2ADTD-KH6320WTPE2Indoor Station

DS-KH6320-WTPE2 Video Intercom Two-Wire Indoor Station Diagram References ENGLISH UD17636B 12 3 2 1 345 6 7 Appearance Installation Before you begin: Wall Mounting with Junction Box Activate Indoor Station 1 3 Getting Started 4 Wiring 2 Display Screen Microphone Debugging Port 123 4 567 1. Make sure the device in the package is in good condition and all the assembly parts are included. 2. The power supply the indoor station supports is 24 VDC. Please make sure your power supply matches your indoor station. 3. Make sure all the related equipment is power-off during the installation. 4. Check the product specification for the installation environment. 5. Here takes wall mounitng with junction box for example. 1. Chisel a hole in the wall. The size of the hole should be 76 mm (width) × 76 mm (length) × 50 mm (depth). 2. Insert the junction box to the hole chiseled on the wall. 3. Fix the wall mounting plate to the junction box with 2 screws. 4. Hook the indoor station to the wall mounting plate tightly by inserting the plate hooks into the slots on the rear panel of the indoor station, during which the lock catch will be locked automatically. 1. Choose Language and tap Next. 2. Set network parameters and tap Next - Edit Local IP, Subnet Mask and Gateway parameters. - Enable DHCP, the device will get network parameters automatically. 3. Configure the indoor station and tap Next. a. Select Indoor Station Type. b. Edit Floor and Room No. 4. Linked related devices and tap Next. If the device and the indoor station are in the same LAN, the device will be displayed in the list. Tap the device or enter the serial No. to link. a. Tap the door station in the list to link. b. Tap the settings icon to pop up the Network Settings page. c. Edit the network parameters of the door station manually or enable DHCP to get the network parameters automatically. d. Optional: Enable Synchronize Language to synchronize the Language of door station with indoor station. e. Tap OK to save the settings. 5. Tap Finish to save the settings. 1. Power on the device. It will enter the activation page automatically. 2. Create a password and confirm it. 3. Tap OK to activate the indoor station. Note: We highly recommend you to create a strong password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product. Loudspeaker Two-Wire Interface Alarm Terminal Power Supply Interface Note: The debugging port is used for debugging only. The wall mounting plate and the junction box are required to install the indoor station onto the wall. The dimension of junction box should be 75 mm (width) × 75 mm (length) × 50 mm (depth). The dimension of wall mounting plate is shown. Refer to Video Intercom Indoor Station Configuration Guide (scan the QR code) for details. Refer to Video Intercom Indoor Station Operation Guide (scan the QR code) for details. You are required to activate the device first by setting a strong password for it before you can use the device. 1 Quick Configuration 2 Wall Mounting without Junction Box 1. Insert 2 expension tubes into the wall. 2. Fix the wall mounting plate to the wall with 2 screws. 3. Hook the indoor station to the wall mounting plate tightly by inserting the plate hooks into the slots on the rear panel of the indoor station, during which the lock catch will be locked automatically. Product Information ©2019 Hangzhou Hikvision Digital Technology Co., Ltd. It includes instructions on how to use the Product. The software embodied in the Product is governed by the user license agreement covering that Product. About this Manual This Manual is subject to domestic and international copyright protection. Hangzhou Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Trademarks and other Hikvision marks are the property of Hikvision and are registered trademarks or the subject of applications for the same by Hikvision and/or its affiliates. Other trademarks mentioned in this manual are the properties of their respective owners. No right of license is given to use such trademarks without express permission. Legal Disclaimer TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE P…

Text truncated - open the document above for the full version.

Hangzhou Hikvision Digital Technology Co., Ltd. Date: 2020-03-30 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2ADTD-KH6320WTPE2 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Hangzhou Hikvision Digital Technology Co., Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Xiuying Zhang Title: Senior Certification engineer Signature: On behalf of Company: Hangzhou Hikvision Digital Technology Co., Ltd. Telephone: +86-0571-88075998-62460

Hangzhou Hikvision Digital Technology Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Hangzhou Hikvision Digital Technology Co., Ltd. No. 555 Qianmo Road, Binjiang District, angzhou 310052, China Regarding: Confidentiality Request regarding application for FCC ID: 2ADTD-KH6320WTPE2 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Xiuying Zhang Title: Senior Certification engineer Company Name: Hangzhou Hikvision Digital Technology Co., Ltd.

