2ADYY-T420Mobile Phone

1 User Manual Mobile Phone FCCID: 2ADYY-T 420 TECNO MOBILE LIMITED P le a se read these instructions for use and have a good look at the illustration before using. RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN, HK. 2 Warning： This device complies with Part 15 of the FCC Rules. Operation is subject tothe following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses andcan radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 3 RF Exposure Information: The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device Types Mobile Phone (FCC ID: 2ADYY-T420) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use when properly worn on the body is 1.163W/kg and head is 0.903W/kg. This device was tested for typical body worn operations with the back of the handset kept 5mm from the body. To maintain complian ce with FCC RF exposure requirements, use accessories that maintain a 5mm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. 4 Thank you for choosing this mobile phone. For a better use of the phone, please read the manual carefully. This color-screen phone is designed for use on the GSM network. The phone supports dual-card online at the same time, you remove the two phones at the same time bring the trouble to truly enjoy a life of science and technology. Along with the basic communication function, it also provides you with practical functions to help with your work and life, such as English input methods, 64-chord ring tone, alarm clock, calendar, Bluetooth, powerful film recorder, mp3 and mp4 player, and memory card. In addition, the phone is programmed with a personalized interface and well-designed functions to satisfy your individual needs. 5 Contents CHAPTER 1 SAFETY INFORMATION······························································ 7 1.1 GENERAL PRECAUTIONS··································· 7 1.2 BAT T E RY PRECAUTIONS···································· 8 1.3 CHARGER PRECAUTIONS································· 10 CHAPTER 2 PHONE INTRODUCTION··························································· 12 2.1 SPECIFICATION················································ 12 2.2 SIM CARD······················································· 12 2.3 BAT T E RY························································· 14 2.4 DATA LINE······················································· 16 2.5 POWER ON/OFF THE PHONE····························· 16 CHAPTER 3 MENU DETAILS··········································································· 18 3.1 PHONEBOOK···················································· 18 3.2 MESSAGES······················································ 19 3.3 CALL CENTER·················································· 22 3.4 SETTINGS························································ 24 3.5 FACEBOOK······················································ 27 3.6 MULTIMEDIA··················································· 27 3.7 EXTRAS··························································· 30 3.8 PROFILES: ······················································· 32 6 3.9 SERVICES························································· 33 CHAPTER 4 INPUT METHODS······································································· 34 TROUBLE SHOOTING······················································································ 36 7 Chapter 1 Safety Information 1.1 General Precautions  Please turn off your phone in an airplane, hospital or areas where the phone may disturb the operation of sensitive or medical equipment. Please use your phone in accordance with the rules of the areas.  To prevent the disturbance of the radio wave from causing malfunction or other problems, do not use your phone around weak signal or high accuracy electronic equipment, especially otophone, pacemaker or other medical equipment, fire detector, auto-controlled door and devices.  Do not knock violently, shake or toss the phone; otherwise the phone may break down or cause fire.  Do not put the battery, phone, or the charger into a microwave oven or high tension apparatus; otherwise the phone may break down.  Do not use the phone in areas with a…

Text truncated - open the document above for the full version.

RF_743, Issue 02 Declaration of Authorization (to use documentation) We Name: TECNO MOBILE LIMITED Address: RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN, HK. City: HONG KONG Country: China Declare that: Name Representative of agent: WST Agent Company name: Shenzhen WST Testing Technology Co., Ltd. Address: 1F,No.9 Building,TGK Science & Technology Park Yangtian Rd., NO.72 Bao'an Dist. City: Shenzhen Country China may use our test reports and documentation of the following (already certified) product: Product description: Mobile Phone Type designation: T420 Trademark: Original FCC ID: 2ADYY-T420 Original Canada ID: ................. Original Japan certificate number: ................. for his own approval/certificate. Date: 2015. 5.29 City: Shenzhen Name: Robben Xie Function: Manager Signature: COMPANY LETTER HEAD

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: TECNO MOBILE LIMITED Address : RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN, City: H.K. Country: China To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2ADYY-T420 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2015-05-29 Name and signature of applicant: Robben Xie Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT

FCCID: 2ADYY-T420 Label Location on EUT FCC ID label: Size 20mm*30mm FCC ID:2ADYY-T420FCC ID:2ADYY-T420FCC ID:2ADYY-T420FCC ID:2ADYY-T420

Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT

Page 1 of 39 FCC SAR Compliance Test Report For TECNO MOBILE LIMITED ROOMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CENTRE, HARBOUR CITY, 17 CANTON ROAD, TSIM SHA TSUI, KOWLOON, HONG KONG Model: T420 Prepared By: Shenzhen WST Testing Technology Co., Ltd.1F,N o.9 Building,TGK Science & Technology ParkYan gtian Rd., NO.72 Bao'an Dist.,GuangDong,China Report Number: FCC15050004-4 FCC ID: 2ADYY-T420 Report Date: 2015-05-25 Checked By: Mark Cheng Approved By: Michal Ling Testing laboratory: World Standardization Certification & Testing CO., LTD. Building A, Baoshi Science & Technology Park, Baoshi Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-26996192 Fax: +86-755-26996253 Report No.: FCC15050004-4 SAR Evaluation Report Page 2 of 39 Table of contents 1 General information .......................................................................................................................................... 4 1.1 Notes ........................................................................................................................................................... 4 1.2 Application details ..................................................................................................................................... 4 1.3 Statement of Compliance .......................................................................................................................... 5 1.4 EUT Information ......................................................................................................................................... 6 2 Testing laboratory ............................................................................................................................................. 7 3 Test Environment .............................................................................................................................................. 7 4 Applicant and Manufacturer ............................................................................................................................ 7 5 Test standard/s: .................................................................................................................................................. 8 5.1 RF exposure limits ..................................................................................................................................... 9 5.2 SAR Definition ............................................................................................................................................ 9 6 SAR Measurement System .............................................................................................................................. 10 6.1 The Measurement System ...................................................................................................................... 10 6.2 Robot ......................................................................................................................................................... 11 6.3 Probe ......................................................................................................................................................... 11 6.4 Measurement procedure ......................................................................................................................... 12 6.5 Description of interpolation/extrapolation scheme .............................................................................. 13 6.6 Phantom .................................................................................................................................................... 14 6.7 Device Holder ........................................................................................................................................... 15 6.8 Video Positioning System ....................................................................................................................... 16 6.9 Tissue simulating liquids: dielectric properties ................................................................................... 17 6.10 Tissue simulating liquids: parameters .................................................................................................. 18 7 System Check .................................................................................................................................................. 19 7.1 System check procedure ........................................................................................................................ 19 7.2 System check results .............................................................................................................................. 20 8 SAR Test Test Configuration ......................................................................................................................... 21 8.1 GSM Test Configurations ........................................................................................................................ 21 9 Detailed Test Results ...................................................................................................................................... 22 9.1 Conducted Power measurements .......................................................................................................... 22 9.1.1 Conducted Power of GSM850 ................................................................................................................. 22 9.1.2 Conducted Power of GSM1900 ............................................................................................................... 23 Report No.: FCC15050004-4 SAR Evaluation Report Page 3 of 39 9.1.3 Conducted Power of BT .......................................................................................................................... 23 9.2 SAR test results ....................................................................................................................................... 25 9.2.1 …

Text truncated - open the document above for the full version.

