2ADYY-T1102Tablet

Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 1 of 244 Appendix B Test Information: Serial No.:38S5-2Test Date:2025/09/10~2025/09/15 Test Site:RFTest Mode:Transmitting Tester:Loge LongTest Result:Pass Environmental Conditions: Temperature: (°C) 25.3~27.6 Relative Humidity: (%) 53~71 ATM Pressure: (kPa) 100.3~100.6 Test Equipment List and Details: ManufacturerDescriptionModelSerial NumberCalibration DateCalibration Due Date Minl-Clrcuits Coaxial Power Splitters & Combiner ZFRSC-183-S+SF4482016142025/02/252026/02/24 Micro-CoaxCoaxial CableUFB205A323308-0152025/06/012026/05/31 HUBER+SUHNERCoaxial Attenuator6610_SMA-50-100642025/06/062026/06/05 EastsheepCoaxial Attenuator5W-N-JK-6G-10dBF-08-EM5042025/06/062026/06/05 R&SSpectrum AnalyzerFSV401019472025/07/282026/07/27 R&S Wideband Radio Communication Tester CMW5001492162025/07/282026/07/27 GLOBAL TEMP&HUMI Test Chamber BTH-150-40301732025/08/012026/07/31 All-sunMultimeterEM305A83488972025/08/182026/08/17 TDK-LambdaDC Power SupplyZ+60-14F-08-EM038-1N/AN/A * Statement of Traceability: Bay Area Compliance Laboratories Corp. (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 2 of 244 Frequency stability vs. temperature &Frequency stability vs. voltage Compliance FCC For 90S LTE B26_1, TN/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T1/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T2/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T3/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T4/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T5/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 3 of 244 LTE B26_1, T6/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T7/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, T8/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, TN/VH Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE B26_1, TN/VL Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass Note: Frequency Error (ppm)=Frequency Error (MHz)/Test Channel(MHz)*10 6 TN: 20°C; T1: -30°C; T2: -20°C; T3: -10°C; T4: 0°C; T5: 10°C; T6: 30°C; T7: 40°C; T8: 50°C. VN: Normal Voltage; VL: Low Voltage; VH: High Voltage. Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 4 of 244 FCC Part 22H LTE Band 5, TN/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T1/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T2/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T3/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T4/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T5/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 5 of 244 LTE Band 5, T6/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T7/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, T8/VN Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, TN/VH Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass LTE Band 5, TN/VL Frequency Error Mode Test Channel (MHz) (Hz)(ppm) Limit (ppm) Verdict [email protected]±2.5Pass [email protected]±2.5Pass Note: Frequency Error (ppm)…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.:2502W27143E-RF-00E Report Template Version: FCC-PCE-V1.2 Page 95 of 127 PCS 1900: Spurious Emissions at Antenna Terminal Channel GSM Lowest Middle Highest Note: The maximum path attenuation of 30MHz-20GHz was added into the offset. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.:2502W27143E-RF-00E Report Template Version: FCC-PCE-V1.2 Page 96 of 127 4.5 Transmitter unwanted emissions-Out of band emission: 4.5.1 Applicable Standard FCC §22.917 (a) Out of band emissions. The power of any emission outside of the authorized operating frequency ranges must be attenuated below the transmitting power (P) by a factor of at least 43 + 10 log(P) dB. (b) Measurement procedure. Compliance with these rules is based on the use of measurement instrumentation employing a reference bandwidth as follows: (1) In the spectrum below 1 GHz, instrumentation should employ a reference bandwidth of 100 kHz or greater. In the 1 MHz bands immediately outside and adjacent to the frequency block, a resolution bandwidth of at least one percent of the emission bandwidth of the fundamental emission of the transmitter may be employed. A narrower resolution bandwidth is permitted in all cases to improve measurement accuracy, provided that the measured power is integrated over the full required reference bandwidth (i.e., 100 kHz or 1 percent of emission bandwidth, as specified). The emission bandwidth is defined as the width of the signal between two points, one below the