2ADXC-QBZ339RXHDMI Wireless Extender

Shenzhen Lenkeng Technology Co., Ltd

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Jan 22, 2026
Application Purpose: Original Equipment
Equipment Note: HDMI Wireless Extender
Frequency Range: 5180.00000000 - 5240.00000000
Company: Shenzhen Lenkeng Technology Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

ReferenceNo.:WTH25X11315634W001Page1of41 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT1-PRODUCTLABELING ProposedFCCIDLabelFormat FCCID:2ADXC-QBZ339RX Thisdevicecomplieswithpart15oftheFCCRules. Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived, includinginterferencethatmaycauseundesiredoperation. Specifications:Thelabelshallbesecurelyaffixedtoapermanentlyattachedpartofthedevice,inalocation whereitisvisibleoreasilyaccessibletotheuser,andshallnotbereadilydetachable.Thelabelshallbe sufficientlydurabletoremainfullylegibleandintactonthedeviceinallnormalconditionsofusethroughout thedevice’sexpectedlifetime. ProposedLabelLocationonEUT FCCIDLabel Location

Cover Letter(s)

1.RFExposureRequirements 1.1GeneralInformation ClientInformation Applicant:ShenzhenLenkengTechnologyCo.,Ltd Addressofapplicant: West4F,JinguangxiaCulture&TechPark,3GuangxiaRoad, Shenzhen,China Manufacturer:ShenzhenLenkengTechnologyCo.,Ltd Addressofmanufacturer: West4F,JinguangxiaCulture&TechPark,3GuangxiaRoad, Shenzhen,China GeneralDescriptionofEUT: ProductName:HDMIWirelessExtender TradeName:/ ModelNo.:LKV699E-KVM-RX AddingModel(s): LKV677E-KVM-RX,LKV655E-KVM-RX,LKV699E-RX, LKV677E-RX,LKV655E-RX RatedVoltage:DC5V BatteryCapacity:/ PowerAdapter1#: S012-1D050200VU-V Input:AC100-240V50/60Hz0.3AOutput:DC5V2.0A PowerAdapter2#: S005-1B050100VU Input:AC100-240V50/60Hz0.2AOutput:DC5V1.0A FCCID:2ADXC-QBZ339RX EquipmentType:Mobiledevice TechnicalCharacteristicsofEUT: Wi-Fi5G SupportStandards: 802.11a,802.11n-HT20,802.11n-HT40,802.11ac-VHT20, 802.11ac-VHT40,802.11ac-VHT80 FrequencyRange:5180-5240MHz Max.RFOutputPower: Antenna1:14.69dBm(Conducted) Antenna2:16.02dBm(Conducted) TypeofModulation:QPSK,16QAM,64QAM,256QAM TypeofAntenna:ExternalAntenna AntennaGain:5.93dBi 1.2RFExposureExemption Accordingto§1.1307(b)(3)andKDB447498D04InterimGeneralRFExposureGuidancev01,system operatingundertheprovisionsofthissectionshallbeoperatinginamannerthatthepublicisnotexposedto radiofrequencyenergylevelinexcesslimitformaximumpermissibleexposure. OptionA:FCCRulePart1.1307(b)(3)(i)(A):Theavailablemaximumtime-averagedpowerisnomorethan 