2AF2N-SSMCOccupancy and Daylight Sensor Lighting Control

Sensors EasySense Fixture-Mount Philips EasySense Quick Installation Guide Commercial Product NameOrder Code EasySense Fixture-Mount SensorSNS210 Connection Color GreenGround WhiteNeutral BlackLine LED Drivers Sensor Part Number Driver Model NumberDescription XI040C110V054VPT2Xitanium 40W 0.1-1.1A 27-54V 120-277V SR XI075C200V054VPT1Xitanium 75W 0.1-2.0A 27-54V 120-277V SR Specifications available at www.philips.com/XitaniumSR. * Wiring diagram for 40W driver shown. Other drivers have different wiring diagrams. Consult datasheet for driver for applicable wiring diagram. Note: Below data applicable for SNS210.. XITANIUM SR LED DRIVER EASYSENSE LED+ LED+ LED- LED- DA+ DA– Connectors SR SR LINE NEUTRAL GROUND NC Connectors (non-polarized) Use 18AWG solid copper wire, rated >=600V/90C. Strip wire to 3/8”. Electrical Information Input VoltagePowered by SR driver low-voltage interface Current Consumption 11mA Nominal Power Consumption130mW Standby Power< 1 W on luminaire level, including driver standby power Occupancy Sensing TypePassive infrared (PIR) Enable/DisableDefault enabled DetectionOff/Auto-on; Red LED indicates “on” Eco On Level 0-100% Hold Time0.5-60 minutes Viewing AngleX=72°, Y = 86° ( See detection pattern) Background Light Level0-100% Prolong Time0 minutes - infinity Grace Fading0-25 sec Response Time/Fading to Switch On/Off 0.7Sec Daylight Sensing Enable/DisableDefault enabled Auto-calibrationUpon power-up Viewing Angle40° (half value sensitivity); 2% cut-off point at 75° Task Tuning Full Light Setting0-100% Environment & Approbation Operating Ambient Temperature Range0°C to 55°C Operating Humidity0–95% non condensing Storage Temperature-25°C to 85°C Storage Humidity0-95% non condensing Max Case Temperature (Tcase)55°C Agency ApprobationsUL, CSA; FCC; Tested and approved for use in plenums CertificationCalifornia Title 20 Limited Warranty5 years Digital InterfaceXitanium SR Other Status IndicatorsRed, Yellow. Yellow LED on: Vacancy & Sensor is functional; Red LED on: Motion is detected No. Drivers per SensorFour (max) Field ConfigurationParameters set via MasterConnect app for Android and iPhone phones using Bluetooth Low Energy (Bluetooth LE). © 2019 Signify Holding. All rights reserved. The information provided herein is subject to change, without notice. Signify does not give any representation or warranty as to the accuracy or completeness of the information included herein and shall not be liable for any action in reliance thereon. The information presented in this document is not intended as any commercial offer and does not form part of any quotation or contract, unless otherwise agreed by Signify. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. All other trademarks are owned by Signify Holding or their respective owners. philips.com/easysense Signify North America Corporation 200 Franklin Square Drive Somerset, NJ 08873 Tel. 855-486-2216 Signify Canada Ltd. 281 Hillmount Rd, Markham, ON, Canada L6C 2S3 Tel. 800-668-9008 PLt-19041QG_EasySense SNS210 QIG 10/19 page 1 of 2 Document #: 4435 631 00371 REV. E Operation and Configuration via Mobile App EasySense operates immediately upon installation and energization without further commissioning. If changes from default settings are desired, EasySense (SNS210) can be configured via MasterConnect app through Bluetooth LE. For a complete description of the features and default settings—as well as details on the app—refer to www.philips.com/easysense. FCC and IC Statement This device complies with part 15 of the FCC rules for the United States and Industry Canada (IC) license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Signify could void the user’s authority to operate this equipment. This product is intended for commercial use only. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. Déclaration De Conformité À La Fcc/Ic Ce dispositif est conforme à la partie 15 des règles de la Federal Communications Commission (FCC) des États-Unis et d’Industrie Canada (IC) exempts de licence RSS norme(s). Son fonctionnement est assujetti aux deux conditions suivantes : (1) Ce dispositif ne doit pas provoquer de brouillage préjudiciable, et (2) il doit accepter tout brouillage reçu, y compris le brouillage pouvant entraîner un mauvais fonctionnement. Tous les changements ou modifications non expressément approuvés par Signify, sont susceptibles d’annuler le droit de l’utilisateur à se servir de cet équipement. Ce produit est exclusivement destiné à un usage commercial. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. Connection Color PurpleDA+ BrownDA- RedLED+ BlueLED- Wiring Diagram* 1.7 2 [43.8] MAX 0.96 [24.3] MAX 0 . 6 6 [1 6 .8 ] M A X 1.9 7 [50.0] MAX 0 .3 0 [7 .5 ] M A X 0 .7 5 [1 9 .0 ] M A X 1. 73 [44.0 ] 0 . 6 7 [ 1 7 . 0 ] R0.09 [2.3] 1. 71 [43.5 ]1. 71 [43.5 ] 0 . 6 3 [ 1 6 . 0 ] 0 .6 3 [ 1 6 . 0 ] Sensor Dimensions (in/mm) Mounting Dimensions (in/mm) Mounting in U-shaped slot in sheet metal (max thickness 1 mm) Mounting in cut-out in sheet metal (thickness 0.7 mm to 1.0 mm) Fixture with EasySense installed Mounting in a slot Mounting in a cut-out with mounting ring Note: Consult factory for accessory mounting ring to secure sensor to cut-out. Accessory Mounting Ring • Part Number SMR-50 / Set of 50. • Ordered separately, not included. Accessory Mounting Bracket • Part Number SMB-50 / Set of 50. • - Ordered separately, not included.

SignifyClassified-Internal 00 ®ignify Date:November22,2019 ULLLC. 12LaboratoryDr RTP,NC27709,USA Towhomitmayconcern: I,theundersigned,herebyauthorizeULLLCtoactonourbehalfinallmannersrelatingtoapplicationfor equipmentauthorization,includingsigningofalldocumentsrelatingtothesematters.Anyandallactscarriedoutby ULLLConourbehalf,shallhavethesameeffectasactsofourown. I,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,thatincludesFCCbenefits, pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C.853(a). InauthorizingULLLCasouragent,westillrecognizethatweareresponsibleto: a)Complywiththerelevantprovisionsofthecertificationprogram; b)Makeallnecessaryarrangementsfortheconductoftheevaluation,includingprovisionforExamining documentationandaccesstoallareas,records(includinginternalauditreports)andpersonnelforthepurposes ofevaluation(e.g.testing,inspection,assessment,surveillance,reassessment)andresolutionofcomplaints; c)Makeclaimsregardingcertificationonlyinrespectofthescopeforwhichcertificationhasbeengranted; d)DonotuseourproductcertificationinsuchamannerastobringtheCertificationDivisionintodisrepute andnotmakeanystatementregardingourproductcertificationwhichtheCertificationDivisionmayconsider misleadingorunauthorized; e)Uponsuspensionorcancellationofcertification,discontinueuseofalladvertisingmatterThatcontainsany referencetheretoandreturnanycertificationdocumentsasrequiredbytheCertificationDivision; 1)UsecertificationonlytoindicatetheproductsarecertifiedasbeinginconformitywithSpecifiedstandards; g)Endeavortoensurethatnocertificateorreportnoranypartthereofisusedinamisleadingmanner; h)Ensurethatanyreferencetoourproductcertificationincommunicationmediasuchasdocuments, brochuresoradvertising,complieswiththerequirementsoftheCertificationDivision; i)Keeparecordofallcomplaintsmadeknowntousrelatingtotheproduct’scompliancewithrequirementsof therelevantstandardandtomaketheserecordsavailabletotheCertificationDivisionwhenrequested; j)Takeappropriateactionwithrespecttosuchcomplaintsandanydeficienciesfoundinproductsorservices thataffectcompliancewiththerequirementsforcertification; k)Documenttheactionstaken. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. @2018SignifyNorthAmericacorp.Allrightsreserved.www.signify.com 10275W.HigginsRd.,Rosemont,iL60018USA Tei:800.3222086 Fax:888.423.1882 YoursSincerely,

