2AE7RSTKGALACTIC6SMARTPHONE

User Manual 1 User Manual User Manual 2 Contents 1．APPEARANCE AND KEYPAD OPERATIONS ............................ 3 2．USING MEMORY CARD AS U DISK ............................. 4/5/6 3．WIFI ....................................................... 7 4．BLUETOOTH .................................................. 8 5．MAIL ....................................................... 9  5.1 GMAIL ...................................................................................................................... 9  5.2 EMAIL .......................................................................................................................... 10 6．DIALLING .......................................... 11/12/13/14 7．MESSAGING ........................................... 15/16/17 8. CONTACTS ............................................ 18/19/20 9. INTENET EXPLOR ............................................ 21 10．RECORDER ................................................. 22 11．CLOCK .................................................... 23 12. CACULATOR ................................................ 24 13．CAMERA ................................................ 25/26  13.1 IMAGE MODE .................................................................................................................. 25  13.2 VIDEO MODE ................................................................................................................. 26 14．IMAGES ............................................. 27/28/29 15．MUSIC ................................................. 30/31 16. CALENDER ................................................. 32 17. FM RADIO ................................................. 33 18. SETTINGS ........................................ 34/35/36/37 19. NOTICES FOR THE USE OF PHONE .............................. 38 User Manual 3 1 . Appearance and Keypad Operations Keys Functions home  Press this button to return home from any application or interface.  Press it to open recently opened application window. menu  Press it to start the menu，which allows you to perform actions in the current interface or options’ menu. back  Press it to return to the previous interface，or to close dialog box 、 options’ menu、notification panel or the keypad. power  Press it to open the phone’s menu，then you could choose to lock the screen、 turn off the phone，or set it to the silent mode . up  Press it to increase the volume  Press it to turn the phone to vibration mode from the silent mode. down  Press it to decrease the volume. P-Serson  Cover it, and then the phone’s backlight will turn off front camera  Entering the camera interface, switched to the front camera can photo yourself. User Manual 4 2. Using Memory Card as U Disk If you want to send music, pictures or other files to the phone’s memory card from the computer，you should set memory card as u disk first. Set memory card as u disk 1) Connect the phone to the computer with USB cable. The notification icon will appear in the status box. 2) Use USB mobile transmission line will connected to the computer 3) In the notification panel, touch USB is connected ，then touch“Open the USB Storage Device”  Uninstall the U Disk from computer The Methods as the same as connection, see the following picture: User Manual 5 1） cell phone connections media equipment (MTP) 2） In the Settings, developers in closed USB debugging options. 3） Use USB mobile transmission line will connected to the computer 4） In the notification panel, the choice of "media equipment (MTP)" connection mode, can be in the PC for SD card  Notice：If you in the cell phone connections to the computer playing media equipment, the mobile phone will not be able to identify memory CARDS. You will not be able to use some of the mobile phone applications, like camera.  The phone connection camera (PTP) 1） Using the USB mobile transmission line will connected to the computer. You don't have to shut down USB debugging, see below. Only under the camera view images User Manual 6 2）After the connection can be directly in the PC check images captured on camera。  Notice: different PC operating system to how to operate to normal use the U disk. 1） WIN7 Can directly use 2） XP update windows media player to 11 3） Install wpdmtp.inf driver 4） V ista Unconfirmed  Notice :On the PC operation assistant tool such as mobile phone, Must be open the USB debugging. User Manual 7 3.WIFI Wi-Fi provides as far as 300feet (100M) range of wireless network access. If you use cell phone to connect wifi, you should connect to the wireless access point or 「hot spots」.  Notices：The availability and coverage of Wi-Fi signal depend on the number, infrastructure and other objects penetrated by the signal. Open Wi-fi and to connect to the wireless network 1) Press home>menu，then touch settings>wifi and internet 2) Select the wi-fi box，to open Wi-Fi. Phone will automatically scan for available wireless networks. 3) Touch Wi-Fi settings. Then a list of Wi-Fi network will show the founded network name and security settings. (open network or WEP、WPA/WPA2 with password).If you enable the notification in Wi-Fi settings, The status box will show this icon () when open available wireless network founded. 4) Touch one of the Wi-Fi choices to connect the network. When you choose open network, phone will connect to it automatically. If you choose WEP、WPA/WPA2 with password, you should type the password first, then touch to connect it.  Notices：when the phone is connected to the wireless network, The status box will show this Wi-Fi icon（）, and the approximate signal strengthen (the number of lit bars).If touch the connected network，will display the name of Wi—Fi network, status, speed, signal, strength, security, information and IP address. If you want to delete the wireless settings, please touch “not reserve” as in the right picture. If you want to connect to this network, you should re-enter these settings.  Notices： Unless you choose…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Santok Limited 2015.11.30 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Santok Limited hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: SMARTPHONE model name: Galactic 6 FCC ID: 2AE7RSTKGALACTIC6 Sincerely, Client’s signature : Gordon Macfadyen Client’s name / title: Senior Project Manager Applicant company: Santok Limited address: Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip,Middlesex, United Kingdom

