2ADYY-CL6Mobile Phone

TECNO MOBILE LIMITED

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Jan 05, 2024
Application Purpose: Original Equipment
Date of Application: Dec 31, 2023
Equipment Note: Mobile Phone
Frequency Range: 2402.00000000 - 2480.00000000
Company: TECNO MOBILE LIMITED
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CL6 User Manual Exploded diagram specification 1 OLED_678 2 LCM_HEAT_FILM 3 FRONT_COVER 4 SIM CONNECTOR 5 0_50M_FCAM_BRACKET_RN M 6 BATTERY 7 MAI N_BOARD 8 32M CAMERA 9 50M CAMERA 10 8W CAMERA 11 2M CAMERA 12 SIDE KEY FPC 13 COAXIAL CABLE 14 RECEIVER 15 LCM_CON_HEAT_SINK 16 MIDDLE HOUSING B-COVER 17 8W CONDUCTIVE ADHESIVE 18 R-MAI N CAM-CON-COP-FOI L 19 2M CAMERA RUBBER 20 SCREW M1.4 L3.5 21 2M CANERA DECORECTION 22 BATTERY COVER 23 SCREW M1.2 L1.7 24 CAM_GLASS DECPRATIOPN 25 CAMERA DECPRATIOPN 26 CAMERA FILM 27 SCREW M1.2 L1.7 28 SPK BOX 29 MAIN CONNECTOR ZIF/BTB) 30 SUB BOARD 31 FINGERPRINT 32 MOTOR 33 AU DI O JACK RU BBER 34 TYPE-C USB RUBBER Know your phone 1. Front camera 2. Volume + button 3. Volume - button 4. Power button 5. NFC SIM/SD card installation 1. Power off your phone. 2. Refer to the following picture for SIM/SD card installation. Charging the phone You can charge your phone with a charger or by connecting it to a computer using a USB cable (comes with the phone). Use only TECNO chargers and cables. Other chargers or cables may damage the phone and invalidate its warranty. FCC Caution 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This mobile phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: CL6 (FCC ID: 2ADYY-CL6) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 1.117 W/kg and when properly worn on the body is 0.958 W/kg. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 1.0 cm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. HiOS runs on Android TM OS. Android is a trademark of Google LLC.

Attestation Statements

TECNO MOBILE LIMITED * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 12/30/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2ADYY-CL6 FRN of Grantee: 0024206328 Per section 2.911(d)(7) of the FCC rules, TECNO MOBILE LIMITED (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Stariver Consulting Company FCC Registration Number (FRN): 0033400433 Company Address: 2363 James St #1098 Syracuse, NY 13206, USA Agent Name: Chong He Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed: Signed: Signed: Printed name: Yiting Luo Printed name: Chong He Title: Manager Title: Manager Company Name: TECNO MOBILE LIMITED Company Name: Stariver Consulting Company Date: 12/30/2023 Date: 12/30/2023

Attestation Statements

TECNO MOBILE LIMITED Covered Equipment Certification Attestation Letter 11/28/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2ADYY-CL6 TECNO MOBILE LIMITED (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the currentCovered List, the applicant should include an explanation on why the equipment is not “covered” equipment. TECNO MOBILE LIMITED(“the applicant”) certifies that, as of the date of the filing of the application, the applicantis not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Yiting Luo Title: Manager Company Name: TECNO MOBILE LIMITED Date: 11/28/2023

Cover Letter(s)

TECNO MOBILE LIMITED DATE :2023-11-28 Equipment Autorisation Division Federal Communications Commission 7345 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADYY-CL6 Product Name: Mobile Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics  Block diagram  Operation description Tune up BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2023-11-28 By: Yiting Luo SignaturePrinted Title: Manager On behalf of : TECNO MOBILE LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

TECNO MOBILE LIMITED DATE :2023-11-28 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADYY-CL6 Product Name: Mobile Phone Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.: Test Setup Photos External Photos Internal Photos User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. <Signature> Name Yiting Luo Title Manager CompanyTECNO MOBILE LIMITED

Cover Letter(s)

TECNO MOBILE LIMITED Date: 2023-11-28 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC.to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Dated this 2023-11-728 By: Yiting Luo Signature Printed Title: Manager On behalf of : INFINIX MOBILITY LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

