E E x x p p l l o o s s i i o o n n d d i i a a g g r r a a m m s s p p e e c c i i f f i i c c a a t t i i o o n n 1 FL(CTP+LCM) 6.52HD+ KE5 Black HX V1.0 2 Astigmatism film 3.5*1.2*0.05 KE5 3 FPC Side key BB4 4 Astigmatism film 3.5*1.2*0.05 KE5 5 Shield Seal Cop foil 20.7*15.5 *0.06 KE5 6 LT sensor Seal rubber KE5 Black 7 F CAM Seal rubber KE5 Black 8 FPC REC KC1 9 FM(ICNF7332AL)04 Aqua Blue19 fingerchip 10 CAM FF 8W GC6153 CSP W6003 XCG V_1.0 11 CAM AF 13M S5K3L6 B B 5P B ST V1.0 12 CAM FF 8M GC8034 A B 4P B TXD V1.0 13 F CAM con fb 10.75*7.75*0.1 KE5 14 DistanceSensorSeal mylar10.7*4.8*0.03 KE5 15 F LED-Flashseal mylar 8*4.8*0.03 KE5 16 PCBA MB H6123 A1 32GB+2GB V1.0 17 REC 1206W H20 broadband H:SPL 50mW Goer 18 R MAIN CAM Con foams 12.61*10.46*0.2 KE5 19 BATT Seal rubber 6.15*4.0*0.65 KE5 20 LCM Con Seal rubber 13.1*3.7 *0.65 KE5 21 R hsg asm KE5 Black PC 22 Bat imp steel KE5 23 R CAM lens KE5 Glass 0.5mm Black 24 mc screw M1.4*L2.5*D2.5 *H0.5 silver glue 25 Bat cover asm KE5 Aqua Blue PC 26 mc screw M1.4*L3.5*D2.5 *H0.5 silver 27 SPK frame asm KE5 Black PC 28 Coaxial cable ECT D 147.9 X653C 29 Bat TECNO BL 49FT 4900mAh FH IN 30 PCBA SUB H6123 1 A V1.0 31 FP graphite film 37.14*28.8 *0.05 KE5 32 FP In mylar 4*4*0.05 KE5 33 FP support foam 13.26*12.78 *0.6 KE5 34 FP con foams 7.5*3.5*1 KE5 35 ZIF mylar 9.5*3.5*0.05 KE5 36 Motor COIN 1027 L22 H JX 37 SPK 1115 SPR H3.0 aluminiumfilmRoHS Goer 38 SUB PCB Con Seal rubber KE5 39 FPC SPK KE5 Know your phone 1. Front camera 2. Volume key 3. Power key SIM/SD card installation 1. Power off mobile. 2. Refer to the following picture for SIM / SD card installation. C C h h a a r r g g i i n n g g t t h h e e p p h h o o n n e e You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone). 1. Please remind the front and back of the plug. 2. Use only TECNO charger and cables. Other chargers or cables may damage the device. This will invalidate your phone warranty. FCC Caution Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Information to user. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: SAR tests are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. Before a new model phone is a available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure limit established by the FCC, tests for each phone are performed in positions and locations as required by the FCC. For body worn operation, this model phone has been tested and meets the FCC RF exposure guidelines when used with an accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 10mm from the body. Non-compliance with the above restrictions may result in violation of RF exposure guidelines.
