2AFBLDX02Deluxe Plus Control

The controls are to be surface mounted onto a wall. Only one master control should be installed to a ventilation system (the face plate on this illustration may not be exactly the same as yours). 1.Remove the operating instructions card from the top of the control (Figure A). 2.Separate the face plate from the back plate by firmly pulling apart (Figure B). Be careful not to damage face plate contact pins. 3.Place the back plate of the control in the desired location on the wall and pencil mark the wall with the right and left screw holes (Figure C). 4.Remove the back plate from the wal l and mark the center hole for the wires in the middle of the screw holes. Refer to Figure C for dimensions. 5.Drill a 1 in hole in the wall to allow for the wire opening and drill (two) 1/8 in holes for the screws and wal l anchors (Figure C). 6.Pull 3 wire 20 gauge (min.) 100 ft length (max.), through the opening in the wall. 7.Connect red, green, and yellow to the wiring terminals located on the back plate (Figure C). 8.Attach the back plate to the wall using the 2 supplied screws and anchors. ATTENTION Operating Instructio n Card Figure A Red #3 Yellow #4 Green #5 Figure D Keep top / bottom vent openings clear Figure C Control Installation Instructions (Two) 1/8 in hole for screws and anchors. 1.5" 1.5" 1 in hole for Wiring wire opening. Terminals 9. 10. 11. Attach the face plate to the back plate (Figure B). Note: Be careful to correctly align the face plate to avoid damaging the face plate contact pins. Insert the operating instructions card into the control (Figure A). Connect the 3 wire 20 gauge (min.) 100 ft length (max.) to the terminal block located on ventilator (Figure D). Pay special attention not to damage the contact pins when removing and attaching the face plate (Figure B). TI-CONTROL-02 7_10_15 Face Pl ate Figure B Back Plate Les commandes doivent être montées en surface sur un mur. Il ne doit y avoir qu’une seule commande principale pour un système de ventilation. (La plaque avant illustrée ici pourrait différer légèrement de la vôtre.) 1.Retirez la carte des directives de fonctionnement (si incluse) du dessus de la commande (Figure A). Remarque: certaines commandes ne contiennent pas de carte de fonctionnement. 2.Retirez la plaque avant de la plaque arrière en tirant fermement pour les séparer (Figure B). Attention à ne pas endommager les chevilles de contact de la plaque avant. 3.Placez la plaque arrière de la commande à l’endroit désigné sur le mur et marquez au crayon les trous de vis (Figure C). 4.Enlevez la plaque arrière et marquez le trou pour le fil au centre entre les trous de vis. Reportez-vous à la figure C pour les dimensions. 5.Percez un trou de 1 po ou sciez un trou ovale de 1 x 3/4 po (selon la commande) dans le mur pour le passage du fil et percez 2 trous de 1/8 po pour les ancrages muraux (Figure C). 6.Tirez le fil 3/20 (calibre minimal) d’une longueur maximale de 100 pi (30 m) à travers le trou dans le mur et. ATTENTION Carte des directives de fonctionnement Figure A Plaque avant Figure B Rouge #3 Jaune #4 Vert #5 Figure D Plaque arrière Trou de 1 po pour le fil. Installation de la Commande 2 trous 1/8 po pour chevilles et vis. 1.5 po 1.5 po Bornes de connexion 7. 8. 9. 10. 11. Veillez à ne pas endommager les chevilles de contact en retirant ou en manipulant la plaque avant (Figure B). TI-CONTROL-02 07_10_15 Connectez les conducteurs rouge (R), vert (G) et jaune (Y) aux bornes de la plaque arrière (Figure C). Fixez l a plaque arrière au mur en utili sant les 2 vis et l es 2 ancrages fournis. Fixez l a plaque avant sur la plaque arrière (Figure B). Attenti on: ali gnez correctement la plaque avant pour ne pas endommager les chevilles de contact. Insérez la carte des directives de fonctionnement dans la commande (Figure A). Connectez le fil 3/20 d’une longueur maximale de 100 pi (30 m) sur le bornier du ventilateur (Figure D). Laissez les ouvertures du haut et du bas dégagées Figure C Ca ution: Changes or modifications not expressly approved Airia Brands Inc. could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including int erference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These lim its are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful int erference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1) l'appareil ne doit pas produire de brouillage; 2) l’utilisateur de l’app…

Text truncated - open the document above for the full version.

