2AF77-H2511910Indoor/Outdoor powered camera

1 FCC E-Label Information A. Information to be displayed 1. The information that will be displayed on the e-label and information that will remain in the user manual is shown below: Information on E-label In Manual FCC ID number Yes No FCC logo No No 15.19 statement (“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”) Yes Yes Images of the e-label screen are provided below: 2 B. Access to the required information on the e-label 1. Users must be able to access the regulatory information without requiring special access codes or permissions, and in all cases the information must be accessible in no more than three steps from a product’s main or home menu. The actual steps are: To access the e-label information, in the device, Choose: Device Settings > General Settings No special access codes or permissions are required to go through the above steps beyond entering a user-defined password to protect against unauthorized access to the device. 2. Instructions must be provided with the product at the time of purchase, in the user manual, operating instructions, packaging material, quick guide pamphlet, etc. Alternatively, a product-related website is permitted, if a reference (URL) to obtain the website information is provided at the time of purchase in the user manual, operating instructions, packaging material, quick guide pamphlet, etc. The information to the user is provided in the user manual. We have included important notes regarding searching for FCC ID, model, and relate info in the user manual. 3. Products must not require special accessories or supplemental plug-ins (e.g., the installation of a SIM/USIM card) to access the information. Access to regulatory information must be provided without special codes, accessories, or permissions beyond the normal security protection to unlock the screen, sign-in page, or overall product access. The devices do not require special code, accessories or supplemental plug-ins to access the information. 4. The FCC ID, warning statements, or other information must be displayed electronically in a manner that is clearly legible without the aid of magnification. Yes, it is clearly legible without the aid of magnification. 5. Both regulatory information and dedicated exclusive application(s) or script(s) must be secured and implemented in a factory-set- unalterable format. The regulatory information must be capable of being retrieved and displayed locally, and under the control of the end user in possession of the product. The method must be secure, such that the application or script ensures that the regulatory information correctly displayed. Yes, it is secured and the user cannot modify it. C. Labeling for Importation and Purchasing 3 1. When e-labeling is used, a physical temporary label is also required on the product, or a label on the packaging, at the time of importation, marketing, and sales. The physical label can be a summary version of the required regulatory information, such that the product can be identified as complying with the FCC’s equipment authorization requirements. The information may simply be the FCC ID for products subject to certification. Products imported that are already packaged for sale and have a physical temporary label will satisfy this requirement. However, for products imported in bulk and not packaged individually, it is acceptable to use a temporary removable adhesive label on the product, or temporary or permanent labels on the shipping packaging or protective bags. Any removable adhesive label shall be of a type intended to survive normal shipping and handling. There is FCC ID on the packaging.

Sporton International Inc. (Kunshan) Page Number : 1 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 RF Exposure Evaluation Report APPLICANT : Immedia Semiconductor LLC. EQUIPMENT : Indoor/Outdoor powered camera BRAND NAME : blink MODEL NAME : BCM00800U FCC ID : 2AF77-H2511910 STANDARD : 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 The product evaluation date was started from Aug. 28, 2025 and completed on Aug. 28, 2025. We, Sporton International Inc. (Kunshan), would like to declare that the device has been evaluated in accordance with47 CFR Part 2.1091 and FCC KDB 447498 D01 v06, and pass the limit. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Si Zhang Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 4 1.1. Testing Laboratory ............................................................................................................................. 4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 5 3. MAXIMUM RF AVERAGE OUTPUT TUNE UP POWER AMONG PRODUCTION UNITS ....................... 5 4. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 6 5. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 7 5.1. Standalone Power Density Calculation ............................................................................................. 7 Sporton International Inc. (Kunshan) Page Number : 3 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA553005-01 Rev. 01 Initial issue of report. Sep. 04, 2025 Sporton International Inc. (Kunshan) Page Number : 4 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 1. Administration Data 1.1. Testing Laboratory Sporton International Inc. (Kunshan) is accredited to ISO/IEC 17025:2017 by American Association for Laboratory Accreditation with Certificate Number 5145.02. Testing Laboratory Test Firm Sporton International Inc. (Kunshan) Test Site Location No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China TEL : +86-512-57900158 Test Site No. Sporton Site No. FCC Designation No. FCC Test Firm Registration No. SAR01-KS CN1257 314309 Applicant Company Name Immedia Semiconductor LLC. Address 100 Riverpark Drive Suite 125, North Reading, MA, United States 01864 Manufacturer Company Name Immedia Semiconductor LLC. Address 100 Riverpark Drive Suite 125, North Reading, MA, United States 01864 Sporton International Inc. (Kunshan) Page Number : 5 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type Indoor/Outdoor powered camera Brand Name blink Model Name BCM00800U FCC ID 2AF77-H2511910 Wireless Technology and Frequency Range WLAN 2.4GHz Band: 2412 MHz ~ 2472 MHz Bluetooth: 2402 MHz ~ 2480 MHz Mode WLAN 2.4GHz 802.11b/g/n HT20 Bluetooth LE Antenna Gain WLAN2.4GHz: 2.0 dBi Bluetooth: 2.0 dBi Antenna Type Bluetooth: PIFA Antenna WLAN: PIFA Antenna EUT Stage Identical Prototype Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Comments and Explanations: 1. The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. 2. The maximum RF output tune up power, antenna gain also the safe distance used for evaluate RF exposure were declared by manufacturer. 3. Maximum RF average output tune up power among production units <2.4GHz WLAN > Mode Maximum Average Power (dBm) 2.4GHz 802.11b 19.00 802.11g 18.00 802.11n-HT20 18.00 <Bluetooth> Mode Maximum Average power(dBm) Bluetooth LE 6.00 Sporton International Inc. (Kunshan) Page Number : 6 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 4. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: 퐒= 퐏퐆 ퟒ훑퐑 ퟐ Where: S = Power Density P = Output Power at Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Distance from Transmitting Antenna Sporton International Inc. (Kunshan) Page Number : 7 of 7 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID : 2AF77-H2511910 Report Version : Rev. 01 RF Exposure Evaluation Report Report No. : FA553005-01 5. Radio Frequency Radiation Exposure Evaluation 5.1. Standalone Power Density …

