I853W User manual I. Introduction Congratulations on the purchase of the Tablet ! This device is built-in high performance Wifi receiver module, G-sensor, also can bring you into the portable media Tablet world and fulfilled your entertainment needs. It can support picture, video, music, E-book, games, online chat and other functions, moreover, various settings will fully show your individuality. This manual contains important safety and operating information in order to prevent accidents, please read this manual thoroughly and keep it for future reference. II. Safety precautions  To use this Tablet safely, please read and follow the instructions in this manual carefully before use.  Never use the Tablet while driving or when operating any vehicle, as this could cause an accident. It is also against the law in many areas. Take care when using the Tablet outdoors, especially when crossing the street.  Do not listen to music at very high volumes using the earphones as this can permanently damage your hearing.  Keep the Tablet clean and never store it next to a heat source or in dirty, humid or wet places. Keep it out of direct sunlight.  Do not put the Tablet in high temperature places (over 40 º C), especially not in a car with the windows closed in summer.  Keep the Tablet away from strong magnetic fields.  Please don’t turn on the device in where the wireless equipment is forbidden or when the usage of the device will cause interference and danger.  Press the Tablet’s buttons gently. Pressing them or the screen too hard can damage the Tablet.  Do not use the Tablet in an electronics-prohibited area, such as in an airplane.  Do not use the Tablet in an extremely dry environment, as this can lead to static discharge, which can damage the Tablet.  Do not subject the product to harsh impacts.  Do not drop the appliance. This may result in damage to the product.  Do not attempt to dismantle or repair this unit yourself, Repairs should only be performed by qualified personnel only.  We will not be responsible for any memory loss caused by product damage, repairs or other reasons.  Disconnect the appliance from the power source when cleaning.  In order to prevent program failure, never disconnect the Tablet suddenly from a PC during downloading, uploading or formatting to prevent program failure.  Use a slightly damp, lint-free cloth to clean this appliance. Do not dismantle the Tablet or use alcohol, thinner or benzene to clean the surface of the Tablet . .III About device 1. Headphone jack； 2. USB port; 3 HDMI port; 4. Frone Camera; 5. Rear Camera; 6. Power key; 7. Volume +/- key; 8. TF/microSD card slot ; 9. MIC; IV. Introduction to Desktop 1. Windows 8.1 start image: On the start screen, you can see many programs fixed in the image. These application programs are displayed in the form of “magnet”. As long as you click them, you can easily visit them. You need to log on your Microsoft account before the application program completely runs. 2. Image slide applications Slide to right Slide to left Slide to the right from the left side Slide to the left from the right side of the of the screen to start the application screen to start Charm menu column. program in running. Reduce Enlarge On the touch screen, narrow two fingers On the touch screen, widen two fingers to reduce the image. to enlarge the image. Slide downward Slide with finger In start screen, slide from the top of the screen In start screen, slide finger right and left to view all application programs to move the image. Slide upward In the start screen, slide upward from the bottom of the screen to visit all application program (APPS) interfaces. 3． Introduction to app Interface Besides the application programs already fixed on the start screen, you can also start other application programs in all application programs, such as other software application programs attached to the Tablet PC. If you want to fix more application programs on the start interface, see the operation in the figure below, (1) lightly touch, press and hold the application program magnet for about one second and then let go, and select (2) to fix to the start screen. Conversely, if you want to cancel or delete a certain application in the start screen, (1) lightly touch, press and hold the application program magnet for about one second and then let it go and run, and select (2) attribute column to cancel the programs such as fixation and deletion and then it can be completed. 4.Charm menu column Slide it to the left from the right side of the screen to start Charm menu column, including: Start, Device, Setup, Share, and Search Program. Slide it to the left from the right side of the screen to start Charm menu column, including: Start, Device, Setup, Share, and Search Program. Can let you search the files and application programs in the Tablet PC. Can let you share the program through social exchange website or e-mail. Can return to the start screen. From the start screen, you can also use this function to return the application program that is opened in the latest. Can let you read, write and share files, connect external screen or printer with the device Can let you set up the Table PC. Search menu Share Menu Device Menu Set up Menu 5． Dual-Screen Application On my computer in (Figure 1), slide it inward from the left side of the screen, drag it and hold. Let go when seeing double interfaces appear. In (Figure 2), press the partition button on the middle partition line and drag right and left to partition the display proportion of the double screens. (Figure 1) (Figure 2) V. Basic Operations 1. Dormancy, restart and power off 2. Security Management User and password setup Method for quick setup: Click the “Setup” button in “Charm” setup, and select “Change computer setup”. Select “User” on the left and click “Create local account” in “Your account” on the right side. After inputting the password of Complete Windows Live Id Account, input use…

Text truncated - open the document above for the full version.

Yuko Technology Co., Ltd. 6th Floor, A9 building, TianRui Industrial Park, FuYuan 1st Road, FuYong,Bao'an,ShenZhen DATE :2014-12-05 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank.Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Yuko Technology Co., Ltd. and 6th Floor, A9 building, TianRui Industrial Park, FuYuan 1st Road, FuYong,Bao'an,ShenZhen Dated this / Day of 12/05/2014 / Agency agreement expiration date: 12/05/2015 By: Sunny Wong Si gnature Printed Title: Sales Director On behalf of : Yuko Technology Co., Ltd. Telephone: 33985818

Differences Declaration To whom concern, We company Yuko Technology Co., Ltd. hereby declares: The product model(s) I695,I890, I971, I102A, I106, I701, I856, I103, I790 Is identical in the same PCB layout, interior structure and electrical circuits with the model I853W which tested in Global Unit Technology Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Date: 2014-12-05

Date: 12/05/2012 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2ADQN-I853W To Whom It May Concern: We, Yuko Technology Co., Ltd. are applying FCC DOC for product Tablet PC which model no. is I853W, I695,I890, I971, I102A, I106, I701, I856, I103, I790. the FCC DOC is doing at proper FCC authorized and recognized lab, and FCC DOC will be issued soon. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature Client’s name / title Sunny Wong / Sales Director Contact information / address Tel: 33985818 Address: 6th Floor, A9 building, TianRui Industrial Park, FuYuan 1st Road, FuYong,Bao'an,ShenZhen

Yuko Technology Co., Ltd. 6th Floor, A9 building, TianRui Industrial Park, FuYuan 1st Road, FuYong,Bao'an,ShenZhen 2014-12-05 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADQN-I853W Product Name: Tablet PC Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 12/05/2014 By: Sunny Wong Signature Printed Title: Sales Director On behalf of : Yuko Technology Co., Ltd. Telephone: 33985818

I853W

FCC ID: 2ADQN-I853W According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 97.29m @3m Ant gain =2Bi, so Ant numeric gain= 1.58 So pt={ [10 (97.29 x 3] 2 /30x1.58 }x1000 mW = 1.014mW So (1.014 mW /5mm)x √2.48 = 0.319<3 Then SAR evaluation is not required
