400 / 600 / 1000 Watt + Turbo Charge ® *** READ THESE IMPORTANT INSTRUCTIONS BEFORE USING YOUR BALLAST *** INSTRUCTION MANUAL KEEP ORIGINAL PACKAGING— all returns need to be in the original packaging in order to avoid product damage during shipping. Any damage to products not in their original packaging will not be covered under warranty. SAFETY FIRST! Failure to observe the following safety warnings may result in serious injury. In addition, failure to observe these safety warnings will result in a waiver of all liabilities and will void all warranties. WARNING  If the exterior of the lamp is damaged, replace lamp immediately.  When re-lamping, make sure lamp has time to cool before touching.  Make sure power cord and lamp cord are connected properly.  Disconnect power before re-lamping.  DO NOT make contact with the interior of the socket while power is on.  DO NOT operate light systems in wet locations.  DO NOT attempt to rewire or reconfigure your system, it will void warranty and could cause serious safety hazards (i.e. power cord, lamp cord, lamp socket or ballast).  DO NOT hang by power or lamp cord.   DO NOT plug system into supply voltage other than what is designated on ballast.  Keep away from children.  DO NOT alter or modify this unit in any way. It may cause bodily injury or death as this is a high power electrical device.  DO NOT submerse in water or splash water on the unit.  DO NOT plug or unplug the lamp cord while the ballast is energized. These high performance Electronic Ballasts are extremely efficient. They have a high power factor and high luminous efficacy. It’s stable performance creates constant power output even when power fluctuates (power surge). Short circuit protection technology prevents damage to the lamp and other ballasts connected to the same circuit. 1. INSTALLATION PROCEDURE  DO NOT alter or modify the electronic ballast in any way. Not only may it damage the unit, it will void the warranty.  Lamp power rating must match electronic ballast power rating. OUTPUT TO HPS/MH LAMP Connect lamp cord with male plug to dual universal female lamp cord receptacle on ballast WARRANTY This unit, when properly used will provide you with years of service. It is covered under a 3 year warranty. This warranty will be voided if the unit is misused, abused or altered. Warranty repair or replacement will be at the sole discretion of the manufacturer. Defective units need to be returned to the place of purchase with proof of purchase/receipt. This warranty is expressly in lieu of all other warranties, expressed or implied, including the warranties of merchantability and fitness for use and of all other obligations or liabilities on the part of the seller. This warranty shall not apply to this product or any part thereof which has been damaged by accident, abuse, misuse, modification, negligence, alteration or misapplication. Manufacturer makes no warranty whatsoever in respect to accessories or parts not supplied by manufacturer. This warranty does not cover labor, materials, equipment, etc. to install or de-install lighting fixtures or any other product. Buyers sole and exclusive remedy shall be the repair or replacement of the defective product at the sellers sole discretion. This warranty shall apply only to the United States, including Alaska, Hawaii and territories of the United States and Canada. RETURNING UNITS Please contact your retail store for returns. CONNECT APPROPRIATE AC POWER PLUG HERE AC input 120 (included) or 240V (purchase separately) The Galaxy Digital Logic offers our exclusive Smart Volt ® feature, allowing operation on either 120 or 240 volt power by simply plugging in the appropriate power cord. There is no further modification necessary. It comes with a 120 volt power cord. To run this ballast on 240 volt, purchase the 240 volt power cord separately (part #903082 six foot or #903084 twenty foot). 2. SPECIFICATIONS  120-240 Volts  Power source frequency: 50/60Hz  Power Factor (cosø): > 0.99  Ambient Temp: 50 ̊F to 120 ̊F  Crest Factor: < 1.5  Acoustic Resonance: none  Total Harmonic Distortion: (THD): < 10.0% www.galaxyballasts.com Part 18 complianceThis device complies with Part 18 of the FCC Rules. Advisory statement This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30 MHz. The interference potential of the device or system The interference potential of the device or system is the operating frequency; 65 kHz. Maintenance of the systemUnplug the unit, wait 30 seconds, and plug the unit back in. Simple measures that can be taken by the user to correct interference Move the unit away from any radio device.  This product contains delicate electronic components. This means that if it is placed near an object that transmits radio signals, it could cause interference. This could be, for example, mobile telephones, walkie talkies, CB radios, remote controls and microwaves. If interference occurs, move such objects away from the appliance. Galaxy Digital Logic Select-A-Watt 400/600/1000/Turbo Charge 120/240 Volt: FCC#: 2AEHV902232 3. NOTES Galaxy Electronic Ballasts will operate with Metal Halide lamps and High Pressure Sodium lamps that are rated at the proper wattage. This unit offers short-circuit and power fluctuation. MAINTENANCE  Regularly check the ballast for dust or dirt buildup. Clean the outside of the fixture using a dry or damp cloth.  Regularly check the wiring of the product to ensure it is undamaged. 240V WIRING - VERY IMPORTANT! All digital ballasts may malfunction if the 240V circuit has a neutral. The input for the ballast is 2 HOT WIRES and 1 GROUND WIRE. If you are using a light controller ONLY bring a ground wire and two hot leads from your electrical panels. HOT RESTRIKE - It is VERY IMPORTANT that the lamp is given adequate time to cool down before…

Text truncated - open the document above for the full version.

