2AEIM-BTVMS01TPMS sensor

Tesla Inc. 3500 Deer Creek Road, Palo Alto, CA. 94304 Model: BTVMS01 Tire Pressure Monitoring Sensor PMN: TPMS Sensor Operating Temperature: -40°C to +120°C EU: Tesla Motors Netherlands B.V. Asteriastraat 1-7 5047 RM Tilburg The Netherlands User Manual The TPMS Transmitter is installed to the valve stem in each tyre of a vehicle. The unit measures tyre pressure periodically and transmits this information by RF communication to a receiver inside the vehicle. In addition, the TPMS Transmitter performs the following functions: • Determines a temperature compensated pressure value. • Determines any abnormal pressure variations in the wheel. • Monitors the state of the Transmitters’ internal battery and informs the receiver of a low battery condition. Modes Rotating Mode While the sensor/transmitter in the Rotating Mode, it shall satisfy the following requirements. The sensor/transmitter shall transmit an instantaneous measured data, if a pressure change of 2.0 psi from the last transmission or greater has occurred with respect to the following conditions. If the pressure change was a decrease of pressure, the sensor/transmitter shall transmit immediately every time it detects the 2.0-psi or greater pressure changes from the last transmission. If the pressure changes of 2.0 psi or greater was an increase of pressure, the sensor shall not react to it. Stationary Mode While the sensor/transmitter in the Stationary Mode, it shall satisfy the following requirements. The sensor/transmitter shall transmit an instantaneous measured data, if a pressure changes of 2.0 psi from the last transmission or greater has occurred with respect to the following conditions. If the pressure change was a decrease of pressure, the sensor/transmitter shall transmit immediately every time it detects the 2.0-psi or greater pressure changes from the last transmission. If the pressure changes of 2.0 psi or greater was an increase of pressure, the silent period between the RPC transmission and the last transmission shall be 30.0 seconds, and the silent period between the RPC transmission and the next transmission (Normal scheduled transmission or another RPC transmission) shall also be 30.0 seconds, to be in compliance of FCC Part 15.231. Factory Mode The factory mode is the mode that the sensor shall transmit more often in the factory to assure the programmability of the sensor ID during the manufacturing process. Off Mode This Off Mode is only for production parts sensors that are used for the builds during the production process and not in the service environment. LF Initiation The sensor/transmitter must provide data upon the presence of an LF signal. The sensor must react (Transmit and provide data) no later than 150.0 ms after the LF data code has been detected at the sensor. The sensor/transmitter must be sensitive (As sensitivity is defined in Table 1) and able to detect the LF field. RF Frequency Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician to help. Compliance with 2014/53/EU Radio Equipment Directive (RED) In accordance with Article 10.8(a) and 10.8(b) of the RED, the following table provides information on the frequency bands used and the maximum RF transmit power of the product for sale in the EU: Frequency range (MHz) Max. Transmit Power 2400-2483.5 MHz -0.82 dBm This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. ****************************************************************************** Note: FCC Radiation exposure: All equipment complies with FCC and IC RSS-102 radiation exposure limits for an uncontrolled environment and the radio device and antennas operating at more than 20cm distance from user. FCC ID: 2AEIM-BTVMS01 IC: 20098-BTVMS01 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ****************************************************************************** This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. WARNING: Changes or modifications not expressively approved by the …

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 30, 2023 FCC ID: 2AEIM-BTVMS01 RE: Attestation Statements Part 2.911(d)(5)(i) Filing Tesla, Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. RE: Attestation Statements Part 2.911(d)(5)(ii) Filing Tesla, Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Applicant : Tesla, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _________________________________ Name and Job Title. : Cindy Li, Certification Engineer E-mail : [email protected] Tel. : +1-408-718-7809

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 30, 2023 FCC ID: 2AEIM-BTVMS01 RE: Attestation Statements Part 2.911(d)(5)(i) Filing Tesla, Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. RE: Attestation Statements Part 2.911(d)(5)(ii) Filing Tesla, Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Applicant : Tesla, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _________________________________ Name and Job Title. : Cindy Li, Certification Engineer E-mail : [email protected] Tel. : +1-408-718-7809

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 30, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: 2AEIM Tesla, Inc (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. The applicant as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC Grantee Code. The service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. The applicant acknowledges that they will maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges their responsibility to inform the FCC whenever the following agent information changes. Designated U.S. Agent Information: FRN: 0020169504 Name: Tesla, Inc Address: 3500 Deer Creek Road, Palo Alto, California 94304, United States Contact Person: Cindy Li Tel.: +1-408-718-7809 Email: [email protected] Sincerely, Applicant Tesla, Inc Cindy Li, Certification Engineer Signature:

Tesla, Inc. 3500 Deer Creek Road, Palo Alto, CA 94304 p +650 681 5100 f +650 681 5101 Federal Communications Commission Office of Engineering & Technology Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Via Electronic Filing Date: April 28, 2021 Re: Authorized Personnel for Grantee Code 2AEIM To Whom It May Concern: I currently serve as Tesla, Inc’s (Tesla) grantee contact (Grantee Code 2AEIM) for Federal Communications Commission (FCC) equipment authorizations. As prescribed in KDB 852134 Authorized Policy Form 731, I authorize the following personnel to act on Tesla’s behalf with regard to all matters that relate to FCC equipment authorization (i.e., signing Form 731, attestation letters, and confidentiality request letters). These individuals also are authorized to assign additional persons to act on Tesla’s behalf as authorized agents. Authorized Personnel: • Peng Zhang • Cindy Li This authorization is valid until further written notice from any of Tesla’s authorized grantee contacts. Sincerely Yours, Sean Lui Sr. Staff Charging Compliance Engineer 3500 Deer Creek Road, Palo Alto, California US 94304 Phone: (650)681-5109 [email protected]

Date: August 30, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: declaration of composite/rated equipment for FCC ID: 2AEIM-BTVMS01 To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as Other Class B digital devices & peripherals has been authorized under the Supplier's Declaration of Conformity (SDoC) procedures. Sincerely, Applicant : Tesla, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _________________________________ Name and Job Title. : Cindy Li, Certification Engineer E-mail : [email protected] Tel. : +1-408-718-7809

Letter of Authorization Date: August 30, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: 2AEIM-BTVMS01 Product Name: TPMS sensor To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization to the FCC Rules and Regulations. Sporton International Inc. Address : No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Name : Leo Huang Job Title : VP e-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Tesla, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : _______________________________ Name and Job Title. : Cindy Li, Certification Engineer E-mail : [email protected] Tel. : +1-408-718-7809

Confidentiality Request Letter Date: August 30, 2023 Federal Communications Commission Authorization and Evaluation Division Subject: Request for confidentiality FCC ID: 2AEIM-BTVMS01 To whom it may concern: Short-term Confidentiality pursuant to Public Notice DA 04-1705, and in order to comply with the marketing regulations in 47 C.F.R. §2.803 and the importation rules in 47 C.F.R. §2.1204 while ensuring that business-sensitive information remains confidential until the actual marketing of newly authorized devices, we are request the Commission grant temporary confidential treatment and not release the following attachments for routine public disclosure until 180 days after the grant date. 1. Internal Photographs 2. External Photographs 3. User’s manual 4. Test Set up photos Permanent Confidentiality Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. 1. Block Diagram 2. Schematics 3. Operational Description It is our understanding that test measurement reports and correspondence during the certification review process cannot be granted confidential treatment, and such information will be available for public review once the grant of equipment authorization is issued. Sincerely, Applicant : Tesla, Inc Address : 3500 Deer Creek Road, Palo Alto, California 94304, United States Signature : ______________________________ Name and Job Title. : Cindy Li, Certification Engineer E-mail : [email protected] Tel. : +1-408-718-7809

PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 1 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 Sample 1 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 2 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 3 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 4 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 Sample 2 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 5 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 6 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01