BT Test Report Application Purpose : Original grant Applicant Name: : TECNO MOBILE LIMITED FCC ID : 2ADYY-T420 Equipment Type : Mobile Phone Model Name : T420 Report Number : FCC15050004-2 Standard(S) : FCC Part 15 Subpart C Date Of Receipt : May 17, 2015 Date Of Issue : May 28, 2015 Test By : ( Neil Wong) Reviewed By : ( Robie Chen) Authorized by : ( Michal Ling) Prepared by : Shenzhen WST Testing Technology Co., Ltd. 1F,No.9 Building,TGK Science & Technology ParkYangtian Rd., NO.72 Bao'an Dist., GuangDong, China ( Registration Number: 939433) Page 2 of 57 Report No.: FCC15050004-2 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / May 28, 2015 Valid Original Report Page 3 of 57 Report No.: FCC15050004-2 Table of Contents Page 1. GENERAL INFORMATION 5 2. TEST DESCRIPTION 8 2.1 MEASUREMENT UNCERTAINTY 8 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 2.4 CONFIGURATION OF SYSTEM UNDER TEST 10 2.5 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 10 3. SUMMARY OF TEST RESULTS 11 4. MEASUREMENT INSTRUMENTS 12 5. EMC EMISSION TEST 13 5.1 CONDUCTED EMISSION MEASUREMENT 13 5.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 5.1.2 TEST PROCEDURE 14 5.1.3 DEVIATION FROM TEST STANDARD 14 5.1.4 TEST SETUP 14 5.1.5 EUT OPERATING CONDITIONS 14 5.1.6 TEST RESULTS 15 5.2 RADIATED EMISSION MEASUREMENT 17 5.2.1 RADIATED EMISSION LIMITS 17 5.2.2 TEST PROCEDURE 18 5.2.3 DEVIATION FROM TEST STANDARD 18 5.2.4 TEST SETUP 19 5.2.5 EUT OPERATING CONDITIONS 20 5.2.5.1 RESULTS (BELOW 30 MHZ) 21 5.2.5.2 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 5.2.5.3 TEST RESULTS(1GHZ TO 25GHZ) 24 6. NUMBER OF HOPPING CHANNEL 6.1 APPLIED PROCEDURES / LIMIT 32 6.2 TEST PROCEDURE 32 6.3 DEVIATION FROM STANDARD 32 6.4 TEST SETUP 32 6.5 EUT OPERATION CONDITIONS 32 6.6 TEST RESULTS 33 7. AVERAGE TIME OF OCCUPANCY 7.1 APPLIED PROCEDURES / LIMIT 34 Page 4 of 57 Report No.: FCC15050004-2 Table of Contents Page 7.2 TEST PROCEDURE 34 7.3 DEVIATION FROM STANDARD 34 7.4 TEST SETUP 34 7.5 EUT OPERATION CONDITIONS 34 7.6 TEST RESULTS 35 8. HOPPING CHANNEL SEPARATION MEASUREMENT 8.1 APPLIED PROCEDURES / LIMIT 37 8.2 TEST PROCEDURE 37 8.3 DEVIATION FROM STANDARD 37 8.4 TEST SETUP 37 8.5 EUT OPERATION CONDITIONS 37 8.6 TEST RESULTS 38 9. BANDWIDTH TEST 9.1 APPLIED PROCEDURES / LIMIT 40 9.2 TEST PROCEDURE 40 9.3 DEVIATION FROM STANDARD 40 9.4 TEST SETUP 40 9.5 EUT OPERATION CONDITIONS 40 9.6 TEST RESULTS 41 10. PEAK OUTPUT POWER TEST 10.1 APPLIED PROCEDURES / LIMIT 43 10.2 TEST PROCEDURE 43 10.3 DEVIATION FROM STANDARD 43 10.4 TEST SETUP 43 10.5 EUT OPERATION CONDITIONS 43 10.6 TEST RESULTS 44 11. ANTENNA APPLICATION 45 12. EUT TEST PHOTO 46 13. PHOTOGRAPHS OF EUT 48 Page 5 of 57 Report No.: FCC15050004-2 1. GENERAL INFORMATION GENERAL DESCRIPTION OF EUT Test Model T420 Applicant TECNO MOBILE LIMITED Address RMS 05-15, 13A/F., SOUTH TOWER, WORLD FINANCE CTR, HARBOUR CITY, KLN, HK. Manufacturer SHENZHEN SMARTTEL CO., LTD. Address 6th Floor, Block 15, shatoujiao Free TRADE Zone, Shenyan Road, Yantian District, Shenzhen, Guangdong, P.R. China Equipment Type Mobile Phone Brand Name Hardware version: A710_MAIN_PCB_V1.2 Software version: N/A Extreme Temp. Tolerance -10 to +50°C°C Battery information: Li-ion Battery: BL-5CAT Batterie: 4.255Wh Voltage: 3.7V Capacity: 1150mAh Limited Charge Voltage: 4.2V Adapter Information: Adapter : M45 Input: AC 100-240V 50/60Hz 150mA Output: DC 5V 500mA Operating Frequency 2402-2480MHz Channels 79 Channel Spacing 1MHz Modulation Type GFSK, π/4-DQPSK, 8-DPSK Version 3.0 Antenna Type: Integral Antenna Antenna gain: 1.55dBi Frequency Bands: GSM 850 PCS 1900 (U.S. Bands) GSM 900 DCS 1800 (Non-U.S. Bands) U.S. Bands: UMTS FDD Band II UMTS FDD Band V Non-U.S. Bands: UMTS FDD Band I UMTS FDD Band VIII Antenna Type: Internal Antenna Antenna gain: 1.0dBi(GSM) Page 6 of 57 Report No.: FCC15050004-2 Dual Card: Card 1: GSM Card Slot, Card 2: GSM Card Slot GPRS Class 12 Data of receipt May 17, 2015 Date of test May 17, 2015 to May 27, 2015 Deviation None Condition of Te s t S a m p l e Normal Page 7 of 57 Report No.: FCC15050004-2 We hereby certify that: All measurement facilities used to collect the measurement data are located at 1F,No.9 Building,TGK Science & Technology Park Yangtian Rd., NO.72 Bao'an Dist., GuangDong, China The data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C 63.4:2009. The sample tested as described in this report is in compliance with the FCC Rules Part15 Subpart C. The test results of this report relate only to the tested sample identified in this report. Page 8 of 57 Report No.: FCC15050004-2 2. TEST DESCRIPTION 2.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±3.2dB 2 RF power, conducted ±0.16dB 3 Spurious emissions, conducted ±0.21dB 4 All emissions, radiated(<1G) ±4.7dB 5 All emissions, radiated(>1G) ±4.7dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 9 of 57 Report No.: FCC15050004-2 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 CH00 Mode 2 CH39 Mode 3 CH78 Mode 4 Normal Hopping For Conducted Emission Final Test Mode Description Mode 4 Normal Hopping For Radiated Emission Final Test Mode Description Mode 1 CH00 Mode 2 CH39 Mode 3 CH78 Note: (1) The measurements are performed at the highest, middle, lowest available channels. (2)The data rate was set in 1Mbp…

Text truncated - open the document above for the full version.

CONDUCTED EMISSION TEST RADIATED EMISSION TEST RADIATED EMISSION TEST

Front view: Rear View Left Hand Touched Left Hand Tilted 15° Right Hand Touched Right Hand Tilted 15° Towards Phantom 5mm Towards Ground 5mm
