2AET4RUT240GLTE Router

Quick Start Guide v2.1 FRONT VIEW BACK VIEW Mobile AUX antenna connector Mobile MAIN antenna connector 1. Push the SIM holder button with the SIM needle. 2. Pull out the SIM holder. 3. Insert your SIM card into the SIM holder. 4. Slide the SIM holder back into the router. 5. Attach all antennas. 6. Connect the power adapter to the socket on the front of the device. Then plug the other end of the power adapter into a power outlet. 7. Connect to the device wirelessly using SSID and password provided on the device information label or use an Ethernet cable connected to LAN port. HARDWARE INSTALLATION POWER SOCKET PINOUT 1. To enter the router's Web interface (WebUI), type http://192.168.1.1 into the URL field of your Internet browser. 2. Use login information shown in image A when prompted for authentication. 3.After you login, you will be prompted to change your password for security reasons. The new password must contain at least 8 characters, including at least one uppercase letter, one lowercase letter and one digit. This step is mandatory and you will not be able to interact with the router's WebUI before you change the password. 4. When you change the router's password, the Configuration Wizard will start. The Configuration Wizard is a tool used to setup some of the router's main operating parameters. 5. Go to the Overview page and pay attention to the Signal Strength indication (image B). To maximize the cellular performance try adjusting the antennas or changing the location of your device to achieve the best signal conditions. LOGIN TO DEVICE A.B. http://192.168.1.1 Please enter username and password Username Password admin admin01 Login -65 dBm Data connection state SIM card slot in use Bytes received/sent * State Registered (home); OPERATOR; 4G (LTE) Connected 348.7 KB / 223.5 KB Ready TECHNICAL INFORMATION *Order code dependent. **Higher gain antenna can be connected to compensate for cable attenuation when a cable is used. The user is responsible for the compliance with the legal regulations. Radio specifications Bundled accessories specifications* RF technologies Max RF power 2G, 3G, 4G, WiFi 33 dBm@GSM, 24 dBm@WCDMA, 23 dBm@LTE, 20 dBm@ WiFi Mobile antenna698~960/1710~2690 MHz, 50 Ω, VSWR<3, gain** 3 dBi, omnidirectional, SMA male connector Power adapterInput: 0.4A@100-240VAC, Output: 9VDC, 1A, 4-pin plug WiFi antenna2400~2483.5 MHz, 50 Ω, VSWR<2, gain** 5 dBi, omnidirectional, RP-SMA male connector RUT240 router must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the communication module in prescribed applications and environments. [EN] English Hereby, TELTONIKA declares that this RUT240 is in compliance with the essential requirements and other relevant provisions of Directive CE/RED. [BG] Bulgarian С настоящето, TELTONIKA декларира, че RUT240 е в съответствие със съществените изисквания и другитеприложими разпоредби на Директива CE/RED. [CZ] Czech TELTONIKA tímto prohlašuje, že RUT240 splňuje základní požadavky a všechna příslušná ustanoveni Směrnice CE/RED. [DE] German Hiermit erklärt TELTONIKA dass sich das Gerät RUT240 in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie CE/RED befindet. [DK] Danish Undertegnede TELTONIKA erklærer herved, at følgende udstyr RUT240 overholder de væsentlige krav og øvrige relevante krav i direktiv CE/RED. [EE] Estonian Käesolevaga kinnitab TELTONIKA seadme RUT240 vastavust direktiivi CE/RED põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. [ES] Spanish Por la presente, TELTONIKA declara que este RUT240 cumple con los requisitos esenciales y otras exigencias relevantes de la Directiva CE/RED. [FI] Finish TELTONIKA vakuuttaa täten että RUT240 tyyppinen laite on direktiivin CE/RED oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. [FR] French TELTONIKA déclare que cette RUT240 est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive CE /RED. [GR] Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Ο ΚΑΤΑΣΚΕΥΑΣΤΗΣ TELTONIKA ΔΗΛΩΝΕΙ ΟΤΙ RUT240 ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ CE/RED. [HU] Hungarian A TELTONIKA ezzennel kijelenti, hogy a RUT240 típusú berendezés teljesíti az alapvető követelményeket és más CE/RED irányelvben meghatározott vonatkozó rendelkezéseket. [IT] Italian Con la presente TELTONIKA dichiara che questo RUT240 è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva CE/RED. [LT] Lithuanian Šiuo dokumentu UAB TELTONIKA deklaruoja, kad šis RUT240 atitinka esminius reikalavimus ir kitas CE/RED Direktyvos nuostatas. [LV] Latvian Ar šo TELTONIKA deklarē, ka RUT240 atbilst Direktīvas CE/RED būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. [NL] Dutch Hierbij verklaart TELTONIKA dat het toestel l RUT240 in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn CE/RED. [NO] Norwegian TELTONIKA Erklærer herved at RUT240 er i samsvar med de grunnleggende krav og øvrige relevante krav i direktiv CE/RED. [PL] Polish Niniejszym TELTONIKA deklaruje że RUT240 jest zgodny z zasadniczymi wymaganiami i innymi właściwymi postanowieniami Dyrektywy CE/RED. [PT] Portuguese Eu, TELTONIKA declaro que o RUT240 cumpre os requisitos essenciais e outras provisões relevantes da Directiva CE/RED. [RO] Romanian Prin prezenta, TELTONIKA declară că aparatul RUT240 este în conformitate cu cerinţele esenţiale şi cu alte prevederi pertinente ale Directivei CE/RED. [SE] Swedish Härmed intygar TELTONIKA att denna RUT240 är i överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv CE/RED. [SI] Slovenian TELTONIKA izjavlja, da je ta RUT240 v skladu z bistvenimi zahtevami in drugimi relevantnimi določili direktive CE/RED. The full text of the EU …

