2ADZR4G06AFastMile 4G Receiver

Nokia — Proprietary and confidential Use pursuant to applicable agreements FastMile 2.1.03 Nokia FastMile 4G Receiver Product Overview 3TG-00386-ABDA-TCZZA Issue: 01 February 2020 Nokia FastMile 4G Receiver Product Overview 2 Nokia FastMile 4G Receiver Product Overview 3TG-00386-ABDA-TCZZAIssue: 01 Nokia is a registered trademark of Nokia Corporation. Other products and company names mentioned herein may be trademarks or tradenames of their respective owners. The information presented is subject to change without notice. No responsibility is assumed for inaccuracies contained herein. © 2020 Nokia. Contains proprietary/trade secret information which is the property of Nokia and must not be made available to, or copied or used by anyone outside Nokia without its written authorization. Not to be used or disclosed except in accordance with applicable agreements. Nokia FastMile 4G Receiver Product OverviewPreface Issue: 013TG-00386-ABDA-TCZZA3 1Preface This preface provides general information about the Product Overview for the Nokia FastMile 4G Receiver. 1.1 Summary of document issue changes Changes between document issues are cumulative. Therefore, the latest document issue contains all changes made to previous issues. Issue 01 is the first issue of the document for this release of the FastMile 4G Receiver. 1.2 Scope This document provides an overview of the Nokia FastMile 4G Receiver along with information about safety and troubleshooting the Nokia FastMile 4G Receiver. 1.3 Audience This document is intended for planners, administrators, operators, and maintenance personnel involved in installing, upgrading, or maintaining the Nokia FastMile 4G Receiver. 1.4 Required knowledge The reader must be familiar with general telecommunications principles. 1.5 Acronyms and initialisms The expansions and optional descriptions of most acronyms and initialisms used in this document appear in the glossary at the back of the document. 1.6 Assistance and ordering phone numbers Nokia provides global technical support through the following URL: https://customer.nokia.com/support/s/. For ordering information, contact your Nokia sales representative. Preface 4 Nokia FastMile 4G Receiver Product Overview 3TG-00386-ABDA-TCZZAIssue: 01 1.7 Nokia quality processes Nokia’s FastMile 4G Receiver quality practices are in compliance with TL 9000 requirements.These requirements are documented in the Fixed Networks Quality Manual 3FQ-30146-6000-QRZZA. The quality practices adequately ensure that technical requirements and customer end-point requirements are met. The customer or its representatives may be allowed to perform on-site quality surveillance audits, as agreed upon during contract negotiations. 1.8 Safety information For safety information, see the appropriate safety guideline chapters. 1.9 Documents Documents are available at the Nokia Documentation Center. Procedure 1 To access a document on the Nokia Documentation Center Individual PDFs of customer documents are accessible through the Nokia Documentation Center. 1Go to http://networks.nokia.com. 2Sign in to the Customer and Business Partner Portals (Sign in link top right) with the username and password for your account. If you do not have an account, click Register or contact your Nokia representative. Choose Online Customer Support (OLCS). 3Click on Documentation Center in the upper menu bar to access the Nokia Documentation Center. 4Select FastMile 4G Receiver from the list of products. 5Filter the search results as needed (by release, content type, issue date, etc.). 6Click on the PDF icon to access a document. Nokia FastMile 4G Receiver Product OverviewPreface Issue: 013TG-00386-ABDA-TCZZA5 1.10 Special information The following are examples of how special information is presented in this document. 1.10.1 Steps with options or substeps When there are options in a step, they are identified by letters. When there are required substeps in a step, they are identified by roman numerals. Procedure 2 Example of options in a step At step 1, you must choose option a or b. 1This step offers two options. You must choose one of the following: aThis is one option. bThis is another option. 2You must perform this step. Danger — Danger indicates that the described activity or situation may result in serious personal injury or death; for example, high voltage or electric shock hazards. Warning — Warning indicates that the described activity or situation may, or will, cause equipment damage or serious performance problems. Caution — Caution indicates that the described activity or situation may, or will, cause service interruption. Note — A note provides information that is, or may be, of special interest. Preface 6 Nokia FastMile 4G Receiver Product Overview 3TG-00386-ABDA-TCZZAIssue: 01 Procedure 3 Example of required substeps in a step At step 1, you must perform a series of substeps within the step. 1This step has a series of substeps that you must perform to complete the step. You must perform the following substeps: iThis is the first substep. iiThis is the second substep. iiiThis is the third substep. 2 You must perform this step. 1.11 Multiple PDF document search You can use Adobe Reader Release 6.0 and later to search multiple PDF files for a common term. Adobe Reader displays the results in a single display panel. The results are grouped by PDF file, and you can expand the entry for each file. Procedure 4 To search multiple PDF files for a common term 1Open Adobe Acrobat Reader. 2Choose Edit→Search from the Acrobat Reader main menu. The Search PDF panel appears. 3Enter the search criteria. 4Click on the All PDF Documents In radio button. 5Select the folder in which to search using the drop-down menu. 6Click on the Search button. Note — The PDF files in which you search must be in the same folder. Nokia FastMile 4G Receiver Product OverviewPreface Issue: 013TG-00386-ABDA-TCZZA7 Acrobat Reader displays the search results. You can expand the entries for each docu…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 1 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP Brand Name: NOKIA Model Name: 4G06-A PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 2 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 3 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 4 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 5 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP

PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 6 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 7 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 8 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 9 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 10 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 11 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 12 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 13 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 14 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 15 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 16 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 17 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 18 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 19 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 20 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 21 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 22 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 23 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 24 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 25 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 26 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 27 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 28 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INTERNATIONAL INC. EMC & Wireless Communications Page Number : 29 of 39 TEL : 886-3-656-9065 Issued Date : Mar. 03, 2020 FAX : 886-3-656-9085 EP Report Version : 01 Report Template No.: CB Ver1.0_EP PHOTOGRAPHS OF EUT Report No. : EP981911 SPORTON INT…

Text truncated - open the document above for the full version.

TEL : +86-512-57900158 Page Number : 1 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 RF Exposure Evaluation Report APPLICANT : Nokia Shanghai Bell Co., Ltd. EQUIPMENT : FastMile 4G Receiver BRAND NAME : NOKIA MODEL NAME : 4G06-A FCC ID : 2ADZR4G06A STANDARD : 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 We, Sporton International (Kunshan) Inc., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1091 and FCC KDB 447498 D01 v06, and pass the limit. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Rose Wang / Supervisor Approved by: Kat Yin / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China TEL : +86-512-57900158 Page Number : 2 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 4 1.1. Testing Laboratory ............................................................................................................................. 4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 5 3. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 6 4. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 7 5. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 8 5.1. Standalone Power Density Calculation ............................................................................................. 8 TEL : +86-512-57900158 Page Number : 3 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA950922 Rev. 01 Initial issue of report Feb. 28, 2020 TEL : +86-512-57900158 Page Number : 4 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 1. Administration Data 1.1. Testing Laboratory Sporton International (Kunshan) Inc. is accredited to ISO/IEC 17025:2017 by American Association for Laboratory Accreditation with Certificate Number 5145.02. Testing Laboratory Test Firm Sporton International (Kunshan) Inc. Test Site Location No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China TEL : +86-512-57900158 FAX : +86-512-57900958 Test Site No. FCC Designation No. FCC Test Firm Registration No. CN1257 314309 Applicant Company Name Nokia Shanghai Bell Co., Ltd. Address 388#, Ningqiao Road, China (Shanghai) Pilot Free Trade Zone, Shanghai 201206, China Manufacturer Company Name Nokia Shanghai Bell Co., Ltd. Address 388#, Ningqiao Road, China (Shanghai) Pilot Free Trade Zone, Shanghai 201206, China TEL : +86-512-57900158 Page Number : 5 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type FastMile 4G Receiver Brand Name NOKIA Model Name 4G06-A FCC ID 2ADZR4G06A Wireless Technology and Frequency Range LTE Band 2: 1850.7 MHz ~ 1909.3 MHz LTE Band 4: 1710.7 MHz ~ 1754.3 MHz LTE Band 7: 2502.5 MHz ~ 2567.5 MHz LTE Band 25: 1850.7 MHz ~ 1914.3 MHz LTE Band 66: 1710.7 MHz ~1754.3 MHz Bluetooth: 2402 MHz ~ 2480 MHz Mode LTE: QPSK, 16QAM, 64QAM Bluetooth BR/EDR Antenna Type/ Single Antenna Gain Dipole Antenna LTE Band 2: 9.50 dBi LTE Band 4: 9.50 dBi LTE Band 7: 11.00 dBi LTE Band 25: 9.50 dBi LTE Band 66: 9.50 dBi Bluetooth: 5.00 dBi MIMO Directional Gain LTE Band 2: 12.51 dBi LTE Band 4: 12.51 dBi LTE Band 7: 14.01 dBi LTE Band 25: 12.51 dBi LTE Band 66: 12.51 dBi HW Version 3TG00171AB SW Version FMR2003 E0115 EUT Stage Identical Prototype Remark: 1. The EUT is a fixed station. 2. The EUT supports CDD Mode. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. TEL : +86-512-57900158 Page Number : 6 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 3. Maximum RF average output power among production units <LTE> Mode Maximum Average power(dBm) SISO LTE Band 2 22.00 Band 4 20.50 Band 7 22.00 Band 25 22.50 Band 66 20.50 Mode Maximum Average power(dBm) MIMO(2X2) LTE Band 2 20.50 Band 4 17.45 Band 7 18.00 Band 25 20.00 Band 66 17.45 <Bluetooth> Mode Maximum Average Power (dBm) Bluetooth BR/EDR 3.00 TEL : +86-512-57900158 Page Number : 7 of 9 FAX : +86-512-57900958 Report Issued Date : Feb. 28, 2020 FCC ID : 2ADZR4G06A Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA950922 4. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: 퐒= 퐏퐆 ퟒ훑퐑 ퟐ Where: S = Power Density P = Output Power at Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Dista…

