2AFBLDET02Wireless Timer

The Timers are to be surface mounted onto a wall. Multiple Timers may be installed in a ventilation system. To increase the range of a wireless Timer, a RX02 Repeater should be used. DET02 Wireless Timer Installation and Operation Instructions BC Series Control NOTE: Your BC control may look different than the one shown. Press Simultaneously to Initiate Pairing Mode TI-DET02 10_19_15 Figure A Figure D NOTE This wireless Timer must be matched to the main wall control of the HRV / ERV. This process is called "Pairing". Multiple Timers can be paired to a single wall control. Figure B 1/8 in hole for screw and anchor 1/8 in hole for screw and anchor Break off tab Alternate Wall Mount 1/8 in hole for screw and anchor Figure C Back Plate Face Plate 1/8 in hole for screw and anchor Break off tab Figure F Figure E Press Simultaneously to Initiate Pairing Mode DX Series Control DET02 Timer 20/40/60 Minute Status Lights Select Button initiates high speed ventilation for 20, 40 or 60 min. Battery Indicator Removable Backplate 1.Turn on the main wall control by pressing the ON/OFF button and remove the battery from Timer. 2.DET02 with DX Series Controls: Press the left and right buttons simultaneously on the main wall control ( and RESET buttons). The screen will go blank and the wireless symbol will appear flashing on the bottom right of the display. This indicates that the main control is now in pairing mode. (Figure D) 3.DET02 with BC Series Controls: Press the left and right buttons simultaneously on the main wall control ( and either or buttons, depending on the main control). The bottom row of 3 LED's will begin flashing. This indicates that the main control is now in pairing mode. (Figure E) 4.Keep the Timer within 16” of the main wall control when pairing. 5.Install the battery in the DET02 Timer. All four lights on the Timer will immediately flash 5 times, then only the red battery light will remain on for approximately 12 seconds after which the "40" light flashes the rev code. 20, 40, 60 lights will flash until paired or will stop if not paired within 12 seconds. If pairing was not successful you now must return to step 1 to restart the pairing process. 6.Press the button on the main wall control to exit pairing mode when Timers have been successfully paired. Pairing: To pair additional DET02 Timers with the same wall control, or if pairing was not successful, repeat steps 1-6. When paired, the DET02 Timers can be moved and installed elsewhere. Estimated range of the Timer is 40’ with no obstructions. A RX02 Repeater may be installed to increase the range of the Timers. Test if pairing was successful by pressing the Select Button and listen for the HRV / ERV to initiate HIGH fan speed Ventilation. Un-pairing: 1.Remove the battery from the back of the DET02 Timer 2.Press and hold the Select Button on the front of the Timer 3.While holding the Select Button, reinsert the battery in the Timer. Continue holding the select button until the LED under "40" begins flashing. The DET02 Timer will now be unpaired with the main wall control. 1.Separate the face plate from the back plate by firmly pulling apart (Figure A). 2.For mounting the control without a Decora plate, break off top and bottom tabs and refer to Figure C for mounting. Installation: 3.Place the back plate of the control in the desired location on the wall and pencil mark the top and bottom screw holes (Figure B or C). Drill two 1/8" holes. 4.Attach the back plate to the wall using the 2 supplied screws and anchors. 5.Attach the face plate to the back plate (Figure A). Minuterie sans fil DET02 – Installation et fonctionnement Appuyer simultanément pour amorcer le pairage Commandes gamme BC NOTE: la commande BC peut différer du modèle illustré. TI-DET02 10_19_15 Figure A Figure D ATTENTION Cette minuterie sans fil doit être appariée à la commande murale principale du VRC / VRE. Ce processus s'appelle le "pairage". On peut apparier plus d’une minuterie à une commande murale unique. Figure B Trou 1/8 po pour cheville et vis Cassez la languette Autre méthode de montage Figure C Plaque arrière Plaque avant Trou 1/8 po pour cheville et vis Cassez la languette Figure F Figure E Appuyer simultanément pour amorcer le pairage Commandes gamme DX Témoins 20/40/60 minutes Minuterie DET02 Bouton Select actionne la ventilation à haute vitesse pour 20, 40 ou 60 min. Témoin de pile Plaque arrière amovible 1.Mettez la commande murale principale en marche en appuyant sur le bouton de marche/arrêt et retirez la pile de la minuterie. 2.DET02 et commandes DX: appuyez simultanément sur les boutons gauche et droit de la commande principale (boutons et RESET). L'écran se vide et le symbole sans fil apparaît en clignotant dans la partie inférieure droite de l'écran. Cela indique que la commande principale se trouve alors en mode de pairage (figure D). 3.DET02 et commandes BC: appuyez simultanément sur les boutons gauche et droit de la commande principale ( et soit ou selon la commande principale). La rangée inférieure des 3 témoins DEL commence à clignoter. Cela indique que la commande principale se trouve alors en mode de pairage (figure E). 4.Lors du pairage, gardez la minuterie dans un rayon de 16 po de la commande principale. 5.Replacez la pile dans la minuterie DET02. Les 4 témoins lumineux clignoteront immédiatement 5 fois, puis le témoin rouge de la pile restera seul allumé pendant environ 12 secondes, après quoi le témoin 40 clignote selon un code interne. Les témoins 20, 40 et 60 clignotent jusqu'au pairage ou arrêteront de clignoter si non apparié dans les 12 secondes. Si le pairage n'est pas réussi, il faut recommencer le processus à partir de l'étape 1. .Une fois que les minuteries ont été appariées avec succès, appuyez sur le bouton de la commande principale pour quitter le mode de pairage. Les minuteries doivent être installées en surface sur un mur. On peut installer plus d’une minuterie dans un système de ventilation. On peut aussi accroître …

Text truncated - open the document above for the full version.

UltraTech Group of Labs FCC TCB & IC CB 0685 91038 1309 46390-2049 AT-1945 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle Oakville, Ontario Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] October 28, 2015 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Certification Application under FCC Part 15, Subpart C, Section 15.249, Low Power Transmitters Operating in the Frequency Band 2400- 2483.5 MHz. Applicant: Airia Brands Inc. Product: DET02 Wireless Timer Model: 99-DET02 FCC ID: 2AFBLDET02 Dear Sir/Madam: As appointed agent for Airia Brands Inc., we submit this application for FCC Certification of the above product. Please review all files uploaded to your electronic filing site. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent

ANNEX 1 - TEST SETUP PHOTOGRAPHS Airia Brands Inc. DET02 Wireless Timer, Model 99-DET02 FCC ID: 2AFBLDET02 A1 - 1 Radiated Emissions at 3m Distance ANNEX 1 - TEST SETUP PHOTOGRAPHS Airia Brands Inc. DET02 Wireless Timer, Model 99-DET02 FCC ID: 2AFBLDET02 A1 - 2 Radiated Emissions at 3m Distance ANNEX 1 - TEST SETUP PHOTOGRAPHS Airia Brands Inc. DET02 Wireless Timer, Model 99-DET02 FCC ID: 2AFBLDET02 A1 - 3 Radiated Emissions at 3m Distance