FCC TCB & IC CB 0685 91038 1309 46390-2049 AT-1945 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle Oakville, Ontario Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] October 30, 2015 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Certification Application under FCC Part 15, Subpart C, Section 15.249, Low Power Transmitters Operating in the Frequency Band 2400- 2483.5 MHz. Applicant: Airia Brands Inc. Product: Deluxe Plus Control Model: 99-DXPL02 FCC ID: 2AFBLDX02 Dear Sir/Madam: As appointed agent for Airia Brands Inc., we submit this application for FCC Certification of the above product. Please review all files uploaded to your electronic filing site. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent

ENGINEERING TEST REPORT Deluxe Plus Control Model: 99-DXPL02 FCC ID: 2AFBLDX02 Applicant: Airia Brands Inc. 511 McCormick Blvd. London, Ontario Canada N5W 4C8 Tested in Accordance With FCC Part 15, Subpart C, Section 15.249 Low Power Transmitters Operating in the Frequency Band 2400-2483.5 MHz UltraTech's File No.: 15FET054_FCC15C249 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: October 30, 2015 Report Prepared by: Dan Huynh Issued Date: October 30, 2015 Tested by: Wei Wu Test Dates: June 29 & Aug. 13, 2015  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] Korea KCC-RRA 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 AT-1945 SL2-IN-E- 1119R CA2049 TL363_B TPTDP DA1300 FCC Part 15, Subpart C, Section 15.249 – Intentional Radiators Content i Deluxe Plus Control, Model: 99-DXPL02 FCC ID: 2AFBLDX02 ULTRATECH GROUP OF LABS File #: 15FET054_FCC15C249 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 30, 2015 Tel.: 905-829-1570, Fax. : 905-829-8050 All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION.............................................................................................................................................. 1 1.1. SCOPE............................................................................................................................................................................................1 1.2. RELATED SUBMITTAL(S)/GRANT(S).......................................................................................................................................1 EXHIBIT 2. PERFORMANCE ASSESSMENT ................................................................................................................... 2 2.1. CLIENT INFORMATION................................................................................................................................................................2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION................................................................................................................2 2.3. EUT’S TECHNICAL SPECIFICATIONS.....................................................................................................................................3 2.4. LIST OF EUT’S PORTS................................................................................................................................................................3 2.5. ANCILLARY EQUIPMENT............................................................................................................................................................3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS .............................................. 4 3.1. CLIMATE TEST CONDITIONS....................................................................................................................................................4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS..............................................................................4 EXHIBIT 4. SUMMARY OF TEST RESULTS ..................................................................................................................... 5 4.1. LOCATION OF TESTS..................................................................................................................................................................5 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS.................................................................................5 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES.......................................................5 EXHIBIT 5. TEST DATA ..................................................................................................................................................... 6 5.1. POWER LINE CONDUCTED EMISSIONS [47 CFR 15.207(a)].............................................................................................6 5.2. 20 dB BANDWIDTH [47 CFR 15.215(c)]....................................................................................................................................9 5.3. FUNDAMENTAL FIELD STRENGTH AND HARMONIC EMISSIONS ( RADIATED @ 3m) [47 CFR 15.249(a), 15.209 & 15.205].......................................................................................................................................................................... 11 EXHIBIT 6. TEST EQUIPMENT LIST ............................................................................................................................... 14 EXHIBIT 7. MEASUREMENT UNCERTAINTY ................................................................................................................ 15 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY.................................................................................... 15 7.2. RADIATED EMISSION MEASUREMENT UNCERTAINTY................................................................................................... 15 FCC Part 15, Subpart C, Section 15.249 – Intentional Radiators Page 1 Deluxe Plus Control, Model: 99-DXPL02 FCC ID: 2AFBLDX02 ULTRATECH GROUP OF LABS File #: 15FET054_FCC15C249 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 30, 2015 Tel.: 905-829-1570, Fax. : 905-829-8050 All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) EXHIBIT 1. INTRODUCTI…
