2AEIM-1877513V4 Supercharger NA Connector/Handle

V4 SUPERCHARGER INSTALLATION MANUAL Confidential Information - Shared Under NDA Only 1 ABOUT THIS MANUAL This manual contains specifications and procedures required for the successful installation of the Tesla V4 Supercharger. READ THIS ENTIRE DOCUMENT BEFORE INSTALLING OR WORKING WITH THE SUPERCHARGER SYSTEM. Failure to do so or to follow any of the instructions or warnings in this document can result in electrical shock, serious injury, death, or damage to one or more parts of the Supercharger system, potentially rendering it inoperable. All specifications and descriptions contained in this document are verified to be accurate at the time of printing. However, because continuous improvement is a goal at Tesla, we reserve the right to make product or documentation modifications at any time, with or without notice. © 2012-2023 TESLA, INC. All rights reserved. All information in this document is subject to copyright and other intellectual property rights of Tesla, Inc. and its lic ensors. This material may not be modified, reproduced, or copied, in whole or in part, without the prior written permission of Tesla, Inc. and its licensors. Additional information is available upon request. The following are trademarks or registered trademarks of Tesla, Inc. in the United States and other countries: MADE IN THE USA 2 DISCLAIMER This document is updated as often as possible, but some sections may become outdated as a result of rapid, unforeseen changes in the service development process. This manual communicates Notes, Cautions, and Warnings with the following icons and definitions. NOTE: Indicates an important step or tip that leads to best results, but is not necessarily related to physical safety or equipment damage. CAUTION: Indicates a hazardous situation which, if not avoided, may result in damage to equipment, tooling, or other hardware. WARNING: Indicates a hazardous situation which, if not avoided, may result in bodily injury or death. ABOUT THIS MANUAL 3 FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF Exposure Information (MPE) This device has been tested and meets applicable limits for Radio Frequency (RF) exposure. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. IC Regulations: CAN ICES-3(B)/NMB-3(B) This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. RF Exposure Information (MPE) This device has been tested and meets applicable limits for Radio Frequency (RF) exposure. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. Informations d'exposition RF (MPE) Cet appareil a été testé et répond aux limites applicables en matière d'exposition aux radiofréquences (RF). Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. COMPLIANCE INFORMATION The V4 Supercharger system is classified as the following for the specified categories: CategoryV4 Supercharger Classification Characteristics of power supply inputElectric Vehicle supply equipment (cabinet) connected to an AC supply network Electrical connection methodPermanently connected Characteristics of power supply outputDC Electric Vehicle supply equipment Normal environmental conditionsOutdoor use AccessEquipment for locations with restricted access Mounting methodStationary equipment; floor/ground mounted Protection against electric shockClass I equipment Charging modeMode 4 4 PART NUMBERS Part NamePart Number Charge Post Skin1671197-00-A Charge Post Side Covers1863921-00-A NOTE: Please find the V4 Supercharger Post Datasheet linked here. 5 STEP 1: REMOVING THE CHARGE POST SKINS 1. Remove the cosmetic cover over the cable attachment by sliding it out. 2. Use a small …

Text truncated - open the document above for the full version.

Tesla, Inc. 3500 Deer Creek Road Palo Alto, California, U.S.A. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: September 12, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, Tesla, Inc. (“the applicant”) certifies that the equipment FCC ID: 2AEIM-1877513 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Tesla, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ________________________ Contact Name: Viraj Andrabadu Kurundu Patabendige Title: Sr Manager, Compliance Engineering E-mail: [email protected]

Tesla, Inc. 3500 Deer Creek Road Palo Alto, California, U.S.A. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: September 12, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, Tesla, Inc. (“the applicant”) certifies that the equipment FCC ID: 2AEIM-1877513 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Tesla, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ________________________ Contact Name: Viraj Andrabadu Kurundu Patabendige Title: Sr Manager, Compliance Engineering E-mail: [email protected]

Tesla, Inc. 3500 Deer Creek Road Palo Alto, California U.S.A. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Certification designating a U.S. agent for service of process pursuant to Part 2.911(d)(7) To whom it may concern, [Tesla, Inc., Grantee Code 2AEIM] (“the applicant”) as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC Grantee Code. The service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. The applicant acknowledges that they will maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges their responsibility to inform the FCC whenever the following agent information changes. Company Name: Tesla, Inc. Company US Address: 3500 Deer Creek Road, Palo Alto, CA, United States 94304 Contact Person: Viraj Andrabadu Kurundu Patabendige Email: [email protected] FRN: 0024474967 Sincerely yours, Signed by the Applicant Name: Viraj Andrabadu Kurundu Patabendige Title: Sr Manager, Compliance Engineering Email: [email protected] Date: April 13, 2023