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 1 of 3 Page 1 of 3 External Photos Applicant: Hangzhou Hikvision Digital Technology Co., Ltd. Address of Applicant: No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China Equipment Under Test (EUT): Product Name: Indoor Station Model No.: DS-KH6320-WTPE2 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 2 of 3 Page 2 of 3 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 3 of 3 Page 3 of 3 End

Label location

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 1 of 7 Page 1 of 7 Internal Photos Applicant: Hangzhou Hikvision Digital Technology Co., Ltd. Address of Applicant: No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China Equipment Under Test (EUT): Product Name: Indoor Station Model No.: DS-KH6320-WTPE2 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 2 of 7 Page 2 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 3 of 7 Page 3 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 4 of 7 Page 4 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 5 of 7 Page 5 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 6 of 7 Page 6 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 7 of 7 Page 7 of 7 End

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200300169602 Page: 1 of 8 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. 1 Cover Page RF Exposure Evaluation Report Application No.: SHEM2003001696CR FCC ID: 2ADTD-KH6320WTPE2 Applicant: Hangzhou Hikvision Digital Technology Co., Ltd. Address of Applicant: No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China Manufacturer: Hangzhou Hikvision Digital Technology Co., Ltd. Address of Manufacturer: No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China Factory: 1, Hangzhou Hikvision Technology Co., Ltd. 2, Hangzhou Hikvision Electronics Co., Ltd. 3, Hangzhou Hikvision Digital Technology Co., Ltd. Address of Factory: 1, No.700, Dongliu Road, Binjiang District, Hangzhou City, Zhejiang, 310052, China 2, No.299, Qiushi Road, Tonglu Economic Development Zone, Tonglu County, Hangzhou, Zhejiang, 310052, China. 3, No. 555 Qianmo Road, Binjiang District, Hangzhou 310052, China Equipment Under Test (EUT): EUT Name: Indoor Station Model No.: DS-KH6320-WTPE2 Add Model No.: DS-KH6320-WTPE2UHK,DS-KH6320-WTPE2CKV,DS-KH6320- WTPE2UVS,DS-KH6320-WTPE2KVO,DS-KH6320-WTPE2HUN,DS- KDXXXXXXXXXXX (X=0-9 /or A-Z or / or -or * or blank space) Trade mark: HIKVISION Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2020-03-19 Date of Test: 2020-03-19 to 2020-03-25 Date of Issue: 2020-03-27 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200300169602 Page: 2 of 8 Revision Record Version Description Date Remark 00 Original 2020-03-27 / Authorized for issue by: Micheal Niu /Project Engineer Parlam Zhan /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200300169602 Page: 3 of 8 2 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 CONTENTS .............................................................................................................................................. 3 3 GENERAL INFORMATION ..................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ............................................................................................................ 4 3.2 TECHNICAL SPECIFICATIONS ..................................................................................................................... 4 3.3 TEST LOCATION ....................................................................................................................................... 5 3.4 TEST FACILITY......................................................................................................................................... 5 4 TEST STANDARDS AND LIMITS .......................................................................................................... 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: .............................................................................. 6 5 MEASUREMENT AND CALCULATION ................................................................................................ 7 5.1 MAXIMUM TRANSMIT POWER .................................................................................................................... 7 5.2 MPE CALCULATION ................................................................................................................................. 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200300169602 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Power supply: DC 24V by adapter Test voltage: AC 120V/60Hz 3.2 Technical Specifications 2.4G WiFi Antenna Gain 2.61 dBi Antenna Type FPC Antenna Channel Spacing 5MHz Modulation Type 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels 802.11b/g/n(HT20):11 802.11n(HT40):7 Operation Frequency 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200300169602 Page: 5 of 8 3.3 Test Location All tests were performed at: All measurement facilities used to collect the measurement data are located at No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC –Designation Number: CN1172 Compliance Certification Services Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. Test Firm Registration Number: 995260. • Industry Canada (IC) – IC…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM200300169601 1. Duty Cycle 1.1 Test Result Test Mode Channel Frequency( MHz) TX Type ANT No. T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) 802.11b 2412 SISO 1 12.420 12.580 98.73 0.06 2437 SISO 1 12.420 12.550 98.96 0.05 2462 SISO 1 12.410 12.560 98.81 0.05 802.11g 2412 SISO 1 2.064 2.181 94.64 0.24 2437 SISO 1 2.063 2.217 93.05 0.31 2462 SISO 1 2.063 2.226 92.68 0.33 802.11n(HT20) 2412 SISO 1 1.920 2.090 91.87 0.37 2437 SISO 1 1.890 2.058 91.84 0.37 2462 SISO 1 1.890 2.058 91.84 0.37 802.11n(HT40) 2422 SISO 1 0.916 1.081 84.74 0.72 2437 SISO 1 0.917 1.082 84.75 0.72 2452 SISO 1 0.916 1.022 89.63 0.48 1.2 Test Graph 802.11b_2412MHz_SISO_ANT1 802.11b_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11b_2462MHz_SISO_ANT1 802.11g_2412MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11g_2437MHz_SISO_ANT1 802.11g_2462MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2412MHz_SISO_ANT1 802.11n(HT20)_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2462MHz_SISO_ANT1 802.11n(HT40)_2422MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT40)_2437MHz_SISO_ANT1 802.11n(HT40)_2452MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 2. Bandwidth 2.