1mW,regardlessofseparationdistance. OptionB:FCCRulePart1.1307(b)(3)(i)(B):Theavailablemaximumtime-averagedpoweroreffective radiatedpower(ERP),whicheverisgreater,islessthanorequaltothethresholdP th (mW)describedinthe followingformula.P th isgivenby: OptionC:FCCRulePart1.1307(b)(3)(i)(C):Theminimumseparationdistance(Rinmeters)fromthebodyof anearbypersonforthefrequency(finMHz)atwhichthesourceoperates,theERP(watts)isnomorethanthe calculatedvalueprescribedforthatfrequency.Rmustbeatleastλ/2π,whereλisthefree-spaceoperating wavelengthinmeters. SingleRFSourcesSubjecttoRoutineEnvironmentalEvaluation RFSourcefrequency(MHz)ThresholdERP(watts) 0.3-1.341,920R 2 1.34-303,450R 2 /f 2 30-3003.83R 2 300-1,5000.0128R 2 f 1,500-100,00019.2R 2 ForMultipleRFsources:FCCRulePart1.1307(b)(3)(ii): (A)Theavailablemaximumtime-averagedpowerofeachsourceisnomorethan1mWandthereisa separationdistanceoftwocentimetersbetweenanyportionofaradiatingstructureoperatingandthe nearestportionofanyotherradiatingstructureinthesamedevice,exceptifthesumofmultiplesourcesis lessthan1mWduringthetime-averagingperiod,inwhichcasetheymaybetreatedasasinglesource (separationisnotrequired). (B)InthecaseoffixedRFsourcesoperatinginthesametime-averagingperiod,orofmultiplemobileor portableRFsourceswithinadeviceoperatinginthesametimeaveragingperiod,ifthesumofthe fractionalcontributionstotheapplicablethresholdsislessthanorequalto1asindicatedinthefollowing equation. 1.3CalculatedResult Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-AveragedPower ERP (MHz)(dBm)(dBi)(%)(dBm)(dBm) Wi-Fi5G ANT1 518014.695.9310015.0018.78 Wi-Fi5G ANT2 518016.025.9310017.0020.78 Frequency Option Min.DistanceMax.PowerExposureLimit Ratio Result (MHz)(cm)(dBm)(mW)(mW)Pass/Fail 5180C20.0018.7875.51768.000.10Pass 5180C20.0020.78119.67768.000.16Pass Note:1.Time-AveragedPower=OutputPower*DutyCycle;ERP=Time-AveragedPower+Antenna gain-2.15dB 2.OptionA,BandCrefersasclause1.2. 3.ForoptionB,Max(time-averagedpower,effectiveradiatedpower(ERP))convertstoMax.Power.For optionC,ERPconvertstoMax.Power; 4.ForoptionB,P th (mW)convertstoExposureLimit(mW);ForoptionC,ERP(W)convertstoExposure Limit(mW). 5.Ratio=Tune-UpERP(mW)/ExposureLimit(mW) ModeforSimultaneousMulti-bandTransmission: RadioAccess Technology Ratio1Ratio2 Simultaneous Ratio Limit Result Pass/Fail ANT1+ANT20.100.160.261.0Pass Result:Pass

