2AF2D-S02Bluetooth Earphone

Manual Partial View 1. Silicone holder to prevent earplugs fall off 2. Earplug 3.Short press to volume up, long press for play next song 4.Short press to volume down, long press for play previous song 5.Indicator light/Power ON/OFF Standby status: red and blue light alternate flashing Working status: blue light Charging status: red light, the light will turn off when earphone is fully charged. Long press to Turn On/Turn Off. Short press to Play/Pause; Answer/Hang Up the phone call under Bluetooth model 6.MIC 7.Micro USB Charging Port. Usage The Bluetooth connection: Hold down the power button until the red and blue lights flashing, the device ready to pair. Play via Computer: Activate Computer's Bluetooth(if the computer does not built-in BT, plug on a BT adapter, also need extra BT driver.)-Turn speaker to pairing mode(Blue light flashing quickly)-Search " JL BT" -Paring-Connect and Play. Play via Mode phone: Activate Mode phone's Bluetooth-Search Find 'JL BT' -paring-Connect and play Parameter Bluetooth version：V4.1 Bluetooth transmission power: CLASS2-4dBm Bluetooth working frequency：2.4GHz Charging voltage: DC5V/500mA Working voltage ：DC 3.7V Battery capacity:100 MA THD: ≤ 0.1% Signal to Noise Ratio：≥95db Music/talking time：5H Bluetooth range :10-20m Charging time: 1 hour Troubleshooting 1.Hands-free call is only available at BT connected status; Still the phone call could be interfered with high frequency electromagnetism. People should try not to use this product under high frequency environment. 2.Bluetooth is a bidirectional transmitting protocol; transmitting distance is highly related to audio player. Compatible BT players are recommended. 3.When BT transmitting devices cannot be connected, please delete the rest BT receiving devices name on the list. Re-activate" JL BT", re-searching and re-paring. 4.The sound performance could also be affected when BT transmitting devices is under poor signal environment, or under low battery capacity. Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ●Reorient or relocate the receiving antenna. ●Increase the separation between the equipment and receiver. ●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ●Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by Shenzhen JiLang Technology Co.,Ltd. may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

Shenzhen JiLang Technology Co.,Ltd 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China TEL: +86 -755-84353106 FAX: +86 -755-84353106 DATE 09-29-2015 FCC ID: 2AF2 D-S02 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Director of Certification Autho rity to Act as Agent On our behalf, I appoint BZT Testing Technology Co., Ltd. ( Jack Kang) at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by MiCOM Labs Inc, still resides with Shenzhen JiLang Technology Co.,Ltd at 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China. Dated this 09-29-201 5 Agency agreement expiration date: 09-28-2016 By: Haijun Zhao Signature Printed Title: Manager On behalf of : Shenzhen JiLang Technology Co.,Ltd Telephone: +86 -755 -84353106

Shenzhen JiLang Technology Co.,Ltd 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China TEL: +86-755-84353106 FAX: +86-755-84353106 DATE 09-29-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AF2D-S02 Product Name: Bluetooth earphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 09-29-2015 By: Haijun Zhao Signature Printed Title: Manager On behalf of : Shenzhen JiLang Technology Co.,Ltd Telephone: +86-755-84353106

Shenzhen JiLang Technology Co.,Ltd 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China TEL: +86-755-84353106 FAX: +86-755-84353106 Series Models Description FCC ID: 2AF2D-S02 Date: Sept.29, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: To whom concern: The device (Product Name: Bluetooth earphone) Models Name: S02,S03, S05, S06, S07, S08 have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. Sincerely, Haijun Zhao/Manager

Shenzhen JiLang Technology Co.,Ltd 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China TEL: +86-755-84353106 FAX: +86-755-84353106 USB Port Statement FCC ID: 2AF2D-S02 Date: Sept.29, 2015 To whom it may concern: We, the undersigned, state that the device's (Model: S02,S03, S05, S06, S07, S08) USB port only used for charge, no any data transfer to PC. Sincerely, Haijun Zhao/Manager

FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: S02 FCC ID:2AF2D-S02 FCCID Label Location

- FCC RADIO TEST REPORT FCC ID: 2AF2D-S02 Product： Bluetooth earphone Trade Name： N/A Model Number： S02 Serial Model： S03, S05, S06, S07, S08 Report No.： BZT-15090233URF Prepared for Shenzhen JiLang Technology Co.,Ltd 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China Prepared by BZT Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China V1.0 Page 2 of 31 Report No.: BZT-15090233URF TEST RESULT CERTIFICATION Applicant’s name...................... Shenzhen JiLang Technology Co.,Ltd Address....................................... 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China Manufacture's Name................. Shenzhen JiLang Technology Co.,Ltd Address....................................... 3rd Floor, C Builing, No.1 East Area of Shangxue Industrial Park, Bantian Town, Longgang District, Shenzhen City, China Product description Product name.............................. Bluetooth earphone Model and/or type reference .................................................... S02 Serial Model： S03, S05,S06 ,S07 ,S08 Ratings DC 5V from PC AC 120V/60Hz or DC 3.7V from battery Standards................................ FCC Part15.249 Test procedure ............................... ANSI C63.10-2010 This device described above has been tested by BZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BZT, this document may be altered or revised by BZT, personal only, and shall be noted in the revision of the document. Date of Test................................................... Date (s) of performance of tests.................... Sept. 17, 2015 ~ Sept. 29, 2015 Date of Issue.................................................. Sept. 29, 2015 Test Result..................................................... Pass Testing Engineer : (Lynn Chen) Technical Manager : (Carlen Liu) Authorized Signatory : (Tommy zhang) The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 31 Report No.: BZT-15090233URF Contents 1 . T E S T S T A N D A R D S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..4 2 . S U M M A R Y. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . .5 2.1. Equipment Under Test 5 2.2. Description of the Equipment under Test (EUT) 5 2.3. EUT operation mode 6 2.4. EUT configuration 6 2.5. Related Submittal(s) / Grant (s) 6 2.6. Modifications 6 3 . T ES T E N V I R O N M E N T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4 . T E S T C O N D I T I O N S A N D R E S U L T S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . .1 0 4.1. Conducted Emissions Test 10 4.2. Transmitter Radiated Unwanted Emissions and Bandedge 14 4.3. Occupied Bandwidth Measurement 21 5 . A N T E NN A R E Q U I R E M E N T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . .2 6 6 . T E S T S E T U P P H O T O S O F T H E E U T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . .2 7 7 . E X T E R N A L A N D I N T E R N AL P H O T O S O F T H E E U T. . . . . . . . . . . . . . . . . . . . . .2 8 V1.0 Page 4 of 31 Report No.: BZT-15090233URF 1 . T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10-2013 V1.0 Page 5 of 31 Report No.: BZT-15090233URF 2 . S U M M A R Y 2.1. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 3.7V from battery 2.2. Description of the Equipment under Test (EUT) The EUT ( Bluetooth earphone ) support Bluetooth function. Name of EUT Bluetooth earphone Model Number S02 Antenna Type Internal BT CE Operation frequency 2402MHz-2480MHz BT Modulation Type GFSK,8DPSK,π/4DQPSK(BT V4.1) Bluetooth BT V4.1 Hardware Version V1.0 Software Version V1.0 Antenna Gain 0dBi Channel List: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 2424 49 2451 76 2478 23 2425 50 2452 77 2479 24 2426 51 2453 78 2480 25 2427 52 2454 26 2428 53 2455 For more details, refer to the user’s manual of the EUT. Serial number: Prototype V1.0 Page 6 of 31 Report No.: BZT-15090233URF 2.3. EUT operation mode Test Mode(TM) Description Remark TM1 Bottom Channel Transmitting / TM2 Middle Channel Transmitting / TM3 Top Channel Transmitting / TM4 Charging and keeping TX power by USB The field strength of radiation emission was …
