User Guide LED Bulb & Speaker PRODUCT OVERVIEW The TZUMI® LED SmartBulb and Speaker lets you transform your surroundings with lights and music using your smartphone or tablet. Downloadable free app allows the user to turn bulb ON/OFF, change color, brighten, dim and more. The bulb is energy efficient and lasts over 30,000 hours. Easy to install, fits into any standard socket. Supports iOS and Android devices. INSTALL APP Download and install FREE app - spectra bulb. • Supports iPhone 4s and later with iOS 7.0 and later versions • Supports Android 2.3.3 and later. M i l l i o n s o f P o s s i b i l i t i e s INSTALL LED SMARTBULB Turn off the power supply before installing the SmartBulb. It can be installed anywhere there is a standard light socket (ceiling, wall or table lamp). It can also be used as a nightlight once you adjust the brightness. PAIRING THE LED SMARTBULB TO BLUETOOTH DEVICE Make sure the Bluetooth function is available on your device. Specific pairing procedures will be different depending on different device. For detailed information, please refer to the User Guide of your device(s). • After a successful pairing, devices will memorize each. Therefore, no pairing will be needed next time. 1. Keep the distance between the device and the LED SmartBulb within 3 feet (for pairing only). 2. Make sure your LED SmartBulb is installed and on. 3. Activate the Bluetooth function of the device to search for the Bluetooth devices. After finishing the search, select “spectra bulb” in the device list displayed. 4. Launch the app and tap on the Connect tab located on the bottom of the screen. Select “spectra bulb” to connect. 5. Your LED SmartBulb is ready for use. PLAYING MUSIC Once you have successfully paired the LED SmartBulb, tap on the Music tab located on the bottom of the screen. All of the music stored in your device will be displayed here. Select and play your favorite music. You can control play/pause, previous, next, volume up/down from this screen. LED COLORS Tap on the Lamp tab located on the bottom of the screen. Select either auto or manual control. For manual control, tap on the color to select it. You may also adjust the brightness by sliding the controls to the left or right. For custom color, use the color spectrum wheel. Just tap in the desired section. LED ON/OFF Tap on the ON/OFF tab located on the bottom of the screen. This will allow you to turn the lights ON or OFF. SETTINGS Tap on the Setting tab located on the bottom of the screen. Scroll through to set a specific time for your LED SmartBulb to turn on automatically. To cancel the set time, tap on the “Cancel the Timing” bar. FOR MULTIPLE USAGE: To keep track of your multiple SmartBulbs, you have an option to name each one (ex. kitchen, livingroom, etc). This allows for easier light control. 1. Rename the Bluetooth name and press OK. 2. Tap on the Connect tab of the app, select the “spectra bulb” to disconnect it. 3. Ignore the Bluetooth device name “spectra bulb” on your device. Shut down the Bluetooth function on your device. 4. Turn off the power of LED SmartBulb. 5. Turn the power back on and start the Bluetooth pairing procedure again. • Keep out of reach of children. This product is not a toy. • Do not use this product in a closed lampshade. • Do not use in lights with dimmer function. • Do not install this product near water, in humid conditions and/or near hot surfaces. • Do not tamper with the product. • Before removing the SmartBulb, always let it cool. IMPORTANT SAFEGUARDS SPECIFICATIONS Power: LED 6W, AMP 3W Working Voltage: AC100-240V Working Frequency: 50-60HZ Bluetooth Version: Bluetooth 4.0 Bluetooth Distance: 33 ft (10m) Compatibility: Android 2.3.3 and later, iPhone 4S/5S/6, etc. LED color: 2805 (white light) 26-28LM RGB: 5050 (red, orange, yellow, green, light blue, blue and purple) Color rendering index: Ra=70.9 Red Ratio: R=13.2% TZUMI ® SpectraSound ™ LED Bulb & Speaker Distributed by TZUMI ® INC. NY, NY 10016 ©Copyright 2015 TZUMI ® All Rights Reserved. Made In China. The Bluetooth trademarks are owned by Bluetooth SIG, Inc. Other trademarks and trade names in this document are those of their respective owners. © 2015 Bluetooth SIG, Inc. Subject to change without prior notice. iPhone is a trademark of Apple Inc., registered in the U.S. and other countries. Subject to change without prior notice. Android is a trademark of Google Inc. 1 23 4 55 over SETTINGS - Continued FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

