2AEEA-E-COPYWireless remote control

Simple manual Parameter 1. Frequency：433.92MHZ， 2. button：4 buttons 3. Voltage：12VDC(battery :12V/23A ) 4. Encode type：copy code 5. Signal delay：0 Seconds 6. Stand by current：0mA 7. Working current：13mA 8. Output power：<2dBm 9. Modulation：ASK(OOK) 10. Distance：>50M (open area) 11. Working Temp：-10°C-60°C How to copy? a) Press the 1 st and 2 nd button at the same time, the LED will slow flash 5 times then quick flash, release the 1 st and 2 nd button then press the button you need to copy, the LED will be on and now come to the copy status. b) Makes the remotes close to the original remote, press the button of the original one, the remote’s LED flash 2 times then off, it means you copy success c) The same copy way for other buttons. Recovery to HT12E code Press the 3 rd and 4 th button of the remote control, the LED will flash 3times, then keep pressing the 3 rd button and press 3 times of the 4 th button, the LED will flash, then the code will be recovery to be HT12E code Mainly used in electric doors, windows, lifting equipment, gates, elevators, industrial control, and security industries. [SEA S.p.A.] certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List(as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement.

Rev 1/26/2023 SEA S.p.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/2/2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AEEA-E-COPY [SEA S.p.A.] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signed: Printed name: Fabrizio Saverio Title: Manager Company Name: SEA S.p.A. Rev 1/26/2023 SEA S.p.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/2/2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AEEA-E-COPY [SEA S.p.A.] certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List(as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signed: Printed name: Fabrizio Saverio Title: Manager Company Name: SEA S.p.A.

SEA S.p.A. Zona Industriale S. Atto Teramo 64100 Italy Teramo, Italy Date: July 1, 2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEEA-E-COPY FRN: 0024427320 US Agent – Attestation Statement / Part 2.911(d)(7) SEA S.p.A.certifies, that as of [06/04/2024], we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AEEA-E-COPY. SEA S.p.A., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of SEA S.p.A. for FCC ID: 2AEEA-E-COPY. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: SEA S.p.A. Designated Agent: FCC US Agent, LLC Company Representative: Fabrizio Saverio Designated Agent Representative: Tim Payne Signature: Signature:

SEA S.p.A. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: July 2, 2024 Subject; Request for Long Term Confidentiality FCC ID: 2AEEA-E-COPY To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune up It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: July 2, 2024 Name Fabrizio Saverio Position Manager Company Name SEA S.p.A. Address Zona Industriale S. Atto Teramo 64100 Italy Teramo, Italy Tel +39 0861 588341 Fax +39 0861 588344 Email [email protected]

SEA S.p.A. 2024-07-02 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Person: Mark Zhu (Name: Shenzhen Alpha Product Testing Co., Ltd. and address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by TMICO still resides with SEA S.p.A.Address: Zona Industriale S. Atto Teramo 64100 Italy Teramo, Italy (applicant name and address). Signature: Name Fabrizio Saverio Position Manager Company Name SEA S.p.A. Address Zona Industriale S. Atto Teramo 64100 Italy Teramo, Italy Tel +39 0861 588341 Fax +39 0861 588344 Email [email protected]

FCC ID: 2AEEA-E-COPY FCC ID: 2AEEA-E-COPY ANT FCC ID: 2AEEA-E-COPY

4.5cm 2.5cm Label Location FCC ID: 2AEEA-E-COPY SEA S.p.A. Product name: Wireless remote control Model No.: Coccinella E-Copy This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AEEA-E-COPY FCC ID: 2AEEA-E-COPY ANT FCC ID: 2AEEA-E-COPY

RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 1-mW Test Exemption A single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 kHz to 100 GHz, regardless of fixed, mobile, or portable device exposure conditions. This is a standalone exemption, and it cannot be applied in conjunction with any other test exemption. 1-mW Test Exemption for Multiple Sources The 1-mW exemption intended for single transmitters may be also applied to simultaneous transmission conditions, within the same host device, according one of the following criteria: a) When maximum available power each individual transmitting antenna within the same time averaging period is ≤ 1 mW, and the nearest parts of the antenna structures of the simultaneously operating transmitters are separated by at least 2 cm. b) When the aggregate maximum available power of all transmitting antennas is ≤ 1 mW in the same time-averaging period. This exemption may not be combined with any other exemption. SAR-Based Exemption This exemption is applicable to the frequency range between 300 MHz and 6 GHz, with test separation distances between 0.5 cm and 40 cm, and for all RF sources in fixed, mobile, and portable device exposure conditions. Accordingly, a RF source is considered an RF exempt device if its available maximum time-averaged (matched conducted) power or its effective radiated power (ERP), whichever is greater, are below a specified threshold. This exemption threshold was derived based on general population 1-g SAR requirements. This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by follow Formulas “f” is in GHz, “d” is the separation distance (cm) Simultaneous Transmission with SAR-based Exemptions For these cases, a device with multiple RF sources transmitting simultaneously will be considered an RF exempt device if the condition of following Formula is satisfied. (1-mW Test Exemption) As this equipment: EIRP = Pt * Gt = (E*d) 2 /30 So Pt=(E*d) 2 /(30*Gt) where: Pt = transmitter output power in watts, Gt = numeric gain of the transmitting antenna (unit-less), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m Field strength: E=62.4 dBuV/m @3m Ant gain 3 dBi; so Ant numeric gain Gt=2 So Pt={[10 (62.4/20) /10 6 x3] 2 /(30*2) }x1000 mW =0.000261 mW<1mW Then the SAR test is exempted.

深圳市创遥科技有限公司 SHENZHEN C&Y TECHNOLOGY CO.,LTD File Name Product Name Product model Drawing number effective date Remote control SEA-COCCINELL A-4K(S02) Remarks：Antenna specification （Antenna specifications） explain： The remote control adopts the radiation power of PCB on board antenna, t he antenna width is 4mm, the gain is 3dBi, SWR<2.0 制作 审核 核准

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008-3008-95 Website: http://www.a-lab.cn FCC TEST REPORT FCC ID: 2AEEA-E-COPY On Behalf of SEA S.p.A. Wireless remote control Model No.: Coccinella E-Copy Prepared for : SEA S.p.A. Address : Zona Industriale S. Atto Teramo 64100 Italy Teramo, Italy Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2406011-C01-R05 Date of Receipt : June 7, 2024 Date of Test : June 7, 2024 - July 30, 2024 Date of Report : July 30, 2024 Version Number : V0 Test Result : Pass Page 2 of 32 Report No.: A2406011-C01-R05 Contents 1. General Information ..........................................................................................................5 1.1. Description of Device (EUT) ............................................................................................ 5 1.2. Accessories of Device (EUT) .......................................................................................... 6 1.3. Tested Supporting System Details .................................................................................. 6 1.4. Test Facility ...................................................................................................................... 6 2. Summary of Test ...............................................................................................................7 2.1. Summary of Test Result .................................................................................................. 7 2.2. Block Diagram ................................................................................................................. 7 2.3. Test Mode ........................................................................................................................ 8 2.4. Test Conditions ................................................................................................................ 8 2.5. Measurement Uncertainty (95% confidence levels, k=2) ................................................ 8 2.6. Test Equipment ................................................................................................................ 9 3. Radiation Emission ........................................................................................................ 10 3.1. Radiation Emission Limits(15.209&231) ....................................................................... 10 3.2. Test Setup ...................................................................................................................... 10 3.3. Test Procedure .............................................................................................................. 11 3.4. Test Equipment Setting For emission test. .................................................................... 12 3.5. Test Condition ................................................................................................................ 12 3.6. Test Result ..................................................................................................................... 12 4. Power Line Conducted Emission ................................................................................. 19 4.1. Conducted Emission Limits (15.209) ............................................................................. 19 4.2. Test Setup ...................................................................................................................... 19 4.3. Test Procedure .............................................................................................................. 19 4.4. Test Results ................................................................................................................... 20 5. Occupied bandwidth ...................................................................................................... 21 5.1. Test Limit ....................................................................................................................... 21 5.2. Method of Measurement................................................................................................ 21 5.3. Test Setup ...................................................................................................................... 21 5.4. Test Results ................................................................................................................... 21 6. Transmission Time ........................................................................................................ 23 6.1. Test Limit ....................................................................................................................... 23 6.2. Method of Measurement................................................................................................ 23 6.3. Test Setup ...................................................................................................................... 23 6.4. Test Results ................................................................................................................... 23 7. Antenna Requirement .................................................................................................... 25 7.1. Standard Requirement ................................................................................................... 25 7.2. Antenna Connected Construction ................................................................................. 25 7.3. Result............................................................................................................................. 25 8. Test Setup Photo ........................................................................................................... 26 9. Ph…

Text truncated - open the document above for the full version.

FCC ID: 2AEEA-E-COPY 1.1. Photo of Radiated Emission test
