2AEN5AUSTINTWS Bluetooth Headset

MANUAL True Wireless in Color AUSTIN CONTROLS VIA THE LOGO BUTTON WHITE INDICATOR LIGHT ENGLISH (ENG) 04 ESPAÑOL (ESP) 14 DEUTSCH (DE) 23 FRANÇAIS (FRA) 33 ITALIANO (IT) 44 PORTUGUÊS (POR) 54 NEDERLANDS (NL) 63 POLSKU (PL) 72 SVENSKA (SWE) 82 SUOMI (FIN) 90 日本語 (JPN) 98 한국어 (KOR) 106 简体中文 (CHI) 113 URBANISTA AUSTIN 4 1. PAIRING MODE FIRST TIME PAIRING 1.1 – To connect the earphones to a Bluetooth device for the first time, open the charging case, remove the earphones from the case and the earphones will automatically enter into pairing mode (white indicator light flashes 3 times). 1.2 – Hold the earphones close to each other while pairing. 1.3 – Open Bluetooth settings on your device and search for “Urbanista Austin”. Once connected to your Bluetooth device you will hear “connected” and you can now start using Urbanista Austin for calls and music. AUSTIN MANUAL(ENG) URBANISTA HELP CENTER Thanks for choosing an Urbanista product! If you have any questions, which you can’t find the answer for in this manual, please check our online help center which not only have an online version of this manual but also FAQ’s of frequently asked questions. https://support.urbanista.com/ 5 2. RESET EARPHONES If the earphones are not working properly, you can reset them. 2.1 – Delete “Urbanista Austin” from the Bluetooth settings on your device. 2.2 – Make sure the earphones are turned off (press and hold the logo button for 5 seconds to switch them off). 2.3 – Press and hold the logo button for 8 seconds, you will hear a beeping sound and the white indicator light will flash once and then flash 3 times. 2.4 – Close the charging case - the reset has now been suc- cessfully completed and you can now follow the instructions in section 1, “First Time Pairing”, to reconnect the earphones to your device. Pairing procedure is just needed the first time you connect your Urbanista Austin with your device. Afterwards, the earphones will automatically reconnect to your Bluetooth device every time you turn them on. If you wish to use them with another device simply follow the steps again with the desired device. 6 POWER ON - Remove the earphones from the case and the indicator light flashes 3 times. Or press and hold the logo button for 2 seconds. POWER OFF- Place the earphones in the case and they will power off automatically. (If only one of the earphones are placed in the case, the other earphone is connected by itself and can be used separately). You may also press and hold the logo button for 5 seconds to turn them off. (If paired, both earphones will be turned off). VOICE ASSISTANT ON - Press twice on the logo button on the left (L) earphone. ANSWER A CALL - Press once on the logo button on the right (R) or left (L) earphone. END A CALL - Press and hold the logo button on the right (R) or left (L) earphone for 2 seconds AUSTIN MANUAL(ENG) 3. CONTROLS VIA THE LOGO BUTTON 7 REJECT A CALL - Press and hold the logo button on the right (R) or left (L) earphone for 2 seconds. PLAY MUSIC - Press the logo button once on the right (R) or left (L) e a rp h o n e . PAUSE MUSIC - Press twice on the logo button on the right (R) earphone. ADJUST THE VOLUME (+) - Press the logo button once on the right (R) earphone. ADJUST THE VOLUME (-) - Press the logo button once on the left (L) earphone. SKIP A TRACK FORWARD - Press and hold the logo button on the right (R) earphone for 2 seconds. SKIP A TRACK BACKWARD- Press and hold the logo button on the left (L) earphone for 2 seconds. 4. CHARGING LOW BATTERY WARNING: If earphone battery level is low you will hear a voice saying “Battery please charge” once every minute. 8 The earphones will charge automatically when placed in the case. The indicator flashes white while charging. When the white flash is off, the earphones are fully charged. 1-25% Light flashes 1 time 26-50% Light flashes 2 times 51-75% Light flashes 3 times 76-100% Light flashes 4 times CHARGE BAT T E RY CAS E: To charge the case - Plug the type-C cable into an energy source, the battery indicator light will con- tinue flashing until the case is fully charged – then the light will be constantly lit. 5. SILICONE EARBUDS The complimentary silicone earbuds come in different sizes. Choose the size that best suits your ears so that they fit com- fortably in your ears. The silicone tips easily pop off/on. CLEANING YOUR EARBUDS: For cleaning, pop the silicone tip off and soak them in lukewarm water with soap. After soaking, use a cotton swab to give them a better cleaning. Rinse the tips well under water and dry with a cloth. Do not put them back on the earbuds until they are completely dry. AUSTIN MANUAL(ENG) 9 ONE YEAR LIMITED WARRANTY All Urbanista earphones are designed and manufactured to meet high ex- pectations and to provide the best customer experience. We are devoted to producing high-quality items featuring the latest technology. However, in exceptional cases, electronic products may have malfunctions due to manufacturing defects. That is why we offer a full one year warranty from the date of original purchase, which covers de - fects in materials and workmanship. Urbanista AB hereby warrants that, under normal use, this product will be free from defects in materials and workmanship for a period of one year starting with the original purchase date. The replacement warranty is valid only if the original proof of purchase issued to the customer, spec - ifying the date of purchase, is presented with the product to be replaced. How does it work? If you believe this product is defective, carefully re - pack the unit and return the product to your authorized dealer within the warranty period, with the original proof of purchase. Your authorized dealer will replace the product, provided a defect in materials or work - manship is identified. This limited replacement warranty does not apply in cases of abuse or misuse of the product, use contrary to the Urbanista instructions, ordi - nary wear and tear, incorrect connection…

Text truncated - open the document above for the full version.

Agent Authorization Company: URBANISTA AB Address: Master Samuelsgatan 10 SE-111 44 Stockholm, Sweden Product Name: TWS Bluetooth Headset Model Number(s): Urbanista Austin Product Description: TWS Bluetooth Headset We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-06-18 Name: Robin Luo Company: Urbanista AB

Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-06-18 Subject; Request for Confidentiality FCC ID: 2AEN5AUSTIN To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Urbanista AB Contact person: Robin Luo

External Photos ALL VIEW OF EUT TOP VIEW OF EUT(Headset) BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT TOP VIEW OF EUT(Charging Dock) BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location Size: 10mm*5mm FCC ID: 2AEN5AUSTIN

Internal Photos VIEW OF EUT(PORT)-right OPEN VIEW OF EUT INTERNAL VIEW-1 OF EUT Antenna INTERNAL VIEW-2 OF EUT VIEW OF BATTERY VIEW OF EUT(PORT) OPEN VIEW OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT VIEW OF BATTERY

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description TWS Bluetooth Headset Model Name Urbanista Austin FCC ID 2AEN5AUSTIN 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION P t =0.417dBm=1.10mW The value of the Maximum output power P t is referred to the test report of the CFR47 §15.247. The result for RF exposure evaluation SAR=(1.10mW /5mm) .[√2.402(GHz)]=0.34<3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. 4. CONCLUSION The SAR evaluation is not required.

Page 1 of 68 FCC Test Report Report No.: AGC01082200503FE03 FCC ID : 2AEN5AUSTIN APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : TWS Bluetooth Headset BRAND NAME : Urbanista MODEL NAME : Urbanista Austin APPLICANT : URBANISTA AB DATE OF ISSUE : May 28, 2020 STANDARD(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC01082200503FE03 Page 2 of 68 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / May 28, 2020 Valid Initial Release Report No.: AGC01082200503FE03 Page 3 of 68 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ............................................................................................................... 5 2. GENERAL INFORMATION ............................................................................................................................ 6 2.1. PRODUCT DESCRIPTION ..................................................................................................................... 6 2.2. TABLE OF CARRIER FREQUENCYS ..................................................................................................... 6 2.3. RECEIVER INPUT BANDWIDTH ............................................................................................................ 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ....................................................................... 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ........................................................ 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................. 8 2.7. TEST METHODOLOGY .......................................................................................................................... 8 2.8. SPECIAL ACCESSORIES ....................................................................................................................... 8 2.9. EQUIPMENT MODIFICATIONS .............................................................................................................. 8 3. MEASUREMENT UNCERTAINTY ................................................................................................................. 9 4. DESCRIPTION OF TEST MODES ............................................................................................................... 10 5. SYSTEM TEST CONFIGURATION ............................................................................................................. 11 5.1. CONFIGURATION OF EUT SYSTEM .................................................................................................... 11 5.2 EQUIPMENT USED IN TESTED SYSTEM .............................................................................................. 11 5.3. SUMMARY OF TEST RESULTS ............................................................................................................. 11 6. TEST FACILITY ........................................................................................................................................... 12 7. PEAK OUTPUT POWER ............................................................................................................................. 13 7.1. MEASUREMENT PROCEDURE ........................................................................................................... 13 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 13 7.3. LIMITS AND MEASUREMENT RESULT ............................................................................................... 14 8. 20DB BANDWIDTH ..................................................................................................................................... 20 8.1. MEASUREMENT PROCEDURE ........................................................................................................... 20 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 20 8.3. LIMITS AND MEASUREMENT RESULTS ............................................................................................. 20 9. CONDUCTED SPURIOUS EMISSION ........................................................................................................ 27 9.1. MEASUREMENT PROCEDURE ........................................................................................................... 27 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 27 9.3. MEASUREMENT EQUIPMENT USED .................................................................................................. 27 Report No.: AGC01082200503FE03 Page 4 of 68 9.4. LIMITS AND MEASUREMENT RESULT ............................................................................................... 27 10. RADIATED EMISSION ............................................................................................................................... 37 10.1. MEASUREMENT PROCEDURE ......................................................................................................... 37 10.2. TEST SETUP ....................................................................................................................................... 39 10.3. LIMITS AND MEASUREMENT RESULT ............................................................................................. 40 10.4. TEST RESULT ..................................................................................................................................... 40 11. NUMBER OF HOPPING FREQUENCY ..................................................................................................... 50 11.1. MEASUREMENT PROCEDURE ............…

Text truncated - open the document above for the full version.

Report No.: AGC01082200503FE03 Page 45 of 68 EUT TWS Bluetooth Headset Model Name Urbanista Austin Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 9 Antenna Horizontal FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4960.02250.790.2251.0174-22.99 peak 4960.02244.170.2244.3954-9.61 AVG 7440.03346.72.6449.3474-24.66 peak 7440.03338.692.6441.3354-12.67 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type EUT TWS Bluetooth Headset Model Name Urbanista Austin Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 9 Antenna Vertical FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4960.02251.470.2251.6974-22.31 peak 4960.02244.990.2245.2154-8.79 AVG 7440.03346.732.6449.3774-24.63 peak 7440.03338.452.6441.0954-12.91 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type RESULT: PASS Note: Other emissions from 1G to 25 GHz are considered as ambient noise. No recording in the test report. Factor = Antenna Factor + Cable loss - Amplifier gain, Over=Measure-Limit. The “Factor” value can be calculated automatically by software of measurement system. All test modes had been tested. The 8DPSK modulation is the worst case and recorded in the report. Report No.: AGC01082200503FE03 Page 46 of 68 TEST RESULT FOR RESTRICTED BANDS REQUIREMENTS EUT TWS Bluetooth Headset Model Name Urbanista Austin Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 7 Antenna Horizontal PK AV RESULT: PASS Report No.: AGC01082200503FE03 Page 47 of 68 EUT TWS Bluetooth Headset Model Name Urbanista Austin Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 7 Antenna Vertical PK AV RESULT: PASS Report No.: AGC01082200503FE03 Page 48 of 68 EUT TWS Bluetooth Headset Model Name Urbanista Austin Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 9 Antenna Horizontal PK AV RESULT: PASS Report No.: AGC01082200503FE03 Page 49 of 68 EUT TWS Bluetooth Headset Model Name Urbanista Austin Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 9 Antenna Vertical PK AV RESULT: PASS Note: The factor had been edited in the “Input Correction” of the Spectrum Analyzer. So the Amplitude of test plots is equal to Reading level plus the Factor in dB. Use the A dB(μV) to represent the Amplitude. Use the F dB(μV/m) to represent the Field Strength. So A=F. All test modes had been pre-tested. The 8DPSK modulation is the worst case and recorded in the report. Report No.: AGC01082200503FE03 Page 50 of 68 11. NUMBER OF HOPPING FREQUENCY 11.1. MEASUREMENT PROCEDURE The EUT shall have its hopping function enabled. Use the following spectrum analyzer settings: 1. Span: The frequency band of operation. Depending on the number of channels the device supports, it may be necessary to divide the frequency range of operation across multiple spans, to allow the individual channels to be clearly seen. 2. RBW: To identify clearly the individual channels, set the RBW to less than 30% of the channel spacing or the 20 dB bandwidth, whichever is smaller. 3. VBW ≥ RBW. Sweep: Auto. Detector function: Peak. Trace: Max hold. 4. Allow the trace to stabilize. 11.2. TEST SETUP (BLOCK DIAGRAM OF CONFIGURATION) Same as described in section 8.2 11.3. MEASUREMENT EQUIPMENT USED The same as described in section 6 11.4. LIMITS AND MEASUREMENT RESULT TOTAL NO. OF HOPPING CHANNEL LIMIT (NO. OF CH) MEASUREMENT (NO. OF CH) RESULT >=15 79 PASS TEST PLOT FOR NO. OF TOTAL CHANNELS Note: The GFSK modulation is the worst case and recorded in the report. Report No.: AGC01082200503FE03 Page 51 of 68 12. TIME OF OCCUPANCY (DWELL TIME) 12.1. MEASUREMENT PROCEDURE The EUT shall have its hopping function enabled. Use the following spectrum analyzer settings: 1. Span: Zero span, centered on a hopping channel. 2. RBW shall be≤channel spacing and where possible RBW should be set >> 1 / T, where T is the expected dwell time per channel. 3. Sweep: As necessary to capture the entire dwell time per hopping channel; where possible use a video trigger and trigger delay so that the transmitted signal starts a little to the right of the start of the plot. The trigger level might need slight adjustment to prevent triggering when the system hops on an adjacent channel; a second plot might be needed with a longer sweep time to show two successive hops on a channel. 4. Detector function: Peak. Trace: Max hold. 5. Use the marker-delta function to determine the transmit time per hop. 6. Repeat the measurement using a longer sweep time to determine the number of hops over the period specified in the requirements. The sweep time shall be equal to, or less than, the period specified in the requirements. Determine the number of hops over the sweep time and calculate the total number of hops in the period specified in the requirements, using the following equation: (Number of hops in the period specified in the requirements) = (number of hops on spectrum analyzer) × (period specified in the requirements / analyzer sweep time) 7. The average time of occupancy is calculated from the transmit time per hop multiplied by the number of hops in the period specified in the requirements. 12.2. TEST SETUP (BLOCK DIAGRAM OF CONFIGURATION) Same as described in section 8.2 12.3. MEASUREMENT EQUIPMENT USED The same as described in section 6 12.4. LIMITS AND MEASUREMENT RESULT Channel Time of Pulse for DH5 (ms) Number of hops in the period specified in the requirements Sweep Time (ms) Limit (ms) Low 2.903 26*4 301.912 400 Middle 2.896 26*4 301.184 400 High 2.908 26*4 302.432 400 Note: The 8DPSK modulation is the worst case and recorded in the report. Report No.: AGC01082200503FE03 Page 52 of 68 TEST PLOT OF LOW CHANNEL Repor…

Text truncated - open the document above for the full version.

Test Setup Photos RADIATED EMISSION TEST SETUP BELOW 1GHZ RADIATED EMISSION TEST SETUP ABOVE 1GHZ