F E D C B A 8 7 654321 A B C D E F 1 ENG-F-044 ISS 05 2345678 SUPPLIERS - PLEASE NOTE WHEN IN COMMUNICATION WITH SENSATA ABOUT DRAFT ITEMS, PLEASE USE PART NUMBER TOGETHER WITH 3D CAD VERSION AS UNIQUE IDENTIFIER OF REFERENCED 3D CAD MODEL 3D CAD VERSION PART NO. DRAFT - FOR TECHNICAL FEEDBACK OR QUOTATION PURPOSES ONLY DRAWING VERSION 15 70503117292 XXX-XXXXXX 2.4GHZ YYMMDD 1819592-00-A 70503117292 MADE IN XXXXXX MODEL: BTVMS01 IC: 20098-BTVMS01 FCC ID: 2AEIM-BTVMS01 CMIIT ID: XXXXXXXXXX ANATEL: XXXX-XX-XXXX NCC: XXXXXXXXXXXXXX XXXX-XXX-XXX-XXXXXX IFT: XXXXXXXXX-XXXX 01 02 13 04 12 09 16 XXXXXXXXXXXXXXXXXXXXXXXXXXXXX 03 10 ASIC ID: XXXXXXXXXXXX 06 11 17 14 13,15, 20-24 18 19 15 08 07 05 EXAMPLE TEXT STRING: "P1819592-00-A:SGEV24001000001" WOULD BE THE FIRST PART MADE IN ANTRIM ON 01ST JAN 2024 TABLE 2 - PRODUCTION LOCATION PRODUCTION LOCATIONCOUNTRY OF MANUFACTURE AGUASCALIENTESMEXICO ANTRIMUK TABLE 4 - COUNTRY APPROVALS ITEMREGIONAUTHORITY FREQUENCY (GHz) REF CODE/TEXT [TEXT FONT: DIN1451] REQ ON SENSORSIZE REQUIRED 13KOREANKCC2.4XXXX-XXX-XXX-XXXXXXTEXT & SYMBOLLEGIBLE 14AUSTRALIAACMA2.4-SYMBOL3MM HIGH 15TAIWANNCC2.4NCC: XXXXXXXXXXXXXXTEXT & SYMBOLLEGIBLE 16EUROPER&TTE2.4-CE SYMBOL4MM HIGH 17JAPANMIC2.4XXX-XXXXXXTEXT & SYMBOLS 3MM & LEGIBLE 18RUSSIATR CU2.4-SYMBOL5MM HIGH 19UKUKCA2.4-SYMBOL5MM HIGH 20MEXICOIFT2.4IFT: XXXXXXXXX-XXXXTEXTLEGIBLE 21USAFCC2.4FCC ID: 2AEIM-BTVMS01TEXTLEGIBLE 22CANADAIC2.4IC: 20098-BTVMS01TEXTLEGIBLE 23BRAZILANATEL2.4ANATEL: XXXX-XX-XXXXTEXTLEGIBLE 24CHINASRRC2.4CMIIT ID: XXXXXXXXXXTEXTLEGIBLE TABLE 3 - PRODUCT MARKINGS ITEMDESCRIPTIONVALUEFORMSIZE REQUIRED 01TESLA PART NUMBER1819592-00-ALASERLEGIBLE 02SENSATA PART NUMBER70503117292LASERLEGIBLE 03TESLA SYMBOLN/ALASERLEGIBLE 04PRODUCTION LOCATIONMADE IN XXXXXXLASERLEGIBLE 05BLUETOOTH SYMBOLN/ALASERLEGIBLE 06 MAC ADDRESS (HEXADECIMAL) ASIC ID: XXXXXXXXXXXX LASERLEGIBLE 07FREQUENCY2.4GHZLASERLEGIBLE 08DATE OF MANUFACTUREYYMMDDLASERLEGIBLE 092D DATA MATRIX (SENSATA)N/ALASER5MM x 5MM 102D DATA MATRIX (SENSATA)N/ALASER10MM × 3MM 112D DATA MATRIX (TESLA)TESLA DATA STRINGLASER10MM x 10MM 12TESLA DATA STRINGSEE TABLE 5LASERLEGIBLE TABLE 1 - MANUFACTURING CODE MECH CODE01924 TABLE 5 - TESLA DATA STRING DATACHARACTERSVALUE PART NO.14P1819592-00-A: ORIGIN4SXXX WITH XXX BEING AMY FOR AGUAS, GEV FOR ANTRIM YEAR2LAST TWO DIGITS OF YEAR, FOR EXAMPLE, 23 FOR 2023 DAY3001 TO 365 (366 FOR LEAP YEAR) WITH 001 BEING 01ST JAN UNIQUE ID6SEQUENTIAL FROM 000001 01A3 TESLA DELTA 2.4GHZ SILVER 70503117292 LASER MARKING DRAWING - DRAFT 00019624 PRJ0014620 N/A N/A SEE NOTES FOR GENERAL TOLERANCE INTERPRET DRAWING PER ASME Y14.5-2009 THIRD ANGLE PROJECTION DO NOT SCALE DRAWING UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS REVISION SYMBOL PROJECT NO. MASS (g) MATERIAL FOR REFERENCE ONLY, CHECK LATEST REVISION BEFORE USE. REFER TO PLM FOR CONTROLLED DATA, CHANGE HISTORY AND APPROVALS. TECHNOLOGY PARK, ANTRIM, UK, BT41 1QS SHEET 1 OF 1SOLIDWORKS 2020SCALE 2:1 DRAWING REV.DRAWING NO.SIZE TITLE PART NUMBER 70503117292 THIS DRAWING IS CONFIDENTIAL AND PROPRIETARY OF SCHRADER ELECTRONICS LIMITED. THE INFORMATION CONTAINED WITHIN IT MAY NOT BE USED, DISCLOSED OR REPRODUCED IN WHOLE OR PART, WITHOUT THE EXPRESSED WRITTEN CONSENT OF SCHRADER ELECTRONICS LIMITED. NO RIGHT IS GRANTED TO DISCLOSE OR USE ANY INFORMATION CONTAINED WITHIN THIS DRAWING. SCHRADER ELECTRONICS LIMITED IS PART OF THE SENSATA TECHNOLOGIES GROUP. 27/SEP/2023ECO-529419M.W. INITIAL RELEASE 01 DATEECOBYREVISION DESCRIPTIONREV

PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 7 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 8 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 9 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 10 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 11 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP341239 Sporton International Inc. Page No. : 12 of 12 Report Template No.: SE Ver 1.0_EP Issued Date : 27/Sep/2023 Report Version : 01 ─────THE END─────

Radio Exposure Evaluation Report Report No. : FA341239 TEL : 886-3-327-3456 Page Number : 1 of 11 FAX : 886-3-327-0973 Issued Date : Sep. 27, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: 2AEIM-BTVMS01 Radio Exposure Evaluation Report FCC ID : 2AEIM-BTVMS01 Equipment : TPMS sensor Brand Name : Tesla Model Name : BTVMS01 Applicant : Tesla, Inc 3500 Deer Creek Road, Palo Alto, CA. 94304 Manufacturer : Tesla, Inc 3500 Deer Creek Road, Palo Alto, CA. 94304 Standard : 47 CFR FCC Part 2 Subpart J, section 2.1091 The product was received on May 29, 2023, and testing was started from Jul. 03, 2023 and completed on Jul. 03, 2023. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in 47 CFR FCC Part 2 Subpart J, section 2.1091 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Jackson Tsai __________________________________________ SDoC by: XXXXX SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) Radio Exposure Evaluation Report Report No. : FA341239 TEL : 886-3-327-3456 Page Number : 2 of 11 FAX : 886-3-327-0973 Issued Date : Sep. 27, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: 2AEIM-BTVMS01 Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 6 1.3 Testing Location ..................................................................................................................................... 6 2 MAXIMUM PERMISSIBLE EXPOSURE ............................................................................................... 7 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 7 2.2 RF Exposure Exempt Measurement ...................................................................................................... 8 2.3 Multiple RF Sources Exposure ............................................................................................................... 9 2.4 MPE Calculation Method ...................................................................................................................... 10 2.5 Calculated Result and Limit .................................................................................................................. 11 Photographs of EUT V01 Radio Exposure Evaluation Report Report No. : FA341239 TEL : 886-3-327-3456 Page Number : 3 of 11 FAX : 886-3-327-0973 Issued Date : Sep. 27, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: 2AEIM-BTVMS01 History of this test report Report No. Version Description Issued Date FA341239 01 Initial issue of report Sep. 27, 2023 Radio Exposure Evaluation Report Report No. : FA341239 TEL : 886-3-327-3456 Page Number : 4 of 11 FAX : 886-3-327-0973 Issued Date : Sep. 27, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: 2AEIM-BTVMS01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: None Reviewed by: Ryan Hsiao Report Producer: Amber Chiu Radio Exposure Evaluation Report Report No. : FA341239 TEL : 886-3-327-3456 Page Number : 5 of 11 FAX : 886-3-327-0973 Issued Date : Sep. 27, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: 2AEIM-BTVMS01 1 General Description 1.1 Information 1.1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type Bluetooth 2400-2483.5 2402-2480 LE: DSSS (GFSK) 1.1.2 Antenna Information Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 Sensata Technologies JP20230601-1 PCB Trace Antenna N/A -3.8 For Bluetooth function: For Bluetooth mode (1TX/1RX) Only Ant. 1 can be used as transmitting/receiving antenna. 1.1.3 Table for Multiple Listing The Sample in the following table are all refer to the identical product. Sample Description 1 All the samples are identical, only the color of appearance is different. 2 Radio Exposure Evaluation Report Report No. : FA341239 TEL : 886-3-327-3456 Page Number : 6 of 11 FAX : 886-3-327-0973 Issued Date : Sep. 27, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: 2AEIM-BTVMS01 1.2 Applicable Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards:  47 CFR FCC Part 2 Subpart J, section 2.1091  KDB 447498 D04 Interim General RF Exposure Guidance v01 The following reference test guidance is not within the scope of accreditation of TAF.  47 CFR Part 1.1307  47 CFR Part 1.1310 1.3 Testing Location Test Lab.：Sporton International Inc. Hsinhua Laboratory Hsinhua ADD: No.52, Huaya 1st Rd., Guishan Dist., Taoyuan …