Cover Letter(s)

ShenZhen HuaDeChang Technology Co.,Ltd Specification Customer Shenzhen Lenkeng Technology Co.,Ltd P/N Specs Ф13 5G SMA（M） Antenna Black ModelH268-10001 Date2023/6/8 Customer R&DENGINEERINGAPPROVED Manufacturer APPROVEDCHECKEDMAKED SongDaniel P/N:H268-10001-BREV.:X1Date:6/23/2023 A4401,A4201A,Building16,Workshop,JunfengIndustrialPark,ChongqingRoad,Heping Community,FuhaiStreet,Bao'anDistrict,Shenzhen Contents ItemPagination 1.Cover1 2.Contents2 3.Productspecification3 4.ProductDrawing4 5.VNATestPattern5 6.MicrowaveUnreflectedChamberTestReport6 7.AntennaParameterSpecification7 8.MaterialsRoHSSheet8 9.MaterialsRoHSReportAttachment P/N:H268-10001-BREV.:X1Date:6/23/2023 A4401,A4201A,Building16,Workshop,JunfengIndustrialPark,ChongqingRoad,Heping Community,FuhaiStreet,Bao'anDistrict,Shenzhen Productspecification ●ElectricalPerformance: 1.FrepuencyRange:5.15GHz~5.825GHz 2.Lmpedance:50Ohmsnominal 3.VSWR :≦1.92 4.Admittedpowerradlation:1W 5.RadationofRadlation:Toroidal 6.Radiation:Omni 7.Polarization:Vertical 8.ConnctorType:SMAP/R ●Mechanicalproperties: 1.Cable:RG-178,50Ohm 2.Operationtemperaturerange:-2 0°C ~+70 °C 3.Storagetemperaturerange :-30°C ~+80 °C 4.Color:Black Frequency Rang:5.15GHz~5.825GHz Return Loss:-10.0 dB or less VSWR:1.92 Max Specification: ROHS ROHS ±0.1 ±0.2 .XX .X ±0.5X. .XXX ±0.05 ±1.0 XX. 深圳市华德昌科技有限公司 ShenZhen HuaDeChang Technology Co.,Ltd HuaDeChang DESCRIPTION NO Q'TY 3 1 4 1 REMARK Antenna Cap 2 TPEE,Color: Black REVISION Date REV. A NEW ISSUE 2023.06.23 ROHS ROHS Label 1PCS/ Bag Packing:20PCS/Bag Cable PBT+PC,Color:Black 1 HDC-268 H268-10001-B 5G ANTENNA RG-178 Cable,Transparency Brown,50Ω 4 Rivet Product Drawing 1 13.0±0.1 13.0±0.1 3 201±2 225±2 2 3 1 5 Connector SMA Straight Plug Reverse for RG-178,Female 2 1 Upper Base PBT+PC,Color:Black Blue Dot Brass Enclosure 1. Carton should be 1 PCS/ROHS label on the carton label 2. Carton need to post 1 PCS/carton label on the carton side top right corner P/N:H268-10001-BREV.:X1Date:6/23/2023 A4401,A4201A,Building16,Workshop,JunfengIndustrialPark,ChongqingRoad,Heping Community,FuhaiStreet,Bao'anDistrict,Shenzhen VNAtestpattern P/N:H268-10001-B Specification:5G5dBiANTENNA(Black) TestItem:ReturnLoss/VSWR P/N:H268-10001-BREV.:X1Date:6/23/2023 A4401,A4201A,Building16,Workshop,JunfengIndustrialPark,ChongqingRoad,Heping Community,FuhaiStreet,Bao'anDistrict,Shenzhen Laboratorytestreport TestItem:AntennaEfficiency/PeakGain Freq. (MHz) Gain (dBi) Directivity (dBi) Efficiency (%) 5150.05.315.8189.2% 5250.05.936.0796.8% 5350.05.906.1993.5% 5450.05.896.2292.6% 5550.05.805.9796.2% 5650.05.886.3290.5% 5750.06.046.4890.3% 5850.05.506.0089.0% 5150MHz5350MHz 5850MHz Parameter Specification 1、Technical Specifications 5.15~5 Frequency Range .825GHz S.W.R ≤1.9 2 Ga in Connection Type SMA Impedance 50 Ohm 2、Reli ability Test ItemTest ConditionSpecification Storage Environment Normal electrical and mechanical Temperature, humidity, and air pressure are tested in the absence of specified conditions: properties High and low 1.emperature-30°C～+80°C 2.Relative humidity 45%-85% 3.pressure 86kpa-106kpa) temperature test The dimensions shall meet Between 70 and 40 degrees C for 5 cycles, and then under normal conditions 1-2H, check the appearance quality。 