Text truncated - open the document above for the full version.

Sporton International Inc. (Kunshan) Page Number : 1 of 35 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR553005-01A FCC RF Test Report APPLICANT : Immedia Semiconductor LLC. EQUIPMENT : Indoor/Outdoor powered camera BRAND NAME : blink MODEL NAME : BCM00800U FCC ID : 2AF77-H2511910 STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DTS) Digital Transmission System TEST DATE(S) : Aug. 08, 2025 ~ Aug. 21, 2025 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 35 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR553005-01A TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Product Feature of Equipment Under Test ........................................................................................ 5 1.3 Product Specification of Equipment Under Test ................................................................................ 5 1.4 Modification of EUT ........................................................................................................................... 5 1.5 Testing Location ................................................................................................................................ 6 1.6 Test Software ..................................................................................................................................... 6 1.7 Applicable Standards ......................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Carrier Frequency Channel ............................................................................................................... 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 9 2.4 Support Unit used in test configuration and system ........................................................................ 10 2.5 EUT Operation Test Setup .............................................................................................................. 10 2.6 Measurement Results Explanation Example ................................................................................... 10 3 TEST RESULT .......................................................................................................................................... 11 3.1 6dB and 99% Bandwidth Measurement .......................................................................................... 11 3.2 Output Power Measurement ............................................................................................................ 16 3.3 Power Spectral Density Measurement ............................................................................................ 17 3.4 Conducted Band Edges and Spurious Emission Measurement ..................................................... 22 3.5 Radiated Band Edges and Spurious Emission Measurement ........................................................ 27 3.6 AC Conducted Emission Measurement........................................................................................... 31 3.7 Antenna Requirements .................................................................................................................... 33 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 34 5 MEASUREMENT UNCERTAINTY ............................................................................................................ 35 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. AC CONDUCTED EMISSION TEST RESULT APPENDIX C. RADIATED SPURIOUS EMISSION APPENDIX D. DUTY CYCLE PLOTS Sporton International Inc. (Kunshan) Page Number : 3 of 35 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR553005-01A REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR553005-01A Rev. 01 Initial issue of report Sep. 04, 2025 Sporton International Inc. (Kunshan) Page Number : 4 of 35 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR553005…

Text truncated - open the document above for the full version.

