2AEAZ-300Cguidercare 300C

Guidercare CO., LTD.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 05, 2026
Application Purpose: Original Equipment
Equipment Note: guidercare 300C
Frequency Range: 2402.00000000 - 2480.00000000
Company: Guidercare CO., LTD.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

300C C C High-strength plastic shell Display Screen High-strength plastic shell Acrylic lenses 2-pin charging contacts Toggle/Power Key Confirm/SOS Button Off-white Cold-sea blue, red-white, light brown ,leather Display Size inch FCC Statement

Attestation Statements

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AEAZ-300C 300C We, Applicant Company Name: Guidercare CO., LTD. Address: 4F., No.197, Jingmao 2nd Rd., Nangang Dist, TAIPEI, Taiwan Phone: +886-2-2728-1155 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc. or any of ist successors and assignees. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-01-05 Signature Date Name / Title: Pin Hsiang Hsu / CEO Company: Guidercare CO., LTD. Address: 4F., No.197, Jingmao 2nd Rd., Nangang Dist, TAIPEI, Taiwan Phone: +886-2-2728-1155 Fax: +886-2-2728-1051 E-Mail: [email protected]

Attestation Statements

Due Diligence Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern FCC ID Model name 2AEAZ-300C 300C Pursuant to KDB 986446 D01 Covered Equipment Guidance the evaluation of the product above shows compliance for the following reasons: Compliance Evaluation process Results Inherent compliance The chipset(s) used is not capable of running the cybersecurity and/or anti-virus software Compliance The memory used does not allow the running the cybersecurity and/or anti-virus software Compliance The storage capacity does not allow the running the cybersecurity and/or anti-virus software Compliance The operating system used is not capable of running the cybersecurity and/or anti-virus software Compliance No inherent compliance Based on software bill of material Based on scan for running software on the device Based on filesystem scan for cybersecurity and/or anti-virus software The equipment for which authorization is sought complies with the rules and fulfils the requirements as detailed in the above mentioned KDB. Evaluation performed by Company Name: Shenzhen LCS Compliance Testing Laboratory Ltd. Contact Name: Martion Lee Address: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Phone: +86-755-82591330 Email: [email protected] Signature: Date: 2025-12-30

Cover Letter(s)

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2AEAZ-300C 300C For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-01-05 Signature Date Name / Title: Pin Hsiang Hsu / CEO Company: Guidercare CO., LTD. Address: 4F., No.197, Jingmao 2nd Rd., Nangang Dist, TAIPEI, Taiwan Phone: +886-2-2728-1155 Fax: +886-2-2728-1051 E-Mail: [email protected]

External Photos

Page1of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com ExternalPhotosoftheEUT Fig.1 Fig.2 Page2of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.3 Fig.4 Page3of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.5 Fig.6 Page4of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.7

ID Label/Location Info

Page1of1FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com LABELANDLOCATION (Size:L1.0cmxW0.5cm) LabelLocation Model:300C FCCID:2AEAZ-300C

Internal Photos

Page1of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com InternalPhotosoftheEUT Fig.1 Fig.2 Page2of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.3 Fig.4 Page3of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.5 Fig.6 Antenna Page4of4FCCID:2AEAZ-300C GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.7 Fig.8