the requirements and shall meet the requirements of the mechanical and electrical properties. Resistance to constant damp heat test Relative humidity 95 + 3%, test temperature: 40 degrees C, after continuing the role of 2H, after testing the electrical performance of the 5min within the test, the sample in the normal environment 1-2H, check the appearance quality vibration test Normal electrical and mechanical Frequency range 10-55HZ, displacement amplitude 0.35MM, acceleration amplitude 50.0M/S, frequency sweep cycle times 30 times properties Drop test Drawing 1m Altitude drop force test Ultraviolet Confirm the strength of the product by using push pull tester：≧10N aging test 2.0(nominal) 1.0GHz 2.9(nominal) 2.0GHz 3.2(nominal) 2.4GHz 3.7(nominal) 3.0GHz 4.3(nominal) 4.0GHz 4.8(nominal) 5.0GHz Allow yellow but with Test temperature：50°C time：4hr different color Attenuation value 5.3(nominal) 6.0GHz 3.3dB/m (at20°C) SHENZHEN HUADECHANG TECHNOLOGY CO.,LTD Raw material hazardous substances management table Product:RF Antenna Assembly Supplier Part No. ITEMRAW MATERIALRAW MATERIAL SUPPLIER Cd (ppm) Pb (ppm) Cr6+ (ppm) Hg (ppm) PBBS (ppm) PBDES (ppm) Testing Agency Test Report Number Date 1RG-178 Silver Cooper JIANGSU YUANDA N.DN.DNegativeN.DN.DN.D CTIA2220412031101018 2022.09.29 FEP N.DN.DN.DN.DN.DN.D Tinned Cooper N.DN.DNegativeN.DN.DN.D Color Masterbatch N.DN.DN.DN.DN.DN.D 2Antenna CapABS CHIMEI N.DN.DN.DN.DN.DN.DTUV238550813d 001 2022.08.10 3Upper BasePBT+PC SHINKONG N.DN.DN.DN.DN.DN.DSGSETR22800750 2022.08.10 4Bottom BasePBT+PC SHINKONG N.DN.DN.DN.DN.DN.DSGSETR22800750 2022.08.10 5RivetPBT+PC SHINKONG N.DN.DN.DN.DN.DN.DSGSETR22800750 2022.08.10 6SMA Plug Resin Emulsion UNIRES N.DN.DN.DN.DN.DN.DSGSCANEC2227954524 2023.01.04 Pigment Paste UNIRES N.DN.DN.DN.DN.DN.DSGSCANEC2227954514 2023.01.04 NI-Plated LIANFENG N.DN.DN.DN.DSGSSZXEC2203378506 2022.10.25 Gold-Plated LIANFENG N.DN.DN.DN.DSGSSZXEC2203378502 2022.10.25 TeflonHUAMEI N.DN.DN.DN.DN.DN.DSGSCANEC2222757410 2022.11.02 BrassYIFENG N.D21314N.DN.DN.DN.DAZTAZT032206080014C-020 2022.06.12 7Solid ColumnZinc Alloy CHENGJUN N.D17N.DN.DN.DN.DSGSSZXEC2300031414 2023.01.11 8Copper PipeBrass YUANDING N.D33NegativeN.DSGSNGBEC22001696604 2022.06.06 9SpringBrass QI FENG N.D21NegativeN.DSGSSZXEC23000111403 2023.02.24 10 Heat Shrink Tubing PE WORE N.DN.DN.DN.DN.DN.DSGSCANEC2211474412 2022.06.08 11TonerColor Masterbatch LONGCHANGSHENG N.DN.DN.DN.DN.DN.DCTIA2220225981101002 2022.06.10

