2ADYY-TU01-RWireless Earphone

FCC ID: 2ADYY-TU01-R MADE IN CHINA Visit the official website for more product information Packing List 2* Bluetooth earphone 1* Charging box 1* Charging cable 1* User Manual 2* Ear tip (large) 2* Ear tip (medium) 2* Ear tip (small) Bluetooth earphones Charging boxCharging cable User Manual Ear tips (The medium-sized ear tips have been pre-installed on the ear plugs.) 1 Overview Mobile phone models supporting intelligent pop-up window for connection 1. Charging pins 2. Charging box indicator light 3. Charging port 4. Reset button 5. Light sensor 6. Earphone touch area 7. Charging contacts 8. MIC ① ⑤ ⑥ ⑦ ⑧ ②③④ 2 PHANTOM X2 5G, PHANTOM X2 Pro 5G, etc. (For mobile phones with the OS version of HiOS V12.0, the WelinkService App version shall be higher than v2.0.86.98. Version No. can be found by searching "WelinkService" in the "Settings" of the mobile phone.) Basic Features Model Charging Port Earphone battery capacity Charging box battery capacity Charging voltage/current Music playback endurance Transmission range Bluetooth name Operating temperature Storage temperature Earphones charging time Charging box charging time TU01 Type-C 55mAh*2 780mAh 5V/0.7A (charging box) 5V/0.11A (earphones) 8H+37H (50% volume, ANC OFF mode) ≥ 10m TECNO Ture 1 Charge: 0°C-45°C; Discharge: -10°C-45°C -20 ~ 70 1.5h ≈2h 3 Earphones Usage Charge the charging box 1. Connect the smaller port of USB-C cable to the Type-C charging port of the charging box. 2. Connect the port at the other end to a USB wall charger (DC5V) or a powered-on computer. Note: It takes about 2 hours for the charging box to be fully charged. A fully charged charging box can charge the earphones for about four times. 4 Proper use of the earphones If it is not comfortable to wear ear tips, please take them off, replace them with the ones in larger or smaller size and try for the best fit; Follow the figure to ensure that you wear the ear tips correctly. Note: When replacing ear tip, make sure that the ear tips are installed in place. 5 Power On/Off Power On Power Off When the battery capacity of the charging box is greater than 5%, the earphones will be turned on automatically once the charging box is open. The earphones will be turned off automatically once they are placed into the charging box which is then closed. 6 Connection to Intelligent Device Note: For the first use, open the charging box, and the earphones will enter the pairing mode for 3 minutes. For some TECNO models, the pop-up window for pairing will pop up automatically on the mobile phone. Please find and connect to "TECNO Ture 1" on the Bluetooth page of the smart device for pairing. If it is not used for the first time, to connect to a new device, put the earphones in the charging box with the box open, press the button on the charging box to enter the pairing mode. 78 If pairing to the Bluetooth device fails, please put the earphones back into the charging box, close the box, and ensure that the earphones have been turned off (The earphones will be turn off within 5 seconds after the charging box is closed). Then pair the earphones with your Bluetooth device again. Each time the earphones are turned on, if they are within the Bluetooth connection range, they will automatically connect to the last device you connected successfully. When the earphones are turned on but not connected to the Bluetooth device, they will automatically turn off after 3 minutes. 11121410 FCC CAUTION: IMPORTANT NOTE: FCC RADIATION EXPOSURE STATEMENT: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 15 CAUTION Frequency Range(RF) RF output power only for CE: BT/BLE: 2400-2483.5MHz (TX/RX); BT left6.17dBm BT right: 9.45dBm BLE left:6.47dBm BLE Right:6.99dBm Hereby, TECNO MOBILE LIMITED. Declares that this Wireless Earphone is in compliance with the essential requirements and other relevant provisions of directive 2014/53/EU. 1.Risk of explosion if battery is replaced by an incorrect type, dispose of used batteries according to the instructions. – disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion; – leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; – a battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. 2.EUT Temperature: 0+45(Standa…

Text truncated - open the document above for the full version.

TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET FOTAN NT HONGKONG Tel.: 86-755-61803856 E-mail: [email protected] Date: 2022-12-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: The RF chip, model: BES2500IH, which installed in our product Wireless Earphone, Model: TU01, FCC ID: 2ADYY-TU01-R, supports BDR (GFSK), EDR (π/4-DQPSK, 8DPSK), BLE 1M and BLE 2M functions. For use in America and this chip will not support/enable BLE 2M. The BLE 2M has been shielded by the manufacturer using the software, the end user has no capability to activate it. Sincerely Yours, Signature: Yiting Luo Manager

TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19- 25 SHAN MEI STREET FOTAN NT HONGKONG Tel.: 86-755-61803856 E-mail: [email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 2023-02-17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: 2ADYY-TU01-R TECNO MOBILE LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Yiting Luo Manager TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19- 25 SHAN MEI STREET FOTAN NT HONGKONG

TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19- 25 SHAN MEI STREET FOTAN NT HONGKONG Tel.: 86-755-61803856 E-mail: [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 2023-02-17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2ADYY-TU01-R TECNO MOBILE LIMITED certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Yiting Luo Manager TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19- 25 SHAN MEI STREET FOTAN NT HONGKONG

