2AEZR-XUIAssembly, User Interface UI, X-DU, NA

User’s Manual Since this module is not sold to the general end users directly, and is designed, limited for use and incorporated into an end product or host device by the grantee (Amazon Robotics LLC), there is no user’s manual for the module. Once incorporated into the end product or host device, the module is hard-coded and cannot be overwritten (read-only) thus full compliance is assured. For details about the module, please refer to the engineering specification sheet of the module. The User Manual and Users Notice shall be in English and in French (when available). The User’s Manual shall contain the following information. End Product Labeling and Manual Requirements The following information must be visible and displayed on the end product.  “Contains FCC ID: 2AEZR-XUI”  “Contains IC: 10244A-XUI”  ”This device complies with Part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.” “Le présent appareil est conforme à la partie 15 des règles de la FCC et CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.” Note: If it is difficult to print the above statement on the end product or host device due to size, then the statement shall be printed in the end product/host device user’s manual. The user’s manual shall contain the following statement cautioning the user that;  “This device must not be collocated or operating in conjunction with any other antenna or transmitter.”  “Changes or modifications not expressly approved by Amazon Robotics LLC could void the user’s authority to operate the equipment.”  This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.  Cet équipement a été testé et déclaré conforme aux limites imposées aux appareils numériques de classe B, conformément à la section 15 du règlement de la FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut émettre de l'énergie de fréquence radio. S'il n'est pas installé et utilisé conformément aux instructions, il peut causer des interférences nuisibles aux communications radio. Cependant, rien ne garantit que des interférences ne se produiront pas dans une installation particulière. Si cet équipement provoque des interférences nuisibles avec la réception de radio ou de télévision, ce qui peut être déterminé en éteignant et en rallumant l'équipement, l'utilisateur est invité à tenter de corriger l'interférence en appliquant l'une ou plusieurs des mesures suivantes: — Réorientez ou déplacez l’antenne de réception. — Augmentez la distance entre l'équipement et le récepteur. — Connectez l’équipement à une prise d’un circuit différent de celui auquel le récepteur est connecté. — Consultez le revendeur ou un technicien expérimenté en radio / télévision pour obtenir de l'aide. RF Exposure Requirements “WARNING! FCC and IC Radiation Exposure Statement: This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment under the following conditions: 1. This equipment should be installed and operated such that a minimum separation distance of 20cm is maintained between the radiator (antenna) & user’s/nearby person’s body at all times. Cet équipement est conforme aux limites d'exposition aux rayonnements RF de la FCC et de l'IC, définies pour un environnement non contrôlé dans les conditions suivantes. 1. Cet équipement doit être installé et utilisé de manière à maintenir une distance de séparation minimale de 20 cm entre le radiateur (antenne) et le corps de l'utilisateur / des personnes proches à tout moment.

Re: Confidentiality Request January 14, 2020 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle, Suite #1 Littleton, MA 01460, FCC ID: 2AEZR-XUI Applicant: Amazon Robotics LLC To whom it may concern: Amazon Robotics LLC requests that the following documents and information be kept confidential referring to the FCC rules 0.457 and 0.459: 1. Block Diagram 2. Schematics 3. Operational Description 4. Internal Photos (The circuit board and internal components are not accessible to the users) The application contains technical data and information, which we deem to be trade secrets and proprietary and would customarily be guarded from competitors. In accordance with KDB document 726920 D01 Confidentiality Request Procedures (II. Long-term Confidentiality Section 3), the radio equipment is strictly controlled and limited for use only by the Grantee and not available for sale to third party purchasers/users. This information is not publically available to anyone outside of the company. If made public, the information might be used to the disadvantage of the applicant. Thank you for your attention to this matter. Sincerely, __________________________ Rick Roberts Manager, Regulatory Compliance Amazon Robotics LLC. 300 Riverpark Drive North Reading, MA 01864

Letter of Authorization Date: 14 January 2020 Bureau Veritas Consumer Product Services, Inc. One Distribution Center Circle, Suite #1 Littleton, MA 01460, FCC ID: 2AEZR-XUI Applicant: Amazon Robotics LLC To whom it may concern: Please be advised we do hereby authorize, until further notice, Bureau Veritas Consumer Products Services, Inc., to act on our behalf in dealings before the Federal Communications Commission with respect to all matters relating to equipment authorizations under 47 CFR. This authorization includes, but is not limited to, the signing of Form 731. We certify that no party (as defined in 47 CFR 1.2002) to this application, including myself, is subject to a denial of federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 853A. Thank you for your attention to this matter. Sincerely, __________________________ Rick Roberts Manager, Regulatory Compliance Amazon Robotics, LLC. 300 Riverpark Drive North Reading, MA 01864