KINLAN INDUSTRIAL LIMITED 3F, Building A4, Yinlong Industrial Park, ShenShan Road, Longgang District, ShenZhen, Guangdong, China h Federal Comniunications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AE3CWS102 s Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type Schematics Block Diagram Operational Description File Name 2AE3CWS 102 FCCID Schematics.pdf 2AE3C WS102~~~~1~~~lock~ia~ram.~df 2AE3C WS102~FCCID~OperationalDescription.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. 'The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, KINLAN INDUSTRhL LIMITED ..................... (Shirley Zhanb - fl (Vice General Manager)

KINLAN INDUSTRIAL LIMITED 3F, Building A4, Yinlong Industrial Park, ShenShan Road, Longgang District, ShenZhen, Guangdong, China -------------------------------------------------------------------------------- (FCC ID：2AE3CWS102) POWER OF ATTORNEY DATE: 2015-11-11 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen SEM.Test Technology Co., Ltd. Jandy So on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen SEM.Test Technology Co., Ltd. Jandy So on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, KINLAN INDUSTRIAL LIMITED, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section.

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 EUT View 3

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2AE3CWS102 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 BT Antenna Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 Solder Board-Component View 2 Solder Board-Component View 3 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 Solder Board-Component View 4 Solder Board-Component View 5 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 Solder Board-Component View 6 Solder Board-Component View 7 Shenzhen SEM.Test Technology Co., Ltd. REPORT NO.: STR15118036I-1/2 FCC PART 15.247 Solder Board-Component View 8 Solder Board-Component View 9

Model: YH-CC12W-LED01 No.NameSpecificationsRemarkQty. 1 PCBYH-CC12W-LED01 45*45*1.6mm，FR-4,1 2 Resistor1MΩ ±5%，1206R3,42 2 Resistor100KΩ ±5%，1206R11 2 Resistor2Ω ±5%，0805R101 2 Resistor100Ω ±5%，0805R71 2 Resistor680Ω ±5%，0805R51 2 Resistor3KΩ ±5%，0805R111 2 Resistor2.2Ω ±1%，1206RS1,22 5Resistor24KΩ ±1%，0805R91 5Resistor2.94KΩ ±1%，0805R81 18 Capacitor200V/1nF(102)±10%,0805C51 18 Capacitor100V/100PF(101)±10%,0805C41 18 Capacitor1000V/1nF(102)±10%,1206C31 20 ICSF5920, SOP-5U11 DiodeMB6FDB11 13 DiodeRS07M，1A，1000V， SOD-123FL D5,6 2 24 DiodeSS310，100V，3A，SMAD91 Resistor3R/1W，F11 26 Capacitor400V/6.8uF±20%,10*17mmC11 29 Capacitor50V/10uF±20%,6*12mmC21 31 Capacitor25V/470uF±20% 8*12mm，LOWESRC61 33 Y Capacitor102M 400V，Y1，P=10CY11 MOS2N60，TO-251Q11 44 TransformerEE19-C1201002T11 BOM

RF Exposure Requirements Product Description: Light bulb BT speaker Model No.: WS102 FCC ID: 2AE3CWS102 According to the KDB 447498 D01 V05r02, the following RF exposure evaluation shall to demonstrate RF exposure compliance. Bluetooth Tx frequency range: 2402~2480MHz Device category: Portable device (Distance: 5mm) Maximum Conducted Output Power: 3.622dBm Maximum Conducted Output Power: 2.303mW Limit: 10mW Source-based time-averaged Conducted output power is 2.303mW < 10mW So the transmitter complies with the RF exposure requirements and the SAR is not required.