carrier center frequency and one above the carrier center frequency, outside of which all emissions are attenuated at least 26 dB below the transmitter power. (2) In the spectrum above 1 GHz, instrumentation should employ a reference bandwidth of 1 MHz FCC §24.238 The rules in this section govern the spectral characteristics of emissions in the Broadband Personal Communications Service. (a) Out of band emissions. The power of any emission outside of the authorized operating frequency ranges must be attenuated below the transmitting power (P) by a factor of at least 43 + 10 log(P) dB. (b) Measurement procedure. Compliance with these rules is based on the use of measurement instrumentation employing a resolution bandwidth of 1 MHz or greater. However, in the 1 MHz bands immediately outside and adjacent to the frequency block a resolution bandwidth of at least one percent of the emission bandwidth of the fundamental emission of the transmitter may be employed. A narrower resolution bandwidth is permitted in all cases to improve measurement accuracy provided the measured power is integrated over the full required measurement bandwidth (i.e. 1 MHz or 1 percent of emission bandwidth, as specified). The emission bandwidth is defined as the width of the signal between two points, one below the carrier center frequency and one above the carrier center frequency, outside of which all emissions are attenuated at least 26 dB below the transmitter power. (c) Alternative out of band emission limit. Licensees in this service may establish an alternative out of band emission limit to be used at specified band edge(s) in specified geographical areas, in lieu of that set forth in this section, pursuant to a private contractual arrangement of all affected licensees and applicants. In this event, each party to such contract shall maintain a copy of the contract in their station files and disclose it to prospective assignees or transferees and, upon request, to the FCC. (d) Interference caused by out of band emissions. If any emission from a transmitter operating in this service results in interference to users of another radio service, the FCC may require a greater attenuation of that emission than specified in this section. FCC §27.53 (a) For operations in the 2305-2320 MHz band and the 2345-2360 MHz band, the power of any emission outside a licensee's frequency band(s) of operation shall be attenuated below the transmitter power P (with averaging performed only during periods of transmission) within the licensed band(s) of operation, in watts, by the following amounts: Bay Area Compliance Laboratories Corp. (Dongguan) Report No.:2502W27143E-RF-00E Report Template Version: FCC-PCE-V1.2 Page 97 of 127 (4)For mobile and portable stations operating in the 2305-2315 MHz and 2350-2360 MHz bands: (i) By a factor of not less than: 43 + 10 log (P) dB on all frequencies between 2305 and 2320 MHz and on all frequencies between 2345 and 2360 MHz that are outside the licensed band(s) of operation, not less than 55 + 10 log (P) dB on all frequencies between 2320 and 2324 MHz and on all frequencies between 2341 and 2345 MHz, not less than 61 + 10 log (P) dB on all frequencies between 2324 and 2328 MHz and on all frequencies between 2337 and 2341 MHz, and not less than 67 + 10 log (P) dB on all frequencies between 2328 and 2337 MHz; (ii) By a factor of not less than 43 + 10 log (P) dB on all frequencies between 2300 and 2305 MHz, 55 + 10 log (P) dB on all frequencies between 2296 and 2300 MHz, 61 + 10 log (P) dB on all frequencies between 2292 and 2296 MHz, 67 + 10 log (P) dB on all frequencies between 2288 and 2292 MHz, and 70 + 10 log (P) dB below 2288 MHz; (iii) By a factor of not less than 43 + 10 log (P) dB on all frequencies between 2360 and 2365 MHz, and not less than 70 + 10 log (P) dB above 2365 MHz. (c) For operations in the 746-758 MHz band and the 776-788 MHz band, the power of any emission outside the licensee's frequency band(s) of operation shall be attenuated below the transmitter power (P) within the licensed band(s) of operation, measured in watts, in accordance with the following: (1) On any frequency outside the 746-758 MHz band, the power of any emission shall be attenuated outside the band below the transmitter power (P) by at least 43 + 10 log (P) dB; (2) On any frequency outside the 776-788 MHz band, the power of any emission shall be attenuated outside the band below the transmitter power (P…

Text truncated - open the document above for the full version.