Text truncated - open the document above for the full version.

FCCStatement (15C)Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe followingtwoconditions: 1. Thisdevicemaynotcauseharmfulinterference; 2.Thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Changesormodificationsnotexpresslyapprovedbythemanufacturercouldvoid theuser'sauthoritytooperatetheequipment. Theantenna(s)usedforthistransmittermustnotbeco-locatedoroperatingin conjunctionwithanyotherantennaortransmitter. (15B)ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass Bdigitaldevice,pursuanttopart15oftheFCCRules. Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful interferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe instructions,maycauseharmfulinterferencetoradiocommunications.However, thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.If thisequipmentdoescauseharmfulinterferencetoradioortelevisionreception, whichcanbedeterminedbyturningtheequipmentoffandon,theuseris encouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing measures: Reorientorrelocatethereceivingantenna. Increasetheseparationbetweentheequipmentandreceiver. Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich thereceiverisconnected. Consultthedealeroranexperiencedradio/TVtechnicianforhelp. FCCRFExposureInformation ThisdevicecomplieswiththerelevantFCCRFradiationexposurelimitsetforthfor anuncontrolledenvironment. Theantenna(s)usedforthistransmittermustnotbeco-locatedoroperatingin conjunctionwithanyotherantennaortransmitterandmustbeinstalledtoprovidea separationdistanceofatleast20cmfromallpersons. ICStatement Thisdevicecontainslicence-exempttransmitter(s)/receiver(s)thatcomplywith Innovation,ScienceandEconomicDevelopmentCanada’slicence-exemptRSS(s). Operationissubjecttothefollowingtwoconditions: 1. Thisdevicemaynotcauseinterference; 2.Thisdevicemustacceptanyinterference,includinginterferencethatmay causeundesiredoperationofthedevice. L’émetteur/récepteurexemptdelicencecontenudansleprésentappareilest conformeauxCNRd’Innovation,SciencesetDéveloppementéconomiqueCanada applicablesauxappareilsradioexemptsdelicence.L’exploitationestautoriséeaux deuxconditionssuivantes: 1. L’appareilnedoitpasproduiredebrouillage; 2.L’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesile brouillageestsusceptibled’encompromettrelefonctionnement. ThisequipmentcomplieswithICRSS‐102radiationexposurelimitssetforthforan uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwith minimumdistance20cmbetweentheradiatorandyourbody. Cetéquipementestconformeauxlimitesd'expositionauxradiationsICCNR‐102 établiespourunenvironnementnoncontrôlé.Cetéquipementdoitêtreinstalléet utiliséavecunedistanceminimalede20cmentreleradiateuretvotrecorps.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name UAB Teltonika Network Address K. Barsausko st. 66, Kaunas LT-51436, Lithuania Grantee Code 2AET4 FCC ID 2AET4RUT240G Authorized Contact Name Mantas Cizauskas Contact Email [email protected] Contact Phone (+370)65546942 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicantshallmake provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicantshall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs:https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs:https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100:https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:2020/07/21 Print Name:Mantas Cizauskas Title:Head of Networking R&D Department *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UAB Teltonika Networks Date:2020/07/21 TO:Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding:FCC ID: 2AET4RUT240G To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch and Keny Xu in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branchto act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with UAB Teltonika Networks This authorization is valid until further written notice from the applicant. Print Name: Mantas CizauskasTitle: Head of Networking R&D Department Signature: On behalf of Company: UAB Teltonika Networks Telephone: (+370)65546942 E-mail: [email protected]

