2AEIM-1509518DB-pillar Endpoint

MODEL Y OWNER'S MANUAL Contents Overview. .................................................... 2 Interior Overview. ................................................................ 2 Exterior Overview. ............................................................... 3 Touchscreen Overview. ........................................................ 4 Opening and Closing. .................................. 6 Keys. ..................................................................................... 6 Doors................................................................................... 12 Windows. ............................................................................ 15 Rear Trunk. ........................................................................ 16 Front Trunk. ...................................................................... 18 Interior Storage and Electronics. ...................................... 21 Seating and Safety Restraints. ................. 25 Front and Rear Seats. ........................................................ 25 Seat Belts. .......................................................................... 29 Child Safety Seats.............................................................. 33 Airbags. .............................................................................. 40 Driving. ..................................................... 44 Driver Profiles .................................................................... 44 Steering Wheel. .................................................................. 46 Mirrors. .............................................................................. 48 Starting and Powering Off ................................................ 50 Gears. ................................................................................. 52 Lights. ................................................................................ 54 Car Status. ......................................................................... 57 Wipers and Washers. ......................................................... 60 Braking and Stopping. ....................................................... 61 Traction Control. ................................................................ 65 Park Assist. ........................................................................ 66 Vehicle Hold. ...................................................................... 68 Track Mode. ........................................................................ 69 Getting Maximum Range. ................................................. 70 Rear View Camera. ............................................................ 71 Dashcam. ............................................................................ 72 Pedestrian Warning System. ............................................. 74 Autopilot. ................................................... 75 About Autopilot. ................................................................. 75 Traffic-Aware Cruise Control. ........................................... 78 Autosteer. ........................................................................... 84 Autopark. ........................................................................... 91 Summon. ............................................................................ 93 Smart Summon. ................................................................. 96 Lane Assist. ........................................................................ 99 Collision Avoidance Assist. .............................................. 102 Speed Assist. .................................................................... 105 Using the Touchscreen. ............................ 107 Controls. ........................................................................... 107 Climate Controls. ............................................................. 116 Maps and Navigation....................................................... 122 Media and Audio. ............................................................. 128 Phone. ............................................................................... 131 Calendar. .......................................................................... 133 Using Voice Commands. .................................................. 134 Security Settings. ............................................................. 135 HomeLink ® Universal Transceiver. ................................ 138 Connecting to Wi-Fi. ........................................................ 141 Software Updates. ............................................................ 142 Charging. ................................................. 144 Electric Vehicle Components. .......................................... 144 Battery Information. ........................................................ 146 Charging Instructions...................................................... 148 Maintenance. .......................................... 153 Maintenance Schedule. .................................................... 153 Tire Care and Maintenance. ............................................ 155 Cleaning. .......................................................................... 162 Wiper Blades and Washer Jets. ...................................... 165 Fluid Reservoirs. .............................................................. 166 Jacking and Lifting. ......................................................... 168 Parts and Accessories. ..................................................... 169 Specifications .......................................... 170 Identification Labels. ....................................................... 170 Vehicle Loading. ............................................................... 171 Dimensions and Weights. ................................................ 173 Subsystems. ...................................................................... 175 Wheels and Tires........…

Text truncated - open the document above for the full version.

Confidentiality Request Letter Date: January 20, 2020 Federal Communications Commission Authorization and Evaluation Division Subject: Request for confidentiality FCC ID: 2AEIM-1509518D To whom it may concern: Short-term Confidentiality Pursuant to Public Notice DA 04-1705, and in order to comply with the marketing regulations in 47 C.F.R. §2.803 and the importation rules in 47 C.F.R. §2.1204 while ensuring that business-sensitive information remains confidential until the actual marketing of newly authorized devices, we are request the Commission grant temporary confidential treatment and not release the following attachments for routine public disclosure until 180 days after the grant date. 1. Internal Photographs 2. External Photographs 3. User’s manual 4. Test Set up photos Permanent Confidentiality Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. 1. Block Diagram 2. Schematics 3. Operational Description It is our understanding that test measurement reports and correspondence during the certification review process cannot be granted confidential treatment, and such information will be available for public review once the grant of equipment authorization is issued. Sincerely, Applicant : Tesla Motors, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _________________________________ Name and Job Title. : Peng Zhang, Sr Certification Engineer E-mail : [email protected] Te l . : 510 213 1367