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template& Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 Santok Limited 11/30/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AE7RSTKGALACTIC6 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Gordon Macfadyen Client’s name / title: Senior Project Manager Applicant company: Santok Limited address: Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip,Middlesex, United Kingdom

Santok Limited WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for IC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : 2AE7RSTKGALACTIC6 Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Client’s signature : Gordon Macfadyen Client’s name / title: Senior Project Manager Applicant company: Santok Limited address: Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip,Middlesex, United Kingdom

ProjectNo:STS1511124 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 ProjectNo:STS1511124 Photo3 Photo4 ProjectNo:STS1511124 Photo5 Photo6 ProjectNo:STS1511124 Photo7 Photo8 ProjectNo:STS1511124 Photo9

Label SMARTPHONE Model name: Galactic 6 FCC ID: 2AE7RSTKGALACTIC6 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

BT/WIFI ANTENNA GSM/WCDMA ANTENNA 2.3CM 1.2CM 2.0CM 4.2CM 15.8CM 1.8CM 4.0CM GPS ANTENNA 2.3CM 14.5CM

Project No: STS1511124 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 GSM/WCDMA Antenna GPS Antenna WIFI/BT Antenna Project No: STS1511124 Photo 3 Photo 4 Project No: STS1511124 Photo 5 Photo 6 Project No: STS1511124 Photo 7 Photo 8 Project No: STS1511124 Photo 9 Photo 10

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1511124H01 Issued for Santok Limited Santok House, Unit L, Braintree Industrial Estate Braintree Road, South RuislipMiddlesex, United Kingdom. Product Name: SMARTPHONE Brand Name: STK Model No.: Galactic 6 Series Model: N/A FCC ID: 2AE7RSTKGALACTIC6 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:0.384 W/kg Body:0.715 W/kg S T L A B S Page 2 of 93 Report No.: STS1511124H01 Test Report Certification Applicant’s name ................. : Santok Limited Address ................................. : Santok House, Unit L, Braintree Industrial Estate Braintree Road, South RuislipMiddlesex, United Kingdom. Manufacture's Name ............ : AAPPAA TECHNOLOGY(HK) LIMITED Address ................................. : 3F, B1 BUILDING, GUANGHAOFENG INDUSTRIAL PARK,GUSHU, BAO'AN, SHENZHEN,CHNIA Product description Product name ........................ : SMARTPHONE Trademark ............................ : STK Model and/or type reference : Galactic 6 Series Model .......................... : N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ............................................ : Date (s) of performance of tests ............. : 26 Nov. 2015 Date of Issue ........................................... : 30 Nov. 2015 Test Result ............................................... : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 93 Report No.: STS1511124H01 TABLE OF CONTENTS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Factory 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Antenna Location Sketch 13 7.1 SAR TEST EXCLUSION CONSIDER TABLE 14 8. EUT Test Position 16 8.1 Define Two Imaginary Lines On The Handset 16 8.2 Hotspot mode exposure position condition 17 9. Uncertainty 18 9.1 Measurement Uncertainty 18 9.2 System validation Uncertainty 20 10. Conducted Power Measurement 22 11. EUT And Test Setup Photo 26 11.1 EUT Photo 26 11.2 Setup Photo 29 12. SAR Result Summary 35 12.1 Head SAR 35 12.2 Body SAR And Hotspot 36 13. Equipment List 39 Appendix A. System Validation Plots 40 Appendix B. SAR Test Plots 52 Appendix C. Probe Calibration And Dipole Calibration Report 93 Page 4 of 93 Report No.: STS1511124H01 1. General Information 1.1 EUT Description Equipment SMARTPHONE Brand Name STK Model No. Galactic 6 Series Model N/A FCC ID 2AE7RSTKGALACTIC6 Model Difference N/A Adapter Input: AC100-240V, 0.15A, 50/60 Hz Output: DC 5V, 1000mA Battery Rated Voltage: 3.8V Charge Limit: 4.35V Capacity: 3000mAh Hardware Version W25_MB_V2.0_20150727 Software Version N/A Frequency Range GSM 850:824.2~848.8 MHz PCS1900:1850.2~1909.8 MHz WCDMA II:1852.4~1907.6 MHz WCDMA V:826.4~846.6 MHz WLAN 802.11 b/g/n(HT20):2412~2462 MHz Bluetooth:2402~2480 MHz Transmit Power(Average): GSM 850: 32.45dBm GSM 1900: 29.04dBm WCDMA II: 22.71dBm WCDMA V: 22.60dBm 802.11b: 16.2dBm 802.11g: 13.5dBm 802.11 n(HT20): 13.6dBm 802.11 n(HT40): 11.9dBm Bluetooth: 4.543dBm Max. Reported SAR(1g): Head: GSM 850: 0.129 W/kg GSM 1900: 0.071 W/kg WCDMA II: 0.169 W/kg WCDMA V: 0.121 W/kg WIFI: 0.384 W/kg Body: GSM 850: 0.715 W/kg GSM 1900: 0.246 W/kg WCDMA II: 0.705 W/kg WCDMA V: 0.353 W/kg WIFI: 0.210 W/kg Operating Mode: GSM: GSM Voice, GPRS, EGPRS Class 12; WCDMA: RMC, HSDPA, HSUPA Release 6; WLAN: 802.11 b/g/n; Bluetooth: V4.0 + EDR (GFSK +π/4DQPSK+8DPSK) Antenna Specification: GSM/WCDMA: PIFA Antenna BT/WIFI: PIFA Antenna Hotspot Mode: Support DTM Mode: Not Support Page 5 of 93 Report No.: STS1511124H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Factory Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building B, Zhuoke Science Park,No.190, Chongqing Road, Fuyong, Baoan District, Shenzhen, Guangdong, China CNAS Registration No.: L7649 FCC Registration No.: 842334; IC Registration No.: 12108A-1 Page 6 of 93 Report No.: STS1511124H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB 941225 D01 v03r01 SAR Mea…

