2AES41001Steam Controller

GET STEAM! www.steampowered.com © 2015 Valve Corporation. All rights reserved. Steam and the Steam logo are trademarks and/or registered trademarks of Valve Corporation in the US and other countries. Use of Steam is subject to the Steam Subscriber Agreement: http://store.steampowered.com/subscriber_agreement/ 1. Please visit: http://www.steampowered.com to download and install Steam on your computer. 2. Launch Steam and create a Steam account if you don't already have one. 3. For additional support, please visit: https://support.steampowered.com STEAM HERUNTERLADEN! 1. Besuchen Sie bitte: http://www.steampowered.com, um mit dem Download und der Installation von Steam auf Ihrem Computer zu beginnen. 2. Starten Sie Steam und erstellen Sie bitte einen Steam-Account, sofern Sie nicht schon einen haben. 3. Für weitere Hilfestellungen besuchen Sie uns bitte auf https://support.steampowered.com INSTALLEZ STEAM ! 1. Visitez : http://www.steampowered.com pour télécharger et installer Steam sur votre ordinateur. 2. Lancez Steam et créez un compte Steam si vous n’en avez pas déjà un. 3. Pour obtenir de l’aide, veuillez visiter : https://support.steampowered.com ¡ BÁJATE STEAM! 1. Visita la página: http://www.steampowered.com para bajarte Steam e instalarlo en tu ordenador. 2. Lanza Steam y hazte una cuenta de Steam si aún no tienes una. 3. Si necesitas asistencia, dirígete a la página https://support.steampowered.com STEAM 1. http://www.steampowered.com Steam 2. SteamSteam 3. https://support.steampowered.com STEAM CONTROLLER QUICK-START GUIDE ® *** WORK IN PROGRESS *** 321 x2AA + - + - + - + - + - + - + - + - + - + - USB 2.0/3.0

Important Safety Information Batteries The Steam Controller can be used with disposable AA batteries (included) or rechargeable AA batteries (not included). Improper use of batteries may result in leakage of corrosive and toxic battery fluid as well as overheating, including risk of fire and explosion. • Keep batteries out of reach of children. • Do not expose batteries to heat or fire or damage the battery enclosure. • Only use alkaline type AA (LR6) batteries. • Do not mix batteries with uneven remaining charge. • Remove batteries if depleted and when storing the device for an extended period of time. • In case of battery leakage, remove all batteries and avoid contact with skin or clothes. Flush any exposed skin immediately under running water. Radio Frequency Emissions This device emits radio frequency (RF) signals. While it has been thoroughly tested for non-interference with other devices, do not operate around critical electronic equipment (e.g. in hospitals) and remove batteries completely before transport by airplane. Exposure to Heat and Humidity You should keep your Steam Controller dry and not use it where it could get wet. You should not expose your Steam Controller to extreme temperatures (operating temperature range should remain between 10 °C and 35 °C (50 °F and 95 °F). If you move your Steam Controller from a cold location to a warm one, moisture may condense and cause the Steam Controller to cease operating properly— in that case, you may need to wait several hours before it can operate properly. Choking hazard This device contains small parts which may be a choking hazard to children under 3. Keep out of reach of children. Musculoskeletal disorder As with many repetitive physical activities, extended use of the Steam Controller may cause occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. However, if you experience persistent or recurring discomfort, pain, throbbing, tingling, numbness, or stiffness, DO NOT IGNORE THESE WARNING SIGNS. PROMPTLY SEE A QUALIFIED HEALTH PROFESSIONAL. Symptoms such as these can be associated with permanent and serious musculoskeletal disorders (MSDs) such as carpal tunnel syndrome, tendonitis, tenosynovitis, vibration syndromes, and other conditions. To reduce the risk of MSD, operate the Steam Controller in a comfortable posture, keep your hands and other body parts relaxed, and take breaks. Photosensitive seizures A very small percentage of individuals may experience epileptic seizures when exposed to certain light patterns or flashing lights. Exposure to certain patterns or backgrounds on a computer screen, or certain types of computer gameplay, may induce an epileptic seizure in these individuals. Certain conditions may induce previously undetected epileptic symptoms even in persons who have no history of prior seizures or epilepsy. If you, or anyone in your family, have an epileptic condition, consult your physician prior to playing. If you experience any of the following symptoms while playing a video or computer game—dizziness, altered vision, eye or muscle twitches, loss of awareness, disorientation, any involuntary movement, or convulsions— IMMEDIATELY discontinue use and consult your physician before resuming play. Regulatory Information UNITED STATES Federal Communications Commission (FCC) Steam Controller FCC ID: 2AES41001 Wireless Dongle FCC ID: 2AES41002 Tested to comply with FCC (Federal Communication Commission) Standards. For home and office use. Not intended for use in machinery, medical, or industrial applications. This device is for use with NRTL- listed (UL, CSA, ETL etc.) and/or IEC/EN 60950 compliant (CE marked) IT equipment. No serviceable parts included. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna -Increase the distance between the equipment and the receiver. -Connect the equipment to outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Warning: The FCC requires that you be notified that any changes or modifications to this device not expressly approved by the manufacturer could void the user’s authority to operate the equipment. CANADA Industry Canada (IC) Steam Controller IC: 20207-1001 Wireless Dongle IC: 20207-1002 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interferences, and (2) this device must accept any interferences, including interferences that may cause undesired operation of the device. Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). L‘utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est suscep…

Text truncated - open the document above for the full version.