January 15, 2020 REQUEST FOR LIMITED MODULAR APPROVAL FCCID: 2AEZR-XUI Applicant: Amazon Robotics LLC 300 Riverpark Drive North Reading, MA 01864 Model: Assembly, User Interface UI, X-DU, NA Since this module is not sold to the general end users directly, and is designed, limited for use and incorporated into an end product or host device by the grantee (Amazon Robotics, LLC), it does not comply with all of the modular transmitter basic requirements (Items 1 to 8) in FCC Part 15 Subpart C Section 15.212(a) as indicated below, thus a limited modular approval per 15.212(b) is requested. Modular Approval Requirements YES NO Remarks 15.212(a)(1)(i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. X Demonstrated compliance of the module without a shield. 15.212(a)(1)(ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over- modulation. X 15.212(a)(1)(iii) The modular transmitter must have its own power supply regulation. X The end product or host device will provide an external power supply regulation to the radio module. 15.212(a)(1)(iv) The modular transmitter must comply with the antenna and transmission system requirements of §§15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of §15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. X 15.212(a)(1)(v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in §15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see §15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see §15.31(i)). X 15.212(a)(1)(vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. X 15.212(a)(1)(vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. X 15.212(a)(1)(viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. X 15.212(b) A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured. X Please see explanation above. ___________________________________________ Rick Roberts Manager, Regulatory Compliance Amazon Robotics LLC. 978-276-2815 [email protected]

FCC ID: 2AEZR-XUI IC: 10244A-XUI FCC ID: 2AEZR-XUI IC: 10244A-XUI FCC ID: 2AEZR-XUI IC: 10244A-XUI FCC ID: 2AEZR-XUI IC: 10244A-XUI

Label and Label Location 1. Material: SUBSTRATE: 7730FL Clear Polyester OVERLAMINATE: 7730FL Clear Polyester ADHESIVE 2. Label will last the lifetime of the product. Figure 1 - Label Figure 2 - Label Location on enclosure Label Location

Bureau Veritas Consumer Products Services, Inc.is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 1 of 17 Test Report Bureau Veritas Consumer Products Services, Inc. Report No ET2827-1 Client Amazon Robotics LLC Address 300 Riverpark Drive North Reading, MA 01864 Phone (978) 276-2815 Items tested User Interface UI, X-DU, NA (Model 600-01648-NA) FCC ID IC 2AEZR-XUI 10244A-XUI FRN 0024656845 Equipment Type Low Power Communication Device Transmitter Equipment Code DXX Standards CFR Title 47 FCC Part 15.249, RSS-210 Issue 9 Annex B.10 Test Dates Nov 6-8, 2019 Results As detailed within this report Prepared by Anna Vancheva – EMC Engineer Authorized by Yunus Faziloglu – Sr. Engineer Issue Date 11/8/2019 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Conditions of Testing’ section on page 16 of this report. Test Report for Amazon Robotics LLC  Report No. ET2827-1 November 8, 2019 ______________________________________________________________________ ____________________________________________________________ Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 2 of 17 Contents Contents .................................................................................................................................. 2 Product Tested - Configuration Documentation ....................................................................... 3 Summary and Test Methodology ............................................................................................. 4 Compliance Statement ............................................................................................................ 5 Modifications Required for Compliance ................................................................................... 5 Test Results ............................................................................................................................ 6 Fundamental Measurements................................................................................................ 6 Radiated Spurious Emissions .............................................................................................. 7 Occupied Bandwidth (99%) ................................................................................................ 11 Conducted Emissions ........................................................................................................ 12 Measurement Uncertainty...................................................................................................... 15 Conditions of Testing ............................................................................................................. 16 Form Final Report REV 2-16-07 (DW) Test Report for Amazon Robotics LLC  Report No. ET2827-1 November 8, 2019 ______________________________________________________________________ _________________________ Issue No. Reason for change Date Issued 1 Original Release September 23, 2019 ____________________________________ Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 3 of 17 Product Tested - Configuration Documentation EUT Configuration Work Order: T2827 Company: Amazon Robotics LLC Company Address: 300 River Park Drive North Reading, MA, 01864 Contact: Dao Keopadith MN PN SN EUT: 600-01648-NA 600-01648-NA -- EUT Description: User Interface UI, X-DU, NA EUT Max Frequency: 925 MHz EUT Min Frequency: 0.125 MHz EUT Components MN SN -- -- -- Support Equipment MN SN XDU X 000020 Test Laptop Lenovo W430 1525 Port Label Port Type # ports # populated cable type shielded ferrites length (m) in/out under test comment CAN cable other 1 1 other No No 10 in yes Software Operating Mode Description: Both 0.125MHz and 925MHz radios are transmitting during testing. Clock Frequencies frequencies (MHz) 0.125, 925 Test Report for Amazon Robotics LLC  Report No. ET2827-1 November 8, 2019 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 4 of 17 Summary and Test Methodology On Nov 6 through 8, 2019 we tested the User Interface UI, X-DU, NA (Model 600-01648-NA) for compliance with the following requirements: CFR Title 47 FCC Part 15.249, RSS-210 Issue 9 Annex B.10 EUT transmits at 925MHz. Emissions were tested with the EUT in its intended installation orientation. EUT has an internal surface mount chip antenna with 3.32dBi gain. Radiated emission testing was performed according to the procedures specified in ANSI C63.10-2013 and RSS-Gen Issue 5. AC mains conducted emission testing was performed at an operating voltage of 120VAC/60Hz. Following bandwidths were used during radiated and conducted spurious emissions testing. Frequency RBW VBW 0.15-30MHz 9kHz 30kHz 30-1000MHz 120kHz 1MHz 1-10GHz 1MHz 3MHz We found that the product met the above requirements without modification. The test sample was received in good condition. Test Report for Amazon Robotics LLC  Report No. ET2827-1 November 8, 2019 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 5 of 17 Compliance Statement RSS-…
