2ADYY-CG7Mobile Phone

TECNO MOBILE LIMITED

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Feb 23, 2021
Application Purpose: Original Equipment
Date of Application: Feb 21, 2021
Equipment Note: Mobile Phone
Frequency Range: 2545.00000000 - 2645.00000000
Company: TECNO MOBILE LIMITED
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

E E x x p p l l o o s s i i o o n n d d i i a a g g r r a a m m s s p p e e c c i i f f i i c c a a t t i i o o n n 1 Card Holder asm CG7 Magnet Black 2 Bat cover asm CG7 Magnet Black 3 R hsg Seal Mylar 19.71*7.94 CG7 4 UP Frame Radiating fin 60.5 *58.51 CG7 5 RCAM LensCG7KN3 41.56 *10.36*0.5DarChrome 6 mc screw M1.4*L3.0*D2.5 *H0.5 black glue 7 mc screw M1.4*L2.0*D3.0 *H0.5 silver glue 8 machine screw M1.4*L3.5* D2.5*H0.5 black 9 R hsg asm CG7 Magnet Black 10 R CAM Rubber QVGA CG7 Black 11 R CAM Rubber 2M X693 Black 12 F CAM Rubber 16M CG7 Black 13 CAM FF 2M GC02M1B YM P 3P+IR B SJ V1.0 14 CAM FF 8W GC6153 B P 1P B 10P XCG V1.0 15 CAM FF 2M GC02M1 A P 3P+IR B LHYX V1.0 16 CAM AF 64M OV64B A A 6PBG B 30P ST V1.0 17 R CAM Frame CG7 18 Shield Radiating Cop foil 30.6*8 X693 19 CAM FF 16M S5K3P9SP04 A B 5P B TS V1.0 20 F CAM frame asm 16M CG7 21 Distance Sensor Rubber X693 Black 22 CAM BTB Waterproof Rubber 5.95*4.05 CG7 23 R CAM BTBWaterproof Rubber 8W5.9*3.92CG7 24 R CAM Con Foam 64M 15.43*13.11 CG7 25 F CAM Con fb 12.01*5 CG7 26 REC Con fb 3.5*12.02 CG7 27 REC 0809W H20 shrapnel 50mW 123dB Goer 28 PCBA MB H697 A1 128GB +6GB V1.0 29 F hsg asm CG7 Black 30 REC Deco part asm CG7 Black 31 FL(CTP+LCM) 6.78FHD+ H CG7 Black TM V1.0 32 PCBA SUB H697 1 A V1.0 33 MAIN Radiating Film 37*55.6 CG7 34 SUB PCB CONN Rubber 9.65* 3.7 CG7 Black 35 Bat CONN Rubber 15.66*4.18 X693 Black 36 LCM CONN Rubber 11*3.7 CG7 Black 37 FPC MAIN CG7 38 FPC Side Key CG7 39 Bat TECNO BL 49GT 4900mAh ATL IN 40 coaxial cable KTA S 145 CG7 RoHS 41 FM(GSL6157) 0821 Black finger chip 42 Motor COIN 0827 L12 H JX 43 SPK 1115 SPR H2.5 1.0W HS 44 Aj Rubber CG7 Black 45 USB Rubber CG7 Black 46 DOWN SPK frame asm CG7 47 SPK Frame Seal Mylar 22.62* 48.59 CG7 Know your phone ① 1. Front camera 2. Volume key 3. Power key SIM/SD card installation 1. Power off mobile. 2. Refer to the following picture for SIM / SD card installation. C C h h a a r r g g i i n n g g t t h h e e p p h h o o n n e e You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone). 1. Please remind the front and back of the plug. 2. Use only TECNO charger and cables. Other chargers or cables may damage the device. This will invalidate your phone warranty. FCC Statement 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.` Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAR Information Statement Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.171W/Kg and when worn on the body, as described in this user guide, is 0.381W/Kg(Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). The maximum scaled SAR in hotspot mode is 0.533W/Kg. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for th…

Text truncated - open the document above for the full version.

