RF_743, Issue 02 Declaration of Authorization (to use documentation) We Name: TECNO MOBILE LIMITED Address: RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN City: HONG KONG Country: China Declare that: Name Representative of agent: WST Agent Company name: Shenzhen WST Testing Technology Co., Ltd. Address: 1F,No.9 Building,TGK Science & Technology Park Yangtian Rd., NO.72 Bao'an Dist. City: Shenzhen Country China may use our test reports and documentation of the following (already certified) product: Product description: Mobile Phone Type designation: A7 Trademark: Original FCC ID: 2ADYY- A7 Original Canada ID: ................. Original Japan certificate number: ................. for his own approval/certificate. Date: 2015.4.13 City: Shenzhen Name: Robben Xie Function: Manager Signature: COMPANY LETTER HEAD

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: TECNO MOBILE LIMITED Address : RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN, City: H.K. Country: China To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2ADYY-A7 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2015-04-13 Name and signature of applicant: Robben Xie Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

FCCID: 2ADYY-A7 Label Location of EUT (The battery cannot be disassembled.) Size：40 * 40 mm

Internal photograph of EUT Internal photograph of EUT WIFI/BT Antenna Internal photograph of EUT Internal photograph of EUT GSM/WCDMA Antenna Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT

FCC Report Application Purpose : Original grant Applicant Name: : TECNO MOBILE LIMITED Equipment Type : Mobile Phone Model Name : A7 Report Number : FCC15016718-5 Standard(S) : FCC Part 15 Subpart B Date Of Receipt : January 16, 2015 Date Of Issue : January 26, 2015 Test By : ( Neil Wong) Reviewed By : ( Robie Chen) Authorized by : ( Michal Ling) Prepared by : Shenzhen WST Testing Technology Co., Ltd. 1F,No.9 Building,TGK Science & Technology Park Yangtian Rd., NO.72 Bao'an Dist., GuangDong, China (Registration Number: 939433) Page 2 of 32 Report No.: FCC15016718-5 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / January 26, 2015Valid Original Report Page 3 of 32 Report No.: FCC15016718-5 Table of Contents Page 1. GENERAL INFORMATION 4 2. TEST DESCRIPTION 6 2.1 MEASUREMENT UNCERTAINTY 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 CONFIGURATION OF SYSTEM UNDER TEST 8 2.4 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 8 3. SUMMARY OF TEST RESULTS 9 4. MEASUREMENT INSTRUMENTS 10 5. EMC EMISSION TEST 11 5.1 CONDUCTED EMISSION MEASUREMENT 11 5.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 5.1.2 TEST PROCEDURE 12 5.1.3 DEVIATION FROM TEST STANDARD 12 5.1.4 TEST SETUP 12 5.1.5 EUT OPERATING CONDITIONS 12 5.1.6 TEST RESULTS 13 5.2 RADIATED EMISSION MEASUREMENT 15 5.2.1 RADIATED EMISSION LIMITS 15 5.2.2 TEST PROCEDURE 16 5.2.3 DEVIATION FROM TEST STANDARD 16 5.2.4 TEST SETUP 17 5.2.5 EUT OPERATING CONDITIONS 17 5.2.5.1 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 18 5.2.5.2 TEST RESULTS(1GHZ TO 6GHZ) 20 12. EUT TEST PHOTO 21 13. PHOTOGRAPHS OF EUT 23 Page 4 of 32 Report No.: FCC15016718-5 1. GENERAL INFORMATION Test Model A7 Applicant TECNO MOBILE LIMITED Address RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN, HK. Manufacturer SHENZHEN SMARTTEL CO., LTD. Address 6th Floor, Block 15, shatoujiao Free TRADE Zone, Shenyan Road, Yantian District, Shenzhen, Guangdong, P.R.China Equipment Type Mobile Phone Brand Name Hardware version: G906_MAIN_PCB_V1.0 Software version: V1.0 Battery information: Model: BL-30BT Voltage: 3.8V Capacity: 2980mAh Adapter Information: Model: A88-502000 Input: AC 100-240 V, 50/60 Hz, 0.35A Output: DC 5V 2.0A Data of receipt January 16, 2015 Date of test January 16, 2015 to January 26, 2015 Deviation None Condition of Te s t S a m p l e Normal Page 5 of 32 Report No.: FCC15016718-5 We hereby certify that: All measurement facilities used to collect the measurement data are located at 1F,No.9 Building,TGK Science & Technology Park Yangtian Rd., NO.72 Bao'an Dist., GuangDong, China The data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C 63.4:2009. The sample tested as described in this report is in compliance with the FCC Rules Part15 Subpart B. The test results of this report relate only to the tested sample identified in this report.ort. Page 6 of 32 Report No.: FCC15016718-5 2. TEST DESCRIPTION 2.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±3.2dB 2 RF power, conducted ±0.16dB 3 Spurious emissions, conducted ±0.21dB 4 All emissions, radiated(<1G) ±4.7dB 5 All emissions, radiated(>1G) ±4.7dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 32 Report No.: FCC15016718-5 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Exchange data For Conducted Emission Final Test Mode Description Mode 1 Exchange data For Radiated Emission Final Test Mode Description Mode 1 Exchange data Page 8 of 32 Report No.: FCC15016718-5 2.3 CONFIGURATION OF SYSTEM UNDER TEST (EUT: Mobile Phone) 2.4 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Mfr/Brand Model/Type No. Series No. Note 1 Computer HP Compaq CNX74417JC / 2 Monitor HP / CND7160R3Z / 3 Mouse DELL / / 1.5m unshielded 4 Keyboard SHENGLI / / 1.5m unshielded Note: (1) The support equipment was authorized by Declaration of Confirmation. (2) For detachable type I/O cable should be specified the length in cm in『Length』column. I/O Port of EUT I/O Port Type Q’TY Cable Tested with USB port 1 1m USB cable, unshielded 1 Earphone 1 1m N/A EUT PC AC Mains USB Cable Page 9 of 32 Report No.: FCC15016718-5 3. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 , Subpart B Standard Section Test Item Judgment Remark 15.107 CONDUCTED EMISSION PASS 15.109 RADIATED EMISSION PASS NOTE: (1)” N/A” denotes test is not applicable in this test report. Page 10 of 32 Report No.: FCC15016718-5 4. MEASUREMENT INSTRUMENTS Kind of Equipment Manufacturer Type No. Serial No. Last Calibrated Calibrated until ESPI Test Receiver R&S ESPI 100379 08/19/2014 08/18/2015 ESCI Test Receiver R&S ESCI 100005 08/19/2014 08/18/2015 LISN AFJ LS16 16010222119 08/19/2014 08/18/2015 LISN(EUT) Mestec AN3016 04/10040 08/19/2014 08/18/2015 pre-amplifier CDSI PAP-1G18-38 -- 08/19/2014 08/18/2015 System Controller CT SC100 - 08/19/2014 08/18/2015 Bi-log Antenna Chase CBL6111C 2576 08/19/2014 08/18/2015 Spectrum analyzer R&S FSU26 200409 08/19/2014 08/18/2015 Horn Antenna SCHWARZBECK 9120D 1141 08/19/2014 08/18/2015 Bi-log Antenna Schwarebeck VULB9163 9163/340 08/19/2014 08/18/2015 Pre Amplifier H.P. HP8447E 294…

Text truncated - open the document above for the full version.

CONDUCTED EMISSION TEST RADIATED EMISSION TEST RADIATED EMISSION TEST