Sporton International Inc. (Kunshan) Page Number : 1 of 34 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CWL AC MA Version 2.0 FCC RF Test Report Report No. : FR553005-01B FCC RF Test Report APPLICANT : Immedia Semiconductor LLC. EQUIPMENT : Indoor/Outdoor powered camera BRAND NAME : blink MODEL NAME : BCM00800U FCC ID : 2AF77-H2511910 STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DTS) Digital Transmission System TEST DATE(S) : Aug. 08, 2025 ~ Aug. 22, 2025 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 34 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CWL AC MA Version 2.0 FCC RF Test Report Report No. : FR553005-01B TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Product Feature of Equipment Under Test ........................................................................................ 5 1.3 Product Specification of Equipment Under Test ................................................................................ 5 1.4 Modification of EUT ........................................................................................................................... 5 1.5 Testing Location ................................................................................................................................ 6 1.6 Test Software ..................................................................................................................................... 6 1.7 Applicable Standards ......................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Carrier Frequency and Channel ........................................................................................................ 7 2.2 Test Mode .......................................................................................................................................... 7 2.3 Connection Diagram of Test System ................................................................................................. 8 2.4 Support Unit used in test configuration and system .......................................................................... 9 2.5 EUT Operation Test Setup ................................................................................................................ 9 2.6 Measurement Results Explanation Example ..................................................................................... 9 3 TEST RESULT ........................................................................................................................................... 10 3.1 6dB and 99% Bandwidth Measurement .......................................................................................... 10 3.2 Output Power Measurement ............................................................................................................ 12 3.3 Power Spectral Density Measurement ............................................................................................ 13 3.4 Conducted Band Edges and Spurious Emission Measurement ..................................................... 15 3.5 Radiated Band Edges and Spurious Emission Measurement ........................................................ 26 3.6 AC Conducted Emission Measurement........................................................................................... 30 3.7 Antenna Requirements .................................................................................................................... 32 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 33 5 MEASUREMENT UNCERTAINTY ............................................................................................................ 34 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. AC CONDUCTED EMISSION TEST RESULT APPENDIX C. RADIATED SPURIOUS EMISSION APPENDIX D. DUTY CYCLE PLOTS Sporton International Inc. (Kunshan) Page Number : 3 of 34 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CWL AC MA Version 2.0 FCC RF Test Report Report No. : FR553005-01B REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR553005-01B Rev. 01 Initial issue of report Sep. 04, 2025 Sporton International Inc. (Kunshan) Page Number : 4 of 34 TEL : +86-512-57900158 Report Issued Date : Sep. 04, 2025 FCC ID: 2AF77-H2511910 Report Version : Rev. 01 Report Template No.: BU5-FR15CWL AC MA Version 2.0 FCC RF Test Report Report N…

Text truncated - open the document above for the full version.

Antenna Specifications FCC ID: 2AF77-H2511910 IC ID: 20741-H2511910 Model Number: BCM00800U Antenna Manufacturer's name Speed Antenna Manufacturer's Address No.99，Weixin Road，SIP，Suzhou，Jiangsu Province，China Antenna Pattern PIFA Antenna Part Number: It’s printing antenna on PCB, no part number for it. Test date:2025/07/25 Frequency range of operation: •Wi-Fi/BLE: 2400~2500MHz Antenna type: PIFA Antenna gain: •Wi-Fi: 2dBi Lab name: Speed Lab address: No.99，Weixin Road，SIP，Suzhou，Jiangsu Province，China Measurement test method: Passive Test equipment: ETS8500 Calibration due: 2026.7.20 OTA chamber: GTS-2800 Test engineer: Gao zhen hao Equipment setup: Software used:EMQuest Test set-up: 1.Place the DUT at the center of the turntable, 2.Connecting the test cable to the DUT, and use the EMQuest software for passive measurement. 3.During the measured process, ETS8500 will conduct radiation testing with the DUT through by a horn antenna; then the turntable will rotate a horizontal 180- degree. 4.After, a complete measurement of spherical 3D is completed. Antenna passive result: Antenna radiation pattern: Linear Effi AVG Peak gain -2.3 2.0 Frequency (MHz) Tot. Rad. Pwr. (dBm) Gain (dBi) 2400 -2.6 1.7 2410 -2.5 1.9 2420 -2.4 1.9 2430 -2.4 2.0 2440 -2.3 2.0 2450 -2.2 2.0 2460 -2.1 2.0 2470 -2.1 1.9 2480 -2.3 1.7 2490 -2.4 1.7 2500 -2.4 1.7 2D Radiation Pattern : WIFI/BLE Antenna : Cut1 Gain (d Bi) Angl e (? Scal e: 5/di v Mi n: -40 Max : 5 0 180 30 210 60 240 90 270 120 300 150 330 2400 MHz 2450 MHz 2500 MHz Cut2 Gain (d Bi) Angl e (? Scal e: 5/di v Mi n: -35 Max : 5 0 180 30 210 60 240 90 270 120 300 150 330 2400 MHz 2450 MHz 2500 MHz Cut3 Gain (d Bi) Angl e (? Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90 270 120 300 150 330 2400 MHz 2450 MHz 2500 MHz 2400MHz 2450MHz 2500MHz 3D Radiation Pattern WIFI/BLE Antenna : XY-Plane XZ-Plane YZ-Plane Total Gain (d Bi) -25 5 -20 -15 -10 -5 0 X Y Z Azi m uth = -90.0 El evati on = 0.0 Rol l = 0.0 Total Gain (d Bi) -25 5 -20 -15 -10 -5 0 X Z Y Azi m uth = 0.0 El evati on = -90.0 Rol l = 90.0 Total Gain (d Bi) -25 5 -20 -15 -10 -5 0 Y Z X Azi m uth = 90.0 El evati on = 0.0 Rol l = -90.0
