FCC ID: 2AE5QBL-099 1 INTERTEK TESTING SERVICES Analysis Report The equipment under test (EUT) is a Earbuds Bluetooth with Bluetooth function operating in 2402-2480MHz. The EUT is powered by DC 3.7V internal rechargeable battery and can be charged through USB interface. For more detail information pls. refer to the user manual. Modulation Type: GFSK, π/4DQPSK, 8DPSK Bluetooth Version: 3.0 with EDR function Antenna Type: Integral antenna (Gain: 0 dBi) The nominal radiated output power (e.i.r.p) specified: 2dBm (Tolerance: +/-3dB) The nominal conducted output power specified: 2dBm (Tolerance: +/-3dB) According to the KDB 447498: The maximum radiated emission for the EUT is 98.5dBμV/m at 3m in the frequency 2.441GHz = [(FS*D) ^2 / 30] mW = 3.3dBm which is within the production variation The minimum radiated emission for the EUT is 96.9dB μV/m for at 3m in the frequency 2.480GHz = [(FS*D) ^2 / 30] mW = 1.7dBm which is within the production variation. The maximun conducted output power specified is 5dBm = 3.2mW The source- based time-averaging conducted output power = 3.2 * Duty cycle mW <= 3.2 mW (Duty Cycle<=100%) The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.5 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing.