Text truncated - open the document above for the full version.

Sporton International (Kunshan) Inc. Page Number : 1 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 FCC RF Test Report APPLICANT : Nokia Shanghai Bell Co., Ltd. EQUIPMENT : FastMile 4G Receiver BRAND NAME : NOKIA MODEL NAME : 4G06-A FCC ID : 2ADZR4G06A STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DSS) Spread Spectrum Transmitter The product was received on May 09, 2019 and testing was completed on Jan. 02, 2020. We, Sporton International (Kunshan) Inc., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Jason Jia / Supervisor Approved by: James Huang / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International (Kunshan) Inc. Page Number : 2 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ...................................................................................................................................... 5 1.3 Product Feature of Equipment Under Test ........................................................................................ 5 1.4 Product Specification of Equipment Under Test ................................................................................ 5 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Testing Location ................................................................................................................................ 6 1.7 Test Software ..................................................................................................................................... 7 1.8 Applicable Standards ......................................................................................................................... 7 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1 Carrier Frequency Channel ............................................................................................................... 8 2.2 Test Mode .......................................................................................................................................... 9 2.3 Connection Diagram of Test System ............................................................................................... 10 2.4 Support Unit used in test configuration and system ........................................................................ 10 2.5 EUT Operation Test Setup .............................................................................................................. 11 2.6 Measurement Results Explanation Example ................................................................................... 11 3 TEST RESULT .......................................................................................................................................... 12 3.1 Number of Channel Measurement .................................................................................................. 12 3.2 Hopping Channel Separation Measurement ................................................................................... 14 3.3 Dwell Time Measurement ................................................................................................................ 20 3.4 20dB Bandwidth Measurement ....................................................................................................... 22 3.5 Output Power Measurement ............................................................................................................ 28 3.6 Conducted Band Edges Measurement............................................................................................ 29 3.7 Conducted Spurious Emission Measurement ................................................................................. 36 3.8 Radiated Band Edges and Spurious Emission Measurement ........................................................ 46 3.9 AC Conducted Emission Measurement........................................................................................... 50 3.10 Antenna Requirements .................................................................................................................... 52 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 53 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 54 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. AC CONDUCTED EMISSION TEST RESULT APPENDIX C. RADIATE…

Text truncated - open the document above for the full version.

