2ADYY-H3-LWireless Earphone

User Manual Wireless Earphone Model：H3 Hereby, TECNO MOBILE LIMITED. declares that this Wireless Earphone is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. WELCOME Thank you for choosing our products. The h3 wirelessearphone has a fashionable design, powerful functions, and highcompatibility, to provide you with hands-free convenience whenmaking calls. PACKAGE CONTENT 2*H3 Bluetooth earphones 1* H3 charging box 1* Charging cable 1* User Manual 2* Large ear tip 2* Medium ear tip (fitted on the earphones) 2* Small ear tip PRODUCT OVERVIEW 1. Charging box 2. Earphones 3. Charging box indicator light 4. Charging port 5. Earphone indicator light 6. Earphone touch area 7. Ear tip 8. Earphone charging contacts Controls and functions Power on 1. Open the charging box, and the earphones are automatically turned on. Power off 1. Put the earphones back into the charging box and close the box, and the earphones are turned off automatically. Bluetooth pairing (with a mobile phone) 1. In case of pairing for the first time, the left and right earphones will automatically pair with each other after being turned on and enter the waiting-for-pairing status. 2. If the earphones have been paired with a Bluetooth device, the left and right earphones will automatically pair with each other after being turned on and then pair with that device. When there is no pairing activity for about 10 seconds, the earphones will enter the wait-for-pairing status; if not paired in about 5 minutes, the earphones will be turned off automatically. Noise reduction mode 1. Press and hold the touch area for 2 seconds to enable the transparency mode, and the ice blue and orange breathing LEDs are on. 2. Press and hold the touch area for 2 seconds to enable noise reduction, and the ice blue and orange breathing LEDs are on. 3. Press and hold the touch area for 2 seconds to disable noise reduction. Pairing with devices 1. After the earphones enter the waiting-for-pairing status, enable Bluetooth on the device and find TECNO-Hipods-H3 on the list of devices available for pairing, and tap to pair. Pop-ups on mobile phones 1. If the earphones have been paired with a mobile phone, to pair again, open the charging box and a pop-up window will automatically appear on the mobile phone. Play/pause music 1. When playing music, double tap the touch area to pause, and double tap again to play. Answer phone calls 1. When there is an incoming call, double tap the touch area to answer the call. Disconnection with the mobile phone when placed beyond a certain distance 1. When the earphones are placed beyond a certain distance from the mobile phone and thus become disconnected, the earphones will enter the waiting-for -pairing status. If there is no device that pairs with the earphones for 5 minutes, the earphones will be turned off automatically. Earphones charging 1. Put the earphones in the charging box, close the charging box, and charging starts automatically. Charging box charging 1. When being charged, the charging box will flash in white. When the charging box is fully charged, the white light will keep on. After the charging cable is unplugged, the white light will go out. Basic Features of Product Product Name H3 Earphone battery capacity 40mAh*2 Charging box battery capacity 350mAh Charging Voltage/Current 5V/40mA Music Playing Time Approx 4H Calling Time Approx 3.5H Standby Time Approx 90H Transmission range ≥ 10m Bluetooth TECNO-Hipods-H3 Operating Temperature 0°C ~ 45°C Storage Temperature -20°C ~ 60°C Earphone Indicator Light Earphone Status Indicator light status Power On Ice blue light on for 1 second Power Off Orange light on for 2 seconds Earphone low battery The earphones flash in orange once every second and the flashing continues for 5 seconds, with an interval of 10 seconds. The low battery reminder is activated every 3 minutes. Charging box low battery When the charging box is opened or closed, the charging box flashes quickly in white for 4 seconds. CUSTOMER SERVICE WARRANTY CERTIFICATE https://www.carlcare.com Name： Address： Telephone number： Date of purchase： Store name： S/N： TECNO MOBILE LIMITED TM and ©2019 TECNO Corporation. All rightsreserved. Otherproduct and company names mentioned herein may betrademarks or trade names of their respective owners. Specifications are subject to change without notice. Modelnames and the availability of particular products may vary byregion. Warning changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. RF Expo…

Text truncated - open the document above for the full version.

TECNO MOBILE LIMITED Address: FLAT 39 8/F BLOCK D WAH LOK INDUSTRIAL CENTRE 31-35 SHAN MEI STREET FOTAN NT, Hong Kong Tel.: +86-0755-61803856 E-mail: [email protected] FCC Confidential Authorization Date: 2021-8-3 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ADYY-H3-L In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, TECNO MOBILE LIMITED hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description As well as short-term confidential treatment of information accompanying this application for a period of 180 days after grant is issued as outlined below: • Internal Photos • User’s Manual • External Photos • Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature Yiting Luo Project Manager

TECNO MOBILE LIMITED Address: FLAT 39 8/F BLOCK D WAH LOK INDUSTRIAL CENTRE 31-35 SHAN MEI STREET FOTAN NT, Hong Kong Tel.: +86-0755-61803856 Email: [email protected] Date: 2021-8-3 FCC certification No. Cover Letter We, TECNO MOBILE LIMITED, hereby submit justification for placing the FCC certification No. in the associated charging case. According to the FCC regulation, the FCC certification No. should be printed on the earbuds, but as the earbuds are too small to print the label (FCC ID: 2ADYY-H3-L) , it will be moved to the charging case. The details are as below: A. Side surface (A): The side surface does not provide enough physical space to fit the printing of the FCC certification No. according to below reference picture. B. Top cover (B): The top cover does not provide enough physical space to fit the printing of the FCC certification No. according to below reference picture. Conclusion: Based on the above description of area A to B, we conclude that the device is unquestionably too small for enabling the FCC certification No. to be printed onto any surface. We therefore request to move the FCC certification No. to the charging case. Label: Best regards, Signature: Yiting Luo Project Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 1 of 6 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 2 of 6 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 3 of 6 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 4 of 6 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 5 of 6 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 6 of 6

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 1 of 3 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 2 of 3 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210707-27715E-RF Page 3 of 3 Antenna

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.247 TEST REPORT For TECNO MOBILE LIMITED FLAT 39 8/F BLOCK D WAH LOK INDUSTRIAL CENTRE 31-35 SHAN MEI STREET FOTAN NT Hong Kong FCC ID: 2ADYY-H3-L Report Type: Original Report Product Type: Wireless Earphone Re port Number: SZ1210707-27715E-00B Re port Date: 2021-08-02 Reviewed B y: Jacob Kong RF En gineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) , 6F, 7F, the 3rd Phase of Wan Li Industrial Building D, Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1210707-27715E-00B FCC Part 15.247 Page 2 of 69 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 SPECIAL ACCESSORIES ................................................................................................................................................. 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 6 EXTERNAL I/O CABLE .................................................................................................................................................. 6 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 TEST EQUIPMENT LIST ........................................................................................................................................... 9 FCC§15.247 (i), §1.1307 (b) (1) &§2.1093 – RF EXPOSURE ...................................................................................... 10 APPLICABLE STANDARD ............................................................................................................................................ 10 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 11 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 EUT SETUP ................................................................................................................................................................ 12 EMI TEST RECEIVER SETUP ....................................................................................................................................... 12 TEST PROCEDURE ...................................................................................................................................................... 12 CORRECTED FACTOR & MARGIN CALCULATION ....................................................................................................... 13 TEST DATA ................................................................................................................................................................ 13 FCC §15.205, §15.209 & §15.247(d) – RADIATED EMISSIONS ..................................................................…