TEST REPORT Applicant: TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT HONGKONG Product Name: Tablet F C C I D : 2ADYY-T1102 Standard(s): 47 CFR Part 2, 47 CFR Part 22, Subpart H 47 CFR Part 24, Subpart E 47 CFR Part 27 47 CFR Part 90 ANSI C63.26-2015 Report Number: 2502W27143E-RF-00E Report Date: 2025/11/1 The above device has been tested and found compliant with the requirement of the relative standards by Bay Area Compliance Laboratories Corp. (Dongguan). Reviewed By: Alice Tan Approved By: Pedro Yun Title: RF Engineer Title: RF Supervisor Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Note: The information marked ▲ is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with ★.This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Each test item follows the test standard(s) without deviation. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.:2502W27143E-RF-00E Report Template Version: FCC-PCE-V1.2 Page 2 of 127 CONTENTS DOCUMENT REVISION HISTORY ................................................................................................. 4 1. GENERAL INFORMATION ........................................................................................................... 5 1.1 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST ............................................................................ 5 1.2 ACCESSORY INFORMATION ........................................................................................................................ 5 1.3 OPERATION VOLTAGE(VDC)▲ ................................................................................................................. 5 1.4 TRANSMISSION ANTENNA INFORMATION▲ .............................................................................................. 6 1.5 EQUIPMENT MODIFICATIONS ..................................................................................................................... 6 2. SUMMARY OF TEST RESULTS ................................................................................................... 7 3. DESCRIPTION OF TEST CONFIGURATION ............................................................................ 8 3.1 EUT OPERATION CONDITION: ................................................................................................................... 8 3.2 SUPPORT EQUIPMENT LIST AND DETAILS ............................................................................................... 15 3.3 SUPPORT CABLE LIST AND DETAILS ........................................................................................................ 15 3.4 BLOCK DIAGRAM OF TEST SETUP ............................................................................................................ 15 3.5 TEST FACILITY .......................................................................................................................................... 17 3.6 MEASUREMENT UNCERTAINTY ................................................................................................................ 17 4. TEST RESULTS .............................................................................................................................. 18 4.1 TRANSMITTER OUTPUT POWER AND EQUIVALENT RADIATED POWER: ................................................. 18 4.1.1 Applicable Standard ............................................................................................................................................ 18 4.1.2 Test Setup Block ................................................................................................................................................. 19 4.1.3 Test Procedure ..................................................................................................................................................... 