UAB Teltonika Networks We, UAB Teltonika Networks declare that this EUT (FCC ID: 2AET4RUT240G) doesn’t have ad Hoc Mode function on “US/Canada frequencies“. For DTS part of this device, only channels 1-11 will be used in North America. The end-user has no possibility to select any other operating channels for devices marketed to the US/ Canada. Country code selection is disabled. Should you have any questions or comments regarding this matter, Please have my best attention. Sincerely yours, Print Name: Mantas CizauskasTitle: Head of Networking R&D Department Signature: On behalf of Company: UAB Teltonika Networks Telephone: (+370)65546942 E-mail: [email protected]

UAB Teltonika Networks TO:Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding:Confidentiality Request regarding application for FCC ID:2AET4RUT240G LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within aforementioned days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Mantas CizauskasTitle: Head of Networking R&D Department Signature: On behalf of Company: UAB Teltonika Networks Telephone: (+370)65546942 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 6 External Photos for SZEM2007006550CR FCC ID: 2AET4RUT240G SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 6 1 EUT Constructional Details 2G3G4G antenna WIFI antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 6 2G3G4G antenna connector WIFI antenna connector SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 6

' ... � (.) ln 0 C 0 - � ro E Q c5 (.) LL � ' Q) 8 0 Q) C. � ' t ro C. C 0 ro ... � ln §: ' Q) E ::::, (.) 0 0 0 Q) C. � ' ::::, ""C e 0... 0 en Q) -� ... ::::, 0 0:: g ' u ::::, 0... 0 Q) C. � �TEL TONIKA RUT240 korpuso TOP lipdukas su FCC, IC zymejimu �TEL TON/KA | Networks RUT240 (9-30V) + � -(GNDJ INPUT ffl OUTPUT Material: JAC ECOPLUS PAPERPRINT Surface finish: DULL Printing color Sticker color C:97 M:65 Y: 1 C:0 M:0 Y:0 C:0 M:0 Y:0 HVIN: RUT240G IC: 26511-RUT240G Contains IC: 10224A-201903EG25G CAN ICES-003(B) / NMB-003(B) FCC ID: 2AET4RUT240G Contains FCC ID: XMR201903EG25G Default IP: 192.168.1.1 User/Pass: admin/admin01 Made in Lithuania TELTONIKA NETWORKS UAB K. Barsausko st. 66 LT-51436 Kaunas, Lithuania K:25 (blue) K:0 (white) K:I00(black) Created by: G. Narkus Date: 2019 12 12 (Label location: top of the device)