U.S. AGENT LETTER OF ATTESTATION Date: 2023-02-17 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2ADYY-TU01-R TECNO MOBILE LIMITED certifies that, as of the date of the filing of the application, Iconsigh Inc. is our designated U.S. agent for service of process for the above referenced FCC ID . TECNO MOBILE LIMITED accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: TECNO MOBILE LIMITED Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19- 25 SHAN MEI STREET FOTAN NT HONGKONG FRN: 0024206328 Tel: 86- 755-61803856 Email: [email protected] Signed by (printed name): Yiting Luo Signature:

TECNOMOBILELIMITED Address:FLATN16/FBLOCKBUNIVERSALINDUSTRIALCENTRE19- 25SHANMEISTREETFOTANNTHONGKONG Tel.: 86-755-61803856 E-mail:[email protected] QA-FR-170-B FCCAuthorization Date:2022-12-14 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:AgentAuthorization Towhomitmayconcern: We,TECNOMOBILELIMITEDherebyauthorizesShenzhenAccurateTechnologyCo., Ltd.toactonitsbehalfinallmattersrelatingtoapplicationforEquipmentauthorization, includingthesigningofalldocumentsrelatingtothesematters.Allactscarriedoutby ShenzhenAccurateTechnologyCo.,Ltd.onourbehalfshallhavethesameeffectasour ownaction. We,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits, thatincludesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988, 21U.S.C.862. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signature YitingLuo Manager

TECNOMOBILELIMITED Address:FLATN16/FBLOCKBUNIVERSALINDUSTRIALCENTRE19- 25SHANMEISTREETFOTANNTHONGKONG Tel.:86-755-61803856 E-mail:[email protected] FCCConfidentialAuthorization Date:2022-12-14 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:ConfidentialityRequestregardingapplicationforcertificationof FCCID:2ADYY-TU01-R InaccordancewithSections0.457and0.459oftheCommission’sRules, TECNOMOBILELIMITEDherebyrequestslong-termconfidentialtreatmentof informationaccompanyingthisapplicationasoutlinedbelow: BlockDiagram Schematics OperationDescription Aswellasshort-termconfidentialtreatmentofinformationaccompanyingthis applicationforaperiodof180daysaftergrantisissuedasoutlinedbelow: InternalPhotos User’sManual ExternalPhotos TestSet-upPhotos Theabovematerialscontainproprietaryandconfidentialinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesematerialsprovidesunjustified benefitstoitscompetitorsinthemarket. SincerelyYours, Signature YitingLuo Manager

TECNOMOBILELIMITED Address:FLATN16/FBLOCKBUNIVERSALINDUSTRIALCENTRE19-25SHANMEI STREETFOTANNTHONGKONG Tel.:86-755-61803856 E-mail:[email protected] Date:2022-12-14 FCCcertificationNo.CoverLetter We,TECNOMOBILELIMITED,herebysubmitjustificationforplacingtheFCCcertificationNo.inthe associatedchargingcase. AccordingtotheFCCregulation,theFCCcertificationNo.shouldbeprintedontheearbuds,butasthe earbudsaretoosmalltoprintthelabel(FCCID:2ADYY-TU01-R),itwillbemovedtothechargingcase. Thedetailsareasbelow: A.Sidesurface(A):ThesidesurfacedoesnotprovideenoughphysicalspacetofittheprintingoftheFCC certificationNo.accordingtobelowreferencepicture. B.Topcover(B):ThetopcoverdoesnotprovideenoughphysicalspacetofittheprintingoftheFCC certificationNo.accordingtobelowreferencepicture. Conclusion:BasedontheabovedescriptionofareaAtoB,weconcludethatthedeviceisunquestionably toosmallforenablingtheFCCcertificationNo.tobeprintedontoanysurface.Wethereforerequesttomove theFCCcertificationNo.tothechargingcase. Labelandlabellocation: Bestregards, Signature: YitingLuo Manager

Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R External Photos Page 1 of 4 External Photos Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R External Photos Page 2 of 4 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R External Photos Page 3 of 4 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R External Photos Page 4 of 4

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221122-56020E-RF LABEL AND LOCATION Page 1 of 1 FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R Internal Photos Page 1 of 3 Internal photos Antenna Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R Internal Photos Page 2 of 3 Shenzhen Accurate Technology Co., Ltd. FCC ID: 2ADYY-TU01-R Internal Photos Page 3 of 3

Shenzhen Accurate Technology Co., Ltd. Report No.: RA221122-56020E-RF-00C Version 11: 2021-11-09 Page 11 of 60 FCC-BT FCC§15.247 (i), §1.1307 (b) (3) &§2.1093 – RF EXPOSURE Applicable Standard According to FCC §2.1093 and §1.1307(b) (3), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB 447498 D04 Interim General RF Exposure Guidance SAR-Based Exemption: SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum timeaveraged power or maximum time-averaged ERP, whichever is greater. Per § 1.1307(b)(3)(i)(B), for single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). P th is given by: Shenzhen Accurate Technology Co., Ltd. Report No.: RA221122-56020E-RF-00C Version 11: 2021-11-09 Page 12 of 60 FCC-BT For worst case: Exemption limit: For f=2.48GHz, d=0.5cm, the P th =2.72mW The higher of the available maximum time-averaged power or effective radiated power (ERP): The antenna gain is 1.56dBi (-0.59dBd), 0dBd=2.15dBi The maximum tune-up conducted power is 2.0dBm (1.58mW), which less than 2.72 mW@2480MHz exemption limit So the stand-alone SAR evaluation can be exempted.
