2AEY6-V710Tablet

7" TABLET FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 1 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. MODEL: PHP_V710R USER MANUAL Preface Thank you for buying the MID. We wish you enjoy using it. Please read and retain all the operating instructions before operating the unit, we do not assume any liability arising out of improper operation or incidental damages. For better services, the content of this operation manual may be changed. If the actual setup and usage of the unit are different from this operation manual, please view the website of our company to inquire about the latest product information. 2 Do not allow water or foreign objects to enter the unit. I. Note: 1. Avoid the unit being dropped. Avoid the display been shake seriously, or the display will be damaged or unusual. 2. Do not use metal object to touch the device to prevent it from short circuit. 3. Please backup your data in case your important data is lost, especially before you upgrade the firmware. The company will not take charge in any loss that caused by lost of data. 4. Do not disassemble. Do not wipe the surface of the unit by alcohol, thinner or benzene. 5. Do not disconnect the unit while it is formatting or uploading/downloading, or the procedures may lead to errors 6. We do not take responsibility to the flash damage caused by product broken, repair or other reasons. Please operate strictly as per the user guide. 7. Avoid water or foreign objects enter the unit. 3 8. Do not use the unit in places that are extremely hot, cold, dusty, or humid. 9. Avoid the unit being dropped. Avoid the display been shake seriously, or the display will be damaged or unusual. 10. Specifications are subject to change and improvement without notice II. Introduction of cover: 1. Power on/off 4 2. Volume+, Volume – 3. Earphone Jack 4. Reset 5. IR 6. Micro USB interface 7. Back Camera 8. TF-CARD interface 9. Loudspeaker 10. Front Camera III. Operation Instruction 1. Basic Operation 1.1. Power on/Power off Power on: Press and hold the power switch for 5 seconds; the unit displays the start-up logo and enters the working mode. Power off: Press and hold the power switch for 3 seconds to turn the unit off. Sleep: 5 While the device is at working status, press the power switch, it enters the sleeping mode, and the screen will be off then. Press the power switch again, it shift to the normal mode. You may use this function when you don’t’ use the device temporary to save power. 1.2. Charging When the device prompts low battery, please charge it by provided charger. Note: To improve the longevity of the battery, you may charge for another 15 minutes after it prompts the battery is full. 1.3. Main menu Click the icon in the main interface, the main menu is appeared. It including the system setting, music playback, video playback, web browser and other applications you installed in the main menu. 2. Settings 6 Click “” in the main interface to enter the setting interface. Click the Corresponding setting items to operate. 7 8 2.1．Date and Time Setting Click “Date & Time” in the setting interface to set the date and time. You may set The date, time zone, time, time format and date format etc. in the menu. 2.2. Brightness Select “Display” in the setting interface. Click “Brightness” to enter, and slide the 9 bar to adjust the brightness. 10 3. Wi-Fi connection Click “Settings” in the main interface and click “Wireless & network” to enter the wireless and network setting interface. Click Wi-Fi to turn on the WIFI. Click Wi-Fi setting to set and manage wireless access. 3.2 Bluetooth Turn on the Bluetooth，Click Bluetooth setting to set and manage Blutooth Devices access.Click “SEARCH FOR DEVICES”,it lists the open devices.Click the name of the devices;it pops up the setting window.choose the device ,pairing it,then you can transfer pictures,movies,music etc with it. 3.3 Ethernet configuration The Unit support USB-Net-Card 3.4 Click “Network Notification”, it lists the open network it searched. Click the name of the network; it pops up the setting window. You may connect it to WIFI according to the prompts. You need to input the user name and password if networks are encrypted. 11 4. Explorer to install App 4.1 Install There are many ways to install applications under Android, such as via USB, by third party program. We introduce installation by Apps Installer here. 12 Click the “File Manager” in the main interface . Select the APK file you want and enter the application installation interface. Click “Install” to install the application automatically. Af…

Text truncated - open the document above for the full version.

Date: 12/16/2015 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AEY6-V710 To Whom It May Concern: We, PHILIPS, are applying FCC DOC for product Tablet which model no. is V710. the FCC DOC is doing at proper FCC recognized and accredited MRA lab, and FCC DOC will be issued soon. If you have any question or concerns, pls. contact us. Sincerely, Dated this / Day of 12/16/2015 / By: Carol Sung Signature Printed Title: Manager On behalf of : PHILIPS Telephone: +886 2 77033970 #146

CN: XXXXXXXXXXXXXXXX Philips V710 FCC ID:2AEY6-V710

Label location:

FCC ID: 2AEY6-V710 The device has a standalone transmission. According to KDB 447498 D01 General RF Exposure Guidance v0.5 The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz power and distance are rounded to the nearest mW and mm before calcuation The result is rounded to one decimal place for comparison Worse case is as below:[2462MHz 7.57dBm(5.71mW) output power] (5.71mW/5mm) ·[√2.462(GHz)]=1.79 <3.0 for 1-g SAR Then SAR evaluation is not required.

Global United Technology Services Co., Ltd. Report No.: GTSE15090182601 FCC Report (WIFI) Applicant: PHILIPS Address of Applicant: 14F.-5, No.258, Liancheng Rd., Zhonghe Dist., New Taipei City, Taiwan Equipment Under Test (EUT) Product Name: Tablet Model No.: V710 Trade Mark: Philips FCC ID: 2AEY6-V710 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2014 Date of sample receipt: December 09, 2015 Date of Test: December 10-15, 2015 Date of report issued: December 16, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Report No.: GTSE15090182601 2 Version Version No. Date Description 00 December 16, 2015 Original Prepared By: Date: December 16, 2015 Project Engineer Check By: Date: December 16, 2015 Reviewer Global United Technology Services Co., Ltd. Project No.: GTSE150901826RF No. 301-309, 3/F., Jinyuan Business Building, No.2, Laodong Industrrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 60 Report No.: GTSE15090182601 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION ......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE ........................................................................................................................................ 6 5.4 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.5 TEST FACILITY .................................................................................................................................... 7 5.6 TEST LOCATION ................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS ................................................................................................................... 10 7.3 CONDUCTED PEAK OUTPUT POWER .................................................................................................. 13 7.4 CHANNEL BANDWIDTH ...................................................................................................................... 14 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 19 7.6 BAND EDGES .................................................................................................................................... 24 7.6.1 Conducted Emission Method ..................................................................................................... 24 7.6.2 Radiated Emission Method ........................................................................................................ 27 7.7 SPURIOUS EMISSION ......................................................................................................................... 32 7.7.1 Conducted Emission Method ..................................................................................................... 32 7.7.2 Radiated Emission Method ........................................................................................................ 37 8 TEST SETUP PHO…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