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 Internal Photos for SZEM2007006550CR FCC ID: 2AET4RUT240G SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655003 Page: 1 of 8 Keny Xu EMC Laboratory Manager 1 Cover page RF Exposure Evaluation Report Application No.: SZEM2007006550CR Applicant: UAB Teltonika Networks Address of Applicant: K. Barsausko st. 66, LT-51436, Kaunas, Lithuania Manufacturer: UAB Teltonika Networks Address of Manufacturer: K. Barsausko st. 66, LT-51436, Kaunas, Lithuania Factory: UAB Teltonika EMS Address of Factory: Liepkalnio st. 132A, LT-02121, Vilnius, Lithuania Equipment Under Test (EUT): Product Name: LTE Router Model No.: RUT240 Trade Mark: Teltonika FCC ID: 2AET4RUT240G Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 47 CFR Part 2.1091 Date of Receipt: 2020-07-15 Date of Test: 2020-07-19 to 2020-12-11 Date of Issue: 2020-12-21 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655003 Page: 2 of 8 2 Version Revision Record Version Chapter Date Modifier Remark 01 2020-12-21 Original Authorized for issue by: Calvin Weng/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655003 Page: 3 of 8 3 Contents Page 1 COVER PAGE ........................................................................................................................................ 1 2 VERSION ................................................................................................................................................ 2 3 CONTENTS ............................................................................................................................................ 3 4 GENERAL INFORMATION ..................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ............................................................................................................. 4 4.2 TEST LOCATION .................................................................................................................................... 5 4.3 TEST FACILITY ...................................................................................................................................... 5 4.4 DEVIATION FROM STANDARDS ................................................................................................................. 5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................ 5 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER .............................................................................. 5 5 RF EXPOSURE EVALUATION ............................................................................................................... 6 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................. 6 5.1.1 Limits .......................................................................................................................................... 6 5.1.2 Test Procedure ........................................................................................................................... 6 4.1.3 EUT RF EXPOSURE EVALUATION ........................................................................................................ 7-8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655003 Page: 4 of 8 4 General Information 4.1 General Description of EUT Power Supply: DC9V by AC/DC Adapter Adapter M/N: SJ-09010033 Adapter input: 100-240VAC, 50/60Hz, 0.8A Adapter output: DC9V/1A Cable: Power cable: 2m unshielded without ferrite core RJ45 cable: 1.5m unshielded Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Channel Spacing: 5MHz Antenna Type: Dipole antenna Antenna Gain: 5dBi SN: 999999999 HVIN: RUT240G FVIN: RUT2XX_R_AA.BB.CC SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655003 Page: 5 of 8 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Innovation, Science and Economic Development Canada SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0006. IC#: 4620C. 4.4 Deviation from Standards None. 4.5 Abnormalities from Standard Conditions None. 4.6 Other Information Requested by the Customer None. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM2007006550…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655002 Page: 1 of 112 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2007006550CR Applicant: UAB Teltonika Networks Address of Applicant: K. Barsausko st. 66, LT-51436, Kaunas, Lithuania Manufacturer: UAB Teltonika Networks Address of Manufacturer: K. Barsausko st. 66, LT-51436, Kaunas, Lithuania Factory: UAB Teltonika EMS Address of Factory: Liepkalnio st. 132A, LT-02121, Vilnius, Lithuania Equipment Under Test (EUT): EUT Name: LTE Router Model No.: RUT240 Trade Mark: Teltonika FCC ID: 2AET4RUT240G Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2020-07-15 Date of Test: 2020-07-19 to 2020-12-11 Date of Issue: 2020-12-21 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655002 Page: 2 of 112 Revision Record Version Chapter Date Modifier Remark 01 2020-12-21 Original Authorized for issue by: Calvin Weng/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655002 Page: 3 of 112 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700655002 Page: 4 of 112 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 DETAILS OF SAMPLE SETTING. ......................................................................................................... 6 4.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 7 4.5 TEST LOCATION ............................................................................................................................. 8 4.6 TEST FACILITY ............................................................................................................................... 8 4.7 DEVIATION FROM STANDARDS ......................................................................................................... 8 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 8 5 EQUIPMENT LIST ............................................................................................................................... 9 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................14 6.1 ANTENNA REQUIREMENT ................................................................................................................14 6.1.1 Test Requirement: ..................................................................................................................14 6.1.2 Conclusion ..............................................................................................................................14 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................15 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................15 7.1.1 E.U.T. Operation .....................................................................................................................16 7.1.2 Test Setup Diagram ................................................................................................................16 7.1.3 Measurement Procedure and Data .........................................................................................16 7.2 MINIMUM 6DB BANDWIDTH .............................................................................................................19 7.2.1 E.U.T. Operation ...................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Setup Photos for SZEM2007006550CR FCC ID: 2AET4RUT240G SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 Photographs 1.1 Conducted Emissions at AC Power Line (150kHz-30MHz) Test Setup 1.2 Radiated Emissions which fall in the restricted bands Test Setup SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3 1.3 Radiated Spurious Emissions Test Setup