RF Exposure Info

Page 1 of 9 FCCID:2AEAZ-300CReportNo.:LCSC12055017EB GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com RFExposureEvaluation For GuidercareCO.,LTD. guidercare300C TestModel:300C Preparedfor:GuidercareCO.,LTD. Address: 4F.,No.197,Jingmao2ndRd.,NangangDist.,TaipeiCity11568, Taiwan Preparedby:GuangzhouLCSComplianceTestingLaboratoryLtd. Address: No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou, Guangdong,China Tel:(+86)020-39166689 Fax:(+86)020-39166619 Web:www.LCS-cert.com Mail:[email protected] Dateofreceiptoftestsample:December12,2025 Numberoftestedsamples:2 SampleNo.:A251201008-1,A251201008-2 Serialnumber:Prototype DateofTest:December12,2025~December29,2025 DateofReport:December30,2025 Page 2 of 9 FCCID:2AEAZ-300CReportNo.:LCSC12055017EB GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com RFExposureEvaluation ReportReferenceNo......................:LCSC12055017EB DateofIssue.......................................:December30,2025 TestingLaboratoryName..............:GuangzhouLCSComplianceTestingLaboratoryLtd. Address................................................: No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou, Guangdong,China TestingLocation/Procedure.............:FullapplicationofHarmonisedstandards■ PartialapplicationofHarmonisedstandards□ Otherstandardtestingmethod□ Applicant’sName.............................:GuidercareCO.,LTD. Address................................................:4F.,No.197,Jingmao2ndRd.,NangangDist.,TaipeiCity11568, Taiwan TestSpecification Standard..............................................:FCCKDBpublication447498D01GeneralRFExposureGuidance v06 FCCCFR47part11.1310 FCCCFR47part22.1093 TestReportFormNo.........................:TRF-4-E-215A/0 TRFOriginator....................................:GuangzhouLCSComplianceTestingLaboratoryLtd. MasterTRF.........................................:Dated2011-03 GuangzhouLCSComplianceTestingLaboratoryLtd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe GuangzhouLCSComplianceTestingLaboratoryLtd.isacknowledgedascopyrightownerandsourceof thematerial.GuangzhouLCSComplianceTestingLaboratoryLtd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. TestItemDescription......................:guidercare300C TradeMark..........................................:Guider TestModel...........................................:300C Ratings.................................................:PleaseRefertoPage6 Result..................................................:PASS Compiledby:Supervisedby:Approvedby: LifengLe/FileadministratorsJustinZhu/TechniqueDirectorGavinLiang/Manager Page 3 of 9 FCCID:2AEAZ-300CReportNo.:LCSC12055017EB GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com RFExposureEvaluation TestResultPASS Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. TestReportNo.:LCSC12055017EB December30,2025 Dateofissue TestModel.............................. : 300C EUT......................................... : guidercare300C Applicant...............................:GuidercareCO.,LTD. Address...................................:4F.,No.197,Jingmao2ndRd.,NangangDist.,TaipeiCity11568, Taiwan Telephone...............................:/ Fax..........................................:/ Manufacturer.........................:GUIDERCAREHOLDINGSLIMITED Address...................................:ROOM1702,SINOCENTRE,582-592NATHANRD.,MONGKOK, KLNHONGKONG Telephone...............................:/ Fax..........................................:/ Factory...................................:GuangdongMingkangyiCloudIntelligentTechnologyCo.,Ltd. Address...................................:B-3Workshop,YangjiangMainPlatformIndustrialNewSpace,Eastof theIntersectionofGaoxinAvenueandHaigangZongyiRoad, YangjiangHigh-techIndustrialDevelopmentZone,YangjiangCity Telephone...............................:/ Fax..........................................:/ Page 4 of 9 FCCID:2AEAZ-300CReportNo.:LCSC12055017EB GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com RevisionHistory ReportVersionIssueDateRevisionContentRevisedBy 000December30,2025InitialIssue--- Page 5 of 9 FCCID:2AEAZ-300CReportNo.:LCSC12055017EB GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com TABLEOFCONTENTS DescriptionPage 1.PRODUCTINFORMATION....................................................................................................................................6 2.EVALUATIONMETHODANDLIMIT....................................................................................................................7 3.REFEREVALUATIONMETHOD..........................................................................................................................7 4.CONDUCTEDPOWERRESULTS........................................................................................................................7 5.MANUFACTURINGTOLERANCE........................................................................................................................8 6.EVALUATIONRESULTS...........................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 1 of 8 Antenna Specifications CUSTOMER 优爱康 CS P/N W93 HX P/NA16-103-W93 Checked by(RF) Checked by(ME) Checked by(QA) Approval led by CustomerApproval Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 2 of 8 Index 1. General Description........................................................................................3 1.1 Print Acceptance...........................................................................................3 1.2 Coordinate System.......................................................................................3 2. Specifications................................................................................................. 