Signify Classified - Internal ®ignify Signify North America Corp. Date: November 11,2019 To: ULLLC333 Pfingsten Rd. Northbrook, IL 60062 From: Ernesto Mendoza Engineering Manager Phone: 847-768-7736 Fax: 847-390-5264 [email protected] 10275 West Higgins Road Rosemont, IL 60018 Applicant: Signify North America Corp Subject: Request for Non-Disclosure for FCC ID: 2AF2N-SSMC Dear Ladies and/or Gentlemen: Pursuant to Title 47 CFR, Section 0.459, Signify North America Corp. hereby requests non disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID: 2AF2N-SSMC. a. Schematic Diagrams b. Operational Description c. Block Diagram d. Parts List The above materials contain trade secrets, proprietary and technical information, which would customarily be guarded from competitors under Title 47 CFR, Section 0.457(d)(2). Disclosure or publication of any portion of this company’s confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Signify North America Corp. understands that pursuant to Title 47 CFR, Section 0.457(d)(l)(ii), disclosure of the applicant and all accompanying documentation will not be made before the date of the Grant. SincerelySignify North America Corp. ©2018 Signify North America Corp. All rights reserved. sww signify corn 10275W. Higgins Rd., Rosernont, IL 60018 USA Tel: 800.322.2086 Fax: 888.423.1882 Ernesto Mendoza Engineering Manager

44.0 mm EasySense DA DA 9290 017 565 Made in Poland Uin: 12-22Vdc t : +55°C c 30.00 mm 6.00 mm DRAWN BY: Peter van Os CHECKED BY ENGINEER: Robert van Hommel A CR-XXXXXX MM.DD.YY RIVISED BY A4 10 1 a b c d e f 1 2 3 4 5 6 7 REV. CHANGE NO DATE CHECKED BY STL APPROVED BY PM SH SH 114 - 1 CHECKED BY CE a b c d e f 1 2 3 4 5 6 7 2019-09-27 9290 017 56513 Type Plate EasySense SNS210 MC SIGNIFY Sig n ify Ho ldin g A ll rig h ts a re r es er ved. Re pr oduction i n wh ole or i n par t is p r oh ibited w ith ou t the w ri tten c ons ent of the c opyrig ht ow ne r. © Signify Holding SNS210 MC Class 2 YYWWXXX Only Class 2 input (SR) FCC ID:2AF2N-SSMC IC:20659-SSMC E335380 7.50 mm 8.00 mm ENERGY MGMT EQPT 2D barcode label A label B Specification (label A): Method: Laser marking, direct on housing. Dimensions of laser marking: 44x8mm. Font: Centrale Sans. Marking height: 5mm min. Print Quality: Water and petrol resistant (acc.IEC61347-1 clause 7.2) YYWWXXX: To be replaced by two-digit year (YY), two-digit week (WW) and two- or three-digit manufacturer code (XXX) 2D Barcode: Production SFC code Specification (label B): Method: Laser marking, direct on housing. Dimensions of laser marking: 30x6mm Fonts: Centrale Sans Printing Quality: Water and petrol resistant (IEC61347-1, clause 7.2) 2019-07-18

FCC Part 1 Subpart I FCC Part 2 Subpart J INDUSTRY CANADA RSS 102 ISSUE 5 RF EXPOSURE REPORT FOR Occupancy and Daylight Sensor Lighting Control MODEL NUMBER: SNS210 MC FCC ID: 2AF2N-SSMC IC: 20659-SSMC REPORT NUMBER: 13092227C ISSUE DATE: 2019-12-06 Prepared for Signify North America Corporation O’Hare International Center 10275 W. Higgins Rd. Rosemont, IL 60018 Prepared by UL LLC 333 Pfingsten Rd. Northbrook, IL 60062, USA TEL: (847) 272-8800 REPORT NO: 13092227C DATE: 2019-12-06 FCC ID: 2AF2N-SSMC IC: 20659-SSMC Page 2 of 9 UL LLC 333 Pfingsten Rd, Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC Revision History Rev. Issue Date Revisions Revised By V1 2019-12-06 Initial Issue B. Mucha REPORT NO: 13092227C DATE: 2019-12-06 FCC ID: 2AF2N-SSMC IC: 20659-SSMC Page 3 of 9 UL LLC 333 Pfingsten Rd, Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................4 2. TEST