TECNO MOBILE LIMITED DATE:2023-11-28 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint JianYan Testing Group Shenzhen Co., Ltd.; No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqia o Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China.； Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. F or instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with TECNO MOBILE LIMITED / FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT HONGKONG Dated this 2023-11-28 By: Y iting Luo Signature Printed Title: Manager On behalf of : TECNO MOBILE LIMITED Telephone: +86 0755-61803856

External Photos

Internal Photos

JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 11 EUT Internal Photos JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 6 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 7 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 8 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 9 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 10 of 11 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 11 of 11 ------End------

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R14-2300164 This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Report No.: JYTSZ-R14-2300164 Applicant: TECNO MOBILE LIMITED Address of Applicant: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT HONGKONG Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: CL6 Trade mark TECNO FCC ID: 2ADYY-CL6 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 25 Nov., 2023 ~ 09 Dec., 2023 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 1.117 Body: 0.958 Hotspot: 1.192 Project by: Date: 25 Dec., 2023 Project Engineer Reviewed by: Date: 25 Dec., 2023 Senior Engineer Approved by: Date: 25 Dec., 2023 Manager Report No.: JYTSZ-R14-2300164 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-286-C Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 2 of 153 2 Version Version No. Date Description 00 25 Dec., 2023 Original Report No.: JYTSZ-R14-2300164 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-286-C Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 3 of 153 3 Contents 1 COVER PAGE ............................................................................................................................................................ 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 7 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 7 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 7 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 9 5.4 ENVIRONMENT OF TEST SITE ....................................................................................................................................................... 11 5.5 TEST SAMPLE PLAN ..................................................................................................................................................................... 11 5.6 LABORATORY FACILITY ........................................................................................................................................................................ 11 5.7 TEST LOCATION ........................................................................................................................................................................... 11 6 INTRODUCTION ................................................................................................................................................. 12 6.1 INTRODUCTION ............................................................................................................................................................................. 12 6.2 SAR DEFINITION .......................................................................................................................................................................... 12 7 RF EXPOSURE LIMITS ..................................................................................................................................... 13 7.1 UNCONTROLLED ENVIRONMENT ................................................................................................................................................... 13 7.2 CONTROLLED ENVIRONMENT ....................................................................................................................................................... 13 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................. 13 8 SAR …

Text truncated - open the document above for the full version.

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 1 of 65 Appendix C: System Calibration Certificate JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 2 of 65 Calibration information for E-field probes JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 3 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 4 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 5 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 6 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 7 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 8 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 9 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 10 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 11 of 65 Calibration information for Dipole JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 12 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 13 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 14 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 15 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 16 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of China. Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 17 of 65 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2311069 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community,Xinqiao Street, Bao'an District, Shenzhen, Guangdong,People's Republic of C…

Text truncated - open the document above for the full version.

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2301638 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page FCC RF Test Report (Bluetooth) Report No.: JYTSZ-R12-2301638 Applicant: TECNO MOBILE LIMITED Address of Applicant: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT HONGKONG Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: CL6 Trade Mark: TECNO FCC ID: 2ADYY-CL6 Applicable Standards: FCC CFR Title 47 Part 15C (§15.247) Date of Sample Receipt: 23 Nov., 2023 Date of Test: 24 Nov., to 22 Dec., 2023 Date of Report Issued: 25 Dec., 2023 Test Result: PASS Project by: Date: 25 Dec., 2023 Project Engineer Reviewed by: Date: 25 Dec., 2023 Senior Engineer Approved by: Date: 25 Dec., 2023 Manager Report No.: JYTSZ-R12-2301638 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-149-C1 Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 43 Version 1 Version No. Date Description 00 25 Dec., 2023 Original Report No.: JYTSZ-R12-2301638 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-149-C1 Project No.: JYTSZR2311068 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 43 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ...........................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Yiting Luo

[email protected]86-755-61803856Fax: +86-755-33979211

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.51 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. This device is approved for use in the handset described in this filing. SAR compliance for body-worn operations is restricted to belt-clips, holsters, or similar accessories that have no metallic component in the assembly and which provide at least 1 cm separation between the device including its antenna and the body of user. End-users must be informed of the body-worn accessory operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission exposure conditions are < 0.10 W/kg, < 0.10 W/kg, < 0.10 W/kg, and 1.20 W/kg, respectively.
