2AEKR-TC80RA6Tablet PC

ELITEGROUP COMPUTER SYSTEMS CO., LTD
Tablet PC - FCC ID 2AEKR-TC80RA6 - ELITEGROUP COMPUTER SYSTEMS CO., LTD
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Aug 30, 2015
Application Purpose
Original Equipment
Date of Application
Aug 30, 2015
Equipment Note
Tablet PC
Frequency Range
2402.00000000 - 2480.00000000
Company
ELITEGROUP COMPUTER SYSTEMS CO., LTD
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗
↗

External Photos

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗
↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Quick Start Guide For Android Tablet TC80RA6 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation 58 2 RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels. The highest SAR value for the device as reported to the FCC is 1. W/kg when placed next to the body. This symbol indicates this Tablet PC complies with the Directive 2004/108/EC, 1999/5/EC and the European Union’s Low Voltage Directive 2006/95/EC. BATTERY CAUTION ※ Risk of explosion if the battery is replaced with an incorrect type one. ※ Dispose of used batteries according to the instructions. ※ Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. ※ Do not remove any batteries from the computer while it is powered on. ※ Recharge the batteries using the Tablet PC system. Incorrect recharging may make the battery explode. 3 ※ Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel. To prevent possible hearing damage, do not listen at high volume levels for long periods. Package contents Carefully unpack your box and take out the items listed below. If any of the items are missing or damaged, please contact your dealer immediately: • One tablet • One USB charger • One USB cable • This guide 4 Tablet layout No. Name No. Name 1 Touchscreen 3 Headphone jack 2 Front facing camera 4 Micro USB DC IN / Micro USB port 5 No. Name No. Name 1 Micro SD card slot 4 Rear facing camera 2 Power button 5 Speaker 3 Volume up/down 6 Microphone 6 Charging your tablet If your tablet is just being unpacked from the box, you need to charge the tablet first. It will take around 4 to 5 hours to be fully charged. 1. Plug the USB head of the cable into the adapter. 2. Plug the micro-USB head of the cable - with the side marked with “B” or an icon facing up - into the micro-USB port on your tablet. 3. Plug the adapter into a wall-socket. 7 Powering ON/OFF your tablet To power on your tablet Press and hold the power button down until the screen turn on. To power off your tablet To turn off your tablet, follow these steps: 1. Press and hold the power button. 2. The Power-off menu appears as shown below. Touch Power off. 3. Your tablet automatically shuts down. 8 Inserting a storage card Your tablet supports micro-SD cards with maximum storage space up to 32G. You can insert the micro SD card and pull it out without powering down the tablet. To do so, follow the steps below. Install your Micro SD Card 1. Hold your tablet with front side up. You can find the micro SD card slot on the same side with the power button. (For detail, see page 5) 2. Insert your micro SD card in the direction as shown. Remove your Micro SD Card 1. Push and release the micro SD card. This will unlock the card. 2. Pull out the micro SD card. 9 Specifications Processor  Intel® Bay Trail-T Z3735G  Base 1.33 GHz, Burst to 1.83GHz  2 MB L2 Cache Memory  DDR3L- 1333  Default 1 GB Storage  eMMC v4.4.1  Default: 8GB (for KK 4.4+) Wireless  Wi-Fi 802.11 b/g/n  Bluetooth 4.0 Touchscreen  8-inch TN LCD  Resolution: 800x1280 pixels  5-points multi-touch Cameras  Front: 0.3M  Rear: 2.0M Battery  1Cell , 1S1P  Li-polymer  3600 mAh Input/Output  1 x micro-USB 2.0 OTG port (Type B)  1 x Mic/head phone jack combo  1 x micro-SD card slot (32G max) 10 Speaker & Mic  Build-in Speaker x 2  Analog MIC x 1 USB charger  DC Output: 5V/2A  Input Voltage: 100 - 240VAC  Input Frequency: 47 - 63Hz Dimension (mm)  218 (W) x 125 (H) x 10.1 (D) Weight  340 g (w/o adapter)

Cover Letter(s)

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan --------------------------------------------------------------------------------------------------------------------- Date: 2015.08.17 Federal Communications Commission Authorization and Evaluation Division FCC ID: 2AEKR-TC80RA6 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name: Patrick, Yen Position: Section Manager ELITEGROUP COMPUTER SYSTEMS CO., LTD

Cover Letter(s)

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Tiding Blvd., Neihu Dist, Taipei City 14, Taiwan (R.O.C) ------------------------------------------------------------------------------------------------------- Date: 2015-08-17 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AEKR-TC80RA6 To Whom It May Concern: This letter is to ascertain that the following information of applicant, product with model(s) have been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. Applicant: ELITEGROUP COMPUTER SYSTEMS CO., LTD Product Name: Tablet PC Model: TC80RA6, TC80XXX(X=0~9, A~Z or blank) Brand: ECS ELITEGROUP If you have any question or concerns, pls. contact us. Sincerely, Name: Patrick, Yen Position: Section Manager ELITEGROUP COMPUTER SYSTEMS CO., LTD

Cover Letter(s)

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan ----------------------------------------------------------------------------------------------------------------------------------- Declaration of Authorization We Name: ELITEGROUP COMPUTER SYSTEMS CO., LTD Address: No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Declare that: Name Representative of agent: Robin Wu Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone, City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: Tablet PC FCC ID: 2AEKR-TC80RA6 Model: TC80RA6, TC80XXX(X=0~9, A~Z or blank) Brand: ECS ELITEGROUP on our behalf. Name: Patrick, Yen Position: Section Manager ELITEGROUP COMPUTER SYSTEMS CO., LTD Date: 2015-08-17

Cover Letter(s)

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan ---------------------------------------------------------------------------------------------------------------------------- Declaration We Name: ELITEGROUP COMPUTER SYSTEMS CO., LTD Address: No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Manufacturer: ELITEGROUP COMPUTER SYSTEMS CO., LTD Address: No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Product description: Tablet PC FCC ID: 2AEKR-TC80RA6 Model: TC80RA6, TC80XXX(X=0~9, A~Z or blank) Brand: ECS ELITEGROUP There is different of models only for marketing different client, the other was the same. Name: Patrick, Yen Position: Section Manager ELITEGROUP COMPUTER SYSTEMS CO., LTD

ID Label/Location Info

Label Label Location

Internal Photos

Internal Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo (12) EUT Photo

Test Report

CERPASS TECHNOLOGY (SUZHOU) CO., LTD Report No.: SESF1508132 Cerpass Technology Corp. Issued Date : August 18 th , 2015 Te l :86-512-6917-5888 Fax:86-512-6917-5666 Page No. : 1 of 26 Report No. : SESF1508132 Client/Manufacturer : ELITEGROUP COMPUTER SYSTEMS CO., LTD Address : No.239, Sec. 2, Tiding Blvd., Neihu Dist, Taipei City 14, Taiwan (R.O.C) Product : Tablet PC Brand : ECS ELITEGROUP Model : TC80RA6, TC80XXX(X=0~9,A~Z or blank) FCC ID : 2AEKR-TC80RA6 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528-2013 / KDB 865664 D01 v01r03 / KDB 248227 D01 v02r01 / KDB 447498 D01 v05r02 / KDB 616217 D04 v01r01 /KDB 648474 D04 v01r02 Test Date : August 14 th , 2015 Statement of Compliance: The SAR values measured for the test sample are below the maximum recommended level of 1.6W/kg averaged over any 1g tissue according to FCC Acknowledge Data Base/ FCC 47CFR Part 2 (2.1093) / IEEE Std.1528-2013. The test result only corresponds to the tested sample. It is not permitted to copy this report, in part or in full, without the permission of the test laboratory. The testing described in this report has been carried out to the best of our knowledge and ability, and our responsibility is limited to the exercise of reasonable care. This certification is not intended to believe the sellers from their legal and/or contractual obligations. Prepared By: ___________________ Leo Chen Approved By: ___________________ Miro Chueh FCC SAR Report CERPASS TECHNOLOGY (SUZHOU) CO., LTD Report No.: SESF1508132 Cerpass Technology Corp. Issued Date : August 18 th , 2015 Te l :86-512-6917-5888 Fax:86-512-6917-5666 Page No. : 2 of 26 Release Version Report No. Issue Date Description SESF1507176 2015-08-18 Initial release CERPASS TECHNOLOGY (SUZHOU) CO., LTD Report No.: SESF1508132 Cerpass Technology Corp. Issued Date : August 18 th , 2015 Te l :86-512-6917-5888 Fax:86-512-6917-5666 Page No. : 3 of 26 Contents 1. Summary of Maximum SAR Value......................................................................................................4 2. Description of Equipment under Test ................................................................................................5 3. General Information .............................................................................................................................6 4. Basic restrictions and Standards .......................................................................................................7 4.1. Test Standards ..................................................................................................................................7 4.2. Environment Condition......................................................................................................................7 4.3. RF Exposure Limits ...........................................................................................................................7 5. DASY5 Measurement System .............................................................................................................8 5.1. Uncertainty of Inter-/Extrapolation and Averaging ............................................................................9 5.2. DASY5 E-Field Probe .......................................................................................................................9 5.3. Data Acquisition Electronics (DAE) ............................................................................................... 10 5.4. Robot.............................................................................................................................................. 10 5.5. Light Beam Unit ............................................................................................................................. 10 5.6. Measurement Server ...................................................................................................................... 11 5.7. SAM Phantom ................................................................................................................................. 11 5.8. Device Holder ................................................................................................................................ 12 5.9. Test Equipment List ........................................................................................................................ 13 6. The SAR Measurement Procedure .................................................................................................. 14 6.1. System Performance Check .......................................................................................................... 14 6.2. Te s t Requirements ......................................................................................................................... 17 7. Wi-Fi/Bluetooth SAR Exclusion and Results ................................................................................. 20 7.1. Maximum Tune-up Conducted Average Power ............................................................................. 20 7.2. Measured Conducted Average Power ........................................................................................... 20 7.3. Antenna Location ........................................................................................................................... 21 7.4. SAR exclusion ................................................................................................................................ 22 7.5. Required Edges for SAR Testing ................................................................................................... 23 7.6. Estimated SAR ............................................................................................................................... 23 7.7. SAR Test Results Summary ........................................................................................................... 24 8. Simultaneous Transmission Analysis ......................…

Text truncated - open the document above for the full version.

Test Report

MRT Technology (Suzhou) Co., Ltd Report No.: 1508RSU00502 Phone: +86-512-66308358 Report Version: V02 Fax: +86-512-66308368 Issue Date: 08-26-2015 Web: www.mrt-cert.com FCC ID: 2AEKR-TC80RA6 Page Number: 1 of 49 FCC ID: 2AEKR-TC80RA6 APPLICANT: ELITEGROUP COMPUTER SYSTEMS CO., LTD Application Type: Certification Product: Tablet PC Model No.: TC80RA6, TC80XXX(X=0~9, A~Z or blank) Brand Name: ECS ELITEGROUP FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15.247 Test Procedure(s): ANSI C63.10-2013, KDB 558074 D01v03r03 Test Date: August 06 ~ 17, 2015 MEASUREMENT REPORT FCC PART 15.247 Bluetooth v4.0 Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 558074 D01v03r03. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1508RSU00502 FCC ID: 2AEKR-TC80RA6 Page Number: 2 of 49 Revision History Report No. Version Description Issue Date 1508RSU00502 Rev. 01 Initial report 08-22-2015 1508RSU00502 Rev. 02 Revise the test distance 08-26-2015 Report No.: 1508RSU00502 FCC ID: 2AEKR-TC80RA6 Page Number: 3 of 49 CONTENTS Description Page 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .................................................................................................. 7 2.2. Device Capabilities ....................................................................................................... 8 2.3. Test Configuration ........................................................................................................ 8 2.4. EMI Suppression Device(s)/Modifications ..................................................................... 8 2.5. Labeling Requirements ................................................................................................. 8 2.6. Test Software ............................................................................................................... 8 3. DESCRIPTION OF TEST ........................................................................................................ 9 3.1. Evaluation Procedure ................................................................................................... 9 3.2. AC Line Conducted Emissions ..................................................................................... 9 3.3. Radiated Emissions .................................................................................................... 10 4. ANTENNA REQUIREMENTS ................................................................................................. 11 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 12 6. MEASUREMENT UNCERTAINTY ......................................................................................... 13 7. TEST RESULT ...................................................................................................................... 14 7.1. Summary .................................................................................................................... 14 7.2. 6dB Bandwidth Measurement ..................................................................................... 15 7.2.1. Test Limit ................................................................................................................ 15 7.2.2. Test Procedure used ............................................................................................... 15 7.2.3. Test Setting ............................................................................................................. 15 7.2.4. Test Setup ............................................................................................................... 15 7.2.5. Test Result .............................................................................................................. 16 7.3. Output Power Measurement ....................................................................................... 17 7.3.1. Test Limit ................................................................................................................ 17 7.3.2. Test Procedure Used .............................................................................................. 17 7.3.3. Test Setting ............................................................................................................. 17 7.3.4. Test Setup ............................................................................................................... 17 7.3.5. Test Result of Output Power ................................................................................... 18 7.4. Power Spectral Density Measurement ........................................................................ 19 7.4.1. Test Limit ................................................................................................................ 19 Report No.: 1508RSU00502 FCC ID: 2AEKR-TC80RA6 Page Number: 4 of 49 7.4.2. Test Procedure Used .............................................................................................. 19 7.4.3. Test Setting ........................................................................…

Text truncated - open the document above for the full version.

Test Report

MRT Technology (Suzhou) Co., Ltd Report No.: 1508RSU00501 Phone: +86-512-66308358 Report Version: V02 Fax: +86-512-66308368 Issue Date: 08-26-2015 Web: www.mrt-cert.com FCC ID: 2AEKR-TC80RA6 Page Number: 1 of 96 FCC ID: 2AEKR-TC80RA6 APPLICANT: ELITEGROUP COMPUTER SYSTEMS CO., LTD Application Type: Certification Product: Tablet PC Model No.: TC80RA6, TC80XXX(X=0~9, A~Z or blank) Brand Name: ECS ELITEGROUP FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15.247 Test Procedure(s): ANSI C63.10-2013, KDB 558074 D01v03r03 Test Date: August 06 ~ 17, 2015 MEASUREMENT REPORT FCC PART 15.247 WLAN 802.11b/g/n Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 558074 D01v03r03. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 2 of 96 Revision History Report No. Version Description Issue Date 1508RSU00501 Rev. 01 Initial report 08-22-2015 1508RSU00501 Rev. 02 Revise the test distance 08-26-2015 Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 3 of 96 CONTENTS Description Page 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .................................................................................................. 7 2.2. Device Capabilities ....................................................................................................... 8 2.3. Test Configuration ........................................................................................................ 8 2.4. EMI Suppression Device(s)/Modifications ..................................................................... 8 2.5. Labeling Requirements ................................................................................................. 8 2.6. Test Software ................................................................................. 错误!未定义书签。 3. DESCRIPTION OF TEST ........................................................................................................ 9 3.1. Evaluation Procedure ................................................................................................... 9 3.2. AC Line Conducted Emissions ..................................................................................... 9 3.3. Radiated Emissions .................................................................................................... 10 4. ANTENNA REQUIREMENTS ................................................................................................. 11 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 12 6. MEASUREMENT UNCERTAINTY ......................................................................................... 13 7. TEST RESULT ...................................................................................................................... 14 7.1. Summary .................................................................................................................... 14 7.2. 6dB Bandwidth Measurement ..................................................................................... 15 7.2.1. Test Limit ................................................................................................................ 15 7.2.2. Test Procedure used ............................................................................................... 15 7.2.3. Test Setting ............................................................................................................. 15 7.2.4. Test Setup ............................................................................................................... 15 7.2.5. Test Result .............................................................................................................. 16 7.3. Output Power Measurement ....................................................................................... 20 7.3.1. Test Limit ................................................................................................................ 20 7.3.2. Test Procedure Used .............................................................................................. 20 7.3.3. Test Setting ............................................................................................................. 20 7.3.4. Test Setup ............................................................................................................... 20 7.3.5. Test Result of Output Power ................................................................................... 21 7.4. Power Spectral Density Measurement ........................................................................ 23 7.4.1. Test Limit ................................................................................................................ 23 Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 4 of 96 7.4.2. Test Procedure Used .............................................................................................. 23 7.4.3. Test Setting ............................................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 41 of 96 7.6.4. Test Setup 9kHz ~ 30MHz Test Setup: 30MHz ~ 1GHz Test Setup: Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 42 of 96 1GHz ~ 18GHz Test Setup: 18GHz ~25GHz Test Setup: Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 43 of 96 7.6.5. Test Result Test Mode: 802.11b Test Site: AC1 Test Channel: 01 Test Engineer: Roy Cheng Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18GHz, there is not show in the report. Mark Frequency (MHz) Reading Level (dBμV) Factor (dB) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization 4825.0 40.1 2.7 42.8 74.0 -31.2 Peak Horizontal * 6482.5 38.1 5.9 44.0 90.4 -46.4 Peak Horizontal 8140.0 36.8 8.5 45.3 74.0 -28.7 Peak Horizontal * 9814.5 34.1 11.6 45.7 90.4 -44.7 Peak Horizontal 4825.0 42.9 2.7 45.6 74.0 -28.4 Peak Vertical * 6516.5 37.0 6.0 43.0 90.4 -47.4 Peak Vertical 8233.5 36.5 8.2 44.7 74.0 -29.3 Peak Vertical * 9789.0 34.9 11.4 46.3 90.4 -44.1 Peak Vertical Note 1: “*” is not in restricted band, its limit is 20dBc of the fundamental emission level (110.4dBμV/m). Note 2: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB) Factor (dB) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 44 of 96 Test Mode: 802.11b Test Site: AC1 Test Channel: 06 Test Engineer: Roy Cheng Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18GHz, there is not show in the report. Mark Frequency (MHz) Reading Level (dBμV) Factor (dB) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization 4791.0 36.3 2.7 39.0 74.0 -35.0 Peak Horizontal * 6601.5 36.4 6.0 42.4 93.8 -51.4 Peak Horizontal 8276.0 36.5 8.1 44.6 74.0 -29.4 Peak Horizontal * 9746.5 35.1 11.3 46.4 93.8 -47.4 Peak Horizontal 4799.5 39.4 2.7 42.1 74.0 -31.9 Peak Vertical * 6448.5 36.2 5.7 41.9 93.8 -51.9 Peak Vertical 8250.5 35.6 8.1 43.7 74.0 -30.3 Peak Vertical * 9695.5 34.9 10.9 45.8 93.8 -48.0 Peak Vertical Note 1: “*” is not in restricted band, its limit is 20dBc of the fundamental emission level (113.8dBμV/m). Note 2: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB) Factor (dB) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: 1508RSU00501 FCC ID: 2AEKR-TC80RA6 Page Number: 45 of 96 Test Mode: 802.11b Test Site: AC1 Test Channel: 11 Test Engineer: Roy Cheng Remark: 1. Average measurement w…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Patrick Yen(Senior Manager)
[email protected]886-2-2162-1177Fax: 886-2-2162-1177

Test Firm

MRT Technology (Suzhou) Co., LtdWu Jian
[email protected]86-512-66308358

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.40 GHz - 2.48 GHz2.90 mW
Confidentiality
Long Term
Grant Notes
Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures or as described in this filing. The highest reported SAR value is 1.34W/kg. This device has a 20 MHz and 40 MHz bandwidth mode.