Sporton International (Kunshan) Inc. Page Number : 40 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 <2Mbps> CSE Plot on Ch 00 between 30MHz ~ 3 GHz CSE Plot on Ch 00 between 2 GHz ~ 25 GHz 720510 720510 Sporton International (Kunshan) Inc. Page Number : 41 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 CSE Plot on Ch 39 between 30MHz ~ 3 GHz CSE Plot on Ch 39 between 2 GHz ~ 25 GHz 720510 720510 Sporton International (Kunshan) Inc. Page Number : 42 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 CSE Plot on Ch 78 between 30MHz ~ 3 GHz CSE Plot on Ch 78 between 2 GHz ~ 25 GHz 720510 720510 Sporton International (Kunshan) Inc. Page Number : 43 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 <3Mbps> CSE Plot on Ch 00 between 30MHz ~ 3 GHz CSE Plot on Ch 00 between 2 GHz ~ 25 GHz 720510 720510 Sporton International (Kunshan) Inc. Page Number : 44 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 CSE Plot on Ch 39 between 30MHz ~ 3 GHz CSE Plot on Ch 39 between 2 GHz ~ 25 GHz 720510 720510 Sporton International (Kunshan) Inc. Page Number : 45 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 CSE Plot on Ch 78 between 30MHz ~ 3 GHz CSE Plot on Ch 78 between 2 GHz ~ 25 GHz 720510 720510 Sporton International (Kunshan) Inc. Page Number : 46 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 3.8 Radiated Band Edges and Spurious Emission Measurement 3.8.1 Limit of Radiated Band Edges and Spurious Emission In any 100 kHz bandwidth outside the intentional radiator frequency band, all harmonics/spurious must be at least 20 dB below the highest emission level within the authorized band. In addition, radiated emissions which fall in the restricted bands must also comply with the limits as below. Frequency (MHz) Field Strength (microvolts/meter) Measurement Distance (meters) 0.009 – 0.490 2400/F(kHz) 300 0.490 – 1.705 24000/F(kHz) 30 1.705 – 30.0 30 30 30 – 88 100 3 88 – 216 150 3 216 - 960 200 3 Above 960 500 3 3.8.2 Measuring Instruments The measuring equipment is listed in the section 4 of this test report. Sporton International (Kunshan) Inc. Page Number : 47 of 54 TEL : +86-512-57900158 Report Issued Date : Feb. 28, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: 2ADZR4G06A Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR950922 3.8.3 Test Procedures 1. The EUT was placed on a turntable with 0.8 meter for frequency below 1GHz and 1.5 meter for frequency above 1GHz respectively above ground. 2. The EUT was set 3 meters from the interference receiving antenna, which was mounted on the top of a variable height antenna tower. 3. For each suspected emission, the EUT was arranged to its worst case and then tune the Antenna tower (from 1 m to 4 m) and turntable (from 0 degree to 360 degrees) to find the maximum reading. A pre-amp and a high pass filter are used for the test in order to get better signal level to comply with the guidelines. 4. Set to the maximum power setting and enable the EUT transmit continuously. 5. Use the following spectrum analyzer settings: (1) Span shall wide enough to fully capture the emission being measured; (2) Set RBW=100 kHz for f < 1 GHz, RBW=1MHz for f>1GHz ; VBW  RBW; Sweep = auto; Detector function = peak; Trace = max hold for peak (3) For average measurement: use duty cycle correction factor method per 15.35(c). Duty cycle = On time/100 milliseconds On time = N 1 *L 1 +N 2 *L 2 +...+N n-1 *LN n-1 +N n *L n Where N 1 is number of type 1 pulses, L 1 is length of type 1 pulses, etc. Average Emission Level = Peak Emission Level …

Text truncated - open the document above for the full version.