Power of Attorney Date: January 20, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: 2AEIM-1509518D Product Name: B-pillar Endpoint To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization to the FCC Rules and Regulations. Sporton International Inc. Address : No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Name : Leo Huang Job Title : Manager e-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Tesla Motors, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _________________________________ Name and Job Title. : Peng Zhang, Sr Certification Engineer E-mail : [email protected] Te l . : 510 213 1367

Tesla, Inc. 3500 Deer Creek Road, Palo Alto, CA 94304 p +650 681 5100 f +650 681 5101 Federal Communications Commission Office of Engineering & Technology Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Via Electronic Filing Date: Oct 3, 2019 Re: Authorized Personnel for Grantee Code 2AEIM To Whom It May Concern: I currently serve as Tesla Motors, Inc’s (Tesla) grantee contact (Grantee Code 2AEIM) for Federal Communications Commission (FCC) equipment authorizations. As prescribed in KDB 852134 Authorized Policy Form 731, I authorize the following personnel to act on Tesla’s behalf with regard to all matters that relate to FCC equipment authorization (i.e., signing Form 731, attestation letters, and confidentiality request letters). These individuals also are authorized to assign additional persons to act on Tesla’s behalf as authorized agents. Authorized Personnel: • Peng Zhang This authorization is valid until further written notice from any of Tesla’s authorized grantee contacts. Sincerely Yours, Sean Lui Sr. Staff Charging Compliance Engineer 3500 Deer Creek Road, Palo Alto, California US 94304 Phone: (650)681-5109 [email protected]

Date: January 20, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Declaration of composite/rated equipment for FCC ID: 2AEIM-1509518D To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as Class B personal computers and peripherals has been authorized under the Supplier's Declaration of Conformity (SDoC) procedures. Sincerely, Applicant : Tesla Motors, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _________________________________ Name and Job Title. : Peng Zhang, Sr Certification Engineer E-mail : [email protected] Te l . : 510 213 1367

Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 1 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020

Note: 1. All logos need to be 5mm minimum diameter. 2. All letters font size needs to be 4pt minimum. 3. TRA label. TRA letter need to be 3mm in height. Other letter in TRA letter need to be 2mm height. If TRA label print on package instead of product. The requirement for size needs to be double. 4. TESLA INC Model Number: 1509518D FCC ID: 2AEIM-1509518D IC: 20098-1509518D This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B)/NMB-3(B) Label Location

Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 2 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 3 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 4 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 5 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 6 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 7 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 8 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 9 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Photographs of EUT Report No. : EP9O2512-01 SPORTON International Inc. Page No. : 10 of 10 TEL : 886-3-327-3456 EP Report Version : Rev. 01 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 ─────THE END─────