SCALE 1:1 NOTES LABEL CUT LINES BACKGROUND COLOR: PANTONE BLACK C TEXT AND GRAPHICS COLOR: PANTONE 422C (GREY) CONFIDENTIAL PROPERTY OF VALVE CORP CONTROLLER PHASE 1 LABEL FONT TEXT REV07 SCALE: 1:1 06/01/15 SELECTIVE ADHESIVE AREA Black Substrate Grey Printed Icon (solid ll) Area without selective adhesive 2D barcode area (on demand) 6mm x 6mm HEIGHT: 56.5mm WIDTH: 86.8mm 4mm marks FONT: DIN-BOLD (PROPRIETARY VALVE FONT) FCYWWHHHHH MODEL 1001 FCC ID: 2AES41001 IC: 20207-1001 5V 500mA 007-XXXXXX FCYWWHHHHH MODEL 1001 FCC ID: 2AES41001 IC: 20207-1001 5V 500mA 007-XXXXXX Label Location (under battery door)

NVLAP Lab code: 100414-0 FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT FOR Steam Controller MODEL NUMBER: 1001 FCC ID: 2AES41001 REPORT NUMBER: 10723151A ISSUE DATE: July 8, 2015 Prepared for Valve Corporation 10900 NE 4 th St. Suite 500 Bellevue, WA 98004 Prepared by UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 TEL: (847) 272-8800 REPORT NO: 10723151 DATE: July 8, 2015 FCC ID: 2AES41001 Page 2 of 32 UL LLC FORM NO: CCSUP4701i 333 Pfingsten Rd., Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC Revision History Rev. Issue Date Revisions Revised By -- 07/08/15 Initial Issue M.Ferrer REPORT NO: 10723151 DATE: July 8, 2015 FCC ID: 2AES41001 Page 3 of 32 UL LLC FORM NO: CCSUP4701i 333 Pfingsten Rd., Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. SAMPLE CALCULATION ............................................................................................................ 5 4.3. MEASUREMENT UNCERTAINTY ............................................................................................... 6 5.5. DESCRIPTION OF TEST SETUP ................................................................................................ 8 6. TEST AND MEASUREMENT EQUIPMENT .............................................................................. 10 7. TEST RESULTS ............................................................................................................................... 11 7.1.1. OCCUPIED BANDWIDTH ............................................................................................... 11 7.2. RADIATED EMISSIONS............................................................................................................. 15 7.2.1. FUNDAMENTAL FREQUENCY RADIATED EMISSION ............................................ 16 7.2.2. TRANSMITTER RESTRICTED BAND EDGES ............................................................. 17 7.2.3. HARMONICS AND SPURIOUS EMISSIONS ABOVE 1GHz ....................................... 21 7.2.4. WORST-CASE BELOW 1 GHz ........................................................................................ 27 8. SETUP PHOTOS .............................................................................................................................. 29 REPORT NO: 10723151 DATE: July 8, 2015 FCC ID: 2AES41001 Page 4 of 32 UL LLC FORM NO: CCSUP4701i 333 Pfingsten Rd., Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Valve Corporation 10900 NE 4 th St. Suite 500 Bellevue, WA 98004 EUT DESCRIPTION: Steam Controller MODEL: 1001 SERIAL NUMBER: Prototype DATE TESTED: March 24, 2015 – July 8, 2015 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass UL LLC tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL LLC based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL LLC and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL LLC will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. Approved & Released For UL LLC By: Tested By: Bart Mucha MICHAEL FERRER Staff Engineer Program Manager UL LLC UL LLC REPORT NO: 10723151 DATE: July 8, 2015 FCC ID: 2AES41001 Page 5 of 32 UL LLC FORM NO: CCSUP4701i 333 Pfingsten Rd., Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4-2009, FCC CFR 47 Part 2, FCC CFR 47 Part 15. Testing Deviation - EUT was tested 1.5m height for above 1GHz Radiated Emissions in accordance TCB Conference call Dec 2014. 3. FACILITIES AND ACCREDITATION The test sites and measurement facilities used to collect data are located at 333 Pfingsten Road, Northbrook, IL 60062 USA. UL NBK is accredited by NVLAP, Laboratory Code 100414-0. The full scope of accreditation can be viewed at http://ts.nist.gov/Standards/scopes/1004140.htm 4. CALIBRATION AND UNCERTAINTY 4.1. MEASURING INSTRUMENT CALIBRATION The measuring equipment utilized to perform the tests documented in this report has been calibrated in accordance with the manufacturer's recommendations, and is traceable to recognized national standards. 4.2. SAMPLE CALCULATION Sample Calculations Radiated Field Strength and Conducted Emission…