Authorization on Behalf of Tesla Inc. For the US Federal Communications Commission Office of Engineering and Technology and other FCC Programs and Offices 1. I, Sean Lui, am on the Compliance Team of Tesla Inc and Applicant/Grantee Contact of Record for Tesla Inc. together with its subsidiaries and affiliates worldwide (collectively, “Tesla, Inc”) for Tesla’s dealings with the United States Federal Communications Commission (“FCC”). I am duly authorized by Tesla Inc. to make this Authorization on Tesla Inc.’s behalf. 2. This authorization will designate the person named below to act on my behalf and Tesla Inc.’s behalf as authorized agent and representative, until further notice, with the additional power to designate one or more third party agents for Tesla Inc. with regard to particular matters and applications. All acts carried out and requests made by this named representative relating to any matter before the FCC, including requests for confidentiality, shall have the same effect as mine. Name: Viraj Andrabadu Kurundu Patabendige Title: Sr Manager, Compliance Engineering Address: 3500 Deer Creek Road Palo Alto, California 94304 Telephone: 650-339-5597 Email: [email protected] 3. Questions about the scope and effect of this Authorization should be addressed as follows: Sean Lui 3500 Deer Creek Road Palo Alto, California 94304 650-681-5109 [email protected] 4. I declare under penalty of perjury that the foregoing is true and correct, and that this Authorization was executed in California on the date indicated below my signature. ________________________________ Signature Sean Lui Tesla Inc. Date: 20 December 2022

Tesla, Inc. 3500 Deer Creek Road Palo Alto, California, U.S.A. Date: September 12, 2023 FCC Laboratory 7435 Oakland Mills Rd Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2AEIM-1877513 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following documents from public disclosure indefinitely.  Schematic Diagram  Block Diagram  Part List  Operational Description  Tune-up Procedure Above mentioned documents which contain detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we are requesting the Commission to withhold the following documents for 180 days after the grant of equipment authorization is issued:  External Photos  Internal Photos  Test Setup Photos  User Manual It is our understanding that all measurement test reports, FCC ID label format cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, _______________________ Viraj Andrabadu Kurundu Patabendige [email protected]

Tesla, Inc. 3500 Deer Creek Road Palo Alto, California, U.S.A. FCC Agent Authorization Date: September 11, 2023 To whom it may concern, Tesla, Inc. hereby authorize Sporton International Inc. to act on our behalf in all matters relating to applications for FCC equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Sporton International Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988. 21 U.S.C. 862. This authorization is limited to the product of as following: FCC ID: 2AEIM-1877513 This authorization is valid until further written notice from Tesla, Inc. Sincerely, ________________________ Viraj Andrabadu Kurundu Patabendige [email protected]

PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 1 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 1. External Photograph of EUT Brand Name: Tesla / Model Name: 1877513-XX-Y PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 2 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 3 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 4 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 5 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 6 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01

Label Location Label on the side of thecharger charger EUT EUT

PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 7 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 2. Internal Photograph of EUT Brand Name: Tesla / Model Name: 1877513-XX-Y PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 8 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 9 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 10 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP230126001 TEL : 886-3-327-3456 Page Number : 11 of 11 FAX : 886-3-328-4978 Issue Date : Sep. 20, 2023 Report Version : 01 ─────THE END──── Bluetooth-LE Antenna and UHF Antenna

TEL : 886-3-327-3456 Page : 1 of 5 FAX : 886-3-328-4978 Issued Date : Aug. 18, 2023 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA230126001 RF EXPOSURE EVALUATION REPORT FCC ID : 2AEIM-1877513 Equipment : V4 Supercharger NA Connector/Handle Brand Name : Tesla Model Name : 1877513-XX-Y Applicant : Tesla, Inc. 3500 DEER CREEK ROAD PALO ALTO, CA 94304 Manufacturer : Tesla, Inc. 3500 DEER CREEK ROAD PALO ALTO, CA 94304 Standard : 47 CFR Part 2.1091 We, SPORTON INTERNATIONAL INC has been evaluated this product in accordance with 47 CFR Part2.1091 and it complies with applicable limit. Sporton Lab is accredited to ISO 17025 by Taiwan Accreditation Foundation (TAF code: 1190) and the FCC designation No. TW1190 under the FCC 2.948(e) by Mutual Recognition Agreement (MRA) in FCC evaluation. The results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Laboratory, the test report shall not be reproduced except in full SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) Approved by: Cona Huang / Deputy Manager TEL : 886-3-327-3456 Page : 2 of 5 FAX : 886-3-328-4978 Issued Date : Aug. 18, 2023 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA230126001 Table of Contents 1. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 4 2. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 4 3. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 5 4. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 5 4.1. Standalone Power Density Calculation ............................................................................................. 5 TEL : 886-3-327-3456 Page : 3 of 5 FAX : 886-3-328-4978 Issued Date : Aug. 18, 2023 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA230126001 History of this test report Report No. Version Description Issued Date FA230126001 Rev. 01 Initial issue of report Aug. 18, 2023 TEL : 886-3-327-3456 Page : 4 of 5 FAX : 886-3-328-4978 Issued Date : Aug. 18, 2023 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA230126001 1. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type V4 Supercharger NA Connector/Handle Brand Name Tesla Model Name 1877513-XX-Y FCC ID 2AEIM-1877513 Wireless Technology and Frequency Range UHF: 315 MHz Bluetooth: 2400 MHz ~ 2483.5 MHz Mode OOK Bluetooth LE Reviewed by: Jason Wang Report Producer: Daisy Peng 2. Maximum RF average output power among production units Mode Maximum Average power(dBm) UHF 13.00 Bluetooth 2.01 TEL : 886-3-327-3456 Page : 5 of 5 FAX : 886-3-328-4978 Issued Date : Aug. 18, 2023 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA230126001 3. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: 퐒= 퐏퐆 ퟒ훑퐑 ퟐ Where: S = Power Density P = Output Power at Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Distance from Transmitting Antenna 4. Radio Frequency Radiation Exposure Evaluation 4.1. Standalone Power Density Calculation Band Antenna Gain (dBi) Maximum Power (dBm) Maximum EIRP (dBm) Maximum EIRP (W) Average EIRP (mW) Power Density at 20cm (mW/cm^2) Limit (mW/cm^2) UHF -10.94 13.00 2.1 0.002 1.61 0.000 0.210 Bluetooth 4.10 2.01 6.1 0.004 4.08 0.001 1.000 Conclusion: According to 47 CFR §1.1307, the RF exposure analysis concludes that the RF Exposure is FCC compliant.