4 2.1 Frequency Band...........................................................................................5 2.2 Impedance....................................................................................................5 2.2.1 Nominal...................................................................................................................................................5 2.2.2 Matching Circuit......................................................................................................................................5 2.3 Passive Measurements................................................................................5 2.3.1 S11 of the Typical Sample.......................................................................................................................5 2.3.2Passive efficiency of antenna..............................................................................................................6 3. Specifications Drawings................................................................................. 7 4. Environmental Characteristic..........................................................................8 Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 3 of 8 1. General Description This document provides the antenna specifications on electric, mechanicand reliability. The testing conditions and related pictures are also included. 1.1Print Acceptance Samples andAntenna Specifications are to be sent to customer. When they are approved, the approval form should be completed, signed, and sent back to HX before further mass production batches can be delivered. 1.2 Coordinate System The coordinate system for the phone is defined as follows:  Origin in center of gravity.  Positive X axis is perpendicular to, and directed from, front plane.  Positive Y axis is perpendicular to, and directed from, right side plane (as seen from front).  Positive Z axis is perpendicular to, and directed from, top plane. a) E0-planeb) E90-planec)Az-plane Figure 1-1 The coordinate system for the phone y x  y z x x y zz Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 4 of 8 2. Specifications This report mainly provides the testing conditions of various electric and structural performance parameters for cell phone antenna ---W93 Figure 2-1 shows theantenna designed by HX & The fixturing of W93 Figure 2-1 The antenna designed by HX & The fixturing of W93 Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 5 of 8 2.1 Frequency Band Band BT antenna2400MHz~2500MHz 2.2Impedance 2.2.1 Nominal Nominal Impedance(including matching circuit) : 50 ohms 2.2.2 Matching Circuit The matching circuit is as Figure 2-2. 匹配无变更 Figure 2-2: Matching circuit 2.3 Passive Measurements 2.3.1 S11 of the Typical Sample BT antenna Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 6 of 8 2.3.2 Passive efficiency of antenna BT antenna Technical Specification Band ModeNameFrequencyAntenna Type Antenna Max Gain BT Bluetooth 2400-2500PIFA -3.24 dBi Technical Specification G/W/B 3-D Patten Plots 2.4G: 2430Mhz2.4G: 2470Mhz Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-27599500 page 7 of 8 3. Specifications Drawings Antenna Specifications SHENZHEN HENGXIANGTONG ANTENNA TECNOLOGY CO., LTD. Add: 606, Building E, Enterprise Aviation Technology Innovation Research and Development Industrial Park, No. 1008, Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Tel. +86-755-27657751 Fax +86-755-…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Appendix A RF Test Data for BT LE (Conducted Measurement) Product Name: guidercare 300C Test Model: 300C Environmental Conditions Temperature: 23.9C Relative Humidity: 52.6% ATM Pressure: 100.0 kPa Test Engineer: Zhang hai Supervised by: Fengliu Tang Page 2 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant1 0.661 >=0.5 Pass NVNT BLE 1M 2440 Ant1 0.682 >=0.5 Pass NVNT BLE 1M 2480 Ant1 0.667 >=0.5 Pass NVNT BLE 2M 2404 Ant1 1.112 >=0.5 Pass NVNT BLE 2M 2440 Ant1 1.141 >=0.5 Pass NVNT BLE 2M 2478 Ant1 1.134 >=0.5 Pass Page 3 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs -6dB Bandwidth NVNT BLE 1M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1M 2440MHz Ant1 Page 4 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com -6dB Bandwidth NVNT BLE 1M 2480MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2404MHz Ant1 Page 5 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com -6dB Bandwidth NVNT BLE 2M 2440MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2478MHz Ant1 Page 6 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.2 Maximum Peak Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT BLE 1M 2402 Ant1 2.37 30 Pass NVNT BLE 1M 2440 Ant1 2.22 30 Pass NVNT BLE 1M 2480 Ant1 1.76 30 Pass NVNT BLE 2M 2404 Ant1 2.07 30 Pass NVNT BLE 2M 2440 Ant1 1.99 30 Pass NVNT BLE 2M 2478 Ant1 2.20 30 Pass Page 7 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs Power NVNT BLE 1M 2402MHz Ant1 Power NVNT BLE 1M 2440MHz Ant1 Page 8 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Power NVNT BLE 1M 2480MHz Ant1 Power NVNT BLE 2M 2404MHz Ant1 Page 9 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Power NVNT BLE 2M 2440MHz Ant1 Power NVNT BLE 2M 2478MHz Ant1 Page 10 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant1 -13.77 8 Pass NVNT BLE 1M 2440 Ant1 -14.12 8 Pass NVNT BLE 1M 2480 Ant1 -14.9 8 Pass NVNT BLE 2M 2404 Ant1 -16.7 8 Pass NVNT BLE 2M 2440 Ant1 -17.18 8 Pass NVNT BLE 2M 2478 Ant1 -16.45 8 Pass Page 11 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs PSD NVNT BLE 1M 2402MHz Ant1 PSD NVNT BLE 1M 2440MHz Ant1 Page 12 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com PSD NVNT BLE 1M 2480MHz Ant1 PSD NVNT BLE 2M 2404MHz Ant1 Page 13 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com PSD NVNT BLE 2M 2440MHz Ant1 PSD NVNT BLE 2M 2478MHz Ant1 Page 14 of 34 FCC ID: 2AEAZ-300C Report No.: LCSC12055017EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.4 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -54.28 -20 Pass NVNT BLE 1M 2480 Ant1 -56.61 -20 Pass NVNT BLE 2M 2404 Ant1 -57.86 -20 Pass NVNT BLE 2M 2478 Ant1 -58.11 …

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Pin Hsiang Hsu

[email protected]Fax: 02-2728-1051

Technical Contact

HOORAY INDUSTRY LLCCindy Wu

[email protected]

1408 Pinon Place Fullerton, · California, 92835 · United States

Test Firm

Guangzhou LCS Compliance Testing Laboratory LtdAndy Yang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	1.70 mW

Confidentiality

Long Term

Grant Notes

Power listed is maximum peak conducted output power. This filing meets the SAR threshold exclusion set forth in KDB 447498 and therefore can be used in mobile/portable configurations. The antenna used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