Cover Letter(s)

TECNO MOBILE LIMITED DATE :2021-2-3 Equipment Autorisation Division Federal Communications Commission 7345 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADYY-CG7 Product Name: Mobile Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description  Tune up  BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2021-2-3 By: Yiting Luo Signature Printed Title: Manager On behalf of : TECNO MOBILE LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

TECNO MOBILE LIMITED DATE:2021-2-3 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint JianYan Testing Group Shenzhen Co., Ltd.; 1st Floor, Block No.B- C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with TECNO MOBILE LIMITED/ ROOM 604 6/F SOUTH TOWER WORLD FINANCE CTR HARBOUR CITY 17 CANTON ROAD TST KL Hong Kong Dated this 2021-2-3 By: Yiting Luo Signature Printed Title: Manager On behalf of : TECNO MOBILE LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

TECNO MOBILE LIMITED DATE :2021-2-3 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADYY-CG7 Product Name: Mobile Phone Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.:  Test Setup Photos  External Photos  Internal Photos  EUT photos and SAR test setup photos  User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. <Signature> Name Yiting Luo Title manager Company TECNO MOBILE LIMITED

External Photos

ID Label/Location Info

label location label location

Internal Photos

Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 49 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 50 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 51 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 52 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 53 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 54 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 55 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 56 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 57 of 58 Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 58 of 58 ------End of report------

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZB-R14-2100009 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: TECNO MOBILE LIMITED Address of Applicant: FLAT 39 8/F BLOCK D WAH LOK INDUSTRIAL CENTRE 31- 35 SHAN MEI STREET FOTAN NT Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: CG7 Trade mark TECNO FCC ID: 2ADYY-CG7 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 12 Jan., 2021~19 Jan., 2021 Test Result: Maximum Reported1-g SAR (W/kg) Head: 1.171 Body: 0.381 Hotspot: 0.533 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 2 of 230 2 Version Version No. Date Description 00 21 Jan., 2021 Original Testedby: Date: 21 Jan., 2021 Report Clerk Reviewed by: Date: 21 Jan., 2021 Project Engineer Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 3 of 230 3 Contents 1 COVER PAGE ....................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 7 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 7 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 7 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 9 5.4 ENVIRONMENT OF TEST SITE ....................................................................................................................................................... 10 5.5 TEST SAMPLE PLAN ..................................................................................................................................................................... 10 5.6 TEST LOCATION ........................................................................................................................................................................... 10 6 INTRODUCTION ................................................................................................................................................. 11 6.1 INTRODUCTION ............................................................................................................................................................................. 11 6.2 SAR DEFINITION .......................................................................................................................................................................... 11 7 RF EXPOSURE LIMITS ..................................................................................................................................... 12 7.1 UNCONTROLLED ENVIRONMENT ................................................................................................................................................... 12 7.2 CONTROLLED ENVIRONMENT ....................................................................................................................................................... 12 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................. 12 8 SAR MEASUREMENT SYSTEM ....................................................................................................................... 13 8.1 E-FIELD PROBE......................................................................................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 151 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 152 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 153 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 154 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 155 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 156 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 157 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 158 of 230 Calibration information for Dipole Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 159 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 160 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 161 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 162 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 163 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 164 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 165 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China., Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 166 of 230 Report No: JYTSZB-R14-2100009 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101050 No.101, Building 8, Innovat…

Text truncated - open the document above for the full version.

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZB-R12-2100084 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT (GSM & WCDMA) Applicant: TECNO MOBILE LIMITED Address of Applicant: FLAT 39 8/F BLOCK D WAH LOK INDUSTRIAL CENTRE 31- 35 SHAN MEI STREET FOTAN NT Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: CG7 Trade mark: TECNO FCC ID: 2ADYY-CG7 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E Date of sample receipt: 12 Jan., 2021 Date of Test: 13 Jan., to 19 Jan., 2021 Date of report issued: 21 Jan., 2021 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 58 2. Version Version No. Date Description 00 21 Jan., 2021 Original Tested by: Date: 21 Jan., 2021 Test Engineer Reviewed by: Date: 21 Jan., 2021 Project Engineer Report No: JYTSZB-R12-2100084 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2101049 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 58 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST ENVIRONMENT AND MODE, AND TEST SAMPLES PLANS ............................................................................... 7 5.4 DESCRIPTION OF TEST AUXILIARY EQUIPMENT .....…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Yiting Luo

[email protected]86-755-61803856Fax: +86-755-33979211

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	27	2.54 GHz - 2.65 GHz	143.20 mW	17M9W7D	0.07 ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for Part 22 and Part 27 for frequencies below 1 GHz, EIRP for Part 24 and Part 27 for frequencies above 1 GHz. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission exposure conditions are 1.17 W/kg, 0.38 W/kg, 0.53 W/kg, and 1.29 W/kg, respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