Text truncated - open the document above for the full version.

Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls TESLA GEN DELTA BLE SENSOR Antenna Manufacturer: Sensata Technologies Unit 11, Antrim Technology Park, Antrim, Northern Ireland, BT41 1QS, UK Issue Amendment History Name of Author Date 01 Initial release Jonathan Prétot 01-06-2023 Author: (Name) Author: (Signature) Approver: (Name) Approver: (Signature) Date: Jonathan Prétot RF Design & Development Support Technician Emmanuel Marguet RF Design & Development Support Team Manager Document #: JP20230601-1 Destination: Reference: Issue: 01 Date: 01/06/2023 ECN #: Author: Jonathan Prétot Approver: Emmanuel Marguet Contributors: ANTENNA ISOTROPIC PEAK GAIN PATTERN Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz DOCUMENT NUMBER: JP20230601-1 ISSUE LEVEL: 01 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz JP01062022.docx Page 2 of 8 Table of Contents Table of Contents ......................................................................................................................................... 2 i.ABBREVIATIONS / GLOSSARY .................................................................................................................... 3 ii.SUPPORTING DOCUMENTS ...................................................................................................................... 3 iii.DOCUMENT HISTORY AND STORAGE ....................................................................................................... 3 1.Introduction ......................................................................................................................................... 4 2.Description ........................................................................................................................................... 4 3.Antenna gain ........................................................................................................................................ 5 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz DOCUMENT NUMBER: JP20230601-1 ISSUE LEVEL: 01 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz JP01062022.docx Page 3 of 8 i.ABBREVIATIONS / GLOSSARY TERM EXPANSION/MEANING dBi Decibel Isotropic ii.SUPPORTING DOCUMENTS REFERENCE ISSUE iii.DOCUMENT HISTORY AND STORAGE DOCUMENT NAME LOCATION Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz DOCUMENT NUMBER: JP20230601-1 ISSUE LEVEL: 01 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz JP01062022.docx Page 4 of 8 1. Introduction This document shows the antenna pattern and antenna gain of TESLA GEN DELTA BLE 2.4GHz transmitter. 2. Description TESLA GEN DELTA BLE 2.4GHz Specifications: 1.Antenna Type: PCB Trace Antenna 2.Antenna Brand: Sensata Technologies Note: There is no external antenna, the antenna is part of the pcb layout Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz DOCUMENT NUMBER: JP20230601-1 ISSUE LEVEL: 01 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz JP01062022.docx Page 5 of 8 3. Antenna gain Test equipment used: Category Mark Type Calibration due date Anechoic Test Site Sensata Spectrum analyser ANRITSU MS2830A 20/09/2023 Coaxial cable RG214U 50 Ohm 11m Open Boundary Quad- Ridged Horns antenna ETS Lindgren 3164-06 Conditions: The test is performed in anechoic test site. The Transmitter is placed on a rotating table in continuous learn emission (EMC). Description of transmitter positioning: All measurements are done in Anechoic Chamber at 3m with TX on table in 3 positions as follow: Pos. θ=0 Pos θ=90 Pos. φ=0 Peak antenna gain: -3.8 dBi Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz DOCUMENT NUMBER: JP20230601-1 ISSUE LEVEL: 01 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz JP01062022.docx Page 6 of 8 Gain in dBi Position θ=0 polarisations V, H and Module TESLA GEN DELTA BLE 2.4GHz Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz DOCUMENT NUMBER: JP20230601-1 ISSUE LEVEL: 01 Antenna Isotropic Peak Gain Pattern TESLA GEN DELTA BLE 2.4GHz JP01062022.docx Page 7 of 8 Gain in dBi Posi…

Text truncated - open the document above for the full version.