Cover Letter(s)

ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 72 of 136 11AC20MIMO-Ant2-5240 11AC40MIMO-Ant1-5190 11AC40MIMO-Ant2-5190 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 73 of 136 11AC40MIMO-Ant1-5230 11AC40MIMO-Ant2-5230 11AC80MIMO-Ant1-5210 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 74 of 136 11AC80MIMO-Ant2-5210 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 75 of 136 AppendixA2:Occupiedchannelbandwidth TestResult TestModeAntennaFrequency[MHz]OCB[MHz]FL[MHz]FH[MHz]Limit[MHz]Verdict 11AAnt1518017.3655171.38225188.7472------ 11AAnt2518018.6455170.47835189.1233------ 11AAnt1520017.3625191.35315208.7151------ 11AAnt2520019.2705190.28185209.5518------ 11AAnt1524016.6305231.68135248.3113------ 11AAnt2524017.0805231.55135248.6313------ 11N20MIMOAnt1518018.1095171.02885189.1378------ 11N20MIMOAnt2518019.1035170.36465189.4676------ 11N20MIMOAnt1520018.1495190.97625209.1252------ 11N20MIMOAnt2520020.4015189.69755210.0985------ 11N20MIMOAnt1524017.6485231.16165248.8096------ 11N20MIMOAnt2524017.9015231.14035249.0413------ 11N40MIMOAnt1519035.9955172.16235208.1573------ 11N40MIMOAnt2519036.1985171.86035208.0583------ 11N40MIMOAnt1523036.1985211.96055248.1585------ 11N40MIMOAnt2523036.2315212.09555248.3265------ 11AC20MIMOAnt1518018.0945171.04205189.1360------ 11AC20MIMOAnt2518019.2005170.26375189.4637------ 11AC20MIMOAnt1520018.1195190.99095209.1099------ 11AC20MIMOAnt2520020.3725189.75245210.1244------ 11AC20MIMOAnt1524017.5875231.20425248.7912------ 11AC20MIMOAnt2524017.9425231.10365249.0456------ 11AC40MIMOAnt1519035.9835172.16525208.1482------ 11AC40MIMOAnt2519036.1895171.87885208.0678------ 11AC40MIMOAnt1523036.0785212.03175248.1097------ 11AC40MIMOAnt2523036.1025212.13625248.2382------ 11AC80MIMOAnt1521074.7385172.88535247.6233------ 11AC80MIMOAnt2521075.7235172.32725248.0502------ ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 76 of 136 TestGraphs 11A-Ant1-5180 11A-Ant2-5180 11A-Ant1-5200 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 77 of 136 11A-Ant2-5200 11A-Ant1-5240 11A-Ant2-5240 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 78 of 136 11N20MIMO-Ant1-5180 11N20MIMO-Ant2-5180 11N20MIMO-Ant1-5200 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 79 of 136 11N20MIMO-Ant2-5200 11N20MIMO-Ant1-5240 11N20MIMO-Ant2-5240 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 80 of 136 11N40MIMO-Ant1-5190 11N40MIMO-Ant2-5190 11N40MIMO-Ant1-5230 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 81 of 136 11N40MIMO-Ant2-5230 11AC20MIMO-Ant1-5180 11AC20MIMO-Ant2-5180 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 82 of 136 11AC20MIMO-Ant1-5200 11AC20MIMO-Ant2-5200 11AC20MIMO-Ant1-5240 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 83 of 136 11AC20MIMO-Ant2-5240 11AC40MIMO-Ant1-5190 11AC40MIMO-Ant2-5190 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 84 of 136 11AC40MIMO-Ant1-5230 11AC40MIMO-Ant2-5230 11AC80MIMO-Ant1-5210 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 85 of 136 11AC80MIMO-Ant2-5210 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 86 of 136 AppendixB:DutyCycle TestResult TestModeAntennaFrequency[MHz] Transmission Duration[ms] Transmission Period[ms] DutyCycle [%] DcFactor [%] 1/T 11AAnt151801.391.4297.890.090.72 11AAnt251801.391.4397.200.120.72 11AAnt152001.391.4397.200.120.72 11AAnt252001.401.4397.900.090.71 11AAnt152401.391.4397.200.120.72 11AAnt252401.401.4397.900.090.71 11N20MIMOAnt151801.301.3497.010.130.77 11N20MIMOAnt251801.291.3396.990.130.78 11N20MIMOAnt152001.291.3396.990.130.78 11N20MIMOAnt252001.301.3397.740.100.77 11N20MIMOAnt152401.301.3497.010.130.77 11N20MIMOAnt252401.301.3497.010.130.77 11N40MIMOAnt151900.650.6895.590.201.54 11N40MIMOAnt251900.650.6895.590.201.54 11N40MIMOAnt152300.650.6895.590.201.54 11N40MIMOAnt252300.650.6895.590.201.54 11AC20MIMOAnt151801.321.3597.780.100.76 11AC20MIMOAnt251801.311.3497.760.100.76 11AC20MIMOAnt152001.311.3497.760.100.76 11AC20MIMOAnt252001.311.3497.760.100.76 11AC20MIMOAnt152401.311.3597.040.130.76 11AC20MIMOAnt252401.311.3597.040.130.76 11AC40MIMOAnt151900.650.6994.200.261.54 11AC40MIMOAnt251900.660.6995.650.191.52 11AC40MIMOAnt152300.660.6995.650.191.52 11AC40MIMOAnt252300.650.6994.200.261.54 11AC80MIMOAnt152100.320.3688.890.513.13 11AC80MIMOAnt252100.330.3691.670.383.03 ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 87 of 136 TestGraphs NTNV-11A-Ant1-5180 NTNV-11A-Ant2-5180 NTNV-11A-Ant1-5200

Cover Letter(s)

ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 103 of 136 11N40MIMO-Ant1-5190-PASS 11N40MIMO-Ant2-5190-PASS 11N40MIMO-Ant1-5230-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 104 of 136 11N40MIMO-Ant2-5230-PASS 11AC20MIMO-Ant1-5180-PASS 11AC20MIMO-Ant2-5180-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 105 of 136 11AC20MIMO-Ant1-5200-PASS 11AC20MIMO-Ant2-5200-PASS 11AC20MIMO-Ant1-5240-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 106 of 136 11AC20MIMO-Ant2-5240-PASS 11AC40MIMO-Ant1-5190-PASS 11AC40MIMO-Ant2-5190-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 107 of 136 11AC40MIMO-Ant1-5230-PASS 11AC40MIMO-Ant2-5230-PASS 11AC80MIMO-Ant1-5210-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 108 of 136 11AC80MIMO-Ant2-5210-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 109 of 136 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaFrequency[MHz]Result[dBm/MHz]Limit[dBm/MHz]Verdict 11AAnt151803.14≤11.00PASS 11AAnt251804.79≤11.00PASS 11AAnt152004.04≤11.00PASS 11AAnt252005.47≤11.00PASS 11AAnt152404.24≤11.00PASS 11AAnt252406.13≤11.00PASS 11N20MIMOAnt151802.08≤11.00PASS 11N20MIMOAnt251804.08≤11.00PASS 11N20MIMOtotal51806.20≤11.00PASS 11N20MIMOAnt152002.88≤11.00PASS 11N20MIMOAnt252004.73≤11.00PASS 11N20MIMOtotal52006.91≤11.00PASS 11N20MIMOAnt152403.36≤11.00PASS 11N20MIMOAnt252404.62≤11.00PASS 11N20MIMOtotal52407.05≤11.00PASS 11N40MIMOAnt151900.55≤11.00PASS 11N40MIMOAnt251901.82≤11.00PASS 11N40MIMOtotal51904.24≤11.00PASS 11N40MIMOAnt152301.21≤11.00PASS 11N40MIMOAnt252301.75≤11.00PASS 11N40MIMOtotal52304.50≤11.00PASS 11AC20MIMOAnt151801.95≤11.00PASS 11AC20MIMOAnt251804.15≤11.00PASS 11AC20MIMOtotal51806.20≤11.00PASS 11AC20MIMOAnt152002.78≤11.00PASS 11AC20MIMOAnt252004.58≤11.00PASS 11AC20MIMOtotal52006.78≤11.00PASS 11AC20MIMOAnt152402.93≤11.00PASS 11AC20MIMOAnt252405.42≤11.00PASS 11AC20MIMOtotal52407.36≤11.00PASS 11AC40MIMOAnt151900.37≤11.00PASS 11AC40MIMOAnt251901.67≤11.00PASS 11AC40MIMOtotal51904.08≤11.00PASS 11AC40MIMOAnt152301.04≤11.00PASS 11AC40MIMOAnt252301.79≤11.00PASS 11AC40MIMOtotal52304.44≤11.00PASS 11AC80MIMOAnt15210-3.52≤11.00PASS 11AC80MIMOAnt25210-3.38≤11.00PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 110 of 136 11AC80MIMOtotal5210-0.44≤11.00PASS Note：1.TheResultandLimitUnitisdBm/500kHzintheband5.7255.85GHz. 2.TheDutyCycleFactorandRBWFactoriscompensatedinthegraph. ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 111 of 136 TestGraphs 11A-Ant1-5180-PASS 11A-Ant2-5180-PASS 11A-Ant1-5200-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 112 of 136 11A-Ant2-5200-PASS 11A-Ant1-5240-PASS 11A-Ant2-5240-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 113 of 136 11N20MIMO-Ant1-5180-PASS 11N20MIMO-Ant2-5180-PASS 11N20MIMO-Ant1-5200-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 114 of 136 11N20MIMO-Ant2-5200-PASS 11N20MIMO-Ant1-5240-PASS 11N20MIMO-Ant2-5240-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 115 of 136 11N40MIMO-Ant1-5190-PASS 11N40MIMO-Ant2-5190-PASS 11N40MIMO-Ant1-5230-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 116 of 136 11N40MIMO-Ant2-5230-PASS 11AC20MIMO-Ant1-5180-PASS 11AC20MIMO-Ant2-5180-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 117 of 136 11AC20MIMO-Ant1-5200-PASS 11AC20MIMO-Ant2-5200-PASS 11AC20MIMO-Ant1-5240-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 118 of 136 11AC20MIMO-Ant2-5240-PASS 11AC40MIMO-Ant1-5190-PASS 11AC40MIMO-Ant2-5190-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 119 of 136 11AC40MIMO-Ant1-5230-PASS 11AC40MIMO-Ant2-5230-PASS 11AC80MIMO-Ant1-5210-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 120 of 136 11AC80MIMO-Ant2-5210-PASS ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 121 of 136 AppendixE:FrequencyStability TestResult TestModeAntenna Frequenc y[MHz] Voltage [Vdc] Temperat ure (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdict 11AAnt15180NVNT-60000.00-11.58301220PASS 11AAnt15180LVNT-60000.00-11.58301220PASS 11AAnt15180HVNT-60000.00-11.58301220PASS 11AAnt25180NVNT-40000.00-7.72200820PASS 11AAnt25180LVNT-60000.00-11.58301220PASS 11AAnt25180HVNT-60000.00-11.58301220PASS 11AAnt15200NVNT-60000.00-11.53846220PASS 11AAnt15200LVNT-60000.00-11.53846220PASS 11AAnt15200HVNT-60000.00-11.53846220PASS 11AAnt25200NVNT-60000.00-11.53846220PASS 11AAnt25200LVNT-60000.00-11.53846220PASS 11AAnt25200HVNT-60000.00-11.53846220PASS 11AAnt15240NVNT-40000.00-7.63358820PASS 11AAnt15240LVNT-60000.00-11.45038220PASS 11AAnt15240HVNT-60000.00-11.45038220PASS 11AAnt25240NVNT-40000.00-7.63358820PASS 11AAnt25240LVNT-40000.00-7.63358820PASS 11AAnt25240HVNT-40000.00-7.63358820PASS 11N20MIM O Ant15180NVNT-60000.00-11.58301220PASS 11N20MIM O Ant15180LVNT-40000.00-7.72200820PASS 11N20MIM O Ant15180HVNT-60000.00-11.58301220PASS 11N20MIM O Ant25180NVNT-40000.00-7.72200820PASS 11N20MIM O Ant25180LVNT-40000.00-7.72200820PASS 11N20MIM O Ant25180HVNT-60000.00-11.58301220PASS 11N20MIM O Ant15200NVNT-60000.00-11.53846220PASS 11N20MIM O Ant15200LVNT-60000.00-11.53846220PASS 11N20MIM O Ant15200HVNT-60000.00-11.53846220PASS 11N20MIMAnt25200NVNT-600…

