2AEJJ-JCBA10XTablet PC

9” Tablet User Manual Model: MiTraveler 918 C o n t e n t s 1. Appearance and keys............................................................ 1 2. Basic operation........................................................................... 1 2.1 Switch o n................................................................................ 1 2.2 Unlock the s c r ee n................................................................ 2 2.3 Lock the s c r ee n...................................................................... 2 2.4 Switch o ff ............................................................................... 2 2. 5 Charge the batter y ............................................................. 2 2. 6 Use the keyboard ............................................................... 3 2. 7 Use a micro SD c a r d................................................................ 3 2. 8 Connect to a computer................................................. 4 2. 9 Browse files in the d e v i c e............................................... 4 2.1 0 Star t programs................................................................... 5 2.11 Close programs.................................................................. 5 2.1 2 Screen operation............................................................... 5 2.1 3 Home screen........................................................................ 5 2.1 4 Display s e tt i n gs................................................................... 7 2.1 5 Wireless and network settings................................ 7 3. Technical s p ec i f i c a t i o n s........................................................ 8 D i s c l a i m e r 1. Thank you for purchasing the MiTraveler 918. Before using your new tablet, please read this manual carefully. We will assume that you have read the manual when you use this product. 2. Michley Tivax is not responsible for any damage or loss of personal data caused by misuse of software or h ardware, abuse, accidents, or removal of batteries. To avoid data loss, please back up your personal data.3. Michley Tivax is not responsible for any misunderstanding o f t h e m a n u al , incorrect operation not according to the manual, or accidental losses that occur while using the manual.4. Please do not try to repair the tablet by yourself, as this will void the warranty.5. Michley Tivax reserves the final right to interpret and explain this manual and other relevant information. Safety information Please carefully read this important safety information before using your product.ထ  3 lease do not drop your tablet, place objects on the screen, or allow hard objects to strike it. This may cause scratches, cracks, data loss, or other damage. Number Name Description 1 Homebutton Returntohomescreen 2 Powerbutton Longpressto turnON/OFF;shortpressto enter  orexitsleep mode 3 Headphoneport Pluginheadphones 4 MIC Microphone 5 TFcardport InsertTFcard(microSDcard) 6 MicroUSBport Chargethedeviceorconnecttootherdevices 7 DCjack Chargethedevice 8 Volumebutton Volumeupanddown ထ  1 eve UH x S os HWKLVSURGXFWWRZDWHURUGDPSHQYLURQPHQWV DV Z ate UPD\ O eak LQDQGGDPDJHLWEH\RQGUHSDLU .  ထ  7RDYRLGSHUPDQHQWKHDULQJGDPDJHSOHDVHGRQRWXVHKHDGSKRQHV ZLWK H[FHVVLYHO\ORXGYROXPHIRUSURORQJHGSHULRGV  ထ  7RDYRLGGDWDORVVDQGV\VWHPHUURUVSO eas HGRQ o WWXUQRII\RXUWDEOHW D bru S t O\G urin JVRI twar HXS dat HVRU  do Z n O oads.  ထ  3O eas HGR not W ur QRQW h HG evic HLQSODFHVZ her HZ ire O es VH qui S men WLV  not allowed RUZ he QX s LQJW h HG evic HZ i OOF aus HL nterferenc HRU  danger  3O eas HR bserv HD n \U e O evan WU estrictions.  ထ  3O eas HX s HRQO\WKHR rigina OD ccessorie VD n GE atteries 'RQ o WX s H incom S atib OH  S roducts with the device.  ထ  3O eas HGR not X s HW h LVSURGXFW a t J a VV tatio QVRUQ ear I ue OD n G  chemica O s   ထ  7RDYRLGDFFLGHQWVSO eas HGR not X s HW hi VS roduc WZKLOHG rivin JRU Z a O kin JLQW h H  street.  ထ  3O eas HGRQ o WV cra SHRUGDPDJHW h HV creen, RULWP a \QRORQJHUZRUN .  ထ  1 eve UFO ea QW h HG evic HZ it KF hemica OVRUG etergent 7KLVPD\  damag HW h HVXU fac HD n GF orrod HW h HS aint.  What’s in the box  0L7UDYHOHUWDEOHW – SF 0LFUR86%FDEOH – SF '&FDEOHSF $GDSWHU – SF 8VHUPDQXDO – SF $SS earanc HD n GN eys % asi FRS eration  2. 6Z itc KRQ  Whe QW h HG evic HLVLQW h H2 F )P ode S res VD n GK o OG the power button to turn it ON . 1 1 3 4 5 2 6 8 7 shiyanshi123 2.2 Unlock the screenPress and drag the padlock icon toward the right to unlock the screen. 2.3 Lock the screenWhen the device is in the ON mode, short press the power button to lock the screen and enter power saving mode. This turns off the screen, but the system is still r unning. 2.4 Switch offWhen the device is in the ON mode, press and hold the power button for about 3 seconds. Choose the Power off option on the screen. Press OK to confirm and shut down the system.2. 5 Charge the batter y Insert the small end of the DC adapter into the DC jack on the device, and connect the other end to a power outlet to charge the device.Note: For best results, charge the device for at least 8-12 hours the first time you use it to make sure it is fully charged. While charging, the blue indicator light on the device turns on , and the battery icon on the screen shows a lightning bolt. 2.6 Use the keyboard The tablet has a soft keyboard that appears automatically when you tap the place on the screen where text is to be entered. To change the keyboard language, hold down the comma ( ) key for one second, then release. Choose Input languages, and select the language you want.Note: You can also change keyboard settings by going to…