21 4.1.4 Test Results ......................................................................................................................................................... 23 4.2 OCCUPIED BANDWIDTH: ........................................................................................................................... 78 4.2.1 Applicable Standard ............................................................................................................................................ 78 4.2.2 Test Setup Block ................................................................................................................................................. 80 4.2.3 Test Procedure ..................................................................................................................................................... 81 4.2.4 Test Results ......................................................................................................................................................... 82 4.3 FREQUENCY STABILITY: ........................................................................................................................... 85 4.3.1 Applicable Standard ............................................................................................................................................ 85 4.3.2 Tes…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 228 of 244 FCC Part 27 LTE Band 4, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~18.55GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 1.4MHz_High_QPSK_1@0(30MHz~18.55GHz) 3MHz_Low_QPSK_1@0(30MHz~18.55GHz) 3MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 3MHz_High_QPSK_1@0(30MHz~18.55GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 229 of 244 5MHz_Low_QPSK_1@0(30MHz~18.55GHz) 5MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 5MHz_High_QPSK_1@0(30MHz~18.55GHz) 10MHz_Low_QPSK_1@0(30MHz~18.55GHz) 10MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 10MHz_High_QPSK_1@0(30MHz~18.55GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 230 of 244 15MHz_Low_QPSK_1@0(30MHz~18.55GHz) 15MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 15MHz_High_QPSK_1@0(30MHz~18.55GHz) 20MHz_Low_QPSK_1@0(30MHz~18.55GHz) 20MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 20MHz_High_QPSK_1@0(30MHz~18.55GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 231 of 244 LTE Band 7, Normal 1RB was the worst case 5MHz_Low_QPSK_1@0(30MHz~26.7GHz) 5MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 5MHz_High_QPSK_1@0(30MHz~26.7GHz) 10MHz_Low_QPSK_1@0(30MHz~26.7GHz) 10MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 10MHz_High_QPSK_1@0(30MHz~26.7GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 232 of 244 15MHz_Low_QPSK_1@0(30MHz~26.7GHz) 15MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 15MHz_High_QPSK_1@0(30MHz~26.7GHz) 20MHz_Low_QPSK_1@0(30MHz~26.7GHz) 20MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 20MHz_High_QPSK_1@0(30MHz~26.7GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 233 of 244 LTE Band 12, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~8.16GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~8.16GHz) 1.4MHz_High_QPSK_1@0(30MHz~8.16GHz) 3MHz_Low_QPSK_1@0(30MHz~8.16GHz) 3MHz_Middle_QPSK_1@0(30MHz~8.16GHz) 3MHz_High_QPSK_1@0(30MHz~8.16GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 234 of 244 5MHz_Low_QPSK_1@0(30MHz~8.16GHz) 5MHz_Middle_QPSK_1@0(30MHz~8.16GHz) 5MHz_High_QPSK_1@0(30MHz~8.16GHz) 10MHz_Low_QPSK_1@0(30MHz~8.16GHz) 10MHz_Middle_QPSK_1@0(30MHz~8.16GHz) 10MHz_High_QPSK_1@0(30MHz~8.16GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 235 of 244 LTE Band 13, Normal 1RB was the worst case 5MHz_Low_QPSK_1@0(30MHz~8.87GHz) 5MHz_Low_QPSK_1@0(763MHz~775MHz) 5MHz_Low_QPSK_1@0(793MHz~806MHz) 5MHz_Low_QPSK_1@0(1559MHz~1610MHz) 5MHz_High_QPSK_1@0(30MHz~8.87GHz) 