Text truncated - open the document above for the full version.

Test Report

WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 1 of 136 TESTREPORT ReferenceNo.......................:WTH25X11315634W001 FCCID....................................:2ADXC-QBZ339RX Applicant...............................:ShenzhenLenkengTechnologyCo.,Ltd Address.................................: West4F,JinguangxiaCulture&TechPark,3GuangxiaRoad,Shenzhen, China Manufacturer........................:ThesameasApplicant Address.................................:ThesameasApplicant ProductName......................:HDMIWirelessExtender ModelNo. .............................. :LKV699E-KVM-RX Standards..............................:FCCPart15.407 DateofReceiptsample.....:2025-11-27 DateofTest ........................... :2025-12-04to2025-12-26 DateofIssue........................:2025-12-30 TestReportFormNo. ......... : WTX_Part15_407W TestResult ............................ :Pass Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbe reproduced,exceptinfull,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithout specificstampoftestinstituteandthesignaturesofapprover. PreparedBy: WaltekTestingGroup(Shenzhen)Co.,Ltd. Address:1/F.,Room101,Building1,HongweiIndustrialPark,Liuxian2ndRoad, Block70Bao'anDistrict,Shenzhen,Guangdong,China Tel.:+86-755-33663308Fax.:+86-755-33663309Email:[email protected] Testedby:Approvedby: DashanChen/ProjectEngineerJasonSu/Manager ReferenceNo.:WTH25X11315634W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 2 of 136 TABLEOFCONTENTS 1.GENERALINFORMATION.......................................................................................................................................5 1.1PRODUCTDESCRIPTIONFOREQUIPMENTUNDERTEST(EUT).................................................................................5 1.2TESTSTANDARDS.......................................................................................................................................................6 1.3TESTMETHODOLOGY.................................................................................................................................................6 1.4TABLEFORPARAMETERSOFTESTSOFTWARESETTING............................................................................................6 1.5EUTOPERATINGDURINGTEST..................................................................................................................................8 1.6TESTFACILITY...........................................................................................................................................................8 1.7EUTSETUPANDTESTMODE....................................................................................................................................9 1.8MEASUREMENTUNCERTAINTY................................................................................................................................11 1.9TESTEQUIPMENTLISTANDDETAILS......................................................................................................................12 2.SUMMARYOFTESTRESULTS.............................................................................................................................16 3.ANTENNAREQUIREMENT....................................................................................................................................17 3.1STANDARDAPPLICABLE...........................................................................................................................................17 3.2EVALUATIONINFORMATION....................................................................................................................................17 4.AUTOMATICALLYDISCONTINUETRANSMISSION......................................................................................18 4.1STANDARDAPPLICABLE...........................................................................................................................................18 4.2SUMMARYOFTESTRESULTS...................................................................................................................................18 5.POWERSPECTRALDENSITY................................................................................................................................19 5.1STANDARDAPPLICABLE...........................................................................................................................................19 5.2TESTPROCEDURE.....................................................................................................................................................19 5.3SUMMARYOFTESTRESULTS/PLOTS.......................................................................................................................20 6.EMISSIONBANDWIDTHANDOCCUPIEDBANDWIDTH...............................................................................21 6.1STANDARDAPPLICABLE...........................................................................................................................................21 6.2TESTPROCEDURE.....................................................................................................................................................21 6.3SUMMARYOFTESTRESULTS/PLOTS.......................................................................................................................23 7.MAXIMUMCONDUCTEDOUTPUTPOWER......................................................................................................24 7.1STANDARDAPPLICABLE...........................................................................................................................................24 7.2TESTPROCEDURE.....................................................................................................................................................24 7.3SUMMARYOFTESTRESULTS/PLOTS.....................................................................................…

Text truncated - open the document above for the full version.

Test Report

MT7921AUN Y1: 40MHz Y1: 24MHz External Antenna 5180-5240MHz

Test Report

Circuit Description The equipment under test (EUT) is anHDMI Wireless ExtenderwithWIFI. This circuit shows the main IC of the product, including theVCT6601 and MT7921AUN. VCT6602is a main control chip with a crystal of24MHzfrequency as base clock signal to control that the WIFI module transmitting and receiving the wireless communication signal in the frequency range from 5180-5240MHz. The MediaTekMT7921AUNWi-Fi chipset is based on a 22nm process, providing higher performance and lower power consumption. The MT7921AUN implements Multi user Multiple Input Multiple Output (MU-MIMO) Orthogonal Frequency Division Multiplexing (OFDM withtwo transmissions and two receive paths (2T2R) Features Two spatial stream transmissions Spatial spreading Support for variant channel bandwidth Work with a40MHzbasic crystal oscillator Antenna,GroundandPowerSource The antenna consists of two External antennas There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by Power Adapter DC5V. Feature: Support Standards: 802.11a, 802.11n-HT20, 802.11n-HT40, 802.11ac-VHT20, 802.11ac-VHT40, 802.11ac-VHT80 Frequency Range: 5180-5240MHz Type of Modulation: QPSK, 16QAM, 64QAM, 256QAM Type of Antenna: External Antenna Antenna Gain:5.93dBi

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Luo yuqun(Manager)

[email protected]Fax: 075582500201

Technical Contact

FCC US Agent, LLCTim Payne

[email protected]

3722 Illinois Avenue, Saint Charles, IL, 60174, · Saint Charles, Illinois, 60174 · United States

Test Firm

Waltek Testing Group (Shenzhen) Co., Ltd.Jandy So

[email protected]Fax: 86-755-33663309

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.18 GHz - 5.24 GHz	59.40 mW

Confidentiality

Long Term

Grant Notes

Output power listed is maximum combined conducted power. This device contains 20, 40 and 80 MHz signal bandwidth. Device is a 2x2 MIMO as is described in the filing. The antennas used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-users must be provided with operating procedures for satisfying RF exposure compliance.