TEL : 408 9043300 Page Number : 1 of 17 Report Template No.: BU5-FR15C15.231 Version 2.0 Issue Date : Aug. 09, 2023 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR230126001B FCC RADIO TEST REPORT FCC ID : 2AEIM-1877513 Equipment : V4 Supercharger NA Connector/Handle Brand Name : Tesla Model Name : 1877513-XX-Y Applicant : Tesla, Inc. 3500 DEER CREEK ROAD PALO ALTO, CA 94304 Manufacturer : Tesla, Inc. 3500 DEER CREEK ROAD PALO ALTO, CA 94304 Standard : FCC Part 15 Subpart C §15.231 The product was received on Jul. 06, 2023, and testing was performed from Jul. 26, 2023 to Jul. 27, 2023. We, Sporton International (USA) Inc., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval from Sporton International (USA) Inc., the test report shall not be reproduced except in full. Approved by: Abi Lin Sporton International (USA) Inc. 1175 Montague Expressway, Milpitas, CA 95035 TEL : 408 9043300 Page Number : 2 of 17 Report Template No.: BU5-FR15C15.231 Version 2.0 Issue Date : Aug. 09, 2023 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR230126001B Table of Contents History of this test report ........................................................................................................................................... 3 Summary of The Result.............................................................................................................................................. 4 1. General Information ............................................................................................................................................... 5 1.1 Product Feature of Equipment Under Test ..................................................................................................................... 5 1.2 Product Specification of Equipment Under Test ............................................................................................................. 5 1.3 Modification of EUT ........................................................................................................................................................ 5 1.4 Testing Location ............................................................................................................................................................. 5 1.5 Applicable Standards...................................................................................................................................................... 5 2. Test Configuration of Equipment Under Test ...................................................................................................... 6 2.1 Descriptions of Test Mode .............................................................................................................................................. 6 2.2 Connection Diagram of Test System .............................................................................................................................. 6 2.3 Support Unit used in test configuration and system ....................................................................................................... 6 2.4 EUT Operation Test Setup ............................................................................................................................................. 6 3. Test Results ............................................................................................................................................................ 7 3.1 Types of Momentarily Operated Devices ........................................................................................................................ 7 3.2 20dB and 99% Occupied Bandwidth Measurement ....................................................................................................... 9 3.3 Field Strength of Fundamental and Spurious Emissions .............................................................................................. 12 4. List of Measuring Equipment .............................................................................................................................. 16 5. Uncertainty of Evaluation .................................................................................................................................... 17 Appendix A. Test Results of Radiated Test Items Appednix B. Setup Photographs TEL : 408 9043300 Page Number : 3 of 17 Report Template No.: BU5-FR15C15.231 Version 2.0 Issue Date : Aug. 09, 2023 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR230126001B History of this test report Report No. Version Description Issue Date FR230126001B 01 Initial issue of report Aug. 09, 2023 TEL : 408 9043300 Page Number : 4 of 17 Report Template No.: BU5-FR15C15.231 Version 2.0 Issue Date : Aug. 09, 2023 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR230126001B Summary of The Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark - 15.207 AC Power Line Conducted Emissions Not Required See Note 3.1 15.231(a) Types of Momentary Signals PASS - 3.2 15.231(c) 20dB and 99% Occupied Bandwidth PASS - 3.3 15.231(b) 15.231(e) Field Strength of Fundamental and Spurious Emissions PASS 5.48 dB Under the limit at 1260.00 MHz Note: The EUT is powered by DC power source, it does not operate from the AC power lines or contain provisions for operation while connected to the AC power lines, according to 47 CFR § 15.207(c), the conducted emission limits are not applicable to the device hence the test is not performed. Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance t…

Text truncated - open the document above for the full version.

TEL : 408 9043300 Page Number : B1 of B1 FCC RADIO TEST REPORT Report No. : FR230126001B Appendix B. Setup Photographs <Radiated Spurious Emission> X Plane 30MHz ~ 1GHz Above 1GHz ─────THE END─────