5MHz_High_QPSK_1@0(763MHz~775MHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 236 of 244 5MHz_High_QPSK_1@0(793MHz~806MHz) 5MHz_High_QPSK_1@0(1559MHz~1610MHz) 10MHz_Middle_QPSK_1@0(30MHz~8.87GHz) 10MHz_Middle_QPSK_1@0(763MHz~775MHz) 10MHz_Middle_QPSK_1@0(793MHz~806MHz) 10MHz_Middle_QPSK_1@0(1559MHz~1610MHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 237 of 244 LTE Band 17, Normal 1RB was the worst case 5MHz_Low_QPSK_1@0(30MHz~8.16GHz) 5MHz_Middle_QPSK_1@0(30MHz~8.16GHz) 5MHz_High_QPSK_1@0(30MHz~8.16GHz) 10MHz_Low_QPSK_1@0(30MHz~8.16GHz) 10MHz_Middle_QPSK_1@0(30MHz~8.16GHz) 10MHz_High_QPSK_1@0(30MHz~8.16GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 238 of 244 LTE Band 38, Normal 1RB was the worst case 5MHz_Low_QPSK_1@0(30MHz~27.2GHz) 5MHz_Middle_QPSK_1@0(30MHz~27.2GHz) 5MHz_High_QPSK_1@0(30MHz~27.2GHz) 10MHz_Low_QPSK_1@0(30MHz~27.2GHz) 10MHz_Middle_QPSK_1@0(30MHz~27.2GHz) 10MHz_High_QPSK_1@0(30MHz~27.2GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 239 of 244 15MHz_Low_QPSK_1@0(30MHz~27.2GHz) 15MHz_Middle_QPSK_1@0(30MHz~27.2GHz) 15MHz_High_QPSK_1@0(30MHz~27.2GHz) 20MHz_Low_QPSK_1@0(30MHz~27.2GHz) 20MHz_Middle_QPSK_1@0(30MHz~27.2GHz) 20MHz_High_QPSK_1@0(30MHz~27.2GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 240 of 244 LTE Band 41, Normal 1RB was the worst case 5MHz_Low_QPSK_1@0(30MHz~27.9GHz) 5MHz_Middle_QPSK_1@0(30MHz~27.9GHz) 5MHz_High_QPSK_1@0(30MHz~27.9GHz) 10MHz_Low_QPSK_1@0(30MHz~27.9GHz) 10MHz_Middle_QPSK_1@0(30MHz~27.9GHz) 10MHz_High_QPSK_1@0(30MHz~27.9GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 241 of 244 15MHz_Low_QPSK_1@0(30MHz~27.9GHz) 15MHz_Middle_QPSK_1@0(30MHz~27.9GHz) 15MHz_High_QPSK_1@0(30MHz~27.9GHz) 20MHz_Low_QPSK_1@0(30MHz~27.9GHz) 20MHz_Middle_QPSK_1@0(30MHz~27.9GHz) 20MHz_High_QPSK_1@0(30MHz~27.9GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 242 of 244 LTE Band 66, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~18.8GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 1.4MHz_High_QPSK_1@0(30MHz~18.8GHz) 3MHz_Low_QPSK_1@0(30MHz~18.8GHz) 3MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 3MHz_High_QPSK_1@0(30MHz~18.8GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 243 of 244 5MHz_Low_QPSK_1@0(30MHz~18.8GHz) 5MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 5MHz_High_QPSK_1@0(30MHz~18.8GHz) 10MHz_Low_QPSK_1@0(30MHz~18.8GHz) 10MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 10MHz_High_QPSK_1@0(30MHz~18.8GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 244 of 244 15MHz_Low_QPSK_1@0(30MHz~18.8GHz) 15MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 15MHz_High_QPSK_1@0(30MHz~18.8GHz) 20MHz_Low_QPSK_1@0(30MHz~18.8GHz) 20MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 20MHz_High_QPSK_1@0(30MHz~18.8GHz) ***** END *****

Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 206 of 244 3MHz_Low_16QAM_1@0 3MHz_Low_16QAM_15@0 3MHz_High_QPSK_1@14 3MHz_High_QPSK_15@0 3MHz_High_16QAM_1@14 3MHz_High_16QAM_15@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 207 of 244 5MHz_Low_QPSK_1@0 5MHz_Low_QPSK_25@0 5MHz_Low_16QAM_1@0 5MHz_Low_16QAM_25@0 5MHz_High_QPSK_1@24 5MHz_High_QPSK_25@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 208 of 244 5MHz_High_16QAM_1@24 5MHz_High_16QAM_25@0 10MHz_Low_QPSK_1@0 10MHz_Low_QPSK_50@0 10MHz_Low_16QAM_1@0 10MHz_Low_16QAM_50@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 209 of 244 10MHz_High_QPSK_1@49 10MHz_High_QPSK_50@0 10MHz_High_16QAM_1@49 10MHz_High_16QAM_50@0 15MHz_Low_QPSK_1@0 15MHz_Low_QPSK_75@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 210 of 244 15MHz_Low_16QAM_1@0 15MHz_Low_16QAM_75@0 15MHz_High_QPSK_1@74 15MHz_High_QPSK_75@0 15MHz_High_16QAM_1@74 15MHz_High_16QAM_75@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 211 of 244 20MHz_Low_QPSK_1@0 20MHz_Low_QPSK_100@0 20MHz_Low_16QAM_1@0 20MHz_Low_16QAM_100@0 20MHz_High_QPSK_1@99 