2AFAZ-PX2000Time & Attendance / Access Control Terminal

1 PX2000 Time & Attendance / Access Control Terminal User Manual 2 Contents I. Features ................................................................................................................................................................ 3 II. Specifications ...................................................................................................................................................... 3 III. Exterior ................................................................................................................................................................ 4 IV. Basic Settings .................................................................................................................................................... 5 Clock ..................................................................................................................................................... 5 Users .................................................................................................................................................... 5 System ................................................................................................................................................. 5 ■ Network ....................................................................................................................................................... 5 ■ Record Option .............................................................................................................................................. 5 ■ Tamper Switch ............................................................................................................................................. 5 ■ Calibration ................................................................................................................................................... 5 ■ Beep Hints ................................................................................................................................................... 5 ■ Menu Password ............................................................................................................................................ 6 ■ Security Level .............................................................................................................................................. 6 ■ Volume ......................................................................................................................................................... 6 ■ HTTP & TCP Port ........................................................................................................................................ 6 ■ FTP User Set(to be performed by professionals of your supplier only) ...................................................... 6 ■ System Maintenance .................................................................................................................................... 6 ■ Database Backup(to internal Micro SD card) — for enable/disable the function of auto database backup from system memory to the internal Micro SD card every day at the time that you set. ........ 6 ■ Language ..................................................................................................................................................... 6 ■ WiFi Setting ................................................................................................................................................. 6 ■ Camera ......................................................................................................................................................... 7 Door .................................................................................................................................................... 7 IO Port(DI/DO) .................................................................................................................................... 7 V. User Interface ...................................................................................................................................................... 8 VI. Self-contained Time & Attendance / Access Control Software ................................................................... 8 Set login password ............................................................................................................................................. 9 Database Backup(External database backup) .................................................................................................... 9 System Setting ................................................................................................................................................... 9 Clone Database(Internal database backup) ...................................................................................................... 10 System Setting - Late/Absence E-mail Notice................................................................................................. 10 System Setting – FTP Setting .......................................................................................................................... 11 Attendance Report (Detailed) – for fixed shifts users ..................................................................................... 12 Attendance Report (Total) – for fixed shifts users ........................................................................................... 12 Attendance Report (Multi Work Shift) – for multiple flexible shifts users...................................................... 13 Transactions ..................................................................................................................................................... 13 Transactions Delete .......................................................................................................................................... 13 Job Code Setting .....................................…

Text truncated - open the document above for the full version.

ProjectNo:STS1507141 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 ProjectNo:STS1507141 Photo3 Photo4 ProjectNo:STS1507141 Photo5 Photo6 ProjectNo:STS1507141 Photo7 Photo8 ProjectNo:STS1507141 Photo9

Label Time & Attendance / Access Control Terminal Model name: PX2000 FCC ID: 2AFAZ-PX2000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Project No: STS1507141 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1507141 Photo 3 Photo 4 Project No: STS1507141 Photo 5 Photo 6 Project No: STS1507141 Photo 7 Photo 8 Project No: STS1507141 Photo 9 Photo 10 Project No: STS1507141 Photo 11 Photo 12 WIFI ANTENNA Project No: STS1507141 Photo 13 Photo 14 Project No: STS1507141 Photo 15 Photo 16

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1507141F02 Issued for Kizone Information Inc. 7F., No. 20, L. 609, Sec. 5, Chongxin Rd., Sanchong, New Taipei, Taiwan. Product Name: Time & Attendance / Access Control Terminal Brand Name: N/A Model No.: PX2000 Series Model: N/A FCC ID: 2AFAZ-PX2000 Test Standard: FCC Part 15.225 S T L A B S Page 2 of 26 Report No.: STS1507141F02 TEST RESULT CERTIFICATION Applicant’s name ................. : Kizone Information Inc. Address .................................. : 7F., No. 20, L. 609, Sec. 5, Chongxin Rd., Sanchong, New Taipei, Taiwan. Product description Product name ............................ : Time & Attendance / Access Control Terminal Model and/or type reference : PX2000 Serial Model .............................. : N/A Standards ............................. : FCC Part15.225 Test procedure ............................. ANSI C63.10: 2013 ANSI C63.4: 2014 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, thidocument may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests.............. : 20 Aug. 2015 ~27 Aug. 2015 Date of Issue ........................................... : 28 Aug. 2015 Test Result ............................................... : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 26 Report No.: STS1507141F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 EUT OPERATING CONDITIONS 12 3.5 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 15 4.1 RADIATED EMISSION LIMITS 15 4.2 TEST PROCEDURE 16 4.3 TEST SETUP 17 4.4 EUT OPERATING CONDITIONS 17 4.5 TEST RESULTS 18 5. FREQUENCY TOLERANCE 21 5.1 REQUIREMENT 21 5.2 TEST PROCEDURE 21 5.3 TEST SETUP 21 5.4 EUT OPERATION CONDITIONS 21 5.5 TEST RESULTS 22 6. 20DB BANDWIDTH 23 6.1 APPLIED PROCEDURES / LIMIT 23 6.2 TEST PROCEDURE 23 6.3 TEST SETUP 23 6.4 EUT OPERATION CONDITIONS 23 6.5 TEST RESULTS 24 Page 4 of 26 Report No.: STS1507141F02 Table of Contents Page 7. ANTENNA REQUIREMENT 25 7.1 STANDARD REQUIREMENT 25 7.2 EUT ANTENNA 25 8. EUT TEST PHOTO 26 Page 5 of 26 Report No.: STS1507141F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.225) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.209 15.225(a)(b)(c)(d) Radiated Emission PASS -- 15.225(e) Frequency Tolerance PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U炻where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2炻providing a level of confidence of approximately 95 %ˤ No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 6 of 26 Report No.: STS1507141F02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Time & Attendance / Access Control Terminal Trade Name N/A Model Name PX2000 Serial Model N/A Model Difference N/A Product Description The EUT is a Time & Attendance / Access Control Terminal Operation Frequency: 13.56MHz Modulation Type: FSK Antenna Designation: Please see Note 3. Antenna Gain (dBi) 0.2 dbi Channel List Please refer to the Note 2. Ratings Adapter: Input:AC 100 -240V,50/60Hz,500mA Output:DC 12V,1000mA Hardware version number N/A Software versioning number N/A Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE A N/A PX2000 Wire Antenna N/A 0.2 ANT Page 7 of 26 Report No.: STS1507141F02 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre -scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mode For Radiated Emission Final Test Mode Description Mode 1 TX Mode Note: (1) The measurements are performed at …

Text truncated - open the document above for the full version.

Page 26 of 26 Report No.: STS1507141F02 8. EUT TEST PHOTO Conduction Measurement Photos Radiated Measurement Photos ଖଖଖଖଖEND OF THE REPORTଖଖଖଖଖ