METHODOLOGY ......................................................................................................5 3. REFERENCES ....................................................................................................................5 4. FACILITIES AND ACCREDITATION ..................................................................................5 5. MAXIMUM PERMISSIBLE RF EXPOSURE ........................................................................6 5.1. FCC RULES .................................................................................................................6 5.2. IC RULES .....................................................................................................................7 5.3. EQUATIONS .................................................................................................................8 5.4. IC EXEMPTION ............................................................................................................9 6. RF EXPOSURE RESULTS ..................................................................................................9 REPORT NO: 13092227C DATE: 2019-12-06 FCC ID: 2AF2N-SSMC IC: 20659-SSMC Page 4 of 9 UL LLC 333 Pfingsten Rd, Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Signify North America Corporation O’Hare International Center 10275 W. Higgins Rd. Rosemont, IL 60018 EUT DESCRIPTION: Occupancy and Daylight Sensor Lighting Control MODEL: SNS210 MC SERIAL NUMBER: 5139650168 (Antenna Port Sample) DATE TESTED: 2019-10-31 TO 2019-11-04 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Complies INDUSTRY CANADA RSS 102 ISSUE 5 Complies UL LLC calculated the RF Exposure of the above equipment in accordance with the requirements set forth in the above standards, using test results reported in the test report documents referenced below and/or documentation furnished by the applicant. All indications of Pass/Fail in this report are opinions expressed by UL Verification Services Inc. based on interpretations of these calculations. The results show that the equipment is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL Verification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL Verification Services Inc. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Approved & Released For UL Verification Services Inc. By: Prepared By: Jeff Moser Bart Mucha CONSUMER TECHNOLOGY DIVISION CONSUMER TECHNOLOGY DIVISION PROJECT LEAD Staff Engineer UL LLC UL LLC REPORT NO: 13092227C DATE: 2019-12-06 FCC ID: 2AF2N-SSMC IC: 20659-SSMC Page 5 of 9 UL LLC 333 Pfingsten Rd, Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC 2. TEST METHODOLOGY All calculations were made in accordance with FCC OET Bulletin 65 Edition 97-01 and IC Safety Code 6. 3. REFERENCES All measurements were made as documented in test report UL LLC, Report No. 12137351A and 12137351B for operation in the 2.4GHz band. Output power and Duty cycle data is excerpted from the above referenced test report. Antenna gain data is excerpted from product documentation provided by the applicant. 4. FACILITIES AND ACCREDITATION The test sites and measurement facilities used to collect data are located at 333 Pfingsten Road, Northbrook, Illinois, USA. UL Verification Services Inc. is accredited by NVLAP, Laboratory Code 1004141-0. The full scope of accreditation can be viewed at http://ts.nist.gov. REPORT NO: 13092227C DATE: 2019-12-06 FCC ID: 2AF2N-SSMC IC: 20659-SSMC Page 6 of 9 UL LLC 333 Pfingsten Rd, Northbrook, IL 60062, USA TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC 5. MAXIMUM PERMISSIBLE RF EXPOSURE 5.1. FCC RULES §1.1310 The criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of §2.1093 of this chapter. TABLE 1—LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength…