Text truncated - open the document above for the full version.

DATE : August 18, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEJJ-JCBA10X Product Name: Windows Tablet PC Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this August 18, 2015 Agency agreement expiration date: Usually Give 8 - 12 Months By: Mike Zhang Signature Printed Title: Manager On behalf of : JiaChuangBo Technology Co., Ltd Telephone: 0412-5061691 Tablet PC

Statement We JiaChuangBo Technology Co., Ltd Hereby Declare that The product Tablet PC, models no. MiTraveler 918, MiTraveler 858, MiTraveler 928, MiTraveler 968, MiTraveler 735, MiTraveler 768, MiTraveler 728, MiTraveler 725, MiTraveler 758, MiTraveler 958, MiTraveler 10Q8B, MiTraveler 10Q8A, MiTraveler 10Q8C, MiTraveler 700, MiTraveler 10D8B, JKY J105, JKY J107, JKY Q8, JKY Q10 are all identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Company Name: JiaChuangBo Technology Co., Ltd

 Statement          ! " "# $%&'($%()($%&*($%&+( $%,-)$%,+($%,*($%,*) $%,)($%&)($%'./( $%'./( $%'./($%,..$%'.( 01'.)  01'.,01/(01/'. 2   3 4 3   !"2 1 222   2"2     1 22    5  #   " 6"#       Are applying FCC DOC for Tablet PC with model number: MiTraveler 918, MiTraveler 858, MiTraveler 928, MiTraveler 968, MiTraveler 735, MiTraveler 768, MiTraveler 728, MiTraveler 725, MiTraveler 758, MiTraveler 958, MiTraveler 10Q8B, MiTraveler 10Q8A, MiTraveler 10Q8C, MiTraveler 700, MiTraveler 10D8B, JKY J105, JKY J107, JKY Q8, JKY Q10 FCC DOC is doing at FCC Authorized and Recognized MRA lab. The FCC DOC application will be completed before sell. Your assistance on this matter is highly appreciated.