Text truncated - open the document above for the full version.

Ref : A CR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING B, ZHUOKE SCIENCE PARK, No.190, CHONGQING ROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONG,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2015 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2015 Checked by : Jérôme LUC Product Manager 9/19/2015 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2015 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2015 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled wit…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1511124F02 Issued for Santok Limited Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip, Middlesex, United Kingdom Product Name: SMARTPHONE Brand Name: STK Model No.: Galactic 6 Series Model: N/A FCC ID: 2AE7RSTKGALACTIC6 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 38 Report No.: STS1511124F02 TEST RESULT CERTIFICATION Applicant’s name .................. : Santok Limited Address ................................... : Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip, Middlesex, United Kingdom Manufacture's Name ............. : AAPPAA TECHNOLOGY(HK) LIMITED Address ................................... : 3F, B1 BUILDING, GUANGHAOFENG INDUSTRIAL PARK, GUSHU, BAO'AN, SHENZHEN,CHNIA Product description Product name............................ : SMARTPHONE Model and/or type reference . : Galactic 6 Series Model ............................. : N/A Standards............................... : FCC Part15.247 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, thidocument may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date (s) of performance of tests .............. : 19 Nov. 2015 ~26 Nov. 2015 Date of Issue ............................................. : 27 Nov. 2015 Test Result ................................................. : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 38 Report No.: STS1511124F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 19 4.5 TEST RESULTS 19 4.6 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 23 5. CONDUCTED SPURIOUS EMISSIONS 24 5.1 REQUIREMENT 24 5.2 TEST PROCEDURE 24 5.3 TEST SETUP 24 5.4 EUT OPERATION CONDITIONS 24 5.5 TEST RESULTS 25 6. POWER SPECTRAL DENSITY TEST 28 6.1 APPLIED PROCEDURES / LIMIT 28 6.2 TEST PROCEDURE 28 Page 4 of 38 Report No.: STS1511124F02 Table of Contents Page 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 6.5 TEST RESULTS 29 7. BANDWIDTH TEST 31 7.1 APPLIED PROCEDURES / LIMIT 31 7.2 TEST PROCEDURE 31 7.3 TEST SETUP 31 7.4 EUT OPERATION CONDITIONS 31 7.5 TEST RESULTS 32 8. PEAK OUTPUT POWER TEST 34 8.1 APPLIED PROCEDURES / LIMIT 34 8.2 TEST PROCEDURE 34 8.3 TEST SETUP 34 8.4 EUT OPERATION CONDITIONS 34 8.5 TEST RESULTS 35 9. ANTENNA REQUIREMENT 36 9.1 STANDARD REQUIREMENT 36 9.2 EUT ANTENNA 36 10. EUT TEST PHOTO 37 Page 5 of 38 Report No.: STS1511124F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b) Peak Output Power PASS -- 15.247 (c) Radiated Spurious Emission PASS -- 15.247 (d) Power Spectral Density PASS -- 15.205 Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 6 of 38 Report No.: STS1511124F02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment SMARTPHONE Trade Name STK Model Name Galactic 6 Series Model N/A Model Difference N/A Product Description The EUT is a SMARTPHONE Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology BLE Number Of Channel 40 Antenna Designation: Please see Note 3. Antenna Gain (dBi) -1 dbi Channel List Please refer to the Note 2. Adapter Input:AC 100-240V,50/60Hz,150mA Output:DC 5V,1000mA Battery Rated Voltage: 3.8V Charge Limit: 4.35V Capacity :3000mAh Hardware version number W25_MB_V2.0_20150727 Software versioning number N/A Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the ma…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1511124F04 Issued for Santok Limited Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip, Middlesex, United Kingdom Product Name: SMARTPHONE Brand Name: STK Model No.: Galactic 6 Series Model: N/A FCC ID: 2AE7RSTKGALACTIC6 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 61 Report No.: STS1511124F04 TEST RESULT CERTIFICATION Applicant’s name .................. : Santok Limited Address ................................... : Santok House,Unit L, Braintree Industrial Estate Braintree Road, South Ruislip, Middlesex, United …