FCC Test Report Report No. : FR9O2512-01AR TEL : 886-3-327-3456 Page Number : 2 of 33 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Report Template No.: HE1-C6 Ver2.4 Report Version : 01 FCC ID: 2AEIM-1509518D Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Testing Applied Standards ..................................................................................................................... 7 1.3 Testing Location Information .................................................................................................................. 7 1.4 Measurement Uncertainty ...................................................................................................................... 7 2 TEST CONFIGURATION OF EUT......................................................................................................... 8 2.1 Test Condition ........................................................................................................................................ 8 2.2 The Worst Case Modulation Configuration ............................................................................................ 8 2.3 Test Channel Frequencies Configuration ............................................................................................... 8 2.4 The Worst Case Measurement Configuration ........................................................................................ 9 2.5 Support Equipment ............................................................................................................................... 10 2.6 Test Setup Diagram ............................................................................................................................. 11 3 TRANSMITTER TEST RESULT .......................................................................................................... 12 3.1 AC Power-line Conducted Emissions .................................................................................................. 12 3.2 Emission Bandwidth ............................................................................................................................. 16 3.3 Field Strength of Fundamental Emissions and Spectrum Mask .......................................................... 18 3.4 Transmitter Radiated Unwanted Emissions ......................................................................................... 20 3.5 Frequency Stability ............................................................................................................................... 29 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 33 Appendix A. Test Photos Photographs of EUT V01 FCC Test Report Report No. : FR9O2512-01AR TEL : 886-3-327-3456 Page Number : 3 of 33 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Report Template No.: HE1-C6 Ver2.4 Report Version : 01 FCC ID: 2AEIM-1509518D History of this test report Report No. Version Description Issued Date FR9O2512-01AR 01 Initial issue of report Jan. 22, 2020 FCC Test Report Report No. : FR9O2512-01AR TEL : 886-3-327-3456 Page Number : 4 of 33 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Report Template No.: HE1-C6 Ver2.4 Report Version : 01 FCC ID: 2AEIM-1509518D Summary of Test Result Report Clause Ref. Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PASS FCC 15.203 3.1 15.207 AC Power-line Conducted Emissions PASS FCC 15.207 3.2 15.215(c) Emission Bandwidth PASS Fall in band F L ≥ 13.553 MHz F H ≤ 13.567 MHz 3.3 15.225(a)~(d) Field Strength of Fundamental Emissions and Spectrum Mask PASS 124 dBuV/m at 3m 3.4 15.225(d) Transmitter Radiated Unwanted Emissions PASS FCC 15.209 3.5 15.225(e) Frequency Stability PASS ± 0.01% (100ppm) Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and explanations: None Reviewed by: Sam Tsai Report Producer: Kate Lo FCC Test Report Report No. : FR9O2512-01AR TEL : 886-3-327-3456 Page Number : 5 of 33 FAX : 886-3-327-0973 Issued Date : Jan. 22, 2020 Report Template No.: HE1-C6 Ver2.4 Report Version : 01 FCC ID: 2AEIM-1509518D 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range Modulation Mode Ch. Frequency (MHz) Channel Number Field Strength (dBuV/m) 13.553 – 13.567 MHz ISO 14443-3A (ASK) 13.56 1 78.56 Note 1: Field strength performed peak level at 3m. 1.1.2 Antenna Information Antenna Category Equipment placed on the market without antennas Integral antenna (antenna permanently attached) Temporary RF connector provided No temporary RF connector provided Transmit chains bypass antenna and soldered temporary RF connector provided for connected measurement. In case of conducted measurements the transmitter shall be connected to the measuring equipment via a suitable attenuator and correct for all losses in the RF path. External antenna (dedicated antennas) Antenna General Information No. Ant. Cat. Ant. Type 1 Integral Loop 1.1.3 EUT Information Operational Condition EUT Power Type From DC Power supply Type of EUT Stand-alone Combined (EUT where the radio part is fully integrated within another device) Combined Equipment - Brand Name / Model No.: Plug-in radio (EUT intended for a variety of host systems) Host Syste…

Text truncated - open the document above for the full version.

Test Report Appendix A SPORTON INTERNATIONAL INC. Page No. : A1 of A4 TEL : 886-3-327-3456 FAX : 886-3-327-0973 9O2512-01 1. Photographs of Conducted Emissions Test Configuration Front view Side view Test Report Appendix A SPORTON INTERNATIONAL INC. Page No. : A2 of A4 TEL : 886-3-327-3456 FAX : 886-3-327-0973 9O2512-01 Under Table View Test Report Appendix A SPORTON INTERNATIONAL INC. Page No. : A3 of A4 TEL : 886-3-327-3456 FAX : 886-3-327-0973 9O2512-01 2. Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz Front view Rear view Test Report Appendix A SPORTON INTERNATIONAL INC. Page No. : A4 of A4 TEL : 886-3-327-3456 FAX : 886-3-327-0973 9O2512-01 For radiated emissions 30MHz~1GHz Front view Rear view ─────THE END─────