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 6dB Bandwidth Verdict Test Result (MHz) Limits (MHz) 802.11b 2412 SISO 1 10.092 ≥0.5 PASS 2437 SISO 1 10.063 ≥0.5 PASS 2462 SISO 1 10.056 ≥0.5 PASS 802.11g 2412 SISO 1 16.376 ≥0.5 PASS 2437 SISO 1 16.389 ≥0.5 PASS 2462 SISO 1 16.360 ≥0.5 PASS 802.11n(HT20) 2412 SISO 1 17.581 ≥0.5 PASS 2437 SISO 1 17.594 ≥0.5 PASS 2462 SISO 1 17.569 ≥0.5 PASS 802.11n(HT40) 2422 SISO 1 35.160 ≥0.5 PASS 2437 SISO 1 35.248 ≥0.5 PASS 2452 SISO 1 35.121 ≥0.5 PASS Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) 802.11b 2412 SISO 1 15.041 Only for Report Use 2437 SISO 1 15.170 Only for Report Use 2462 SISO 1 15.340 Only for Report Use 802.11g 2412 SISO 1 16.956 Only for Report Use 2437 SISO 1 16.924 Only for Report Use SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 2462 SISO 1 16.987 Only for Report Use 802.11n(HT20) 2412 SISO 1 17.977 Only for Report Use 2437 SISO 1 18.035 Only for Report Use 2462 SISO 1 18.068 Only for Report Use 802.11n(HT40) 2422 SISO 1 36.221 Only for Report Use 2437 SISO 1 36.310 Only for Report Use 2452 SISO 1 36.332 Only for Report Use 2.2 Test Graph - 6dB Bandwidth 802.11b_2412MHz_SISO_ANT1 802.11b_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11b_2462MHz_SISO_ANT1 802.11g_2412MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11g_2437MHz_SISO_ANT1 802.11g_2462MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2412MHz_SISO_ANT1 802.11n(HT20)_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2462MHz_SISO_ANT1 802.11n(HT40)_2422MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT40)_2437MHz_SISO_ANT1 802.11n(HT40)_2452MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 2.3 Test Graph - 99% Occupied Bandwidth 802.11b_2412MHz_SISO_ANT1 802.11b_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11b_2462MHz_SISO_ANT1 802.11g_2412MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11g_2437MHz_SISO_ANT1 802.11g_2462MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2412MHz_SISO_ANT1 802.11n(HT20)_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2462MHz_SISO_ANT1 802.11n(HT40)_2422MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT40)_2437MHz_SISO_ANT1 802.11n(HT40)_2452MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 3. Maximum Conducted Output Power 3.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict Ant 1 802.11b 2412 SISO 12.78 30 PASS 2437 SISO 14.09 30 PASS 2462 SISO 14.34 30 PASS 802.11g 2412 SISO 15.10 30 PASS 2437 SISO 15.55 30 PASS 2462 SISO 15.85 30 PASS 802.11n(HT20) 2412 SISO 15.13 30 PASS 2437 SISO 15.52 30 PASS 2462 SISO 15.87 30 PASS 802.11n(HT40) 2422 SISO 16.56 30 PASS 2437 SISO 16.83 30 PASS 2452 SISO 17.05 30 PASS 3.2 Test Graph 802.11b_2412MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11b_2437MHz_SISO_ANT1 802.11b_2462MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11g_2412MHz_SISO_ANT1 802.11g_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11g_2462MHz_SISO_ANT1 802.11n(HT20)_2412MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT20)_2437MHz_SISO_ANT1 802.11n(HT20)_2462MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT40)_2422MHz_SISO_ANT1 802.11n(HT40)_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11n(HT40)_2452MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 4. Maximum Power Spectral Density (PSD) 4.1 Test Result Test Mode Frequency (MHz) Tx Type Maximum Power Spectral Density (dBm/3KHz) Limits (dBm/3kHz) Verdict Ant 1 802.11b 2412 SISO -11.67 ≤8 PASS 2437 SISO -11.06 ≤8 PASS 2462 SISO -10.54 ≤8 PASS 802.11g 2412 SISO -17.91 ≤8 PASS 2437 SISO -17.21 ≤8 PASS 2462 SISO -16.43 ≤8 PASS 802.11n(HT20) 2412 SISO -17.36 ≤8 PASS 2437 SISO -18.33 ≤8 PASS 2462 SISO -15.10 ≤8 PASS 802.11n(HT40) 2422 SISO -18.56 ≤8 PASS 2437 SISO -19.09 ≤8 PASS 2452 SISO -18.40 ≤8 PASS 4.2 Test Graph 802.11b_2412MHz_SISO_ANT1 802.11b_2437MHz_SISO_ANT1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 802.11b_2462MHz_SISO_ANT1 802.11g_2412MH…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 1 of 4 Page 1 of 4 Test Setup Photos-FCC Applicant: Hangzhou Hikvision Digital Technology Co., Ltd. Address of Applicant: No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China Equipment Under Test (EUT): Product Name: Indoor Station Model No.: DS-KH6320-WTPE2 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS............................................................................................................... 2 2 EQUIPMENT UNDER TEST PICTURES ............................................................ 3 2.1 RF Conducted Test Setup ................................................................................. 3 2.2 Radiated Emission Test Setup .......................................................................... 3 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 3 of 4 Page 3 of 4 2 EQUIPMENT UNDER TEST PICTURES 2.1 RF Conducted Test Setup 2.2 Radiated Emission Test Setup 30MHz to 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 4 of 4 Page 4 of 4 Above 1GHz - End -
