUCT INFORMATION.......................................................................................4 2.1. Product Function..................................................................................................................4 2.2. Description of Device (EUT).................................................................................................4 2.3. Difference between Model Numbers....................................................................................4 2.4. Independent Operation Modes.............................................................................................4 2.5. Test Supporting System.......................................................................................................4 3. TEST SITES................................................................................................................................5 3.1. Test Facilities.......................................................................................................................5 3.2. List of Test and Measurement Instruments..........................................................................6 4. TEST SET-UP AND OPERATION MODES.................................................................................7 4.1. Principle of Configuration Selection......................................................................................7 4.2. Block Diagram of Test Set-up..............................................................................................7 4.3. Test Operation Mode and Test Software..............................................................................7 4.4. Special Accessories and Auxiliary Equipment......................................................................7 4.5. Countermeasures to Achieve EMC Compliance...................................................................7 5. EMISSION TEST RESULTS........................................................................................................8 5.1. Radiated Emission Test.......................................................................................................8 6. 20DB OCCUPY BANDWIDTH...................................................................................................14 6.1. Limits.................................................................................................................................14 6.2. Test setup..........................................................................................................................14 7. BAND EDGE COMPLIANCE TEST...........................................................................................17 7.1. Limits.................................................................................................................................17 7.2. Test setup..........................................................................................................................17 8. ANTENNA REQUIREMENTS....................................................................................................18 8.1. Limits.................................................................................................................................18 8.2. Result.................................................................................................................................18 9. PHOTOGRAPHS OF TEST SET-UP.........................................................................................19 10. PHOTOGRAPHS OF THE EUT.............................................................................................20 FCC ID: 2ADQM-KMC10 Keyway Testing Technology Co., Ltd. Report No. 15KWE012358R Page 3 of 23 Keyway Testing Technology Co., Ltd. Applicant: Address: CPS Distributors, Inc 6024 Parretta Drive Kansas City, MO 64120, USA Manufacturer: Address: EVERVICTORY ELECTRONIC COMPANY LIMITED Chu Chi Management District, Hu Men Town, Dong-Guan City, Guang-Dong Province, P.R.China E.U.T: Media Center Model Number: KMC10 Trade Name: ------ Serial No.: ------ Date of Receipt: Jan. 15, 2015 Date of Test: Jan. 16~21, 2015 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2014 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jan. 22, 2014 Tested by: Reviewed by: Approved by: Jack Bu / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2ADQM-KMC10 Keyway Testing Technology Co., Ltd. Report No. 15KWE012358R Page 4 of 23 1. TEST SUMMARY Test Items Test Requirement Result Conducted Emissions 15.207 N/A Radiated Emissions 15.209 15.249(a)(d) PASS 20dB Bandwidth 15.249 PASS Emissions from out of band 15.249(d) PASS Antenna Requirement 15.203 PASS Remark: N/A means not application. 2. GENERAL PRODUCT INFORMATION 2.1…
