2AEZQCASECase for iphone6

Moment Inc
Case for iphone6 - FCC ID 2AEZQCASE - Moment Inc
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Jun 10, 2015
Application Purpose
Original Equipment
Date of Application
Jun 10, 2015
Equipment Note
Case for iphone6
Frequency Range
2402.00000000 - 2480.00000000
Company
Moment Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

External Photos

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Manual Model:Case for iPhone6 GETTING STARTED 1. Download the Moment App 2. Turn on your iPhone Bluetooth 3. Remove the battery "PULL" tab from inside your case 4. Open the App, then press the case shutter button all the way down 5. You should now be connected, go forth and #makemoments We're here to help ‐ [email protected] FCC ID:2AEZQCASE N OTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Attestation Statements

Moment Inc 55 South Atlantic Street Suite 204,Seattle Washington 98134 United States TEL: 1.206.356.0607 FAX: 1.206.356.0607 E-mail: [email protected] Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 6/8/2015 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AEZQCASE including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Moment Inc Contact person: Wes Wirth Title: Electrical Engineer

ID Label/Location Info

FCC ID Label Location Model:Case for iphone6 Brand:Moment FCC ID: 2AEZQCASE

Internal Photos

Internal Photos OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 Antenna

RF Exposure Info

RF Exposure evaluation Product Description:Case Model Number: Case for iphone6 FCC ID: 2AEZQCASE According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation According to the follow transmitter output power(P t )formula: P t =(E x d) 2 /(30 x g t ) P t =transmitter output power in watts g t =numeric gain of the transmitting antenna (unitess) E=electric field strength in V/m d=measurement distance in meters (m) According to the above test data, Emax=96.66dBuv/m=0.068V/m,d=3m,g t =1.12 P t =(E x d) 2 /(30 x g t )=(0.068x3) 2 /(30x1.12)=0.001239W=1.24mW The result is rounded to one decimal place for comparison Worse case is as below: [2440MHz -1.24mW output power] (1.24mW /5mm) .[√2.440(GHz)]= 0.387<3.0 for 1-g SAR Then SAR evaluation is not required NOTE: For the maximum power, you can refer FCC test report.

Test Report

Page 1 of 44 FCC Test Report Report No.: AGC04628150501FE03 FCC ID : 2AEZQCASE APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Case BRAND NAME : Moment MODEL NAME : Case for iphone6 CLIENT : Moment Inc DATE OF ISSUE : June 04,2015 STANDARD(S) TEST PROCEDURE(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC04628150501FE03 Page 2 of 44 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid VersionNotes V1.0 / June 04,2015Valid Original Report Report No.: AGC04628150501FE03 Page 3 of 44 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ............................................................................................................... 5 2. GENERAL INFORMATION ............................................................................................................................ 6 2.1. PRODUCT DESCRIPTION ..................................................................................................................... 6 2.2. TABLE OF CARRIER FREQUENCYS ..................................................................................................... 6 3. MEASUREMENT UNCERTAINTY ................................................................................................................. 7 4. DESCRIPTION OF TEST MODES ................................................................................................................. 7 5. SYSTEM TEST CONFIGURATION ............................................................................................................... 8 5.1. CONFIGURATION OF EUT SYSTEM ..................................................................................................... 8 5.2. EQUIPMENT USED IN EUT SYSTEM ..................................................................................................... 8 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 8 6. TEST FACILITY ............................................................................................................................................. 9 7 ALL TEST EQUIPMENT LIST ........................................................................................................................ 9 8. RADIATED EMISSION ................................................................................................................................. 10 8.1TEST LIMIT ............................................................................................................................................. 10 8.2. MEASUREMENT PROCEDURE ............................................................................................................ 11 8.3. TEST SETUP ......................................................................................................................................... 13 8.4. TEST RESULT(WORST MODULATION:GFSK) .......................................................................................... 15 9. BAND EDGE EMISSION ............................................................................................................................. 28 9.1. MEASUREMENT PROCEDURE ........................................................................................................... 28 9.2 TEST SETUP .......................................................................................................................................... 28 9.3 RADIATED TEST RESULT(WORST MODULATION:GFSK) ......................................................................... 29 10 6DB BANDWIDTH ...................................................................................................................................... 33 10.1. MEASUREMENT PROCEDURE ......................................................................................................... 33 10.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................ 33 10.3. LIMITS AND MEASUREMENT RESULTS ........................................................................................... 33 11. FCC LINE CONDUCTED EMISSION TEST ............................................................................................... 36 Report No.: AGC04628150501FE03 Page 4 of 44 11.1. LIMITS OF LINE CONDUCTED EMISSION TEST ............................................................................... 36 11.2. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ............................................................. 36 11.3. PRELIMINARY PROCEDURE OF LINE CONDUCTED EMISSION TEST ........................................... 37 11.4. FINAL PROCEDURE OF LINE CONDUCTED EMISSION TEST ......................................................... 37 11.5. TEST RESULT OF LINE CONDUCTED EMISSION TEST ................................................................... 37 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ........................................................................................ 38 APPENDIX B: PHOTOGRAPHS OF EUT ....................................................................................................... 39 Report No.: AGC04628150501FE03 Page 5 of 44 1. VERIFICATION OF CONFORMITY Applicant Moment Inc Address 55 South Atlantic Street Suite 204, Seattle WA USA, 98134 Manufacturer Radial International Ltd Address Room 604 Turbo Logistics Center Futian Free Trade Zone Shenzhen Product Designation Case Brand Name Moment Test Model Case for iphone6 Date of test June 01,2015 June 04,2015 Deviation None Condition of Test Sample Normal Report Template AGCRT-US-BR/RF We hereby certify that: The above equipment was tested by Compliance Certification Service(Shenzhen) Inc. The test data, data evaluation, test procedures, and equi…

Text truncated - open the document above for the full version.

Test Setup Photos

APPENDIX IV PHOTOGRAPHS OF TEST SETUP FCC RADIATED EMISSION TEST SETUP