20MHz_High_QPSK_100@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 212 of 244 20MHz_High_16QAM_1@99 20MHz_High_16QAM_100@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 213 of 244 Duty Cycle FCC Part 27 LTE Band 38, Normal Mode Ton (ms) Ton+Toff (ms) Duty Cycle (%) Duty Cycle Factor(dB) [email protected] [email protected] [email protected] [email protected] [email protected] [email protected] [email protected] [email protected] LTE Band 41, Normal Mode Ton (ms) Ton+Toff (ms) Duty Cycle (%) Duty Cycle Factor(dB) [email protected] [email protected] [email protected] [email protected] [email protected] [email protected] [email protected] [email protected] Duty Cycle = Ton/(Ton+Toff)*100% Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 214 of 244 LTE Band 38, Normal 5MHz_Middle_QPSK_25@0 5MHz_Middle_16QAM_25@0 10MHz_Middle_QPSK_50@0 10MHz_Middle_16QAM_50@0 15MHz_Middle_QPSK_75@0 15MHz_Middle_16QAM_75@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 215 of 244 20MHz_Middle_QPSK_100@0 20MHz_Middle_16QAM_100@0 LTE Band 41, Normal 5MHz_Middle_QPSK_25@0 5MHz_Middle_16QAM_25@0 10MHz_Middle_QPSK_50@0 10MHz_Middle_16QAM_50@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 216 of 244 15MHz_Middle_QPSK_75@0 15MHz_Middle_16QAM_75@0 20MHz_Middle_QPSK_100@0 20MHz_Middle_16QAM_100@0 Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 217 of 244 Spurious Emissions at Antenna Terminal FCC For 90S LTE B26_1, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~9.24GHz) 1.4MHz_High_QPSK_1@0(30MHz~9.24GHz) 3MHz_Low_QPSK_1@0(30MHz~9.24GHz) 3MHz_High_QPSK_1@0(30MHz~9.24GHz) 5MHz_Low_QPSK_1@0(30MHz~9.24GHz) 5MHz_High_QPSK_1@0(30MHz~9.24GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 218 of 244 10MHz_Low_QPSK_1@0(30MHz~9.24GHz) 15MHz_Low_QPSK_1@0(30MHz~9.24GHz) LTE B26_3, Normal 1RB was the worst case 1.4MHz_Middle_QPSK_1@0(30MHz~9.24GHz) 3MHz_Middle_QPSK_1@0(30MHz~9.24GHz) 5MHz_Middle_QPSK_1@0(30MHz~9.24GHz) 10MHz_Middle_QPSK_1@0(30MHz~9.24GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 219 of 244 15MHz_Middle_QPSK_1@0(30MHz~9.24GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 220 of 244 FCC Part 22H LTE Band 5, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_High_QPSK_1@0(30MHz~9.49GHz) 3MHz_Low_QPSK_1@0(30MHz~9.49GHz) 3MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 3MHz_High_QPSK_1@0(30MHz~9.49GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 221 of 244 5MHz_Low_QPSK_1@0(30MHz~9.49GHz) 5MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 5MHz_High_QPSK_1@0(30MHz~9.49GHz) 10MHz_Low_QPSK_1@0(30MHz~9.49GHz) 10MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 10MHz_High_QPSK_1@0(30MHz~9.49GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 222 of 244 LTE B26_2, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_High_QPSK_1@0(30MHz~9.49GHz) 3MHz_Low_QPSK_1@0(30MHz~9.49GHz) 3MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 3MHz_High_QPSK_1@0(30MHz~9.49GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 223 of 244 5MHz_Low_QPSK_1@0(30MHz~9.49GHz) 5MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 5MHz_High_QPSK_1@0(30MHz~9.49GHz) 10MHz_Low_QPSK_1@0(30MHz~9.49GHz) 10MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 10MHz_High_QPSK_1@0(30MHz~9.49GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 224 of 244 15MHz_Low_QPSK_1@0(30MHz~9.49GHz) 15MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 15MHz_High_QPSK_1@0(30MHz~9.49GHz) Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 225 of 244 FCC Part 24E LTE Band 2, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~20.1GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~20.1…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Dongguan)Report No.:2502W27143E-RF-00E FCC-LTE-V1.0Page 189 of 244 5MHz_Low_16QAM_1@0 5MHz_Low_16QAM_25@0 5MHz_High_QPSK_1@24 5MHz_High_QPSK_25@0 5MHz_High_16QAM_1@24 5MHz_H…