Sunlight Supply, Inc Page 1 Cover Letter for FCC Application FCC ID: 2AEHV902518 Date: 05/19/2015 Sunlight Supply requests certification under FCC Part 18 for our consumer RF lighting device with FCC ID number 2AEHV902518. This contains the 120/240V Model 902518. These are all listed under Class B Residential requirements and tested under NWEMC Test Report # SNSY0015. The radio frequency for each model is identical and was tested under all the same requirements. It utilized a 1000W High Pressure Sodium Lamp in a Single Ended Reflector with a 15 foot lamp cord. Sincerely, Bruce LeBlanc Compliance Manager

Confidentiality Letter-FCC Date: 5/19/2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We hereby respectfully request that under the provision of 47 CFR 0.459 and 0.457(d) the documents listed below and attached with this application for certification be provided with confidential status.  Schematics.pdf  Operational Description.pdf  Frequency Block Diagrams.pdf  Internal Photos o Long term Confidentiality due to the circuit board is covered in epoxy and not accessible by the users. Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, Bruce LeBlanc Compliance Manager

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. This Report may only be duplicated in its entirety Sunlight Supply Galaxy Legacy 902518 Report # SNSY0015 NVLAP Lab Code: 200630-0 WTD 13.9.30 CERTIFICATE OF TEST Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Last Date of Test: November 05, 2014 Sunlight Supply Model: Galaxy Legacy 902518 Emissions Standards Specification Method FCC 18.305:2014 RF lighting - consumer levels (c) MP-5:1986 FCC 18.307:2014 RF lighting - consumer levels (c) MP-5:1986 Results Test Description Applied Results Comments Radiated Emissions Yes Pass Conducted Emissions Yes Pass Deviations From Test Standards None Approved By: Kyle Holgate, Operations Manager Report No. SNSY00152/19 REVISION HISTORY REV 2014.10.14 Revision Number Description Date Page Number 00 None Report No. SNSY00153/19 ACCREDITATIONS AND AUTHORIZATIONS REV 2014.10.08 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIP / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ Report No. SNSY00154/19 EMISSIONS MEASUREMENTS REV 2014.10.08 Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document WP 342. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) can be found included as part of the applicable test description page. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-2 as applicable), and are available upon request. Measurement Bandwidths Frequency Range (MHz) Peak Data (kHz) Quasi-Peak Data (kHz) Average Data (kHz) 0.01 - 0.15 1.0 0.2 0.2 0.15 - 30.0 10.0 9.0 9.0 30.0 - 1000 100.0 120.0 120.0 Above 1000 1000.0 N/A 1000.0 Measurements were made using the bandwidths and detectors specified. No video filter was used. Sample Calculations Radiated Emissions: Field Strength Measured Level Antenna Factor Cable Factor Amplifier Gain Distance Adjustment Factor External Attenuation 33.5 = 42.6 + 28.6 + 3.1 - 40.8 + 0.0 + 0.0 Conducted Emissions: Adjusted Level Measured Level Transducer Factor Cable Factor External Attenuation 47.1 = 26.7 + 0.3 + 0.1 + 20.0 Report No. SNSY00155/19 FACILITIES REV 2014.10.08 Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs NC01-05,SU02,SU07 19201 120 th Ave. NE Bothell, WA 98011 (425) 984-6600 VCCI A-0108 A-0029 A-0109 A-0110 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834F-1 NVLAP NVLAP Lab Code: 200630-0 NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200629-0 Report No. SNSY00156/19 WTD 13.9.30 PRODUCT DESCRIPTION Client and Equipment Under Test (EUT) Information Company Name: Sunlight Supply Address: 5408 NE 88th Street Bldg A101 City, State, Zip: Vancouver, WA 98665 Test Requested By: Ken Garver Model: Galaxy Legacy 902518 First Date of Test: November 05, 2014 Last Date of Test: November 05, 2014 Receipt Date of Samples: November 05, 2014 Equipment Design Stage: Production Equipment Condition: No Damage Information Provided by the Party Requesting the Test Functional Description of the EUT: RF lighting device Highest frequency generated or used i…

Text truncated - open the document above for the full version.

RADIATED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 1 RADIATED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 1 RADIATED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 2 RADIATED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 2 CONDUCTED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 1 Report No. SNSY00152/8 CONDUCTED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 1 Report No. SNSY00153/8 CONDUCTED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 2 Report No. SNSY00154/8 CONDUCTED EMISSIONS WTD.2014.10.14 PSA-ESCI 2014.09.10, EmiR5 2014.07.09 Configuration 2 Report No. SNSY00155/8