Outside view Outside view Outside view Outside view

FCC Label Location

Product Name: Tablet PC Model No.: MiTraveler 918 FCC ID: 2AEJJ-JCBA10X Input: DC5V, with Li-ion Battery 3.7V, 4000mAh JiaChuangBo Technology Co., Ltd. FCC Caution: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Inside view Inside view Inside view Inside view

RF Exposure Applicable Standard According to §1.1307(b)(5), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. The Section 4.3.1 and Appendix A of KDB447498 D01 V05 was used as the guidance. Calculation Result (Worse Case): WIFI Mode: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] =9.04/5 * 1.56= 2.82 this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Bluetooth Mode: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] =1.32/5 * 1.56= 0.41 this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Note: Worse case was recorded. The SAR measurement is not necessary. Note: Bluetooth and WIFI can not transmit at the same time.

Report No: FCC 1507103-03 File reference No: 2015-08-19 Applicant: JiaChuangBo Technology Co., Ltd Product: Tablet PC Model No: MiTraveler 918, MiTraveler 858, MiTraveler 928, MiTraveler 968, MiTraveler 735, MiTraveler 768, MiTraveler 728, MiTraveler 725, MiTraveler 758, MiTraveler 958, MiTraveler 10Q8B, MiTraveler 10Q8A, MiTraveler 10Q8C, MiTraveler 700, MiTraveler 10D8B, JKY J105, JKY J107, JKY Q8, JKY Q10 Trademark: N/A Test Standards: FCC Part 15 Subpart C, Paragraph 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10,FCC Part 15 Subpart C, Paragraph 15.247 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: August 19, 2015 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Room 512-519, 5/F., East Tower, Building 4, Anhua Industrial Zone, Futian District, Shenzhen, Guangdong, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No: FCC1507103-03 Page 2 of 48 Date: 2015-08-19 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement˖ The testing quality ability of our laboratory meet with “Quality Law of People’s Republic of China” Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAL-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAL/AC01:2002 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC-Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-02. Report No: FCC1507103-03 Page 3 of 48 Date: 2015-08-19 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT ........................................................................................... 4 1.4 Submitted Sample.............................................................................................. 5 1.5 Test Duration................................................................................................... 5 1.6 Test Uncertainty............................................................................................... 5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification.............................................................................................7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure................................................................…

Text truncated - open the document above for the full version.

Report No: FCC 1507103-01 File reference No: 2015-08-19 Applicant: JiaChuangBo Technology Co., Ltd Product: Tablet PC Model No: MiTraveler 918, MiTraveler 858, MiTraveler 928, MiTraveler 968, MiTraveler 735, MiTraveler 768, MiTraveler 728, MiTraveler 725, MiTraveler 758, MiTraveler 958, MiTraveler 10Q8B, MiTraveler 10Q8A, MiTraveler 10Q8C, MiTraveler 700, MiTraveler 10D8B, JKY J105, JKY J107, JKY Q8, JKY Q10 Trademark: N/A Test Standards: FCC Part 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10, FCC Part 15 Subpart C, Paragraph 15.247 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: August 19, 2015 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Room 512-519, 5/F., East Tower, Building 4, Anhua Industrial Zone, Futian District, Shenzhen, Guangdong, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No: FCC1507103-01 Page 2 of 101 Date: 2015-08-19 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement˖ The testing quality ability of our laboratory meet with “Quality Law of People’s Republic of China” Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAL-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAL/AC01:2002 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC-Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-02. Report No: FCC1507103-01 Page 3 of 101 Date: 2015-08-19 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details............................................................................................... 4 1.3 Description of EUT ........................................................................................... 4 1.4 Submitted Sample.............................................................................................. 5 1.5 Test Duration................................................................................................... 5 1.6 Test Uncertainty............................................................................................... 5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 8 3.1 Summary of Test Results..................................................................................... 8 3.2 Test Standards.................................................................................................. 8 4.0 EUT Modification.............................................................................................8 5.0 Power Line Conducted Emission Test...................................................................... 9 5.1 Schematics of the Test........................................................................................ 9 5.2 Test Method and Test Procedure............................................................................ 9 5.3 C…

Text truncated - open the document above for the full version.

Conducted Emission Test Setup: Radiated Emission Test Setup:
