2AEOF-WLDB2324TXWIRELESS DOOR CHIME PUSH BUTTON

HOMEDEPOT.COM Please contact 1-855-556-1852 for further assistance. Use and Care Guide Installation 1 ACTIVATING THE PUSH BUTTON BATTERY □Remove the front cover of the push button by inserting a flat head screwdriver in the slot on the bottom of the button and pulling up slightly. □Remo ve the plastic tab from the battery compartment to allow connection to the terminal. □Snap the front co ver onto the base by first hooking the tops together, then snapping the base on. □Repeat for second button if applicable . 2 POWERING THE CHIME □Install the chime batteries or plug in the chime, following the instructions included in the chime. 3 SYNCING THE CHIME AND PUSH BUTTON □Follow the instructions included in the chime. 4 MOUNTING THE PUSH BUTTON □Remove the front cover from the base by following step 1. □Mount the push button base to a clean wall or door jamb with included screws or mounting tape. If mounting with screws, predrill a pilot hole through the push button base in the desired location using a 5/64 in. drill bit. □Snap the push button cover onto the base by first hooking the tops together, then snapping the base on. 216595Inst.ai TOOLS REQUIRED Phillips screwdriverFlat Head ScrewdriverDrill HARDWARE INCLUDED #4x3/4 #6x3/4 #4x1 White Zinc #6x1 Self Tapping ScrewHardware.ai (2) #4 x 3/4 in. Screws(1) Adhesive Sticker 216595Inst.ai 5/64 in. Drill Bit 216595Inst.ai #4x3/4 #6x3/4 #4x1 White Zinc #6x1 Self Tapping ScrewHardware.ai HOMEDEPOT.COM Please contact 1-855-556-1852 for further assistance. Safety Information WARNING: Keep batteries out of reach of children. Specifications 216593 Doorbell TypeWireless Number of Push Buttons1 Included Hardware(2) #4 x ¾ in. Screws and (1) 18x31mm Adhesive Sticker Finished Product Dimensions2.518 in. Height x 1.268 in. Width x .79 in. Depth Power SourceCR2032 Battery (included) Finish ColorBlack Lighted ButtonYes 216594 Doorbell TypeWireless Number of Push Buttons1 Included Hardware(2) #4 x ¾ in. Screws and (1) 18x31mm Adhesive Sticker Finished Product Dimensions2.518 in. Height x 1.268 in. Width x .79 in. Depth Power SourceCR2032 Battery (included) Finish ColorBrass Lighted ButtonYes 216595 Doorbell TypeWireless Number of Push Buttons1 Included Hardware(2) #4 x ¾ in. Screws and (1) 18x31mm Adhesive Sticker Finished Product Dimensions2.518 in. Height x 1.268 in. Width x .79 in. Depth Power SourceCR2032 Battery (included) Finish ColorWhite Lighted ButtonYes Troubleshooting Problem Possible CauseSolution Chime does not sound when push button is pressed. Push button battery has not been activated. Confirm the activation tab has been removed and the battery is seated properly in the button. The chime and push button are out of transmission range. Move the chime closer to the push button location. Ensure there are no metallic objects or concrete walls hindering the signal. Push button battery needs to be replaced. Replace the push button battery with a CR2032 Lithium Coin battery. Chime is sounding without the push button being pushed. An outside signal is interfering with the signal between the chime and push button. Resync the chime and push button following the steps in the instructions. Warranty WHAT IS COVERED The Warrantor is pleased to extend this Warranty to you, the original consumer/end user (“Consumer”) of the doorbell products and listed by model number below (“Doorbell Product”). This Warranty is valid for any Doorbell Product used in standard residential applications, and may not be assigned or transferred by you. For a period of one (1) year from the date of purchase, Warrantor, at its sole option, will repair, replace or refund the purchase price for any Doorbell Product used in a standard residential application that malfunctions due to factory defective parts or defective workmanship in the manufacture or assembly of the Doorbell Product. WHAT IS NOT COVERED Warrantor shall have no further liability or obligation except as expressly stated herein. This Warranty does not apply to any Doorbell Product that has been abused, misused, modified, subjected to abnormal use conditions, stored improperly prior to installation, or otherwise used in any way not intended by Warrantor. HOMEDEPOT.COM Please contact 1-855-556-1852 for further assistance. This Warranty is limited to repair, replacement or refund as set forth above and any additional reimbursement is expressly excluded from this Warranty, including but not limited to reimbursement for inconvenience, installation costs, loss of use, return shipping charges, and batteries or other expendable items. If a claim is made under this Warranty on a product that is no longer available, Warrantor reserves the right to provide a similar product of comparable quality and value. To make a claim under this Warranty, the Consumer must, within ninety (90) days of actual or constructive knowledge of damage covered by this Warranty, return the product to your local The Home Depot store, or call Customer Service at 1-855-556-1852. Warrantor does not make any implied warranty of merchantability or fitness of the product for a particular purpose. There are no other warranties that extend beyond the description on the face hereof. This Warranty gives you specific legal rights and you may have additional rights under applicable law. Contact the Customer Service Team at 1-855-556-1852 or visit www.HomeDepot.com. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This …

Text truncated - open the document above for the full version.

DATE : Apr. 28, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEOF-WLDB2324TX Product Name: WIRELESS DOOR CHIME PUSH BUTTON Request for Confidentiality Pursu ant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Agency agreement expiration date: Apr. 28, 2015 to Apr. 27, 2016 By: He Jun SignaturePrinted T i tle: Manager On behalf of : DONGGUAN SMART HERO ELECTRONIC PRODUCTS CO LTD Telephone :0769-81119390

Model difference letter Hereby we: DONGGUAN SMART HERO ELECTRONIC PRODUCTS CO LTD All models are same except model name and brand name. Models: 2324-TX, 2325-TX, 2326-TX, 2327-TX Sincerely, Client’s signature Client’s name / title: He Jun / Manager  Contact information / address: 118 LI XIANG ROAD WEST, SHUI PING VILLAGE, DALANG, DONGGUAN, GUANGDONG, CHINA All models are electrically identical except model name and brand name.

Label information:

Report No. : EED32H000300-1 Page 1 of 18 TEST REPORT Product : WIRELESS DOOR CHIME PUSH BUTTON Trade mark : N/A Model/Type reference : 2324-TX, 2325-TX, 2326-TX, 2327-TX Serial number : N/A Ratings : DC 3V FCC ID : 2AEHS-WLDB2324TX Report number : EED32H000300-1 Date : Apr. 28, 2015 Regulations : See below Test Standards Results 47 CFR FCC Part 15 Subpart C 15.231: 2014 PASS Prepared for: DONGGUAN SMART HERO ELECTRONIC PRODUCTS CO LTD 118 LI XIANG ROAD WEST, SHUI PING VILLAGE, DALANG, DONGGUAN, GUANGDONG, CHINA Prepared by: Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date: Apr. 28, 2015 Jimmy Li Lab manager Check No.: 1996277469 2AEOF Report No. : EED32H000300-1 Page 2 of 18 TABLE OF CONTENTS 1.CERTIFICATION INFORMATION ............................................................................................................... 3 2.TEST SUMMARY ........................................................................................................................................ 3 3.MEASUREMENT UNCERTAINTY .............................................................................................................. 4 4.PRODUCT INFORMATION ......................................................................................................................... 4 5.TEST EQUIPMENT LIST ............................................................................................................................. 4 6.SUPPORT EQUIPMENT LIST .................................................................................................................... 4 7.OPERATION CHARACTERISTICS ............................................................................................................ 5 7.1.LIMITS ................................................................................................................................................. 5 7.2.BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 5 7.3.TEST PROCEDURE ........................................................................................................................... 5 7.4.TEST RESULT .................................................................................................................................... 5 8.20DB/ 99% BANDWIDTH MEASUREMENT .............................................................................................. 6 8.1.LIMITS ................................................................................................................................................. 6 8.2.BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 6 8.3.TEST PROCEDURE ........................................................................................................................... 6 8.4.TEST RESULT .................................................................................................................................... 6 9.RADIATED EMISSION MEASUREMENT ................................................................................................... 8 9.1.LIMITS ................................................................................................................................................. 8 9.2.BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 8 9.3.TEST PROCEDURE ........................................................................................................................... 9 9.4.TEST RESULT .................................................................................................................................. 10 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ............................................................................................ 15 APPENDIX 2 EXTERNAL PHOTOGRAPHS OF PRODUCT ............................................................................ 16 APPENDIX 3 INTERNAL PHOTOGRAPHS OF PRODUCT ............................................................................. 17 N/A means not applicable. Report No. : EED32H000300-1 Page 3 of 18 1. CERTIFICATION INFORMATION The above equipment was tested by Centre Testing International (Shenzhen) Corporation for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart C and the measurement procedure according to ANSI C63.4:2014 and ANSI C63.10:2013. 2. TEST SUMMARY No. Test Item Rule Result 1 Operation characteristics FCC Part15.231(a) & A1.1.1 PASS 2 Radiated Emission FCC Part15.231(b) & A1.1 PASS 3 20dB bandwidth & 99% bandwidth FCC Part15.231 & A1.1.3 PASS 4 AC Conducted Emission FCC PART15.207 & RSS-Gen 7.2.4 N/A 5 Antenna requirements FCC PART15.203 & RSS-Gen 7.1.2 PASS (See Note 1) Note: 1. According to Section 15.203 and RSS-Gen 7.1.2, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The EUT has a built in antenna which is a short wire solder on the PCB, this is permanently attached antenna and meets the requirements of this section. 2. New battery is used during all the test. Applicant: DONGGUAN SMART HERO ELECTRONIC PRODUCTS CO LTD 118 LI XIANG ROAD WEST, SHUI PING VILLAGE, DALANG, DONGGUAN, GUANGDONG, CHINA Manufacturer: UNIVERSAL CONSUMER PRODUCTS 2801 EAST BELTLINE NE, GRAND RAPIDS, MI 49525, USA FCC ID: 2AEHS-WLDB2324TX Product: WIRELESS DOOR CHIME PUSH BUTTON Model/Type reference: 2324-TX, 2325-TX, 2326-TX, 2327-TX Trade Name: N/A Serial Number: N/A Report Number: EED32H000300-1 Sample Received Date: Mar. 20, 2015 Sample tested Date: Mar. 20, 2015 to Apr. 28, 2015 2AEOF Report No. : EED32H000300-1 Page 4 of 18 3…
